Interflex IF-4076-0 Bedienungsanleitung

IF-4076-0

Access Manager

Controller

00-4076-04xx

1 General information.......................................................................................................................... 4

1.1 Short description ......................................................................................................................... 4

1.2 Scope of delivery ........................................................................................................................ 4

1.3 Intended use ............................................................................................................................... 4

1.4 Target group ............................................................................................................................... 5

1.5 Notes on safety ........................................................................................................................... 5

1.6 Abbreviations .............................................................................................................................. 5

1.7 Cable lengths and cable types.................................................................................................... 6

2 System overview............................................................................................................................... 7

2.1 Access manager overview .......................................................................................................... 7

Electronic assembly units ........................................................................................................... 7

Components ............................................................................................................................... 9

2.2 IF-4070 controller overview......................................................................................................... 10

Connections on the printed circuit board .................................................................................... 10

LEDs and switches ..................................................................................................................... 11

3 Installing the access manager......................................................................................................... 12

4 Connecting the access manager..................................................................................................... 12

4.1 Cable routing............................................................................................................................... 12

4.2 Wiring components ..................................................................................................................... 13

Ethernet network......................................................................................................................... 13

Bus data cables with slave terminals.......................................................................................... 14

Floating status contacts and relays ............................................................................................ 15

4.3 Connecting the controller ............................................................................................................ 17

Connecting the power supply ..................................................................................................... 17

5 Initial operation ................................................................................................................................. 18

5.1 Connecting the controller to the network .................................................................................... 18

IF-ServiceApp ............................................................................................................................. 18

Service interface ......................................................................................................................... 18

5.2 Checking and setting network parameters.................................................................................. 20

Input syntax for commands......................................................................................................... 20

Setting the network parameters.................................................................................................. 20

Restoring the default IP address ................................................................................................ 21

5.3 Configuring the interfaces and the booking memory .................................................................. 21

5.4 Listing the configuration data of slave terminals ......................................................................... 23

5.5 Restarting the controller.............................................................................................................. 24

6 Updating the software ...................................................................................................................... 26

7 Upgrading the controller.................................................................................................................. 26

8 Technical specifications .................................................................................................................. 27

8.1 General ....................................................................................................................................... 27

8.2 IF-4070........................................................................................................................................ 27

9 Disposal............................................................................................................................................. 28

10 EU Declaration of Conformity.......................................................................................................... 29

1 General information

1.1 Short description

The IF-4076-0 access manager in metal housing with an integrated

IF-4070 controller is used to accommodate up to 16 I/O controller

boards and serves as a link between the host system and a maximum

of 16 terminals (slaves) of the IF-7xx/IF-8xx series.

1.2 Scope of delivery

The package contains

n1 housing with integrated IF-4070 controller, supporting plate for I/O controller boards and power

supply unit

nCable gland, M20 x 15

nStrain relief plates with screw nuts

nSplit ferrite

nAccessory bag with screws, screw anchors and a key for the bolt lock

n95-10436 product Info

Check the completeness and condition of the goods upon receipt and report any damage caused

during transport immediately.

1.3 Intended use

Controllers of this series are designed for fixed installation in dry rooms.

Any other use is not in accordance with the intended purpose and therefore not permitted. Modifications

to the terminal are not permitted.

1 General information

1.4 Target group

This document is solely intended for experts and people trained in electrical engineering.

Only perform the actions described in this document if you belong to this target group. Interflex

Datensysteme GmbH is not liable for any damages caused by improper installation or initial

operation.

1.5 Notes on safety

WARNING

Danger to life due to electric shock

People can be seriously hurt or killed through physical contact with live parts (e.g. 230V~).

uMake sure that you cannot touch live lines during installation.

uSwitch off the power supply of the devices.

uPlease observe the applicable safety regulations and take all precautionary measures to ensure safe

installation.

NOTICE

Damage due to electrostatic discharge (ESD)

Electrical components and modules can be damaged by only slight, hardly noticeable electrostatic

discharge (ESD) without this becoming immediately obvious. ESD damages result in malfunctions and

even failure of the product.

uMake sure that effective protective measures against electrostatic discharge are in place when

working on the open device.

NOTICE

Property damage due to transient overvoltages

Transient overvoltages (surges, bursts) in the energy supply network can lead to malfunctions and

failures.

uUse suitable mains filters that are professionally installed and operated.

