9
Installaon Instrucons
This secon will provide a quick instrucon to install the PDU.
A) Elevated Operang Ambient - If installed in a closed or
mul-unit rack assembly, the operang ambient temperature
of the rack environment may be greater than room ambient.
Therefore, consideraon should be given to installing the
equipment in an environment compable with the maximum
ambient temperature specified by the manufacturer.
B) Reduced Air Flow - Installaon of the equipment in a rack
should be such that the amount of air flow required for safe
operaon of the equipment is not compromised.
C) Mechanical Loading - Mounng of the equipment in the
rack should be such that a hazardous condion is not
achieved due to uneven mechanical loading.
D) Circuit Overloading - Consideraon should be given to the
connecon of the equipment to the supply circuit and the
effect that overloading of the circuits might have on over
current protecon and supply wiring. Appropriate
consideraon of equipment nameplate rangs should be
used when addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted
equipment should be maintained. Parcular aenon should
be given to supply connecons other than direct connecons
to the branch circuit (e.g. use of power strips)."
Diagram
