Intermec 6820 Series Bedienungsanleitung

6820 Printer

Installation

Instructions

ii 6820 Printer Installation Instructions

Intermec Technologies Corporation

Worldwide Headquarters Cedar Rapids Technical Communications

6001 36th Ave.W. 550 Second Street SE

Everett, WA 98203 Cedar Rapids, IA 52401

U.S.A. U.S.A.

www.intermec.com

The information contained herein is provided solely for the purpose of allowing customers to operate and ser-

vice Intermec-manufactured equipment and is not to be released, reproduced, or used for any other purpose

without written permission of Intermec Technologies Corporation.

Information and specifications contained in this document are subject to change without prior notice and do

not represent a commitment on the part of Intermec Technologies Corporation.

The word Intermec, the Intermec logo, Norand, ArciTech, Beverage Routebook, CrossBar, dcBrowser, Durath-

erm, EasyADC, EasyCoder, EasySet, Fingerprint, i-gistics, INCA (under license), Intellitag, Intellitag Gen2,

JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower, Sabre, ScanPlus, ShopScan, Smart

Mobile Computing, TE 2000, Trakker Antares, and Vista Powered are either trademarks or registered trade-

marks of Intermec Technologies Corporation.

There are U.S. and foreign patents as well as U.S. and foreign patent applications pending.

Document Change Record

This page records changes to this document. The document was originally released as Revision A.

Revision

Letter Date Description of Change

B 08/2005 Updated Customer Support information.

C06/2006 Updated to include RoHS part numbers.

D 07/2006 Enhanced to include additional part numbers.

Contents

6820 Printer Installation Instructions iii

Contents

Global Services and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

Web Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

Telephone Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv

Installation Kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Installation Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Tools Required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Vehicle Electrical System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Power Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Direct-to-Battery Cable Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Route the Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Prepare the Vehicle Battery Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connect to the Vehicle Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Secure the Vehicle Battery Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Ground the Printer Power Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Printer Power Cable Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Mechanical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Fixed Mount Printer 709-850-006 Mounting Plate (Optional) . . . . . . . . . . . . . . . 8

Wall Mount Printer Kits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

With Flat Paper Tray - 203-486-002. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

With Compact Paper Tray - 203-489-001 . . . . . . . . . . . . . . . . . . . . . . . 10

Dimensions with Flat Paper Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Dimensions with Compact Paper Tray . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Install the 714-417-001 Mounting Plate . . . . . . . . . . . . . . . . . . . . . . . . . 12

Attach Either Paper Tray to 714-417-001 Mounting Plate . . . . . . . . . . . 12

Mount the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Global Services and Support

6820 Printer Installation Instructions iv

Global Services and Support

Warranty Information

To understand the warranty for your Intermec product, visit the Intermec

web site at www.intermec.com and click Service & Support. The Inter-

mec Global Sales & Service page appears. From the Service & Support

menu, move your pointer over Support, and then click Warranty.

Disclaimer of warranties: The sample code included in this document is

presented for reference only. The code does not necessarily represent com-

plete, tested programs. The code is provided “as is with all faults.” All war-

ranties are expressly disclaimed, including the implied warranties of

merchantability and fitness for a particular purpose.

Web Support

Visit the Intermec web site at www.intermec.com to download our current

documents (in PDF). To order printed versions of the Intermec manuals,

contact your local Intermec representative or distributor.

Visit the Intermec technical knowledge base (Knowledge Central) at inter-

mec.custhelp.com to review technical information or to request technical

support for your Intermec product.

Telephone Support

These are available from Intermec Technologies Corporation. Outside the

U.S.A. and Canada, contact your local Intermec representative. To search

for your local representative, from the Intermec web site, click Contact.

Service Description

In the U.S.A. and Canada, call

1-800-755-5505 and choose

this option

Order Intermec products • Place an order.

• Ask about an existing order.

1 and then choose 2

Order Intermec media Order printer labels and ribbons. 1 and then choose 1

Order spare parts Order spare parts 1 or 2 and then choose 4

Technical Support Talk to technical support about your

Intermec product.

