Invacare®Formula™PTO Plus (PowerTilt Only)

for Pronto®M71™

,M91

™and Storm Series®TDX™

Invacare®

Formula™PTO

Plus for Pronto®

M71™

,M91

™&Storm

Series®TDX™

Invacare®Formula™PTO Plus (PowerTilt Only)

for Pronto®M71™

,M91

™and Storm Series®TDX™

The Invacare®Formula™PTO Plus (PowerTilt Only) is designed for active consumers who

require a basic tilt for positioning and pressure relief. The PTO Plus is available on the Pronto®

M71™and M91™and the Storm Series®TDX™,while still maintaining sleek style,indoor and out-

door maneuverability and a tight turning radius. With the new and improved features of the PTO Plus

on the M71,M91 andTDX consumers are offered the powered tilt they need on the bases they want.

Invacare®Formula™ PTO Plus for Storm Series®TDX™

FEATURES:

•18" Seat to floor height for easy access to everyday environments

•Weight capacity of 275 lb.or optional 375 lb.when combined with heavy-duty

motor options

•Up to 55˚ of tilt for pressure relief (0˚–55˚,5˚–60˚)

•Weight ShiftingTechnology

•MK5™Electronics

•Up to 7.5 mph

•SureStep™for smooth driving over transitions up to 3 inches in height

•Stability Lock for added stability and control

Invacare®Formula™PTO Plus (PowerTilt Only)

for Pronto®M71™

,M91

™and Storm Series®TDX™

Invacare®Formula™PTO Plus for

Pronto®M91™with SureStep™

FEATURES:

•18" Seat to floor height for easy access to everyday

environments

•Weight capacity of 275 lb.or optional 375 lb.with heavy-duty

motor package

•Up to 55˚ of tilt for pressure relief (0˚–55˚,5˚–60˚)

•Weight ShiftingTechnology

•MK5™NX™-80 Electronics

•Up to 6.5 mph

•SureStep for smooth driving to overcome transitions

3" in height

Invacare Formula PTO Plus for Pronto®

M71™with SureStep

FEATURES:

•18" Seat to floor height for easy access to everyday

environments

•Weight capacity of 275 lb.

•Up to 55˚ of tilt for pressure relief (0˚–55˚,5˚–60˚)

•Weight ShiftingTechnology

•MK5NX-80 Electronics

•Up to 4.25 mph

•SureStep for smooth driving to overcome transitions

2" in height

BatteryAccess

The PTO Plus integrates into the base of the chairs while still

maintaining easy battery access through a simple flip back design

Invacare Corporation

www.invacare.com

USA

One InvacareWay

Elyria,Ohio

44036-2125

(800) 333-6900

Canada

Invacare Canada Inc.

570 Matheson Blvd E

Unit 8

Mississauga Ontario

L4Z 4G4 Canada

Invacare,the blue

medallion design,Pronto

and Storm Series are

registered trademarks

and Yes,you can.,

Formula,M71, M91,TDX,

MK5,SureStep,NX and

GB are trademarks of

Invacare Corporation.

Specifications

are subject to

change without

notification.

Invacare Corporation

Form No. 04-093

‘‘Invacare says‘Yes, you can™,’

and I couldn’t have said it

better myself.’’

Invacare®Formula™PTO Plus (PowerTilt Only)

for Pronto®M71™

,M91

™and Storm Series®TDX™

Specifications

M91™M71™TDX™

Tilt Range 0˚ – 55˚ 0˚ – 55˚ 0˚ – 55˚

5˚ – 60˚ 5˚ – 60˚ 5˚ – 60˚

Seat-to-floor height* 18" 18" 18"

*At 0˚ of tilt

Overall dimensions

Length 39" 34" 35"

Width (excluding joystick) 26" 24" 25"

Height* 39" 33.5" 42"

* Height measured without headrests and with a 20" back on the Pronto M71 and M91 and a 24" back onTDX

PTO Plus Seat dimensions

Widths 16" – 22" 16" – 20" 16" – 22"

Depths 16" – 22" 16" – 20" 16" – 22"

Back Height 16" – 24" 16" – 24" 16" – 24"

Weight

With Batteries 296 lb. 231 lb. 361 lb*

* ProductWeight onTDX was measured on aTDX5 with Gearless Brushless GB motors and Group 24 batteries

Wheel and Caster Sizes

Front Casters 6" x 2" 6" x 2" 6" x 2"

DriveWheels 14" x 3" 10.5" x 3.5" 12" x 2.5"*

14" x 3"

Rear Casters 6" x 2" 6" x 2" 6" x 2"

* OnTDX standard wheel size dependent on base pick

Maximum Speed 6.5 mph 4.25 mph 6 - 7.5 mph*

* Speed onTDX dependent on base pick

Incline Capability 9˚ 9˚ 9˚

Weight Capacity 275 lb. 275 lb. 275 lb.

375 lb. 375 lb.

*Weight capacity dependent on motor package

Turning Radius

Center Mount 19" 19" 22"

LimitedWarranties

Base Frame 60 months 60 months 60 months

Seat Frame 36 months 36 months 36 months

Electronics/Actuator 12 months 12 months 12 months

**Due to manufacturing variances, all dimensions,weights,and degrees may be ±.5", ±10%,or ± 3˚
