SOM-4486 ETX Module

Intel® Celeron® M SOM-ETX

Module with CPU, VGA/LVDS,

Audio & LAN

Users’ Manual

SOM-4486 User’s Manual ii

This document is copyrighted, 2002, by Advantech Co., Ltd. All rights

are reserved. The original manufacturer reserves the right to make

improvements to the products described in this manual at any time

without notice. No part of this manual may be reproduced, copied,

translated or transmitted in any form or by any means without the prior

written permission of the original manufacturer. Information provided

in this manual is intended to be accurate and reliable. However, the

original manufacturer assumes no responsibility for its use, nor for any

infringements upon the rights of third parties which may result from its

use.

Acknowledgements

SOM and DTOS are trademarks of Advantech Co., Ltd.

AMD is a trademark of Advanced Micro Devices, Inc.

Award is a trademark of Award Software International, Inc.

Cyrix is a trademark of Cyrix Corporation.

IBM, PC/AT, PS/2 and VGA are trademarks of International Business

Machines Corporation.

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows®is a registered trademark of Microsoft Corp.

RTL is a trademark of Realtek Semiconductor Co., Ltd.

C&T is a trademark of Chips and Technologies, Inc.

UMC is a trademark of United Microelectronics Corporation.

Winbond is a trademark of Winbond Electronics Corp.

STPC is a trademark of SGS Thomson Corp.

For more information on this and other Advantech products, please

visit our website at: http://www.advantech.com

For technical support and service, please visit our support website at:

http://support.advantech.com

This manual is for the SOM-4486

Part No. 2006448600

1st Edition, Printed Mar 2005

iii

Packing List

Before you begin installing your card, please make sure that the fol-

lowing materials have been shipped:

• 1 SOM-4486 System On Module CPU module

• CD-ROM or Disks for utility, drivers, and manual (in PDF format.

• Heatsink

If any of these items are missing or damaged, contact your distributor

or sales representative immediately.

Additional Information and Assistance

1. Visit the Advantech web site at WWW.advantech.com where you

can find the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's cus-

tomer service center for technical support if you need additional assis-

tance.

Please have the following information ready before you call:

. Product name and serial number

. Description of your peripheral attachments

. Description of your software (operating system, version, application

software, etc.)

. A complete description of the problem

. The exact wording of any error messages

Version History

March, 2005 (manual no. 2006448600) SOM-4486

SOM-4486 User’s Manual iv

FCC

This device complies with the requirements in part 15 of the

FCC rules: Operation is subject to the following two condi-

tions:

1.This device may not cause harmful interference, and

2. This device must accept any interference received, includ-

ing interference that may cause undesired operation

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment

is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instruc-

tion manual, may cause harmful interference to radio commu-

nications. Operation of this device in a residential area is

likely to cause harmful interference in which case the user will

be required to correct the interference at his/her own

expense. The user is advised that any equipment changes or

modifications not expressly approved by the party responsi-

ble for compliance would void the compliance to FCC regula-

tions and therefore, the user's authority to operate the

equipment.

Caution!

There is a danger of a new battery exploding if it is incorrectly

installed. Do not attempt to recharge, force open, or heat the

battery. Replace the battery only with the same or equivalent

type recommended by the manufacturer. Discard used batter-

ies according to the manufacturer’s instructions.

