Inout Panelplayer Bedienungsanleitung

USER MANUAL

Version 1.4

Panelplayer User Manual v.1.4

Page 1

Warranty

Panelplayer has a 24 month warranty on the electronic parts, running from the date of

purchase. The warranty will not be valid in case of tampering with the device or in case

personnel not authorised by the manufacturer or by the authorised dealer should carry out

work on it.

N.B. responsibility of the purchaser: in case of operation under warranty, the device must

be packaged so as to prevent damage during transport and shipped to the manufacturer

together with all the accessories.

Warranty rules

1. In order to exercise his warranty rights, the purchaser must enclose with the device a

copy of evidence of purchase duly stamped by the dealer (bill/invoice).

2. The warranty lasts for 24 months for the electronic parts. The warranty is granted at the

point of sale or else directly requested from the manufacturer.

3. The warranty only covers damage to the product which makes it work badly.

4. Work under warranty will only mean repairing or replacing, free of charge, any parts

acknowledged to be defective during manufacture or in their material, including labour

costs.

5. The warranty does not apply to damage caused by negligence or failure to comply with

the instructions, or damage caused by unauthorised people, with a special reference to

the outside parts.

6. Also, the warranty does not apply to damage caused to the device by connection to

unsuitable power sources.

7. The warranty does not cover parts subject to wear after use, or the container if the

material is not defective.

8. The warranty does not include transport costs, which will be paid for by the purchaser

in relation to the manner and time of transport.

9. The warranty will run out after 24 months have elapsed. In this case, service will be

provided charging for the parts replaced, labour costs and transport according to the

current rates.

10. Any dispute will be settled exclusively before the Court of Law of Venice.

Panelplayer User Manual v.1.4

Page 2

TABLE OF CONTENTS

Introduction

1.1 What is Panelplayer?

1.2 What is Mp3?

1.3 Encoder

1.4 Decoder

1.5 Player

1.6 Wave

1.7 Audio compression in various formats

Installation

2.1 Content of the Panelplayer kit

2.2 Notices

Description and connections

3.1 Command description

3.2 Connection description

3.3 Power supply

3.4 Logical inputs

3.5 IN/OUT 8 - Vlink input/output

3.6 Serial RS485 connection

3.7 Pre-amplified audio input

3.8 Pre-amplified audio output

3.9 Amplified audio output

Configuration file

4.1 What is the configuration file?

4.2 Content of the configuration file

4.3 How it is managed by Panelplayer

4.4 Preparing the file

4.5 Memorising the files in the Flash memory

4.6 Audio adjustment parameters

4.7 Timing and switchover parameters

4.8 Diagram of the operating parameters

4.9 Input management parameters

4.10 Infrared movement sensor management parameters

Scheduled operation

5.1 Introduction to timed operation

5.2 The palimpsest file – palin.txt

5.3 MIXER function

5.4 AVC function – automatic control of the output volume

Playlist operation

6.1 Introduction to playlist mode operation

6.2 What is a playlist file?

6.3 Playlist activation by logical inputs - MPLL (Mode PLayList) parameter

6.4 Stop & Play Priority Playlist

6.5 Priority Playlist

6.6 Stop & Play Standard Playlist

6.7 Standard Playlist

6.8 Stop & Play Restart Playlist

6.9 Restart Playlist

6.10 Music player function

Panelplayer User Manual v.1.4

Page 3

Operation with logical inputs

7.1 Introduction to the logical input operation mode

7.2 Binary input command codes

Special operations

8.1 Connection of two Panelplayers with different programming

8.2 Amplifier connection to 40W bridge

RS485 serial communication

9.1 RS485 communication

9.2 Serial port communication parameters (config.txt)

9.3 Framing error on master

9.4 NAK reply by Panelplayer

9.5 Transmitting a command by master

9.6 How to read the figures of the dedicated protocols

9.7 When the Master delivers a command to Panelplayer

9.8 Basic format of the dedicated protocols

9.9 Basic set-up of the data transmission

9.10 Control codes

9.11 Address (ADD)

9.12 Command (CMD)

9.13 CheckSum (CHK)

9.14 Basic protocol

9.15 Basic protocol with CheckSum

9.16 Basic protocol with CR and LF

9.17 Basic protocol with CheckSum, CR and LF

9.18 List of commands

9.19 Error codes

10.

Specifications

10.1 Technical features

10.2 Obsolete devices disposal

Addendum:

Examples of serial RS485 communication

Panelplayer User Manual v.1.4

Page 4

1Introduction

1.1 What is Panelplayer?

Panelplayer is a sophisticated amplified player of audio MP3 with a solid state memory,

designed to manage sequences of audio messages, musical items, commercial

communications and all kinds of audio MP3 files in a rapid, effective and interactive way.

