Invacare® Harrier XHDTM

User Guide

Contents Page

Warranty Terms & Conditions…………………………………………………….. 6

Standard INVACARE Terms…………………………………………………………………… 6

Limitation of liability……………………………………………………………………………… 7

1 Useful Symbols In This Manual…………………………………………………….. 5

2 Introduction…………………………………………………………………………… 8

2.1 Intended Use…………………………………………………………………………………. 9

2.2 Type Classification…………………………………………………………………………… 10

3 Safety Notes……………………………………………………………………………

3.1 Repair or Service Information………………………………………………………………... 11

3.2 General Safety notes…………………………………………………………………………. 12

3.3 Safety Information On Electromagnetic Interference………………………………………... 14

3.4 Safety Precautions/Safe Operation…………………………………………………………... 15

4 Some Useful Tips……………………………………………………………………... 18

5 Safety Inspection Checklist…………………………………………………………. 23

6 Trouble Shooting……………………………………………………………………... 26

6.1 Trouble Shooting – Mechanical………………………………………………………………. 26

6.2 Trouble Shooting – Electrical………………………………………………………………… 27

6.3 Checking Battery Charge Level……………………………………………………………… 29

6.4 Care And Maintenance………………………………………………………………………. 30

6.5 Product End of Life…………………………………………………………………………... 30

7 Adjustment…………………………………………………………………………….. 31

7.1 Seat Depth & Backrest Angle Adjustment (Manual)……………………………………… 31

7.2 Tension Adjustable Back Upholstery (where fitted)…...…………………………………….. 33

7.3 Tray Assembly………………………………………………………………………………... 34

7.4 Installing Or Adjusting Lateral Supports (where fitted)……………………………………... 35

7.5 Lap Belt Adjustment…………………………………………………………………………. 36

7.6 Armrest Adjustment…………………………………………………………………………. 38

7.7 Installing/Removing Or Adjusting Headrest (where fitted)………………………………….. 40

7.8 Seating………………………………………………………………………………………... 41

7.9 Installing/Removing Seat/Back Cushion (where fitted)………………………………………. 41

7.10 Installing/Removing Seat Board……………………………………………………………... 42

7.11 Kerb Climber………………………………………………………………………………... 43

7.12 Leg Rests……………………………………………………………………………………. 44

7.13 Amputee Supports…………………………………………………………………………... 45

7.14 Anti Tippers………………………………………………………………………………… 46

8 Batteries………………………………………………………………………………... 47

8.1 Removing/Installing…………………………………………………………………………… 47

8.2 Battery Transportation Strap………………………………………………………………… 50

8.3 Disconnecting Battery Cables………………………………………………………………... 51

8.4 Connecting Battery Cables…………………………………………………………………... 53

8.5 Batteries And Charging………………………………………………………………………. 54

8.6 Disposing & Recycling Of Used Batteries…………………………………………………. 57

9 Motor Locks, Wheels & Brakes…………………………………………………….. 58

9.1 Disengaging/Engaging Motor Lock Levers…………………………………………………… 58

9.2 Drive Wheels………………………………………………………………………………… 59

9.3 Manual Parking Brakes………………………………………………………………………... 60

10 Transportation………………………………………………………………………… 61

10.1Disassembly and folding……………………………………………………………………... 63

11 Controls Systems……………………………………………………………………... 66

11.1 Types Of User Control …………………………………………………………………….. 66

11.2 Joystick Mounting Hardware………………………………………………………………... 67

12 Transfers………………………………………………………………………………... 68

13 Keeping Your Chair In Good Condition…………………………………………... 70

14 Fault Finding……………………………………………………………………………

15 Waste Electrical & Electronic Equipment (WEEE) Directive 2002/96/EC... 73

16 ISO 7176 Part 15 Requirements……………………………………………………. 74

Contacting INVACARE…………………………………………………………….. 76

1Useful Symbols In This Manual

WARNING!

This symbol warns you of danger! Always follow the instructions to avoid injury to the user or damage to the

product!

EXPLOSION HAZARD!

This symbol warns you of an explosion hazard, an example of which can be caused by excessive tyre pressure

in a pneumatic tyre!

•Always follow the instructions to avoid injury to the user or damage to the product.

BURN HAZARD!

This symbol warns you of burns due, for example, to leaking battery acid.

