Intel®ServerBoardS5520HC,

Intel®ServerBoardS5500HCV,

Intel®ServerBoardS5520HCT,

Intel®WorkstationBoardS5520SC,

Intel®ServerChassisSC5600,

Intel®ServerChassisSC5650,

Intel®ServerSystemSC5650HCBRP,

Intel®WorkstationSystemSC5650SCWS

SparesPartsList&ConfigurationGuide

A reference guide to assist customers in ordering the necessarycomponents to configure the

Intel®Server Board S5520HC, Intel®Server Board S5520HCT, Intel®Server Board S5500HCV,

and Intel®Workstation Board S5520SC with appropriate Intel chassis.

Rev 2.3

April 2011

Enterprise Platforms and Services Marketing

Disclaimer

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTIONWITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANYINTELLECTUAL PROPERTY RIGHTS IS GRANTED

BYTHIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH

PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED

WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITYOR WARRANTIES

RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY

PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTYRIGHT.

Intel products are not intended for use in medical, life saving, life sustaining applications. Intel maymake changes to

specifications and product descriptions at anytime, without notice.

Intel server boards, server chassis, and processors may contain design defects or errors known as errata, which maycause

the product to deviate from published specifications. Current characterized errata are available on request.

Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in

the United States and other countries.

*Other names and brands may be claimed as the propertyof others.

Contents

Contents.............................................................................................................3

Production Configuration.............................................................................4

Production Board SKUs..............................................................................8

Production System ....................................................................................10

Production Chassis....................................................................................12

Production Spares and Accessories.........................................................14

Production RAID Accessories (not including BBU) .................................20

Production RAID Expander Card..............................................................21

Production RAID Controller.......................................................................21

Intel Tested Memory List...........................................................................23

Intel THOL List...........................................................................................24

Intel®System Management Software –(Upgrade SKUs).......................25

Supported Processor List..........................................................................27

Production Intel Thermal Solution STS100 Series..................................28

Heat Sink Configuration Guide .................................................................28

VMware* vSphere* Virtualization Software Configuration Guide for vSphere* SKUs 29

Product Descriptions –Overview..............................................................29

VMware vSphere* and vCenter* Server SKUs........................................29

Production Configuration

This section contains information needed to order and configure the Intel®Server System SC5650HCBRP, Intel®

Workstation System SC5650SCWS, and Intel®Server Chassis SC5600, SC5650 Family with Intel®Server Board

S5520HC, S5520HCT and S5500HCV and Intel®Workstation Board S5520SC.

1) Production boxed Intel Server Boards contain the following:

One baseboard with unified back plate assembly

ATX I/O shield

Cables: Serial B (COM2), 4 SAS/SATA cables

Resource CD-ROM with utilities, drivers, documentation and technical information*

Quick Start User’s Guide and Quick Reference Label

ISMS CD*

Compatible with Intel®Xeon®processor 5500 series & 5600 series

2) Production OEM 10-packs of Intel Server Boards contain the following:

One baseboard with unified back plate assembly

Compatible with Intel®Xeon®processor 5500 series & 5600 series

3) The production SC5600LX KDK is compatible with the Intel®Server Boards S5520HC and S5500HCV. it

includes:

Redundant (1+1) PMBus-compliant 750W high efficiency PFC power supply with dual line cord support (2nd

redundancy 750W high efficiency PFC module included)

Four redundant, hot-swap fans and ducting

Support for six tool-free non hot-swap hard drives. Upgradeable to 10 cabled or 10 (6+4 configuration) hot-

swap SAS or SATA drives.

Quick Start User’s Guide and Configuration Label

Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oCOM2 Cable

oAdapter Cable providing two additional SATA power connectors

oAC power cords are included onlyin SC5600LXNA

Five Bumpers for installing Intel®Server Board S5520HC or S5500HCV

The Intel®Server Chassis SC5600LX is designed to work with Intel®Xeon®processor 5500 series with

95W maximum power or with Intel® Xeon® processor 5600 series with 130W maximum power and

FXXRGTHSINK or FXXRGTHS tower heat sink accessory (required).

4) The production Intel®Server Chassis SC5600BRP KDK is compatible with the Intel® Server Boards S5520HC

and S5500HCV. it includes:

Redundant (1+1) PMBus-compliant 750W high efficiency PFC power supply with dual line cord support

(2nd redundancy 750W high efficiency PFC module included)

Three non-redundant fixed cooling fans with ducting

Support for six tool-free non hot-swap hard drives. Upgradeable to 10 cabled or 10 (6+4 configuration) hot-

swap SAS or SATA drives.

