Intergraph Zx10 Ultra-Tower Bedienungsanleitung

Zx10

System Board Manual

May 2000

D1AA0035A

by any means, or be used to make any derivative work, without written consent from Intergraph Computer Systems.

Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subdivision

(c)(1)(ii) of the rights in technical data and computer software clause at DFARS 252.227-7013. Unpublished rights are

reserved under the copyright laws of the United States.

Intergraph Computer Systems, Huntsville AL 35894-0001

Notice

Information in this document is subject to change without notice and should not be considered a commitment by

Intergraph Computer Systems. Intergraph Computer Systems shall not be liable for technical or editorial errors in, or

omissions from, this document. Intergraph Computer Systems shall not be liable for incidental or consequential

damages resulting from the furnishing or use of this document.

All warranties given by Intergraph Computer Systems about equipment or software are set forth in your purchase

contract. Nothing stated in, or implied by, this document or its contents shall be considered or deemed a modification

or amendment of such warranties.

Trademarks

Intergraphand the Intergraph logo are registered trademarks of Intergraph Corporation. Zxis a trademark of

Intergraph Computer Systems. Inteland Pentiumare registered trademarks of Intel Corporation. ServerSetis a

trademark of ServerWorks Corporation. Microsoft is a registered trademark of Microsoft Corporation. Other brands

and product names are trademarks of their respective owners.

FCC/DOC Compliance

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a residential installation. This equipment generates, uses, and can radiate radio frequency

energy. If the equipment is not installed and used in accordance with the instructions, it may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, try to correct the interference as follows: reorient or relocate the affected device; increase

the separation between this equipment and the affected device; connect this equipment to an outlet on a circuit different

from the circuit to which the affected device is connected; consult a dealer or an experienced radio/television

technician for help.

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigencies du Règlement sur le materiél brouilleur du Canada.

Safety Notices

Service and upgrade tasks should be performed by users who can follow instructions in a manual to service equipment,

and can do so without harm to themselves or damage to the equipment.

To reduce the risk of electrical shock and energy hazards, do not attempt to open the equipment unless instructed, and

do not use a tool for purposes other than instructed.

Internal components may be at high temperatures. Allow time for them to cool before handling them.

Internal components can be damaged by static electricity. Use an antistatic wrist strap connected to the bare metal of

the system’s chassis to protect against electrostatic discharge.

Notes

Changes or modifications made to the system that are not approved by the party responsible for compliance could void

the user's authority to operate the equipment.

Procedures in this document assume familiarity with the general terminology associated with personal computers, and

with the safety practices and regulatory compliance required for using and modifying electronic equipment.

Read all operating instructions before using this device. Keep these instructions for future reference. Follow all

warnings on the device or in the operating instructions.

Contents

Preface...........................................................................................................................................vii

About This Document.....................................................................................................................vii

Document Conventions...................................................................................................................vii

Customer Support...........................................................................................................................vii

1 Overview....................................................................................................................................... 1

Features and Components................................................................................................................. 1

Block Diagrams................................................................................................................................ 3

Major Components ........................................................................................................................... 6

2 Components.................................................................................................................................. 7

Processors......................................................................................................................................... 7

Memory Modules.............................................................................................................................. 9

Expansion Sockets.......................................................................................................................... 13

Power and Data Connectors............................................................................................................ 14

Fan Connectors............................................................................................................................... 14

ATAPI Connectors ......................................................................................................................... 16

Jumper Connectors ......................................................................................................................... 17

I/O Port Connectors........................................................................................................................ 18

Keyboard, Mouse ............................................................................................................. 19

Parallel ............................................................................................................................. 19

Serial ................................................................................................................................ 20

Universal Serial Bus......................................................................................................... 20

Ethernet Network ............................................................................................................. 20

External Wide Ultra2 SCSI (LVDS)................................................................................ 21

Audio Line Out, Line In, Microphone.............................................................................. 21

Integrated Controllers..................................................................................................................... 22

SCSI Controller................................................................................................................ 22

Network Controller........................................................................................................... 23

Audio Controller .............................................................................................................. 23

Hardware Monitoring and Power Management.............................................................................. 24

CMOS/Clock Lithium Battery........................................................................................................ 26

3 BIOS Setup................................................................................................................................. 27

BIOS Overview .............................................................................................................................. 27

Using BIOS Setup .......................................................................................................................... 27

BIOS Setup Screens........................................................................................................................ 28

Main Screen.................................................................................................................................... 28

Advanced Screen............................................................................................................................ 29

Security Screen............................................................................................................................... 30

Misc. Screen................................................................................................................................... 30

Boot Screen .................................................................................................................................... 31

Exit Screen...................................................................................................................................... 31

Using CMOS Reset......................................................................................................................... 32

Updating the System BIOS............................................................................................................. 32

4 Resources.................................................................................................................................... 33

ISA Interrupt Requests (IRQs) ....................................................................................................... 33

PCI-to-ISA Interrupt Map............................................................................................................... 34

Direct Memory Access (DMA) Channels....................................................................................... 34

Input/Output (I/O) Map .................................................................................................................. 35

Memory Map.................................................................................................................................. 37

5 Messages..................................................................................................................................... 39

POST Tasks and Beep Codes......................................................................................................... 39

Error Messages............................................................................................................................... 43

vii

Preface

This System Board Manual provides detailed information on the Intergraph Computer Systems

Zx10 system board.

About This Document

This System Board Manual is organized as follows:

♦Chapter 1, “Overview,” introduces the system board, its features, and its major components.

♦Chapter 2, “Components,” locates and describes the major components on the system board.

♦Chapter 3, “BIOS Setup,” describes the BIOS Setup program and the system’s BIOS settings.

