Insinger GW-40 BarMaster Bedienungsanleitung

DESIGN

Automatic, chemical sanitizing glasswasher with timed wash and rinse cycles.

Fully automatic operation with power on/off button. Capacity is 40- 20”x20”

racks per hour. Designed to save energy and water. Quiet operation.

GW-40 BarMaster

AUTOMATIC GLASSWASHER

• 40 racks per hour

• 1.4 gallon per cycle

• 11" wash clearance

• Electromechanical controls

• Automatic fill, wash, drain, and rinse cycles

• S/S frame, legs and feet

• Door safety switch

• Adjustable bullet feet

• EZ-Clean™ wash and rinse arms

• Multiple cycle selection 90 seconds, 150 seconds

• 110V electrical connection

• Side panels

6245 State Road

Philadelphia, PA 19135-2995

215-624-4800

215-624-6966 FAX

800-344-4802

www.insingermachine.com

OTHER SPECIFICATIONS

STANDARD EQUIPMENT

• Sanitizer required:

• Sodium Hypochlorite 50 ppm

• Iodiphor 12.5 ppm

• Operating temperatures:

• 120ºF minimum (140ºF recommended)

OPTIONAL EQUIPMENT

• Heated maintenance tank to maintain 120ºF-140ºF water

Note: For all rough in connections see Installation and Layout Detail drawing

GW-40 BarMaster

SPECIFICATIONS

CONSTRUCTION- Hood and tank constructed of type 304 S/S. Hood unit of all welded seamless construction.

S/S frame, legs and feet. All internal castings are non-corrosive lead free nickel alloy or bronze.

CONTROLS- Electro-mechanical controls are simple to use and located in a splash proof box.

WASH/RINSE SYSTEM- Rotating lower S/S wash arms. End caps are easily removable for cleaning.

DRAIN SYSTEM- Drain valve externally controlled.

Capacity

Per Hour

40 racks

Tank

Capacity

1.5 gals

Pump

Motor Size

1 hp

Optional

Maintenance

Tank

2.0 kW

Water Inlet

Temperature

120ºF minimum

140ºF recommended

Water

Usage

1.4 gal./rack

56 gals./hr.

Water Requirements

6 gpm max. flow

20-25 psi flow supply

Exhaust Hood

Requirement

none

Time Cycle

Standard-90 sec.

Extreme-150 sec.

Peak Rate

Drain Flow

9 gals./min.

Shipping Weight

210 lbs.

Current Draw

Amps

115v/1PH/HZ............14.0...................16.0

2/2008 PRINTED IN USA Available in AutoQuotes and KCL Cadalog

Information and specifications subject to change without notice.

with Optional

Maintance

Tank

Washer