Quick Start User’s Guide and Configuration Label

Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oCOM2 Cable

oAdapter Cable providing two additional SATA power connectors

oAC power cords are included only in SC5600BRPNA

Five Bumpers for installing Intel®Server Board S5520HC, S5500HCV

The Intel®Server Chassis SC5600BRP is designed to work with Intel®Xeon®processor 5500 series with

95W maximum power or with Intel® Xeon® processor 5600 series with 130W maximum power, and is

compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.

5) The production Intel®Server Chassis SC5600 Base KDK is compatible with Intel®Server Chassis S5520HC,

S5500HCV, and Intel®Workstation Board S5520SC. It includes:

Non-redundant 670W PFC power supply

Three non-redundant fixed cooling fans with ducting

Support for six tool free non hot-swap hard drives. Upgradeable to 6 hot-swap SAS or SATA.

Quick Start User’s Guide and Configuration Label

Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oCOM2 Cable

oAdapter Cable providing two additional SATA power connectors

oAC power cord is included only with SC5600BASENA.

Five Bumpers for installing Intel®Server Board S5520HC, S5500HCV, and Intel®Workstation Board

S5520SC.

The Intel®Server Chassis SC5600BASE is designed to work with Intel®Xeon®processor 5500 series with

95W maximum power or with Intel® Xeon® processor 5600 series with 130W maximum power, and is

compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.

6) The production Intel®Workstation Chassis SC5650WS SKU is compatible with the Intel®Workstation Board

S5520SC. It includes:

Non-redundant 1000W high efficiency PFC power supply

Three non-redundant fixed cooling fans with ducting

Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.

Quick Start User’s Guide

Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oAdapter Cable providing two additional SATA power connectors

oAC power cord is included only with SC5650WSNA

Chassis intrusion switch assembly

Five Bumpers for installing Intel®Workstation Board S5520SC.

The chassis is designed to work with Intel®Xeon®processor 5500 series & 5600 series with 130W

maximum power, and is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.

7) The production Intel®Server Chassis SC5650DP SKU is compatible with the Intel®Server Board S5520SC,

S5500HCV, and S5500BC. It includes:

Non-redundant 600W PFC power supply

Three non-redundant fixed cooling fan with ducting

Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.

Note: Check the Power budget spreadsheet for supportable hard drive, memory and PCI configurations.

Quick Start User’s Guide

Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oAdapter Cable providing two additional SATA power connectors

oAC power cord is only included in SC5650DPNA

Chassis intrusion switch assembly

Five Bumpers for installing Intel®Server Board S5520SC, S5500HCV, and S5500BC.

The chassis is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power or with

Intel® Xeon® processor 5600 series with 130W maximum power, and is compatible with boxed STS100C

(Combo) or STS100A (Active) heat sink.

8) The production Intel®Server Chassis SC5650BRP SKU is compatible with the Intel®Server Board S5520SC,

S5500HCV, and S5500BC. It includes:

Redundant (1+0) PMBus-compliant 600W high efficiency PFC power supply with dual line cord support (full

redundancy requires additional 600W module purchased separately)

Three non-redundant fixed cooling fan with ducting

Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.

Quick Start User’s Guide

Cables (one each):

oFront Panel Cable (baseboard header to front panel)

oUSB Cable (USB header to chassis front panel)

oAdapter Cable providing two additional SATA power connectors

oAC power cord is only included in SC5650BRPNA

Chassis intrusion switch assembly

Five Bumpers for installing Intel®Server Board S5520SC, S5500HCV, and S5500BC.

The chassis is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power or with

Intel® Xeon® processor 5600 series with 130W maximum power, and is compatible with boxed STS100C

(Combo) or STS100A(Active) heat sink.

9) The Intel®Server System SC5650HCBRP includes:

Intel®Server Board S5520HC pre-installed in the Intel®Sever Chassis SC5650BRP

Expander-based Intel® Hot Swap Drive Bay AXX6DRV3GEXP pre-installed with cooling and mounting kit

(APP3HSDBKIT) in the Intel®Server Chassis SC5650BRP (Require SAS add-in card or SAS module

purchased separately)

Redundant (1+0) PMBus-compliant 600W high efficiency PFC power supply with dual line cord support (full

redundancy requires additional 600W module purchased separately)

Three non-redundant fixed cooling fan with ducting

Quick Start User’s Guide and Configuration Label

Cables (one each)

oFront Panel Cable (baseboard header to front panel, pre-routed))

oUSB Cable (USB header to chassis front panel, pre-routed)

oAdapter Cable providing two additional SATA power connectors (in cable kit)

oAC power cord is only included in SC5650HCBRPNA

Chassis intrusion switch assembly (pre-routed)

The server system is designed to work with Intel®Xeon®processor 5500 series with 95W maximum power

or with Intel® Xeon® processor 5600 series with 130W maximum power, and is compatible with boxed

STS100C (Combo) or STS100A (Active) heat sink.

