INVENTOR V4MFI-24 Bedienungsanleitung

• USER’S MANUAL

• ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ

• MANUAL UTILIZATORULUI

MODELS:

REMOTE CONTROLLERREMOTE CONTROLLER

V4MFI-24/ V4MFO-24 | V1MFI-50B/ V1MFO-50B

V1MFI-66B/ V1MFO-66B

V4MCRI-12/U4MRS-12 | V4MCRI-18/U4MRS-18

V4MCI-24UR/U4MRS-24 | V4MCI-36UR/U4MRS-36

V4MCI-42/U4MRT-42 | V4MCI-50UR/U4MRT-50

V4MCI-60UR/U4MRT-60

V4MKI-18/U4MRS-18 | V4MKI-24UR/U4MRS-24

V4MKI-36UR/U4MRS-36 | V4MKI-42/U4MRT-42

V4MKI-50/U4MRT-50 | V4MKI-60/U4MRT-60

V4MLI-12/V4MLO-12 | V4MLI-18/V4MLO-18

CONTENTS

Model

Rated Voltage

3.0V(Dry batteries R03/LR03 2)

RG57B2/BGE

Remote Controller Specifications

Environment

Signal Receiving

Range

-5 C 60C

MODE

FAN

TEMP

SLEEP

TURBO LED

ON/OFF

SHORT

CUT

TIMER

OFF

NOTE:

Buttons design isbased on typicalmodel and mightbe slightly different from the

actual one youpurchased the actual shapeshall prevail.

All the functionsdescribed are accomplishedby the unit.If the unithas no this

feature, there isno corresponding operationhappened when pressthe relative

button on theremote controller.

When there arewide differences between Remote controllerIllustration and

USER'S MANUAL on function description,the description of USER'S MANUAL

shall prevail.

,,,,

Handling the remote controller ......................................................

Remote controller Specifications...................................................

Operation buttons .................. .........................................................

Indicators on LCD ..........................................................................

How to use the buttons .................................................................

Auto operation.................................................................................

Cooling/Heating/Fan operation......................................................

Dehumidifying operation ...............................................................

Adjusting air flow direction............................................................

Timer operation...............................................................................

3344

MODE

FAN

TEMP

ON/OFF

SHORT

CUT

SHORT

CUT

TIMER

OFF

TIMER

OFF

Press this button to modify the air conditioner

mode in a sequence of following:

MODE Button

ON/OFF Button

This button turns the air conditioner ON

and OFF.

AUTO

COOL

DRY

HEAT FAN

Used to select the fan speed in four steps:

AUTO LOW MED HIGH

FAN Button

SLEEP Button

NOTE: While the unit is running under SLEEP

mode, it would be cancelled if MODE, FAN

SPEED or ON/OFF button is pressed.

Active/Disable sleep function. It can

maintain the most comfortable temperature

and save energy. This function is available

on COOL, HEAT or AUTO mode only .

For the detail, see sleep operation in

USER S MANUAL.

,, ,,

NOTE Please do notselect HEATmode if the

machine you purchasedis cooling onlytype.

Heat mode isnot supported bythe cooling only

appliance.

NOTE: You can not switch the fan speed in

AUTO or DRY mode.

Operation of buttons

SHORTCUT Button

TIMER ON Button

TIMER OFF Button

Used to restore the current settings or

resume previous settings.

On the first time connecting to the power,

if push the SHORTCUT button, the unit

will operate on AUTO mode, 26 C, and fan

speed is Auto.

Push this button when remote controller is

on, the system will automatically revert

back to the previous settings including

operating mode, setting temperature, fan

speed level and sleep feature(if activated).

If pushing more than 2 seconds, the system

will automatically restore the current

operation settings including operating mode,

setting temperature, fan speed level and

sleep feature(if activated ).

UP Button( )

Push this button to decrease the indoor

temperature setting in 1 C increments to 17 C.

DOWN Button( )

Press this button to initiate the auto-on

time sequence. Each press will increase

the auto-timed setting in 30 minutes

increments. When the setting time displays

10.0, each press will increase the auto-

timed setting 60 minutes increments.

To cancel the auto-timed program, simply

adjust the auto-on time to 0.0.

Press this button to initiate the auto-off time

sequence. Each press will increase the auto

-timed setting in 30 minutes increments.

When the setting time displays 10.0, each

press will increase the auto-timed setting

60 minutes increments. To cancel the auto-

timed program, simply adjust the auto-off

time to 0.0

Push this button to increase the indoor

temperature setting in 1 C increments to 30 C.

Operation of buttons

NOTE Temperaturecontol is notavailable

in Fan mode.

