Intel®80303 and 80302 I/O

Processors

Specification Update

May 6, 2003

Notice: The Intel®80303 and Intel®80302 I/O Processors processor may contain design defects

or errors known as errata. Characterized errata that may cause the product’s behavior to deviate

from pubished specifications are documented in this specification update.

Order Number: 273355-010

Intel®80303 and 80302 I/O Processors Specification Update

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY

ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN

INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS

ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES

RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER

INTELLECTUAL PROPERTY RIGHT.

Intel products are not intended for use in medical, life saving, life sustaining applications.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for

future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.

The Intel®80303 and Intel®80302 I/O Processors may contain design defects or errors known as errata which may cause the product to deviate from

published specifications. Current characterized errata are available on request.

Intel®internal code names are subject to change.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by calling

1-800-548-4725 or by visiting Intel's website at http://www.intel.com.

AlertVIEW, i960, AnyPoint, AppChoice, BoardWatch, BunnyPeople, CablePort, Celeron, Chips, Commerce Cart, CT Connect, CT Media, Dialogic,

DM3, EtherExpress, ETOX, FlashFile, GatherRound, i386, i486, iCat, iCOMP, Insight960, InstantIP, Intel, Intel logo, Intel386, Intel486, Intel740,

IntelDX2, IntelDX4, IntelSX2, Intel ChatPad, Intel Create&Share, Intel Dot.Station, Intel GigaBlade, Intel InBusiness, Intel Inside, Intel Inside logo, Intel

NetBurst, Intel NetStructure, Intel Play, Intel Play logo, Intel Pocket Concert, Intel SingleDriver, Intel SpeedStep, Intel StrataFlash, Intel TeamStation,

Intel WebOutfitter, Intel Xeon, Intel XScale, Itanium, JobAnalyst, LANDesk, LanRover, MCS, MMX, MMX logo, NetPort, NetportExpress, Optimizer

logo, OverDrive, Paragon, PC Dads, PC Parents, Pentium, Pentium II Xeon, Pentium III Xeon, Performance at Your Command, ProShare,

RemoteExpress, Screamline, Shiva, SmartDie, Solutions960, Sound Mark, StorageExpress, The Computer Inside, The Journey Inside, This Way In,

TokenExpress, Trillium, Vivonic, and VTune are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and

other countries.

*Other names and brands may be claimed as the property of others.

Intel®80303 and 80302 I/O Processors Specification Update 3

Contents

Revision History......................................................................................... 5

Preface....................................................................................................... 7

Summary Table of Changes....................................................................... 8

Identification Information.......................................................................... 14

Errata....................................................................................................... 16

Specification Changes............................................................................. 23

Specification Clarifications....................................................................... 25

Documentation Changes ......................................................................... 28

4 Intel®80303 and 80302 I/O Processors Specification Update

This Page Intentionally Left Blank

Intel®80303 and 80302 I/O Processors Specification Update 5

Revision History

Date Version Description

05/01/03 010 Added Errata 2.

Revised Specification Clarifications 4, 7and 8.

08/27/02 009 Reworded Specification Clarification 4.

Added Specification Clarifications 7and 8.

11/15/01 008 Added Specification Clarifications 5and 6.

Added Document Changes 32 and 33.

08/22/01 007 Added Specification Clarification 4.

Added Document Changes 30 and 31.

04/24/01 006 Added Document Changes 25 through 29.

Revised Device ID Registers “A-2” Revision ID Registers data.

Added Note to Device ID Registers.

04/02/01 005 Added Specification Clarification 3.

03/22/01 004

Added Errata 1.

Added Specification Change 1.

Added Specification Clarifications 1and 2.

Added Document Changes 13 through 24.

Updated Die Details Table and Device ID Registers for A-2 step.

02/23/01 003 Die Details and Device ID Registers tables, corrected stepping A-0 to A-1.

08/2000 002 Updated Die Details Table.

Revised Device ID Registers Table.

Added Document Changes 1through 12.

06/2000 001 Thisis the new Specification Update document. It contains all identified errata published

prior to this date.

Preface

6Intel®80303 and 80302 I/O Processors Specification Update

Preface

This document is an update to the specifications contained in the Affected Documents/Related

Documents table below. This document is a compilation of device and documentation errata,

specification clarifications and changes. It is intended for hardware system manufacturers and

software developers of applications, operating systems, or tools.

Information types defined in Nomenclature are consolidated into the specification update and are

no longer published in other documents.

This document may also contain information that was not previously published.

Affected Documents/Related Documents

Nomenclature

Errata are design defects or errors. These may cause the Intel®80303 and Intel®80302 I/O

Processors behavior to deviate from published specifications. Hardware and software designed to

be used with any given stepping must assume that all errata documented for that stepping are

present on all devices.

