Intel®Carrier Grade Server TIGI2U &

Intel®IP Network Server NSI2U

Tested Hardware and Operating System List

Revision 1.3

September, 2006

Enterprise Platforms and Services Marketing

Revision History

Revision 1.3

Revision History

Date Revision

Number Modifications

September 2005 1.0 Initial Release

Q106 1.1 RoHS Updates

Q206 1.2 Supported OS Updates and Certifications

September 2006 1.3 Addition of Suse 9.x SP3 support

Disclaimers

THE INFORMATION IN THIS DOCUMENT IS PROVIDED "AS IS" WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY

WARRANTY OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE

ARISING OUT OF ANY PROPOSAL, SPECIFICATION, OR SAMPLE.

Information in this document is provided in connection with Intel®products. No license, express or implied, by estoppel or otherwise,

to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such

products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of

Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any

patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining

applications.

Intel retains the right to make changes to its test specifications at any time, without notice.

The hardware vendor remains solely responsible for the design, sale and functionality of its product, including any liability arising

from product infringement or product warranty.

Intel, the Intel logo, and EtherExpress are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United

States and other countries.

*Other names or brands may be claimed as the property of others.

Table of Contents

Revision 1.3

iii

Table of Contents

1. Introduction ..........................................................................................................................1

1.1 Test Overview..........................................................................................................1

1.1.1 Basic Installation Testing.........................................................................................1

1.1.2 Adapter / Peripheral Compatibility and Stress Testing............................................2

1.2 Pass/Fail Test Criteria .............................................................................................3

2. Base System Definitions .....................................................................................................4

3. Supported Operating Systems............................................................................................5

3.1 Operating Systems Supported but not Tested.........................................................6

3.2 Operating System Certifications..............................................................................6

4. Adapters and Peripherals....................................................................................................8

4.1 PCI SCSI RAID......................................................................................................10

4.2 PCI SATA RAID.....................................................................................................10

4.3 PCI SCSI ...............................................................................................................11

4.4 PCI MROMB..........................................................................................................12

4.5 PCI Fibre Channel.................................................................................................12

4.6 PCI NIC..................................................................................................................13

4.7 Modems.................................................................................................................14

4.8 Keyboard/Mouse....................................................................................................14

4.9 CDROM Drives......................................................................................................15

4.10 DVD Drives............................................................................................................16

4.11 Tape Drives .............................................................Error! Bookmark not defined.

4.12 Removable Drives .................................................................................................16

4.13 KVM.......................................................................................................................17

5. Hard Disk Drives.................................................................................................................18

6. Installation Guidelines & Test Notes................................................................................22

6.1 LSI* Add-in RAID Card Option ROM Utility Access Issue .....................................22

Introduction

Revision 1.3

1. Introduction

This document is intended to provide users of the Intel®Carrier Grade Server TIGI2U and the

Intel®IP Network Server NSI2U with a list of the operating systems, adapter cards, and

peripherals tested by Intel on this server platform. The Intel®Carrier Grade Server TIGI2U and

the Intel®IP Network Server NSI2U are both integrated using the Intel®Server Board

SE7520JR2.

This document will continue to be updated as new adapters, peripherals, and operating systems

are tested or until the Intel®Carrier Grade Server TIGI2U and the Intel®IP Network Server

NSI2U are no longer in production. Each new release of the document will present updated

information as well as continue to provide the information from previous releases.

The adapters and peripherals specified in this document may or may not have been tested on

all available board/riser combinations that make up the TIGI2U and NSI2U product family. Intel

will provide support for the adapters and peripherals listed when used within this family of

products.