TURBO Button

Active/Disable Turbo function. Turbo function

enables the unit to reach the preset temper-

ature at cooling or heating operation in the

shortest time(if the indoor unit does not

support this function, there is no

corresponding operation happened when

pressing this button.)

SLEEP

TURBO

LED

Operation of buttons

Swing Button

Used to stop or start horizontal louver move-

ment or set the desired up/down air flow

direction. The louver changes 6 degree in

angle for each press. If keep pushing more

than 2 seconds, the louver will swing up and

down automatically.

Used to stop or start vertical louver movement

and set the desired left/right air flow direction.

The vertical louver changes 6 degree in angle

for each press. And the temperature display

area of indoor unit displays for one

second. If keep pushing more than 2 seconds,

the vertical louver swing feature is activated.

And the display area of indoor unit displays

, flashes four times, then the tempera-

IIII

ture setting reverts back. If the vertical louver

swing feature is stopped, it displays LC and

remains on for 3 seconds.

NOTE: For some units , the indoor units

display when the swing feature is

activated, and display when the

swing feature is stopped.

LED Button

Disable/Active indoor screen Display. When

pushing the button, the indoor screen display

is cleared, press it again to light the display.

Indicators on LCD

Fan speed indication

Mode display

Information are displayed when

the remote controller is powered

up.

Displayed when data transmitted.

Displayed when remote controller is ON.

Battery display(low battery detection)

Not available for this unit

Low speed

Medium speed

High speed

Auto fan speed

Note:

All indicators shown in the figure are for the purpose

of clear presentation. But during the actual operation

only the relative functional signs are shown on the

display window.

Displayed when TIMER ON time is set.

Displayed in Sleep Mode operation.

Not available for this unit

Displayed when TIMER OFF time is set.

Show set temperature or room

temperature, or time under TIMER

setting.

AUTO

HEAT FAN

COOL DRY

5566

MODE

FAN

TEMP

ON/OFF

SHORT

CUT

TIMER

OFF

SLEEP

TURBO LED

How to use the buttons

Cooling /Heating/Fan operation

Ensure the unitis plugged inand power is

available.

1. Press theMODE button to selectCOOL,

HEAT(cooling & heating modelsonly) or

FAN mode.

2. Press theUP/DOWN buttons to setthe

desired temperature.

3. Press theFAN button to selectthe fan speed

in four steps-Auto, Low, Med,or High.

4. Press theON/OFF button to startthe air

conditioner.

The temperature can

OOO

be set withina range of17 C~ 30 C in 1 C

increments.

In the FAN mode, the setting temperature is not

displayed in the remote controller and you are not

able to control the room temperature either. In this

case, only step 1, 3 and 4 may be performed.

NOTE

Auto operation

Ensure the unitis plugged inand power is

available. The OPERATION indicator on the

display panel ofthe indoor unitstarts flashing.

1. Press theMODE button to selectAuto.

2. Press theUP/DOWN button to set the

desired temperature. The temperature can

OOO

be set withina range of17 C~ 30 C in 1 C

increments.

3. Press theON/OFFbutton to startthe air

conditioner.

1. In the Auto mode, the air conditioner can logically

choose the mode of Cooling, Fan, and Heating

by sensing the difference between the actual

ambient room temperature and the setting

temperature on the remote controller.

2. In the Auto mode, you can not switch the fan speed.

It has already been automatically controlled.

3. If the Auto mode is not comfortable for you , the

desired mode can be selected manually.

NOTE

MODE

FAN

TEMP

ON/OFF

SHORT

CUT

TIMER

OFF

MODE

FAN

TEMP

ON/OFF

SHORT

CUT

TIMER

OFF

Dehumidifying operation

Ensure the unitis plugged inand power is

available. The OPERATION indicator on the

display panel ofthe indoor unitstarts flashing.

1. Press theMODE button to selectDRY mode.

2. Press theUP/DOWN buttons to setthe

desired temperature.

3. Press theON/OFF button to startthe air

conditioner.

The temperature

can be setwithin a rangeof 17 C~ 30 C

in 1 C increments.

In the Dehumidifying mode, you can not switch the

fan speed. It has already been automatically controlled.

NOTE

Adjusting air flow direction

Use the SWING & button to adjust

the desired airflow direction.

1. Up/Down direction can be adjusted with the

button on the remote controller. Each

time when you press the button, the louver

moves an angle of 6 degree. If pressing more

than 2 seconds ,the louver will swing up and

down automatically.

2. Left/Right direction can be adjusted with the

button on the remote controller. Each

time when you press the button, the louver

moves an angle of 6 degree. If pressing more

than 2 seconds ,the louver will swing up and

down automatically.

NOTE: When the louver swing or move to a

position which would affect the cooling

or heating effect of the air conditioner,

it would automatically change the

swing/moving direction.