The device may only be installed, placed into initial operation and troubleshooted by qualified

personnel and people trained in electrical engineering.

1.6 Abbreviations

AC Alternating Current

BLE Bluetooth Low Energy

CIDR Classless Inter-Domain Routing

DC Direct Current

1 General information

DIP switch Switch in IC design, connections in two rows (Dual In-line Package)

EMC Electromagnetic Compatibility

ESD Electrostatic discharge

GND Ground

IEEE Institute of Electrical and Electronics Engineers

NC contact Normally closed contact

NO contact Normally open contact

PoE Power over Ethernet

RFID Radio-Frequency Identification

SH Shield

SSH Secure shell

1.7 Cable lengths and cable types

Cable Function Max. Length Recommended cable type

230 V AC power supply to power supply unit (if not

pre-installed)

NYM 3 x 1.5mm2

Network cabling: RJ45 patch cable, preferably shield

braiding

100m From category 5

Cable to floating status contacts, control cable 100m J-Y(St) Y 2 x 2 x 0.6mm2

J-Y(St) Y 2 x 2 x 0.8mm2

RS485 bus cable to parent or child devices 1200m J-Y(St) Y 2 x 2 x 0.6mm2

J-Y(St) Y 2 x 2 x 0.8mm2

RS485 branch cable to bus cable 100m J-Y(St) Y 2 x 2 x 0.6mm2

J-Y(St) Y 2 x 2 x 0.8mm2

Connecting cable between I/O controller board and

slave terminal

100m J-Y(St) Y 4 x 2 x 0.6mm2

J-Y(St) Y 4 x 2 x 0.8mm2

In long cables, voltage losses can impair the functionality of the connected device. Therefore, do not use

cables longer than specified in the table. Wire the +5 V and GND lines with two cores each for a cable

length > 50 m.

2 System overview

The IF-4076-0 access manager includes the following functions:

nOperation in conjunction with a host system for access control or time recording (e.g., IF-6020 or

IF-6040)

nConnection and control of up to 16 slave terminals via I/O controller boards

nRecording of bookings (IN, OUT, absences, access)

nAccess control including door control and monitoring

nStorage of data required for offline operation, e.g. credential numbers, temporal and local permissions

In offline mode, the access manager takes over the functions of the host system. It checks and

acknowledges booking permissions during identification procedures at slave terminals.

2.1 Access manager overview

Electronic assembly units

The I/O controller boards are included in scope of delivery of the slave terminals.

The cables on bus 1 of the IF-4070 controller are fed through a split ferrite (not shown in the

figure).

2 System overview

1IF-4070 controller

2Anti-tamper switch

3Mounting rail for fastening additional power supply units

4Strain relief for voltage feed

5Ground

6Voltage filter with fuse

7Transformer

8Supporting plate for up to 16 I/O controller boards

The anti-tamper switch 2 can be configured in such a way that it is monitored by the host

system and triggers an alarm when the housing is opened.

1. Before opening an access manager that has already been put into operation, deactivate the

alarm

2. Reactivate the alarm after work has been completed

Detailed information on this subject can be found in the documentation of the host system

2 System overview

Components

1Host system 2IF-4070 controller

3Slave Terminal 4Readers

5Control element 6Door opening push-button

7Door contact 8Power supply

2 System overview

2.2 IF-4070 controller overview

Connections on the printed circuit board

11 8

1235

1USB connection (for future use)

214-pin screw terminal for floating status contacts

314-pin screw terminal for floating status contacts and relay contacts

414-pin screw terminal for relay contacts

56-pin screw terminal for relay contacts

6Connection for optional rechargeable battery for emergency power supply (IF-4070 only)

7Screw terminal for the connection of the power supply

8RJ45 socket for the connection to the Ethernet network (host system)

9USB connection (for future use or ServiceApp)

10 3x RJ45 sockets with RS485 interfaces for the connection of bus data cables 1, 2, 3

11 RJ45 socket with RS485 interface for the connection to the host system

12 RJ45 socket with RS232 interface for the connection to the host system

13 RJ45 socket with RS232 interface for the connection of a service device

14 3-pin screw terminal for RS232 service cable (same function as socket 13)

15 7-pin screw terminal for RS485 data cable (same function as socket 10)