The Intel®Carrier Grade Server TIGI2U and the Intel®IP Network Server NSI2U product

families consists of the following server building blocks and integrated systems:

Product Code Product Description

TLIA0201 Intel®Carrier Grade Server TIGI2U, Server Board SE7520JR2 - Onboard SCSI +

DDR2 – 400 MHz + Two PCI Risers + 20 inch Chassis Depth + CDR-RW/DVD-

ROM + Two SCSI HDD Support + AC Power

TLID0201 Intel®Carrier Grade Server TIGI2U, Server Board SE7520JR2 - Onboard SCSI +

DDR2 – 400 MHz + Two PCI Risers + 20 inch Chassis Depth + CDR-RW/DVD-

ROM + Two SCSI HDD Support + DC Power + NEBS + ETSI

NSIA0100 Intel®IP Network Server NSI2U, Server Board SE7520JR2 - Onboard SATA +

DDR2 – 400 MHz + Two PCI Risers + 20 inch Chassis Depth + Two SATA HDD

Support + AC Power + Eight Ports Front NIC Support

1.1 Test Overview

Testing performed on the Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server

NSI2U is divided under two separate categories:

•Basic Operating System Installation Testing

•Adapter / Peripheral Compatibility testing, and System Stress Testing.

1.1.1 Basic Installation Testing

Basic installation testing is performed with each supported operating system. Basic installation

testing validates that the server board can install the operating system and that the base

hardware feature set is functional. A small set of peripherals is used for installation purposes

only. No add-in adapter cards are tested. Testing includes network connectivity and running of

proprietary and industry standard test suites.

Introduction

Revision 1.3



The latest version of an operating system signifies the latest supported version

at the time of the actual test run. Each new release of this document may have

a newly supported release of a given operating system. Previous releases of a

supported operating system may not be tested beyond the basic installation

test process.

1.1.1.1 Support Commitment for Basic Installation Testing

Intel commits to provide the following level of customer support for operating systems that

receive only basic installation testing:

•Intel will provide and test operating system drivers for each of the server board’s

integrated controllers, provided that the controller vendor has a driver available upon

request. Vendors will not be required by Intel to develop drivers for operating systems

that they do not already support. This may limit the functionality of certain server board

integrated controllers.

•Intel will support customer issues that involve installation and/or functionality of

operating system with the server board’s integrated controllers only if a driver has been

made available.

•Intel will NOT provide support for issues related to use of any add-in adapters or

peripherals installed in the server system when an operating system that received basic

installation testing only is in use.

•Support is defined as assistance in root causing issues, and determining a customer

acceptable resolution to the issue associated with the operating system. The resolution

may include, but is not limited to, on-board controller driver changes, engaging the

vendor for resolution, BIOS changes, firmware changes, or determining a customer

acceptable workaround for the issue.

1.1.2 Adapter / Peripheral Compatibility and Stress Testing

Adapter / Peripheral Compatibility and Stress testing is performed only on the most current

release of a supported operating system at the time of a given validation run. The Adapter /

Peripheral Compatibility and Stress testing process consists of three areas: Base Platform,

Adapter Compatibility, and Stress.

Base Platform: Each base platform will successfully install a given operating system,

successfully run a disk stress test, and successfully run a network stress test.

Adapter Compatibility: Adapter compatibility validation (CV) testing uses test suites to gain an

accurate view of how the server performs with a wide variety of adapters under the primary

supported operating systems. These tests are designed to show hardware compatibility

between the add-in cards and the server platform and include functional testing only. No heavy

stressing of the systems or the cards is performed for CV testing.

Stress Testing: This test sequence uses configurations that include add-in adapters in all

available PCI slots for a minimum 72-hour test run without injecting errors. Each configuration

passes an installation test, a Network/Disk Stress test, and tape backup test. Any fatal errors

that occur will require a complete test restart.

Introduction

Revision 1.3

1.1.2.1 Support Commitment for Adapter / Peripheral Compatibility and Stress

Testing

Intel commits to provide the following level of customer support for operating systems that

receive Adapter / Peripheral Compatibility and Stress testing:

•Intel will provide support for customer issues with these operating systems involving

installation and/or functionality of the server board with or without the adapters and

peripherals listed in this document as having been tested under the particular operating

system.

•Support is defined as assistance in root causing issues, and determining a customer

acceptable resolution to the issue associated with the operating system. The resolution

may include, but is not limited to, on-board controller driver changes, engaging the

vendor for resolution, BIOS changes, firmware changes, or determining a customer

acceptable workaround for the issue.

•Intel will provide and test operating system drivers for each onboard video, network, and

storage controller.

•Intel will enable vendors to provide driver support for add-in adapters using these

operating systems.

•Intel will go through some of the steps to achieve certification to ensure its customers do

not run across any problems, but the actual certification is the responsibility of the

individual customer.



