ATS125x/1260 Four-

Door/Four-Lift DGP

Programming Guide

P/N 1044982 (EN) • REV B • ISS 21JUN17

reserved.

Trademarks and

patents

Interlogix, ATS125x/1260 Four-Door/Four-Lift DGP name and logo

are trademarks of UTC Fire & Security.

Other trade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacturer

UTC Fire & Security Americas Corporation, Inc.

3211 Progress Drive, Lincolnton, NC, 28092, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, Netherlands

Warnings and

Disclaimers

These products are intended for sale to, and installation by, an

experienced security professional. UTC Fire & Security cannot

provide any assurance that any person or entity buying its products,

including any “authorized dealer,” is properly trained or experienced

to correctly install security related products.

For more information on product warnings, refer to

www.utcfssecurityproducts.eu/productwarning/ or scan the code.

Version

This document applies to the product firmware version 2.13.

Certification

European Union

directives

UTC Fire & Security hereby declares that this device is in

compliance with the applicable requirements and provisions of the

Directive 2014/30/EU and/or 2014/35/EU. For more information see

www.utcfireandsecurity.com or www.interlogix.com.

2012/19/EU (WEEE directive): Products marked with this symbol

cannot be disposed of as unsorted municipal waste in the European

Union. For proper recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.utcfssecurityproducts.eu/recycle/

Contact information

www.utcfireandsecurity.com or www.interlogix.com

Customer support

www.utcfssecurityproducts.eu

ATS125x/1260 Four-Door/Four-Lift DGP Programming Guide i

Content

Important information iii

Programming sequence 1

Minimal set-up 1

Basic set-up 2

Advanced settings 4

How to program the options 6

Accessing the installer programming menu 6

Programming the menu options 7

Accessing the door/lift programming menu 9

How to access the door / lift programming menu 9

1-DGP options 10

2-Door / Lift options 16

Access options 16

Request To Exit options 23

Alarm control 25

Reader options 27

Hardware options 33

Lift options 36

3-Initialise database 40

4-Display card 41

5-Door groups 42

6-Floor groups 43

7-System Options 44

8-Macro logic 45

9-Version number 47

10-To Local Devices 48

Reader and interface type programming 49

Short list of available zones and outputs per DGP address 50

Door/lift data hardware defaults 51

Hardware options: default zone/output number assignments 51

ii ATS125x/1260 Four-Door/Four-Lift DGP Programming Guide

Macro event flags 52

List of predefined event flags 52

Programming sheet: DGP options 56

Programming sheet: Door options 57

Programming sheet: Macro logic 60

Glossary 61

Index 65

Programming map 69

ATS125x/1260 Four-Door/Four-Lift DGP Programming Guide iii

Important information

This manual provides detailed explanations for programming the ATS125x/1260

and includes detailed explanations for the entire door / lift menus. All references

to the programming menus, and their numbers, are menus within programming

Remote Devices, Installer menu 28, and Titan Advisor Master > To Remote

Devices > DGP.

When installing a new 4-Door/4-Lift DGP, it is strongly recommended that you

first initialise the ATS125x/1260 using Menu 3 - Initialise Database. This step

may only be accomplished by programming using a RAS on the system databus

of the Advisor Master. It will set all programming to factory default; as listed in

this programming manual. Once initialised, the DGP may be programmed using

a RAS or a PC running TITAN software.

The ATS1250 and ATS1260 are the same physical products except for the

firmware (software) EPROM. The factory defaults are different for each product

and are listed in the programming sheets in this guide.

Whenever the ATS125x is mentioned, ATS1250, ATS1251, ATS1252, ATS1253,

ATS1254, and ATS1260 are included except where explicitly stated.

iv ATS125x/1260 Four-Door/Four-Lift DGP Programming Guide

ATS125x/1260 Four-Door/Four-Lift DGP Programming Guide 1

Programming sequence

The ATS125x/1260 four-door/four-lift DGP is a versatile access control panel to

extend the Advisor Master system with advanced access control functions. When

programming it is easy to lose track if one does not use a good method. Using a

good method also provides for an efficient way of programming.

Minimal set-up

The minimal set-up only consists of settings required to enable cards being read

and door opening due to a valid card.

1. Set the DGP address for the four-door/four-lift DGP (1 to 12 available).

2. Check if the RAM memory in ATS125x/1260 and the Advisor Master control

panel is the same.

3. Set addresses of RASes (readers or DGPs connected to the local databus of

the four-door/four-lift DGP.

4. In the Advisor Master control panel, installer programming (menu 19):

- In the Advisor Master control panel menu 4. DGP, activate polling for the

four-door/four-lift DGP and set the DGP type.