10) The Intel®Workstation System SC5650SCWS includes:

Intel®Workstation Board S5520SC pre-installed in the Intel®Sever Chassis SC5650WS

Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.

Non-redundant 1000W high efficiency PFC power supply

Three non-redundant fixed cooling fan with ducting

Quick Start User’s Guide and Configuration Label

Cables (one each)

oFront Panel Cable (baseboard header to front panel, pre-routed))

oUSB Cable (USB header to chassis front panel, pre-routed)

oAdapter Cable providing two additional SATA power connectors (in cable kit)

oAC power cord is only included in SC5650SCWSNA

Chassis intrusion switch assembly (pre-routed)

The workstation system is designed to work with Intel®Xeon®processor 5500 series & 5600 series with

130W maximum power, and is compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.

11) Common accessories include:

Hot Swap Drive Bays:

–AXX6DRV3GEXP: Expander-based 6-drive bay that supports SAS/SATA drives. Requires two free

SAS ports from the SAS module or SAS RAID card.

–AXX4DRV3GEXP: Expander-based 4-drive baythat supports SAS/SATA drives. Requires two free

SAS ports from the SAS module or SAS RAID card. Only supported in Intel®Server Chassis

SC5600BRP, and SC5600LX.

–AXX6DRV3GR: 6-drive baythat supports SAS/SATA drives. Requires six free SAS or SATA ports.

SAS hard drive support requires SAS connectors from a SAS module or SAS RAID Card. Support 6Gb

SAS Hard Drives with compatible 6Gb SAS adapters

–AXX4DRV3GR: 4-drive baythat supports SAS/SATA drives. Requires four free SAS or SATA ports.

SAS hard drive support requires SAS connectors from a SAS module or SAS RAID Card. Only

supported in Intel®Server Chassis SC5600BRP and SC5600LX. Support 6Gb SAS Hard Drives with

compatible 6Gb SAS adapters.

AXX750WPS: Spare 750W power supply module for Intel®Server Chassis SC5600LX and SC5600BRP

ARIGRACK: Rack conversion kit (SC5600BASE, SC5600BRP and SC5600LX)

APP3RACKIT: Rack conversion kit (SC5600 chassis family).

AXXRAKSW5: Intel®RAID Activation Key AXXRAKSW5 to enable Intel Embedded RAID technology II for SAS

and/or SATA Software RAID 5 on S5520HC, S5500HCV, and S5520SC boards.

APPT600WHPSU: Additional 600W power supply module- required for full redundancy for SC5650BRP only.

APPTHSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis

family. This kit shouldbe used with AXX6DRV3GR

APP3HSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis

family. This kit shouldbe used with AXX6DRV3GEXP.

AXX25DRVADPTR: 2.5” hard drive carrier kit for installing 2.5” SATA or SAS hard drive or Solid State Drive into 3.5”

hot swap drive bay

Production Board SKUs


Product Code

MM #

UPC

MOQ

Description

S5520HC

900402

00735858207485

Boxed Intel®Server Board S5520HC. (Includes

I/O shield, cables, resource CD and ISMS CD)

S5520HCR

905721

00735858213783

Boxed Intel®Server Board S5520HCR.(Includes

I/O shield, cables, resource CD and ISMS CD)

BB5520HC

901640

00735858207492

Bulk pack of the Intel®Server Board S5520HC

BB5520HCR

905718

00735858213790

Bulk pack of the Intel®Server Board S5520HCR

S5520HCT

904912

00735858213776

Boxed Intel®Server Board S5520HCT. (Includes

I/O shield, cables, resource CD and ISMS CD)

S5500HCV

902386

00735858207508

Boxed Intel®Server Board S5500HCV. (Includes

I/O shield, cables, resource CD and ISMS CD)

S5500HCVR

905723

00735858213820

Boxed Intel®Server Board S5500HCVR.