♦Chapter 4, “Resources,” lists and describes system board resources.

♦Chapter 5, “Messages,” lists and describes messages produced by the system board.

Document Conventions

Bold Commands, words, or characters that you key in literally.

Italic Variable values that you supply, or cross-references.

Monospace Output displayed on the screen.

SMALL CAPS Key names on the keyboard (such as D, ALT,or F3) and names of files and

directories. You can type filenames and directory names in the dialog boxes or

the command line in lowercase unless directed otherwise.

CTRL+DPress a key while simultaneously pressing another key; for example, press CTRL

and D simultaneously.

Customer Support

Intergraph Computer Systems hardware has a factory warranty ranging from 30 days to three years.

A detailed warranty description is available on the World Wide Web. You can also take advantage

of other available hardware support services.

Intergraph Computer Systems provides complimentary operating system and system software

support for 30 or 90 days following shipment of a hardware or software product. At the end of the

complimentary support period, you can take advantage of other levels of software support.

viii

To get more information on support services:

♦Visit the Support pages on the World Wide Web at http://www.intergraph.com/ics.

♦In the United States, call 1-800-414-8991.

♦Outside the United States, contact your local Intergraph Computer Systems subsidiary or

distributor.

To visit Intergraph Computer Systems on the World Wide Web:

Use your World Wide Web browser to go to http://www.intergraph.com/ics.

To get customer support by telephone:

♦In the United States, call 1-800-633-7248 between the hours of 7:00 a.m. and 7:00 p.m.

Central Time, Monday through Friday (except holidays).

♦Outside the United States, contact your local Intergraph Computer Systems subsidiary or

distributor.

♦Have the following information available when you call:

−Your service number, which identifies your site to Intergraph Computer Systems. You

use your service number for warranty or maintenance calls.

−Your Customer Personal Identification Number (CPIN). You get a CPIN the first time

you call the Customer Response Center; it is associated with your service number for

future call logging.

−The product’s name or model number.

−The product’s serial number. Software product serial numbers are included in the product

packaging. Hardware product serial numbers are on a sticker affixed to the hardware

product.

−Your name and telephone number.

−A brief description of the question or problem.

1Overview

This chapter describes the system board, its features, and its major components.

Features and Components

Processors Dual Intel SC242 (Slot 1) support

Intel Pentium III processors

Two integrated voltage regulators

64-bit front-side bus (FSB) – 133 MHz or 100 MHz (varies by system)

System Chipset ServerWorks ServerSet III WS

Streaming Multiport Controllers

32-bit fast I/O interface – 266 MHz (for 133 MHz FSB) or 200 MHz

(for 100 MHz FSB)

AGP controller – one AGP Pro expansion socket

USB controller – four Universal Serial Bus (USB) ports – two external,

one internal, one for the AGP controller

EIDE controller – two Peripheral Component Interconnect (PCI)

bus-mastering EIDE channels

I/O Controller SMC FDC37B787

Controls keyboard, mouse, real-time clock, and floppy disk

Two serial ports, one parallel port

Memory Synchronous Dynamic Random Access Memory (SDRAM) – PC133 or

PC100 (to match FSB speed)

Six (133 MHz FSB) or eight (100 MHz FSB) 168-pin registered dual-

inline memory module (DIMM) sockets

Supports 72-bit Error Correction Code (ECC) memory modules

Four banks, two DIMMs per bank, two-way interleaved

128-bit memory bus – 133 MHz or 100 MHz (to match FSB speed)

SCSI Controller LSI 53C1010

Low-voltage differential (LVD) Ultra 3 SCSI bus

Two 16-bit 80 MHz SCSI channels

Two high-density (HD) 68-pin SCSI connectors

320 MB/sec Ultra 3 SCSI throughput

Handles both Ultra2 and Ultra3 devices at their assigned transfer rates

Network Controller Intel 82559

100 Mbit/sec and 10 Mbit/sec Ethernet network interface

Wake-on-Modem support

Wake-on-LAN support

Audio Controller Creative Labs ES1373 AudioPCI

Audio Codec ’97 (AC97)

Advanced Technology Attachment Packet Interface (ATAPI) CD-ROM

audio header, modem audio header, and video header

Expansion Sockets One full-length AGP Pro socket

Two full-length fast/wide PCI sockets (64 bits, 66 MHz/33 MHz, 3.3 V)

Four full-length wide PCI sockets (64 bits, 33 MHz, 5 V)

One full-length Industry Standard Architecture (ISA) socket (16 bits)

Input/Output Ports One PS/2 mouse port (6-pin mini-DIN)

One PS/2 keyboard port (6-pin mini-DIN)

One parallel (LPT) port (25-pin D-sub)

Two serial (COM) ports (9-pin D-sub)

Two USB ports (self-identifying, hot-pluggable, 12 MB/sec)

One SCSI port (68-pin HD) – Ultra 3

One Ethernet port (8-pin RJ-45)

One each microphone in, line in, and line out audio ports (PC standard

1/8-inch phone jacks)

One MIDI/game port (15-pin D-sub)

Four ATAPI connectors (internal) – CD IN, VIDEO IN, MONO IN,

MPEG IN

BIOS Phoenix BIOS

Supports Advanced Configuration and Power Interface (ACPI)

Supports Desktop Management Interface (DMI)

Supports PC99

Supports S0, S1, S3, and S5 system states

Auto-configuration of IDE hard disk types

Form Factor Extended ATX (12 in x 13 in)

Two 20-pin ATX power connectors

Stacked input/output ports

Andere Handbücher für Zx10 Ultra-Tower

Inhaltsverzeichnis

Andere Intergraph Hauptplatine Handbücher

Intergraph

Intergraph S1832DL Tiger 100 Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