For operating systems, adapter cards, and peripherals not listed in this

document, there is no support commitment. Intel will consider support requests

on a case-by-case basis.

1.2 Pass/Fail Test Criteria

For each operating system, adapter, and peripheral configuration, a test passes if specific

criteria are met. Specific configurations may have had particular characteristics that were

addressed on a case-by-case basis. In general, a configuration passes testing if the following

conditions are met:

•The operating system installed without error.

•Manufacturer’s installation instructions or Intel’s best-known methods were used for the

operating system installation.

•No extraordinary workarounds were required during the operating system installation.

•The server system behaved as expected during and after the operating system

installation.

•Application software installed and executed normally.

•Hardware compatibility tests ran to completion without error.

•Test software suites executed successfully

•Test and data files were created in the correct directories without error.

•Files copied from client to server and back compare to the original with zero errors

reported.

•Clients remain connected to the server system.

•Industry standard test suites run to completion with zero errors reported.

Base System Definitions

4 Revision 1.3

2. Base System Definitions

The following table lists the base system configurations tested for a given validation test run.

Each specific product/system software combination tested is assigned a Base System Identifier

Number. These numbers are used in the lists of supported adapters and peripherals referenced

in the following sections.

The adapters and peripherals specified in this document may or may not have been tested on

all available board/riser combinations that make up the TIGI2U and the NSI2U product family.

However, Intel will provide support for the adapters and peripherals listed when used within this

family of products

This table is updated when a new test run is performed and a new product/system software

combination was used.



Intel will only provide support for adapters and peripherals under the specified

operating systems versions with which they were tested.

Base System

Configuration

Identifier # Product Family BIOS

Revision

mBMC/BMC

Firmware

Revision HSC Firmware Revision

Intel®Server Board

SE7520JR2 in

Intel®Chassis

SR1400/SR2400

Production

Release

P07.x

mBMC FW2.40

IMM BMC FW 32

SCS1 1.06

SATA 1.08

Intel®Server Board

SE7520JR2 in

Intel®Chassis

SR1400/SR2400

Production

Release

P08.x

mBMC FW2.40

IMM BMC FW 46

SCS1 1.06

SATA 1.08

3 Intel®Carrier

Grade Server

TIGI2U

Production

Release

P08.10

mBMC FW2.40

IMM BMC FW 48 SCSI 1.01

4 Intel®Carrier

Grade Server

TIGI2U

Production

Release

P10

mBMC FW2.40

IMM BMC FW 48 SCSI 1.01

Supported Operating Systems

Revision 1.3

3. Supported Operating Systems

The following table provides a list of supported operating systems for the Intel® Carrier Grade

Server TIGI2U and the Intel® IP Network Server NSI2U. Each of the listed operating systems

was tested for compatibility with the Intel® Server Board SE7520JR2 in the base system

configurations listed in section 2 of this document. Operating systems are supported only with

the specified base system configuration(s) with which they were tested.

The following table also indicates whether each operating system received Basic Installation

testing, or Adapter / Peripheral Compatibility and Stress testing. For information on the support

commitments for Basic Installation Testing vs. Adapter / Peripheral Compatibility and Stress

Testing, please reference Section 1 of this document.

Any variations to the standard operating system installation process are documented in the

Installation Guidelines section of this document. If there are no installation guidelines noted in

the following table, then the operating system installed as expected using manufacturer’s

installation instructions or Intel’s best-known methods.



Operating systems supported by Intel®Server Management software or

LANDesk* Client Manager software may be different than the operating

systems supported by the Intel®Server Board SE7520JR2. Please reference

the Readme and User Guide documents that are included as part of each Intel

Server Management and LANDesk* Client Manager distribution for operating

systems that are supported by that release.