Coupled with switches, touch-sensors or infrared movement sensors, it permits one to

create info-interactive areas, didactic and museum routes, information totems for trade

fairs and expositions, musical shows and interactive points for commercial promotions.

1.2 What is Mp3?

Mp3 is an acronym for Mpeg-1 layer 3. This is an audio compression standard which

eliminates sounds which the human ear cannot hear via a psycho-acoustic algorithm. The

purpose of this compression is to reduce the space taken up by an audio file while still

ensuring excellent quality. The greater the compression, the less the audio quality. The

right compromise, which guarantees a quality comparable to that of a Compact Disc, is

128 Kbps (thousands of bits per second) which represents the most widely used manner,

and reduces the size of an uncompressed file by 10 times.

1.3 Encoder

Software which compresses a CD audio or wave file in MP3. There are many programmes

of this kind, and it is virtually impossible to say which is the best.

1.4 Decoder

Software which decompresses an MP3 audio file in order to send it to a digital-analog

converter and reconstruct the original audio signal.

1.5 Player

Hardware and software system able to read MP3 audio files. Panelplayer is able to carry

out this function.

1.6 Wave

High quality audio format (extension .wav), compatible with the tracks of normal music

CD’s. If one uses a wave file in format 44.1 KHz/sec. at 16 bit in stereo, one will get

exactly the same quality as a music CD, but the size of the file is about 10Mb per minute.

1.7 Audio compression in various formats.

The following graphic shows the space taken up by an uncompressed audio file of about 5

minutes (.wav) and compressed in MP3 at 128Kbps (MP3).

Wave 51,1 MB

MP3 4,6 MB

Panelplayer User Manual v.1.4

Page 5

2Installation

2.1 Content of the kit Panelplayer

-n° 1 Panelplayer device;

-n° 1 Panelplayer user manual;

-n° 1 adaptor mains AC230V (*)

-n° 1 flash memory.

(*) optional depending on the country )

2.2 Notices

1. Panelplayer has been designed and made to work only with the following mains power

supply: 12÷24VDC.

2. The device must be serviced only by qualified staff.

3. Do not put objects inside the device through the openings, in order to prevent the risk

of fire or shock.

4. Disconnect the device from the power socket before cleaning. Clean the device using a

soft, dry cloth. Do not use liquids or spray which can contain flammable substances.

Obsolete devices disposal :



When you find this picture on a device, it means that the device is

compliant with European Directive 2002/96/EC.

All electronic and electric devices should be disposed separately from

normal garbage.

The proper disposal of old devices, accessories, and of the batteries in

particular, it contributes to prevent possible negative consequences for

human health and for the environment.

For more detailed information on the disposal of obsolete devices, contact

the municipality, the garbage disposal service or the shop in which the

product has been acquired.

Panelplayer User Manual v.1.4

Page 6

3Description and connections

3.1 Command description

1Connector for outside connection of the memory and command buttons.

2Flash memory introduction slot for Secure Digital or MultiMedia Card.

Command keys:

= (brief pressure) precedent MP3 file / (prolonged pressure) reduce output volume

= STOP

= PLAY

= (brief pressure) next MP3 file / (prolonged pressure) increase output volume

4Red LED: lit = device is live.

5Green LED: lit =

blinking =

MP3 file playing;

Panelplayer in pause/STOP.

IMPORTANT:

volume control with the keys is active only during the playing of the MP3 file.

pressing STOP during play, Panelplayer remains in pause excluding all the logical inputs until

reactivation with the PLAY key. This condition is indicated by the blinking green LED.

Panelplayer User Manual v.1.4

Page 7

3.2 Connection description

VAC/DC Input feed 12÷24VDC.

+12VDC Auxiliary + 12Vdc voltage, available for input activation or outside feed sensors.

MAX. 100mA.

GND Ground for input activation using outside contacts; auxiliary ground voltage.

IN1 Multi-function input for activating 1.mp3 file or 1.m3u playlist (direct or bit 0 in

binary combination).

IN2 Multi-function input for activating 2.mp3 file or 2.m3u playlist (direct or bit 1 in

binary combination).

IN3 Multi-function input for activating 4.mp3 file or 3.m3u playlist (direct or bit 2 in

binary combination).

IN4 Multi-function input for activating 8.mp3 file or 4.m3u playlist (direct or bit 3 in

binary combination).

IN5/485A

Multi-function input for activating 16.mp3 file or 5.m3u playlist (direct or bit 4 in

binary combination).

Configurable for serial RS485 communication (see chap. 9).

