3-2 Set Parameters
Every device needs to have its parameters changed in order to connect to the
server. The MRS Device configurator allows the user to make changes in the
settings of the device, changes that would take effect on activation.
There are two stages to installing and setting up the configurator:
a. Installing the drivers (Difference depending on OS)
b. Setting parameters
3-2-1 Install drivers (Device Configurator –7 and below)
1. Browse to the website: www.infodraw.com/dlds
2. Open the folder of the latest version of the PMRS ("5.4.0.5" for example).
3. Enter the “MRS device config” folder and activate the
Setup_MRS_DeviceConfig.msi file.
4. Change the 2 dip switches (1 & 2) to external USB mode (up position).
5. Insert the USB cable into the unit and to the PC.
6. Activate the PMRS device.
7. Open the MRS Device Configurator program.
8. Open the driver menu and Download drivers
9. Click on test mode –the computer will restart
(Only for windows Vista, 7 - 64-bit OSs)
10. If the drivers are not automatically installed, update the drivers by inserting
the path to the folder where the drivers were downloaded (on stage 7) on
the “MRS Device” in the device manager.
11. Turn on the unit and wait about 2 minutes.
12. After a few seconds system shows new hardware is detected.
13. Turn on the device.
3-2-2 Install Drivers (Device Configurator –WIN 8.1 and 10)
In WIN 8.1 and up there is no need to install drivers.
1. Elevate the two DIP switches.
2. Activate the device