- Check and note in the Advisor Master control panel, menu 7. System

options the settings for Dual zone and the Number of prefix digits.

- In menu 13. Timezones, program timezones required for access control

functions (Request To Exit, Override timezone and Door groups).

- In menu 2, Area database, determine which areas will inhibit Request to Exit

or will inhibit access through a door when the areas are armed.

5. Go to menu 28, To remote devices. Select type 1 (DGP) and press [ENTER].

Enter the DGP address and press [ENTER]. You now are in the four-

door/four-lift programming menu.

6. Go to menu 1-DGP options.

Set or select the following options:

- Enter the required Batch Number (range 1 to 40). If card numbers or system

codes are unknown, then first see “Finding system codes for cards” on page

- Enter Alarm Code Prefix Digits (same as in control panel).

- Enter RASes to be polled connected to the local databus.

- Enter LCD RAS connected to the local databus.

- Set Dual zone to the same setting as used in the control panel.

- Enter Re-lock delay time.

7. Go to menu 2-Door / Lift options.

8. Select the door to program. Only doors available on the selected DGP can be

entered.

2 ATS125x/1260 Four-Door/Four-Lift DGP Programming Guide

9. Move to menu Reader options.

10.Select the required Card format.

11.Press [ENTER] until the display indicates menu Hardware options.

12.Press 0 [ENTER] [ENTER] to leave menu 2-Door / Lift options

13.Move to menu 4-Display card and badge a number of cards to verify the

cards are being read, the card number is known.

14.Proceed with the basic set-up.

Basic set-up

1. Set the DGP address for the four-door/four-lift DGP (1 to 12 available).

2. Check if the RAM memory in ATS125x/1260 and the Advisor Master control

panel is the same.

3. Set addresses of RAS's (readers or DGP's connected to the local databus of

the four-door/four-lift DGP.

4. In the Advisor Master control panel, installer programming (menu 19):

- In the Advisor Master control panel menu 4. DGP, activate polling for the

four-door/four-lift DGP and set the DGP type.

- Check and note in the Advisor Master control panel, menu 7. system options

the settings for Dual zone and the Number of prefix digits.

- In menu 13. Timezones, program timezones required for access control

functions (Request To Exit, Override timezone and Door groups)

- In menu 2, Area database, determine which area/s will inhibit Request to

Exit or will inhibit access through a door when the area/s are armed.

5. Go to menu 28, To remote devices. Select type 1 (DGP) and press [ENTER].

Enter the DGP address and press [ENTER]. You now are in the four-

door/four-lift programming menu.

6. Go to menu 1-DGP options.

Set or select the following options:

- Number of Output controllers.

- Enter the required Batch Number (range 1 to 40). If card numbers or system

codes are unknown, then first see Finding system codes for cards (page 5).

- Alarm Code Prefix Digits (same as in control panel).

- Enter RASes to be polled connected to the local databus.

- Enter LCD RAS connected to the local databus.

- Enter RASes with RTE enabled that are connected to the local databus.

- Enter DGP to be polled connected to the local databus.

- Set Dual zone to the same setting as used in the control panel.

- Enter the Card to PIN time (only if Card & PIN required).

- Enter Two cards time (only if required).

- Enter Multiple Badge time (only if alarm control is required).

ATS125x/1260 Four-Door/Four-Lift DGP Programming Guide 3

- Enter Re-lock delay time.

- Enter Region count limit (only if anti-passback is used).

7. Go to menu 2-Door / Lift options.

8. Select the door to program. Only doors available on the selected DGP can be

entered.

9. Now the first menu will be visible, Access options.

Set or select the following options:

- Select the door to program

- Unlock time

- Extended unlock time (if required)

- Shunting option (if required)

- Shunt time (if required)

- Extended shunt time (if required)

- Shunt warning time (if required)

- Shunt until door has closed

- Cancel shunt time after door closed

- Low security timezone (if required)

- IN / OUT reader requires card and PIN

- IN / OUT reader inhibit PIN if timezone

- IN / OUT reader inhibit region 0 user

- Anti-passback option (if required)

- IN / OUT reader region (if required)

- IN / OUT reader Two Cards function

10.Move to menu Request To Exit options (only if required)

Set or select the following options:

- Request To Exit Timezone

- IN or OUT RTE disabled if area is armed

- Request To Exit control

- Request To Exit reporting

11.Move to menu Reader options

Set or select the following options:

- Card format

- Zone holds door unlocked

- Door unlocked until door open

- Unlocked timezone (if required)

- Unlocked timezone after entry

- Report when door closed and locked

- Report open/unlocked as unlocked

- Report door open / close

- Report forced door

- Report DOTL

- Reader LED options

- Pulsed lock and unlock

- Disable Duress functionality

4 ATS125x/1260 Four-Door/Four-Lift DGP Programming Guide

12.Move to menu Hardware options.