2 and then choose 2

Service • Get a return authorization number for

authorized service center repair.

• Request an on-site repair technician.

2 and then choose 1

Service contracts • Ask about an existing contract.

• Renew a contract.

• Inquire about repair billing or other ser-

vice invoicing questions.

1 or 2 and then choose 3

6820 Printer Installation Instructions 1

The 6820 Printer and associated electrical wiring should be installed under

the supervision of properly trained and qualified personnel. Follow these

installation instructions to ensure safe, reliable performance of the 6820

Printer.

Installation Kit

When the installation is complete, you will have a secure place to store the

printer and hand-held or mobile computer. The vehicle electrical system

provides power to operate the printer and vehicle dock; and to charge the

printer internal battery.

In this installation, the power cable is wired directly to the vehicle battery.

This reduces installation problems and uses the vehicle battery filtering.

The installation kits contain nuts, bolts, washers, a terminal ring, and a fuse

link (on direct to battery installations) for connecting the battery cable

directly to the vehicle battery. These kits also contain adjustable wire clamps

to secure the cable in place.

Installation Procedures

This section leads you through these three installation steps:

1Electrical installation (battery cable).

2Mechanical installation (printer).

3Final assembly and cable connection.

Tools Required

You should have a wire crimping and stripping tool, an electric drill with 3/

16” and 9/16” drill bits, and common hand tools.

Note: These instruction are required to install the following kit numbers:

203-242-101 (Fixed Mount and Wall Mount Printers)

203-242-102 (Portable Printers)

2 6820 Printer Installation Instructions

Vehicle Electrical System

The vehicle electrical system must be in good condition for all types of

installations. The charging circuit must work properly and vehicle-gener-

ated electrical “noise” must be minimized. Do the following to determine

your vehicle’s voltage level:

1Measure the vehicle battery voltage with a voltmeter. It should read

approximately 13.0 V dc with the engine OFF.

2Start the vehicle engine. Continue monitoring the battery’s voltage while

you run the engine at a fast idle for five minutes. The voltage should read

below 14.5 V dc. It must not exceed 18.0 V.

Excess electrical noise can be severe enough to defeat the electrical filtering

that is built into Intermec® cables, printers, and vehicle docks. Defective

ignition wiring, damaged insulation, or a faulty vehicle electrical compo-

nent can cause electrical noise — possibly causing unpredictable behavior

in printers and docks.

Electrical Installation

Decide where to mount the 6820 Printer and vehicle dock, then follow

these instructions.

Power Cable Routing

•Cable Length:

A shorter printer dc power cable connects the printer to the vehicle bat-

tery cable, extending the overall cable length.

•“Y” Power Cable:

A special “Y” (power) cable and a remote data communications cable are

required when using vehicle docks with 61XX, 63XX, or 66XX Comput-

ers. The “Y” cable limits the separation of the dock and printer to 8.0 ft

(2.4 m). However, using separate power cables for the dock and printer

do locate the printer and the vehicle dock up to 30 ft (9.1 m) apart.

Note: If the vehicle voltage is too high or too low, the printer may not

work.

Note: If the battery voltage exceeds 18.0 V dc, there is a problem with the

vehicle electrical system which must be diagnosted and repaired before the

printer and vehicle dock will work properly. Check your engine for a bad

voltage regulator or a poor ground, either of which cause excessive voltage.

6820 Printer Installation Instructions 3

Direct-to-Battery Cable Installation

We recommend you connect printers directly to the battery based on the

following criteria:

• The vehicle battery acts as an electrical filter and regulator.

• If there is any damage to the printer dc power cable, the cable is easily

replaced.

Route the Cables

Use the following guidelines when routing the printer dc power cable and

the vehicle battery cable:

• Route the vehicle battery cable from the area where the printer is to be

mounted toward the vehicle battery.

• When possible, route the printer power cable along with existing vehicle

wiring. Use cable ties to join the cable and wiring together.