Operating System Base System

Configuration Tested

& Type of Testing

Notes

Microsoft Windows Server 2003*, Enterprise

Edition Base Config # - 1

Compatibility & Stress

Microsoft Windows Server 2003, Enterprise

Edition, Service Pack 1 Base Config # - 2

Compatibility & Stress

Microsoft Windows Server 2003, Enterprise x64

Edition, Service Pack 1 Base Config # - 2

Compatibility & Stress

Red Hat* Enterprise Linux 3.0, Update 3 Base Config # - 1, 2

Compatibility & Stress

Red Hat Enterprise Linux 3.0, Update 3 (Intel®

EM64T Edition) Base Config # - 1, 2

Compatibility & Stress

Microsoft Windows Server2003, Enterprise

Edition, Service Pack 1 Base Config # - 3

Compatibility & Stress

Microsoft Windows Server2003, Enterprise x64

Edition Base Config # - 3

Compatibility

Red Hat Enterprise Linux 3.0, Update 4 Base Config # - 3

Compatibility & Stress

Red Hat Enterprise Linux 3.0, Update 4 (Intel®

EM64T Edition) Base Config # - 3

Compatibility

Red Hat Enterprise Linux* 4.0 w/Update 1 Base Config # - 4

Supported Operating Systems

6 Revision 1.3

Operating System Base System

Configuration Tested

& Type of Testing

Notes

Compatibility & Stress

SuSE* Linux Enterprise Server 9, Service Pack

1 Base Config # - 4

Compatibility & Stress

SuSE* Linux Enterprise Server 9, Service Pack

2 Base Config # - 4

Compatibility & Stress

SuSE* Linux Enterprise Server 9, Service Pack

3 Base Config # - 4

Compatibility & Stress

3.1 Operating Systems Supported but not Tested With THOL HW

Listed below are the operating systems that Intel has tested only to install and boot properly on

the platform. No testing has been done with any of the hardware contained within this Tested

Hardware and Operating System document.

Operating System Version Comments

Microsoft* Windows*

2000 Advanced Server Service Pack 4 (SP4) The SE7520JR2 Team Tested the OS on the Board and

Limited Testing has been done on the system.

SCO Open Unix 6.0 In process

SCO UnixWare 7.1.3 Complete

SCO UnixWare 7.1.4 Complete

Monta Vista 4.0 (64-bit) Complete

3.2 Operating System Certifications

Listed below are the operating systems that Intel will certify with the Intel® Carrier Grade Server

TIGI2U and the Intel®IP Network Server NSI2U. However, the customer is responsible for their

own certification from the individual operating system vendors. In many cases, the customer

may leverage their operating system certifications from Intel’s testing. See the “Comments”

section next to each operating system in the table below for additional information. Intel’s

certifications, pre-certification, and operating system testing may help reduce some of the risk in

achieving customer certifications with the operating system vendors.

Operating System Certification Listing Comments

Microsoft Windows

2003*, Enterprise Edition OEM must request certification by Microsoft for their

specific product.

URL - TBD

Microsoft Windows 2003,

Enterprise x64 Edition OEM must request certification by Microsoft for their

specific product.

URL - TBD

Red Hat* Enterprise

Linux 3.0

Red Hat checks Intel’s results, certifies (if appropriate),

and posts the certificate on their web site.

Customer can leverage the Intel certification, if customer

product meets the operating system vendor standard.

URL - TBD

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Intel Server Handbücher

Intel

Intel MFSYS35 Bedienungsanleitung

Intel

Intel S9200WK Series Bedienungsanleitung

Intel

Intel SR2600URLXNA Leitfaden

Intel

Intel S7000FC4UR - Server System - 0 MB RAM Konfigurationshandbuch

Intel

Intel SR2612UR - Server System - 0 MB RAM Betriebsanleitung

Intel

Intel P4000M Bedienungsanleitung

Intel

Intel S2600CW Bedienungsanleitung

Intel

Intel M70KLP Series Konfigurationshandbuch

Intel

Intel SC5650HCBRP Bedienungsanleitung

Intel

Intel SR870BN4 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel SRMK2 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel MFSYS25V2 Bedienungsanleitung

Intel

Intel MFSYS25V2 Bedienungsanleitung

Intel

Intel SR1630GP - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel SR1530CLR - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel ISP1100 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel SC5400RA - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel SBXL52 - Server Compute Blade Betriebsanleitung

Intel

Intel R1000BB Family Bedienungsanleitung

Intel

Intel ISP4400 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel SR1520ML - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel SR2520SAFRNA - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel SR1530HSH - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel S9200WK Series Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