(Includes I/O shield, cables, resource CD and

ISMS CD)

BB5500HCV

902387

00735858207515

Bulk pack of the Intel®Server Board S5500HCV


Product Code

MM #

UPC

MOQ

Description

BB5500HCVR

905720

00735858213875

Bulk pack of the Intel®Server Board

S5500HCVR

S5520SC

900963

00735858207522

Boxed Intel®Workstation Board S5520SC.

(Includes I/O shield, cables, resource CD and

ISMS CD)

S5520SCR

905722

00735858213806

Boxed Intel®Workstation Board S5520SCR.

(Includes I/O shield, cables, resource CD and

ISMS CD)

BB5520SC

901634

00735858207539

Bulk pack of the Intel®Workstation Board

S5520SC.

BB5520SCR

905719

00735858213813

Bulk pack of the Intel®Workstation Board

S5520SCR.

MOQ = Minimum Order Quantity.

Production System


Product Codec

MM #

UPC

MOQ

Description

SC5650HCBRP

904553

00735858212557

Intel®Server System SC5650HCBRP with

(1+0) PMBus-compliant 600W Redundant

power supply, 3 fixed chassis fans with

ducting, rackable with optional rack kit.

Supports up to 6 Hot-Swap drives (SAS or

SATA, require SAS add-in card or SAS

module purchased separately). Supports

Intel® Xeon® processor 5500 series with

95W maximum power or Intel® Xeon®

processor 5600 series with 130W maximum

power. No power cord or heat sinks

included.

SC5650HCBRPR

907331

TBD

Intel®Server System SC5650HCBRPR with

(1+0) PMBus-compliant 600W Redundant

power supply, 3 fixed chassis fans with

ducting, rackable with optional rack kit.

Supports up to 6 Hot-Swap drives (SAS or

SATA, require SAS add-in card or SAS

module purchased separately). Supports

Intel® Xeon® processor 5500 series with

95W maximum power or Intel® Xeon®

processor 5600 series with 130W maximum

power. No power cord or heat sinks

included.

SC5650HCBRPNA

903806

00735858213196

Same as Intel®System SC5650HCBRP

with North American power cord included.

No heat sinks included.

SC5650HCBRPRN

905764

TBD

Same as Intel®System SC5650HCBRPR

with North American power cord included.

No heat sinks included.

SC5650SCWS

904581

00735858212571

Intel®Workstation System SC5650SCWS

with 1000W fixed PSU, supports up to two

150W workstation graphics cards or single

300W workstation graphics card, 3 fixed

chassis fans with ducting, rackable with

optional rack kit, supports up to 6 fixed

drives, upgradeable to 6 Hot-Swap drives

(SAS or SATA). Supports Intel® Xeon®

processor 5500 series & 5600 series with

130W maximum power.. No power cord or

heat sinks included.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Intel Hauptplatine Handbücher

Intel

Intel BOXDG33TLM Konfigurationshandbuch

Intel

Intel BLKDH57DD Konfigurationshandbuch

Intel

Intel DG965MQ Bedienungsanleitung

Intel

Intel D865GVHZ Bedienungsanleitung

Intel

Intel D410PT Bedienungsanleitung

Intel

Intel D845EBG2 - Desktop Board Motherboard Bedienungsanleitung

Intel

Intel PMB-601LF Bedienungsanleitung

Intel

Intel I865PE Bedienungsanleitung

Intel

Intel ATC6430M Bedienungsanleitung

Intel

Intel D815EEA2 Referenzhandbuch

Intel

Intel D845GBV Bedienungsanleitung

Intel

Intel D845HV Konfigurationshandbuch

Intel

Intel DG965OT - Desktop Board Motherboard Bedienungsanleitung

Intel

Intel DQ77CP Bedienungsanleitung

Intel

Intel BLKDG31PR - 1333FSB DDR2 800 Audio Lan 4SATA uATX 10Pack... Bedienungsanleitung

Intel

Intel DQ965CO Bedienungsanleitung

Intel

Intel S2600IP4 Bedienungsanleitung

Intel

Intel BLKDQ45CB Bedienungsanleitung

Intel

Intel H67 Bedienungsanleitung

Intel

Intel BLKD946GZABL Konfigurationshandbuch

Intel

Intel DG45FC - CARACTERISTIQUES TECHNIQUES Bedienungsanleitung

Intel

Intel MB960 Bedienungsanleitung

Intel

Intel DH77EB Bedienungsanleitung

Intel

Intel DQ57TML Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