• Use a snap-in bushing (requires 9/16” hole) if the vehicle battery cable

passes through the firewall or other sheet-metal.

• Make sure that cable routing does not interfere with other equipment or

vehicle controls.

• Ensure that cable routing does not invite damage to the cable.

• Secure the vehicle battery cable at least every 18” (50 cm) throughout the

cable run: use adjustable clamps (provided) or wire-tie to existing vehicle

cable runs.

• Completely install the printer power cable and take voltage measure-

ments before connecting the printer.

DC power cable (4 ft or 1.2 m - goes to printer)

P/N: 226-215-101

Vehicle battery cable

P/N: 206-875-00X

part of Install Kit

P/N: 203-242-001

Ground strap

4 6820 Printer Installation Instructions

Prepare the Vehicle Battery Cable

After you route the vehicle battery cable to the vehicle battery, do the fol-

lowing to prepare the vehicle battery cable for the terminal ring and fuse

link assembly.

Strip the Vehicle Battery Cable Jacket

Strip the gray vehicle battery cable jacket and insulation:

1Cut the gray battery cable near the battery to avoid coiling or tying

excess cable.

2Strip the battery cable jacket (gray) back 12-14” (31-36 cm).

3Strip 1/4” (6 mm) of insulation from the black (or brown) and red wires.

Crimp the Cable Ends

Do the following to attach a terminal ring and a preassembled in-line fuse

link to the vehicle battery cable.

1Strip the black wire.

2Crimp the 3/8” terminal ring (P/N: 809-165-001) onto the black wire.

3Attach the fuse link assembly (P/N: 315-071-002) to the red wire (if

needed, shorten red wire), strip 1/4” (6 mm) of insulation off the red wire.

4Crimp the red wire onto the fuse link.

Note: You may have to shorten and restrip the red wire when attaching the

fuse link assembly.

Gray battery cable

P/N: 226-271-101 Red wire

Black (or brown) wire

Strip each wire end

1/4” (6 mm)

Strip the cable jacket 12” to 14” (31-36 cm)

Strip the wire, then install the terminal ring

Fuse link

Crimp here

3/8” terminal ring

Black (or brown) wire

Vehicle battery cable

Red wire Fuse link assembly

P/N: 236-107-001

6820 Printer Installation Instructions 5

Connect to the Vehicle Battery

Your vehicle has either a top-mount battery with the terminals on the top;

or a side-mount battery with terminals on the side. Determine which bat-

tery is in your vehicle and proceed with applicable instructions:

Connect to a Side-Mount Vehicle Battery

Do the following to attach the vehicle battery cable to a side-mount battery

terminal as shown in the following illustration:

1First, disconnect the negative battery cable, then disconnect the positive

battery cable, and remove the bolts from each cable.

2Screw a 3/8” nut as far as it will go onto a 3/8” x 1-1/2” bolt furnished in

kit, then slip a 3/8” washer onto the bolt.

3Slide the positive (red wire with fuse link) terminal ring from the printer

power cable onto the bolt.

4Slip a second 3/8” washer, then slip the vehicle positive battery cable onto

the bolt.

5Thread bolt assembly (steps 2-4) into the positive (+) battery terminal.

6Securely tighten the bolt, then the nut installed in step 2 to secure wash-

ers and cables into place.

7Repeat steps 2-6 for the negative vehicle battery cable wire (black or

brown), hooking up the negative cable to the negative battery terminal.

3/8” nut

3/8 x 1-1/2” bolt

Vehicle battery

Vehicle battery cable

Fuse holder

3/8” washers

6 6820 Printer Installation Instructions

Connect to a Top-Mount Vehicle Battery

Do the following to attach the vehicle battery cable to a top-mount battery

terminal as shown in the following illustration:

1First, disconnect the negative battery cable, then disconnect the positive

battery cable.

2Remove the bolts from the battery cable and replace these bolts with

3/8” x 1-1/2” bolts and nuts furnished in the installation kit.

3Reinstall the positive battery cable, then tighten the nut securely.