v Table of Contents

Contents

Chapter 1 Introduction ......................................................2

1.1 Introduction ....................................................................... 2

1.2 Specifications .................................................................... 3

1.2.1 Standard System On Module functions .......................... 3

1.2.2 VGA/flat panel Interface ................................................ 4

1.2.3 Audio function ................................................................ 4

1.2.4 LCI .................................................................................. 4

1.2.5 Mechanical and environmental....................................... 4

1.3 Board Dimensions ............................................................. 5

Figure 1.1:SOM-4481 dimensions................................. 5

1.4 Board layout: dimensions.................................................. 6

Figure 1.2: SOM-4481 Top view.................................... 6

Figure 1.3:SOM-4481 Solder view................................. 7

Chapter 2 Connector Assignments .................................10

2.1 Connector Locations ....................................................... 10

Figure 2.1:SOM-4486 Locating Connectors ................ 10

2.2 Pin Assignments for X1/2/3/4 connectors....................... 10

2.3 Safety precautions ........................................................... 11

Chapter 3 Software Configuration .................................14

3.1 Introduction ..................................................................... 14

3.2 Utility CD disk ................................................................ 14

3.3 VGA display software configuration .............................. 14

Figure 3.1:BIOS VGA setup screen ............................. 15

3.4 Connections for two channel LVDS ............................... 16

3.4.1 SOM-4486 X3............................................................... 16

Chapter 4 PCI Graphic Setup.........................................18

4.1 Introduction ..................................................................... 18

4.1.1 Chipset .......................................................................... 18

4.1.2 Display memory............................................................ 18

4.1.3 Display types................................................................. 18

4.1.4 Dual/Simultaneous Display .......................................... 18

Figure 4.1:Selecting Display Settings........................... 20

4.2 Installation of the PCI Graphic driver............................. 20

4.2.1 Installation for Windows 98/ME/2000/XP ................... 20

4.3 Further Information......................................................... 23

Chapter 5 Audio Setup.....................................................26

5.1 Introduction ..................................................................... 26

SOM-4486 User’s Manual vi

5.2 Driver installation............................................................ 26

5.2.1 Before you begin........................................................... 26

Chapter 6 LCI Bus Ethernet Interface...........................30

6.1 Introduction ..................................................................... 30

6.2 Features ........................................................................... 30

6.3 Installation of Ethernet Driver......................................... 30

6.3.1 Installation for Windows 2000 ..................................... 31

6.3.2 Further information....................................................... 34

Appendix A Prog. Watchdog Timer ..................................36

A.1 Watchdog programming.................................................. 36

Appendix B System Assignments .......................................40

B.1 System I/O ports ............................................................. 40

Table B.1:System I/O ports .......................................... 40

B.2 DMA channel assignments.............................................. 41

Table B.2:DMA channel assignments .......................... 41

B.3 Interrupt assignments ...................................................... 42

Table B.3:Interrupt assignments ................................... 42

B.4 1st MB memory map .............................................. 43

Table B.4: 1st MB memory map .................................. 43

1 Chapter1

CHAPTER

General Information

This chapter gives background infor-

mation on the SOM-4486 CPU System

On Module.

Sections include:

• Introduction

• Specifications

• Board Dimensions

SOM-4486 User’s Manual 2

Chapter 1 Introduction

1.1 Introduction

The SOM-4486 is an Intel Ultra Low Voltage Intel® Celeron® M proces-

sor System On Module (SOM) with audio controller, a 4X AGP SVGA

controller, a PCI 10/100Base-T Ethernet interface. Using an Intel ULV

Celeron® M processor, the SOM-4486 achieves quite good performance

on the SOM-ETX CPU module. On-board features include two serial

ports, one multi-mode parallel (ECP/EPP/SPP) port, four USB (Universal

Serial Bus) ports, a floppy drive controller, and a keyboard/PS/2 mouse

interface. The built-in high-speed PCI IDE controller supports both PIO

and UDMA/66 bus master modes. Up to two IDE devices can be con-

nected, including large hard disks, CD-ROM drives, and tape backup

drives. The SOM-4486 features power management to minimize power

consumption. It complies with the "Green Function" standard and sup-

ports Doze, Standby and Suspend modes. In addition, the board's watch-

dog timer can automatically reset the system or generate an interrupt if

the system stops due to a program bug or EMI.The small size (95 mm x

114 mm) and use of four high capacity connectors based on the proven

SOM-ETX form factor, allow the SOM-ETX modules to be easily and

securely mounted onto a customized solution board or our standard

SOM-DB4400 development board.

The SOM-4486 is a highly integrated multimedia SOM that combines

audio, video, and network functions. It provides 16-bit half-duplex, 8-bit

full-duplex, integrated 3D audio, and up to 1024 x 768 resolution @ 16.8

M colors with 8/16/32 MB system memory. Major on-board devices

adopt PCI technology, to achieve outstanding computing performance

and 10W power consumption when used with Intel® Celeron® M pro-

cessors.

3 Chapter1

1.2 Specifications

1.2.1 Standard System On Module functions

• CPU:

Intel® Celeron® M processor w/64KB primary cache memory

• BIOS: Award 4 Mbit Flash BIOS

• Chipset: Intel® 852GM GMCH/ICH4 Chipset 400 MHz PSB

• System memory: 1x200 pin SO-DIMM sockets, support ECC Double

DataRate (DDR) 128 MB to 512 MB, accept 128/256/512 MB DR200/

266/333 DRAM

• Power management: Supports power saving modes including Normal/

Standby/Suspend modes. APM1.2/ACPI 1.0 compliant

• Enhanced IDE interface: 2 EIDE channels support up to 4 IDE

devices. BIOS auto-detect, PIO Mode3 or Mode4,

UDMA/66 transfer

• FDD interface/Parallel port: Both of two interface can’t co-exist, Par-

allel port is default use for designer, FDD interface hardware design is

required to be modified, for detailed information, please refer to our

website: http://service.advantech.com.tw/

• Infrared: One 115 Kbps infrared port, IrDA compliant

• Serial port: two serial ports, COM 1: RS-232 and COM 2 : RS-232

(TTL Output)