IN6/485B

Multi-function input for activating 32.mp3 file or 6.m3u playlist (direct or bit 5 in

binary combination).

Configurable for serial RS485 communication (see chap. 9).

IN/OUT7 Multi-function input/output for activating 64.mp3 file or 7.m3u playlist (direct or bit

6 in binary combination).

IN/OUT8 Multi-function input/output for activating 128.mp3 file (direct or bit 7 in binary

combination).

Configurable for outside applications. 0=standby 1=in play (+5V). Permits two

Panelplayers to be connected in cascade for the synchronised management of

he musical bases and commercials and spots in a scheduled time frame

(connection Vlink, par. 8.1).

IN L Pre-amplified audio input L channel, for outside music sources (SAT, DAB, CDE,

etc.) with Mixer function.

GND Ground signal of pre-amplified audio input.

IN R Pre-amplified audio input R channel, for outside music sources (SAT, DAB, CD,

etc.) with Mixer function.

OUT L Pre-amplified audio output L channel.

GND Ground signal of pre-amplified audio output.

OUT R Pre-amplified audio output R channel.

SPK L Amplified 20W audio output for speaker, L channel.

GND Ground signal of amplified audio output.

SPK R Amplified 20W audio output for speaker, R channel.

Panelplayer User Manual v.1.4

Page 8

3.3 Power supply

Panelplayer may operate with the following voltage power supplies: 12÷24VDC.

The red POWER LED lights up when it is turned on with active feed.

3.4 Logical inputs

Panelplayer has six/eight multi-function logical inputs to control the playing of the playlists or

direct calling up of individual audio files.

In order to activate the playing of a file, connect the desired GND input (or the desired inputs

when one is operating in binary logic).

Panelplayer User Manual v.1.4

Page 9

3.5 IN/OUT 8 - input/output Vlink

Programmable input/output to connect two Panelplayers in cascade, for synchronised

management of musical playlists with commercials at scheduled introduction without

interruptions.

Vlink: 0 = standby

1 = in play (+5V).

3.6 Serial RS485 connection

Panelplayer can be connected through serial gate, to a RS485 bus that can be controlled

by a system master or by a computer. To enable the RS485 gate (pin IN5/485A and

IN6/485B), raise the cover of the device and move the relative jumpers (see para. 9.1).

3.7 Pre-amplified audio input

Pre-amplified STEREO L+R audio input for outside music source (SAT, DAB, CD, etc.)

with Mixer function to mix a music source with scheduled commercials; extractable

terminal strip.

3.8 Pre-amplified audio output

Pre-amplified STEREO L+R audio output on extractable terminal strip.

3.9 Amplified audio output

Amplified STEREO 20W+20W audio output on extractable terminal strip.

Connect the outside 4/8speakers to the SPK L/GND and SPK R/GND terminal strip.

IMPORTANT:

Use a speaker with equal or greater power to that supplied to the amplifier within

Panelplayer.

It is recommended to cable the device far from power cables; the two cables that

connect the speaker with Panelplayer could be a potential source of interference.

Inhaltsverzeichnis

Andere inout MP3-Player Handbücher

inout

inout Dinplayer D01-MKII Bedienungsanleitung

Beliebte MP3-Player Handbücher anderer Marken

Blaupunkt

Blaupunkt Compact Drive MP3 Bedienungsanleitung

Memorex

Memorex MMP9008 - 8GB USB 2.0 Bedienungsanleitung

Meizu Electronic Technology

Meizu Electronic Technology E5 Bedienungsanleitung

Naxa

Naxa NMV-173NX Bedienungsanleitung

Philips

Philips PSA250 Bedienungsanleitung

Zipy

Zipy go! Waving Bedienungsanleitung

Sylvania

Sylvania SMPK4068 Bedienungsanleitung

Sony

Sony NW-MS7 - Memory Stick Walkman Bedienungsanleitung

Irradio

Irradio RF-42UC Bedienungsanleitung

NABAIJI

NABAIJI SWIM MUSIC 100 Bedienungsanleitung

Laser

Laser MP3-A9-4GB Bedienungsanleitung

Samsung

Samsung YP-T7F Bedienungsanleitung

Savant

Savant SMS-1001-00 Kurzanleitung

Trevi

Trevi XP 71 BT Bedienungsanleitung

AGPtek

AGPtek C2 Bedienungsanleitung

MobiBlu

MobiBlu DAH-1500i Bedienungsanleitung

Denver

Denver MPS-201 Bedienungsanleitung

Steren

Steren MP3-002 Bedienungsanleitung

inout Panelplayer Bedienungsanleitung

Beliebte MP3-Player Handbücher anderer Marken