Specification Changes are modifications to the current published specifications. These changes

will be incorporated in any new release of the specification.

Specification Clarifications describe a specification in greater detail or further highlight a

specification’s impact to a complex design situation. These clarifications will be incorporated in

any new release of the specification.

Documentation Changes include typos, errors, or omissions from the current published

specifications. These will be incorporated in any new release of the specification.

Note: Errata remain in the specification update throughout the product’s lifecycle, or until a particular

stepping is no longer commercially available. Under these circumstances, errata removed from the

specification update are archived and available upon request. Specification changes, specification

clarifications and documentation changes are removed from the specification update when the

appropriate changes are made to the appropriate product specification or user documentation

(datasheets, manuals, etc.).

Title Order #

Intel®80303 I/O Processor Developer’s Manual 273353

Intel®80303 I/O Processor Data Sheet 273358

Intel®80303 I/O Processor Design Guide 273308

Intel®80303 and 80302 I/O Processors Specification Update 7

Summary Table of Changes

The following table indicates the errata, specification changes, specification clarifications, or

documentation changes which apply to the Intel®80303 and Intel®80302 I/O Processors product.

Intel may fix some of the errata in a future stepping of the component, and account for the other

outstanding issues through documentation or specification changes as noted. This table uses the

following notations:

Codes Used in Summary Table

Stepping

X: Errata exists in the stepping indicated. Specification Change or

Clarification that applies to this stepping.

(No mark)

or (Blank box): This erratum is fixed in listed stepping or specification change does not

apply to listed stepping.

Page

(Page): Page location of item in this document.

Status

Doc: Document change or update will be implemented.

Fix: This erratum is intended to be fixed in a future step of the component.

Fixed: This erratum has been previously fixed.

NoFix: There are no plans to fix this erratum.

Eval: Plans to fix this erratum are under evaluation.

Row

Change bar to left of table row indicates this erratum is either new or

modified from the previous version of the document.