• Watchdog timer: 255 timer intervals, from 1 to 255 in seconds or min-

utes, setup by software, jumperless selection, generates system reset

• Keyboard/mouse: Supports standard PC/AT keyboard and PS/2 mouse

interface

• USB interface: Four USB connectors compliant with

USB Spec. Rev. 2.0

SOM-4486 User’s Manual 4

1.2.2 VGA/flat panel Interface

• Chipset: Intel 852 GM, supports a single 1.5V accelerated graphics

port interface

• Frame buffer: Supports 8/16/32 MB frame buffer with system mem-

ory

• Display type: Simultaneously supports CRT and flat panel displays,

also supports dual channel LVDS interface.

• Display mode: CRT Mode: 1280 x 1024 @ 32bpp (60Hz), 1024 x 768

@ 32bpp(85Hz); LCD/Simultaneous Modes: 1280 x 1024

@16bpp(60Hz), 1024 x 768 @16bpp(60Hz)

1.2.3 Audio function

• Chipset: REALTEK ALC202

• Audio controller: AC97 Ver. 2.0 compliant interface,

• Multistream Direct Sound and Direct Sound 3D acceleration

• Stereo sound: 8-bit full-duplex

• Audio interface: Microphone in, Line in, Line out

1.2.4 LCI

• Chipset: Intel 82562EZ

• Ethernet interface: IEEE 802.3U compatible 100/10Base-T interface

includes software drivers and boot ROM

1.2.5 Mechanical and environmental

• Dimensions: (L x W): SOM-ETX form factor, 95 mm x 114 mm (3.7"

x 4.5")

• Power supply voltage: +5 V power only

• Power requirements:

• Max:+5.0 [email protected] A, Typical: [email protected] A (Celeron M 600 MHz, 256

MB DDR 333)

• Operating temperature: 0 ~ 60° C (32 ~ 140° F)

• Operating humidity: 0% ~ 90% Relative Humidity, Noncondensing

• Weight: 0.074 Kg (weight of total package)

Inhaltsverzeichnis

Andere Intel Computerhardware Handbücher

Intel

Intel RS25NB008 Bedienungsanleitung

Intel

Intel NUC Kit NUC1ATKPE Bedienungsanleitung

Intel

Intel Celeron 847 Bedienungsanleitung

Intel

Intel 810A3 Leitfaden

Intel

Intel CORE 2 DUO E7000 - UPDATE 7-2010 Bedienungsanleitung

Intel

Intel 80C188EC Bedienungsanleitung

Intel

Intel CHIPS HiQVideo Series Bedienungsanleitung

Intel

Intel BX80562QX6700 - Core 2 Extreme 2.66 GHz... Bedienungsanleitung

Intel

Intel Pentium 4 Leitfaden

Intel

Intel E2180 - Pentium Dual-Core 2.00GHz 800MHz 1MB Socket 775... Bedienungsanleitung

Intel

Intel D815EEA2 Bedienungsanleitung

Intel

Intel SBEFCM4 Bedienungsanleitung

Intel

Intel NUC11ATKPE Bedienungsanleitung

Intel

Intel AXXRMS2LL040 Installationshandbuch

Intel

Intel E5345 - Xeon 2.33 GHz 8M L2 Cache 1333MHz FSB LGA771 Active Quad-Core... Bedienungsanleitung

Intel

Intel I7-900 DESKTOP PROCESSOR - VOLUME 1 Bedienungsanleitung

Intel

Intel BX80619I73960X Bedienungsanleitung

Intel

Intel 7512 Bedienungsanleitung

Intel

Intel DQ77MK Kurzanleitung zur Einrichtung

Intel

Intel Core i7-3960X Bedienungs- und Sicherheitshinweise

Intel

Intel 945G - Bulk Single Unit Atx Exp Bedienungsanleitung

Intel

Intel 12Gb/s Bedienungsanleitung

Intel

Intel BX80569Q9550 - Core 2 Quad 2.83 GHz... Bedienungsanleitung

Intel

Intel iAPX 86 Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung

Advantech

Advantech ASMB-935 Series Bedienungsanleitung

Jupiter

Jupiter RAM PACK Bedienungsanleitung