Set or select the following options:

- Unlock output number

- Zone number

- Monitor second door zone (if required)

- Forced output number (if required)

- Shunt zone numbers (if required)

- Warning output number (if required)

- DOTL zone number (if required)

- DOTL output number (if required)

- Request To Exit zone number (if required)

- Interlock zone numbers (if required)

- Areas assigned to door (if required)

- Alarm output number (if required)

13.When out of the Hardware options, press 0 [ENTER] to leave the menus in

Door options. Press [ENTER] again to leave the Door options. Press 0

[ENTER] again to leave the four-door/four-lift programming menu.

14.Set-up the required door groups in the Advisor Master user program

(menu 20)

15.Program users that require access control functions (door group)

16.Program zones available on the 4-Door DGP

Advanced settings

Add alarm control functions

In the Advisor Master installer programming:

•Program timezones required for alarm control functions (used in alarm

groups)

•Program alarm groups (if required) for access control functions

In the four-door/four-lift programming menu:

•Select menu 2-Door / Lift options and select the door to program

•Move to menu Alarm control

•Enter the required Alarm group

•Select the required Alarm control

•Select if Entry or Exit denied if area armed

•Select the Authorised RAS on the system databus (if required)

Assign the alarm groups to users that should have alarm control.

Andere Handbücher für ATS125

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Interlogix Sicherheitssystem Handbücher

Interlogix

Interlogix ZeroWire Bedienungsanleitung

Interlogix

Interlogix Simon XT Bedienungsanleitung

Interlogix

Interlogix DC107 Series Montageanleitung

Interlogix

Interlogix Simon XTi-5 Version 2 Bedienungsanleitung

Interlogix

Interlogix ZeroWire Bedienungsanleitung

Interlogix

Interlogix AS620RF Montageanleitung

Interlogix

Interlogix Advent Bedienungsanleitung

Interlogix

Interlogix Simon XTi Bedienungsanleitung

Interlogix

Interlogix Learn Mode Water Resistant Pendant Panic... Bedienungsanleitung

Interlogix

Interlogix ACL800SUW-BSMF Bedienungsanleitung

Interlogix

Interlogix Simon 3 Bedienungsanleitung

Interlogix

Interlogix advisorone Benutzerhandbuch

Interlogix

Interlogix ITI Simon Bedienungsanleitung

Interlogix

Interlogix NX-595E Bedienungsanleitung

Interlogix

Interlogix Simon XTi-5 Version 2 Bedienungsanleitung

Interlogix

Interlogix ATSx500A Series Montageanleitung

Interlogix

Interlogix NX-595E Bedienungsanleitung

Interlogix

Interlogix Simon XT Bedienungsanleitung

Interlogix

Interlogix ATS111 A Series Montageanleitung

Interlogix

Interlogix ZeroWire Bedienungsanleitung

Interlogix

Interlogix advisorone Montageanleitung

Interlogix

Interlogix ZeroWire ZW-6400H Bedienungsanleitung

Interlogix

Interlogix ATS1235 Montageanleitung

Interlogix

Interlogix DC108 Series Montageanleitung

Beliebte Sicherheitssystem Handbücher anderer Marken

Inner Range

Inner Range Concept 2000 Bedienungsanleitung

Climax

Climax Mobile Lite R32 Montageanleitung

CADDX

CADDX NX-6 Bedienungsanleitung

FBII

FBII XL-31 Series Bedienungsanleitung

Johnson Controls

Johnson Controls PENN Connected PC10 Bedienungsanleitung

Aeotec

Aeotec Siren Gen5 Bedienungsanleitung

Blaupunkt

Blaupunkt SA 2700 Bedienungsanleitung

IDEAL

IDEAL Accenta Betriebsanleitung

AJAX

AJAX DoubleButton Bedienungsanleitung

Swann

Swann SW-P-MC2 Bedienungsanleitung

Ecolink

Ecolink Siren+Chime Bedienungsanleitung

Digital Monitoring Products

Digital Monitoring Products XR150 Bedienungsanleitung

EDM

EDM Solution 6+6 Wireless-AE Bedienungsanleitung

Highway Safety Group

Highway Safety Group EA401 Bedienungsanleitung

Siren

Siren LED GSM Bedienungsanleitung

Detection Systems

Detection Systems 7090i Montageanleitung

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung

Siemens

Siemens FDM273 Bedienungsanleitung