Summary Table of Changes

8Intel®80303 and 80302 I/O Processors Specification Update

Errata

No. Steppings Page Status Errata

A-0 A-1 A-2

1XXX 12 NoFix Single-bit and Multi-bit Error Reporting Cannot Be

Individually Enabled by ECC Control Register

2XXX 12 NoFix Instruction Sequence Can Scoreboard a Register

Indefinitely

Specification Changes

No. Steppings Page Status Specification Changes

A-2 #-# #-#

1X14 Doc Summary of the Intel® 80302 I/O Processor

Specification Clarifications

No. Steppings Page Status Specification Clarifications

A-0 A-1 A-2

1XXX 15 Doc ECC is Always Enabled

2XXX 15 Doc 32-bit SDRAM is Not Supported

3XXX 15 Doc Non-Battery Backup Systems

4XXX 15 Doc POCCDR and SOCCDR Functionality

5XXX 15 Doc ‘Bus Hold’ Devices on the RAD Bus

6XXX 16 Doc SREQ64# Functionality

7XXX 16 Doc PCI Local Bus Specification, Revision 2.3 Compliancy

8XXX 16 Doc DMA and AAU End of Chain Functionality

Intel®80303 and 80302 I/O Processors Specification Update 9

Summary Table of Changes

Documentation Changes

No. Document Revision Page Status Documentation Changes

1272353-001 17 Doc Title Page revision number

2272353-001 17 Doc Figure 9-3 on pg 9-9 did not print correctly

3272353-001 18 Doc Figure 13-22 on pg 13-40 did not print correctly

4272353-001 18 Doc Figure 13-18, pg 13-35

5272353-001 19 Doc Figure 15-2 on pg 15-3 did not print correctly

6272353-001 20 Doc Incorrect Vendor ID in ATU register

7272353-001 20 Doc Section 23.2 on pg 23-2 has incorrect text

8272353-001 21 Doc Table 24-4 on pg 24-8 is incorrect

9272353-001 31 Doc Figure 25-1 on pg 25-1 has incorrect data

10 272353-001 31 Doc Section 25.1.3 on page 25-2

11 272353-001 32 Doc Figure 25-2 on pg 25-2 did not print correctly

12 272353-001 32 Doc Table 25-2 on page 25-3 did not print completely

13 272353-001 33 Doc Section 1.2.2 on page 1-2 has incorrect data

14 272353-001 33 Doc Figure 12-2 on page 12-10 has incorrect data

15 272353-001 33 Doc Section 19.1 on page 19-1 has incorrect data

16 272353-001 33 Doc Table 14-46 on page 14-109 has missing data

17 272353-001 34 Doc Section 13.2.4.3 on page 13-30 has incorrect data

18 272353-001 34 Doc Figure 15-3 on page 15-7 has missing text

19 272353-001 34 Doc Section 15.7.39 on page 15-100 has incorrect data

20 272353-001 35 Doc Table 8-17 on page 8-38 has incorrect data

21 272353-001 35 Doc Section 11.2.8 on page 11-5 has incorrect data

22 272353-001 35 Doc Section 13.2.3.1 on page 13-13 has incorrect data

23 272353-001 35 Doc Table 13-4 on page 13-9 has incorrect data

24 272353-001 36 Doc Table 8-15 on page 8-36 needs clarification

25 272353-001 36 Doc Table 13-13 on page 13-30 has incorrect data

26 272353-001 37 Doc Section 13.2.4.3, First Paragraph after Table 13-13 has

Incorrect Data

27 272353-001 37 Doc Section 13.2.4.3, First Paragraph after “Current” Figure

13-16. H-Matrix has Incorrect Data

28 272353-001 37 Doc Section 11.3.1.5 FAIL# Code

29 272353-001 37 Doc Section 13.5 Reset Conditions has Incorrect Data

30 272353-001 37 Doc Section 13.2.4.2, First Sentence has Incorrect Data

31 272353-001 37 Doc Section 13.6.2, Second Sentence has Incorrect Data

32 272358-007 38 Doc Section 4.5.2 on page 50 is only correct for A-0 and A-1

steppings

33 272353-001 38 Doc Section 17.5.1 on page 17-12 is only correct for A-0 and

A-1 steppings

Identification Information

10 Intel®80303 and 80302 I/O Processors Specification Update

Identification Information

Markings

Topside Markings

Die Details

Part Number Stepping QDF/

Spec

Number

Voltage

(V)

Intel®

i960®Core

Processor

Speed

(MHz)

Notes

GC80303 A-0 Q176 3.3 100 Samples - limited testing

GC80303 A-0 Q196 3.3 100 Samples - limited testing

GC80303 A-1 Q189 3.3 100 Samples - limited testing

GC80303 A-1 SL4Q4 3.3 100 Production

GC80303 A-2 SL57T 3.3 100 Production - Yield

improvement only, no

functionality changes.

GC80302 A-2 Q229 3.3 100 Samples - limited testing,

66 MHz internal bus and

SDRAM memory interface.

GC80302 A-2 SL5HS 3.3 100 Production - 66 MHz internal

bus and SDRAM memory

interface.

Intel®80303 I/O Processor

FFFFFFFF-[{SN}]

M© ‘2000

SSSSSS

GC80303

MALAY

INTEL

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Intel Computerhardware Handbücher

Intel

Intel BX80623G530 Bedienungsanleitung

Intel

Intel SOM-4486 ETX Module Bedienungsanleitung

Intel

Intel AXXROMBSASMR Installationshandbuch

Intel

Intel 855PM Leitfaden

Intel

Intel SROMBSASMR Installationshandbuch

Intel

Intel NetStructure ZT 5515 Betriebsanleitung

Intel

Intel U3-1L Bedienungsanleitung

Intel

Intel Xeon E3-1125C Bedienungsanleitung

Intel

Intel P4000IP Series Bedienungsanleitung

Intel

Intel DG45ID - CARACTERISTIQUES TECHNIQUES Bedienungsanleitung

Intel

Intel 925 - Pentium D 925 3.0GHz 800MHz 4MB-Cache Socket 775... Bedienungsanleitung

Intel

Intel G23557-002 Bedienungsanleitung

Intel

Intel WPC2011NA - Pro/wireless 2011 Pccard Wireless... Installations- und Betriebshandbuch

Intel

Intel DBPXA210 Technisches Handbuch

Intel

Intel T8300 - Core 2 Duo 2.4GHz 800MHz 3MB Socket P Mobile... Bedienerhandbuch

Intel

Intel Xeon X5570 Bedienungsanleitung

Intel

Intel DC3217BY Bedienungsanleitung

Intel

Intel SRCSAS144E - RAID Controller Montageanleitung

Intel

Intel VC820 - Desktop Board Motherboard Leitfaden

Intel

Intel Pentium II Montage- und Bedienungsanleitung

Intel

Intel SASWT4I Installationshandbuch

Intel

Intel RMS25PB080 Installationshandbuch

Intel

Intel Pentium II Bedienungsanleitung

Intel

Intel E7500 Leitfaden

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung

Advantech

Advantech ASMB-935 Series Bedienungsanleitung

Jupiter

Jupiter RAM PACK Bedienungsanleitung