•Always follow the instructions to avoid injury to the user or damage to the product.

NOTE:

This symbol identifies general information which is intended to simplify working with your product and which

refers to special functions.

REQUIREMENTS:

This symbol identifies a list of various tools, components and items which you will need in order to carry out

certain work.

TRANSPORTATION:

This symbol identifies important information relevant to transporting your powered wheelchair in a motor

vehicle.

Warranty Terms & Conditions

Standard INVACARE Terms

This is to certify that your powered wheelchair is warranted by INVACARE Ltd. for a period of 2 years for

parts, 3 years for frames and 12 months for batteries.

1. Only INVACARE chairs purchase at full price are warranted against defective workmanship and materials.

2. If a defect or fault is discovered the INVACARE dealer from whom the appliance was obtained should be

notified immediately.

3. The manufacturer will not accept responsibility for damage caused by misuse or non-observance of the

instructions set out in the user manual.

4. During the period of the warranty any parts that have become defective, due to faulty workmanship or

materials, will be renewed or repaired without charge by the INVACARE dealer.

5. The warranty will be forfeited should any unauthorized alteration be made to the equipment.

6. The purchaser’s statutory rights under the Consumer Protection Act are not affected.

Limitation Of Liability

This warranty does not extend the consequential costs from fault clearance, in particular freight and travel

costs, loss of earnings, expenses, etc.

•Natural wear and tear

•Inappropriate or incorrect use

•Defective assembly or setting-up by the purchaser or third parties

•Defective or neglectful treatment

•Use of unsuitable spares

2 Introduction

Dear Customer,

First of all we wish to thank you for your confidence in our products. We hope you will enjoy your new

Harrier XHDTM powered wheelchair.

This manual contains important information and hints on:

•Safety

•Operation

•Care and maintenance

The information contained in this document is subject to change without notice.

As a manufacturer of wheelchairs, INVACARE endeavours to supply a wide variety of wheelchairs to meet

many needs of the customer. However, final selection of the type of wheelchair to be used by an individual

rests solely with the user and his/her healthcare professional capable of making such a selection.

Do not operate this equipment without first reading and understanding this manual. If you are unable to

understand the warnings, cautions, and instructions, contact your dealer otherwise injury or damage may

result.

The initial set up of this wheelchair must be performed by an experienced technician.

Procedures other than those described in this manual must be performed by an experienced technician.

Note:

Not all of the components within this manual will necessarily be available with your powered wheelchair. Any

references not applicable to your product should be ignored.

2.1 Intended Use

Indoor and outdoor configurable wheelchair offered with various options compliant with EN12184:2009

section 5 class B.

The Harrier XHDTM powered wheelchair has been designed to provide mobility and comfort for persons with

impaired mobility.

The wheelchair has been designed to be used either/or by a seated user/carer/attendant in both indoor and

outdoor environments.

The wheelchair has, in its standard format, been designed to accommodate users who have all limbs intact and

have sufficient upper body strength to maintain a safe position within the wheelchair without the addition of

supporting aids.

Adaptations from the standard wheelchair format are available to accommodate users who do not meet these

criteria, these will only be considered after a suitable risk assessment has been carried out by the product

prescriber. When prescribing wheelchairs for use by full or partial amputees (above or below knee, single or

double) it is important to recognise that lower limb amputation will affect the sitting centre of balance of the

wheelchair. The impossibility of generalising the individual ability of a wheelchair user means it is imperative

that the product prescriber carries out a full stability evaluation to ensure that the user is safe in the use of

the wheelchair and the risk of the wheelchair tipping is minimised.

The wheelchair should only be used in accordance with the safety advice given within this user guide. Failure to

follow the recommended advice within this user guide could lead to personal injury.

2.2 Type Classification

Your powered wheelchair is a Class B (EN12184) and Class 2 (Road Traffic Act) available with a maximum

speed of 4mph for use only on pavements, footpaths, pedestrian zones and areas free from motor traffic. It is

not allowed on the highway except for the purpose of crossing. Under no circumstance must the top speed of

the Powered wheelchair be increased, to do so will infringe the ‘The Use of Invalid Carriages on Highways

Regulations 1988, Statutory Instrument 1988 No. 2268’

WARNING!

WEIGHT LIMITATION – Your powered wheelchair has a maximum user weight limit of 160kg/25stone.