4Slip a 3/8” washer onto the extended end of each bolt.

5Slide the positive (fuse link with red wire) terminal ring from the printer

power cable onto the positive (+) battery bolt.

6Slip a second 3/8” washer onto the bolt, then thread and tighten a sec-

ond 3/8” nut onto that bolt.

7Repeat steps 5 and 6 for the negative battery cable wire (black or brown),

connecting the wire to the negative battery terminal.

Secure the Vehicle Battery Cable

1Secure the vehicle battery cable every 18” (50 cm) with adjustable cable

clamps. Work from the battery to the mounting area for the printer.

2Remove the paper backing from a clamp (P/N: 807-059-001) and stick

the clamp in place while drilling a pilot hole with a #26 drill bit. Use #6

sheet-metal screws to permanently hold clamps in place.

3/8” x 1 1/2” bolt

3/8” nut

Vehicle battery

Vehicle battery cable

Fuse holder

Washers

#6 sheet-metal screw goes here

Andere Handbücher für 6820 Series

Inhaltsverzeichnis

Andere Intermec Drucker Handbücher

Intermec

Intermec PB2 Series Bedienungsanleitung

Intermec

Intermec EasyCoder 301 Bedienungsanleitung

Intermec

Intermec PR2 Bedienungsanleitung

Intermec

Intermec PB42 Bedienungsanleitung

Intermec

Intermec 4820F Bedienungsanleitung

Intermec

Intermec 4630 Bedienungsanleitung

Intermec

Intermec ColorCoder 901 Bedienungsanleitung

Intermec

Intermec EasyCoder PX4i Leitfaden

Intermec

Intermec EasyCoder PX6i Bedienungsanleitung

Intermec

Intermec EasyCoder PF8 Bedienungsanleitung

Intermec

Intermec PB3 Series Bedienungsanleitung

Intermec

Intermec EasyCoder 501S Betriebsanleitung

Intermec

Intermec EasyCoder PF8 Bedienungsanleitung

Intermec

Intermec EasyCoder 3400e Bedienungsanleitung

Intermec

Intermec 3240 Bedienungsanleitung

Intermec

Intermec EasyCoder PF4i Bedienungsanleitung

Intermec

Intermec EasyCoder PX4i Bedienungsanleitung

Intermec

Intermec PR2 Bedienungsanleitung

Intermec

Intermec PF8D Bedienungsanleitung

Intermec

Intermec EasyCoder 4420 Bedienungsanleitung

Intermec

Intermec PB2 Series Bedienungsanleitung

Intermec

Intermec EasyCoder 4420 Bedienungsanleitung

Intermec

Intermec EasyCoder 401 Stücklistenhandbuch

Intermec

Intermec PF8D Bedienungsanleitung

Beliebte Drucker Handbücher anderer Marken

Lexmark

Lexmark 1400 Series Handbuch

Canon

Canon i70 Series Bedienungsanleitung

Evolis

Evolis Elypso Bedienungsanleitung

Kyocera

Kyocera FS-9530DN Bedienungsanleitung

Canon

Canon LASER SHOT LBP-1210 Bedienungsanleitung

Samsung

Samsung BIXOLON SRP-350plusF Bedienungsanleitung

Canon

Canon PIXMA PRO-1 Series Bedienungsanleitung

Canon

Canon PIXMA G3560 Einrichtungshandbuch

Dell

Dell Color Laser Printer 2130cn Bedienungsanleitung

Tektronix

Tektronix Phaser 840 Bedienungsanleitung

Epson

Epson ET-7750 Betriebsanleitung

Canon

Canon CLBR 460ps Bedienungsanleitung

Eltron

Eltron P210 Guide Bedienungsanleitung

Ricoh

Ricoh MD-P1 Bedienungsanleitung

Epson

Epson SC-F7100 series Bedienungsanleitung

Epson

Epson Stylus C40UX Bedienungsanleitung

Canon

Canon imagePASS-A2 Bedienungsanleitung

Canon

Canon S820D Bedienungsanleitung