MODE

FAN

TEMP

ON/OFF

SHORT

CUT

TIMER

OFF

How to use the buttons

7788

SLEEP SLEEP

SLEEP

TURBO TURBO

TURBO

LED LED

LED

Timer operation

Press the TIMER ON button can set the auto-on

time of the unit. Press the TIMER OFF button

can set the auto-off time of the unit.

1. Press the TIMER ON button. The remote

controller shows TIMER ON, the last Auto-on

setting time and the signal "H" will be shown on

the LCD display area. Now it is ready to reset

the Auto-on time to START the operation.

2. Push the TIMER ON button again to set desired

Auto-on time. Each time you press the button,

the time increases by half an hour between 0

and 10 hours and by one hour between 10 and

24 hours.

3. After setting the TIMER ON ,there will be a one

second delay before the remote controller

transmits the signal to the air conditioner. Then,

after approximately another 2 seconds, the

signal "h" will disappear and the set temperature

will re-appear on the LCD display window.

To set the Auto-on time.

To set the Auto-off time.

1. Press the TIMER OFF button. The remote

controller shows TIMER OFF, the last Auto-off

setting time and the signal "H" will be shown on

the LCD display area. Now it is ready to reset

the Auto-off time to stop the operation.

2. Push the TIMER OFF button again to set

desired Auto-off time. Each time you press the

button, the time increases by half an hour

between 0 and 10 hours and by one hour

between 10 and 24 hours.

3. After setting the TIMER OFF ,there will be a

one second delay before the remote controller

transmits the signal to the air conditioner. Then,

after approximately another 2 seconds, the

signal "H " will disappear and the set temperature

will re-appear on the LCD display window.

MODE

FAN

TEMP

ON/OFF

SHORT

CUT

TIMER

OFF

When you select the timer operation, the remote controller automatically transmits the

timer signal to the indoor unit for the specified time. Therefore, keep the remote

controller in a location where it can transmit the signal to the indoor unit properly.

The effective operation time set by the remote controller for the timer function

is limited to the following settings: 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0,

5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10, 11, 12, 13, 14, 15,16,17, 18, 19, 20,

21, 22, 23 and 24.

CAUTION

Example of timer setting

Start

Off

6 hours later

(Auto-on Operation)

The TIMER ON feature is useful when you want

the unit to turn on automatically before you return

home. The air conditioner will automatically start

operating at the set time.

To start the air conditioner in 6 hours.

1. Press the TIMER ON button, the last setting

of starting operation time and the signal "H"

will show on the display area.

2. Press the TIMER ON button to display "6.0H "

on the TIMER ON display of the remote

controller.

3. Wait for 3 seconds and the digital display

area will show the temperature again. The

"TIMER ON" indicator remains on and this

function is activated.

TIMER ON

Example:

Set

991010

SLEEP

TURBO LED

1111 1212

Stop

Set 10 hours later

(Auto-off Operation)

The TIMER OFF feature is useful when you want the

unit to turn off automatically after you go to bed. The

air conditioner will stop automatically at the set time.

To stop the air conditioner in 10 hours.

1. Press the TIMER OFF button, the last setting of

stopping operation time and the signal "H" will

show on the display area.

2. Press the TIMER OFF button to display "10H " on

the TIMER OFF display of the remote controller.

3. Wait for 3 seconds and the digital display area

will show the temperature again. The "TIMER

OFF" indicator remains on and this function is

activated.

TIMER OFF

Example:

Stop

2 hours later

after setting

Set

To stop the air conditioner 2 hours after setting and

start it again 10 hours after setting.

1. Press the TIMER OFF button.

2. Press the TIMER OFF button again to display

2.0H on the TIMER OFF display.

3. Press the TIMER ON button.

4. Press the TIMER ON button again to display 10H

on the TIMER ON display .

5. Wait for 3 seconds and the digital display area

will show the temperature again. The "TIMER

ON OFF" indicator remains on and this function is

activated.

TIMER OFF TIMER ON

(On Stop Start operation)

This feature is useful when you want to stop the air

conditioner after you go to bed, and start it again in

the morning when you wake up or when you return

home.

Example:

COMBINED TIMER

(Setting both ON and OFF timers simultaneously)

Start

10 hours later

after setting

Example:

TIMER ON TIMER OFF

(Off Start Stop operation)

This feature is useful when you want to start

the air conditioner before you wake up and

stop it after you leave the house.

To start the air conditioner 2 hours after setting,

and stop it 5 hours after setting.

1. Press the TIMER ON button.

2. Press the TIMER ON button again to display

2.0H on the TIMER ON display.

3. Press the TIMER OFF button.

4. Press the TIMER OFF button again to display

5.0H on the TIMER OFF display .

5. Wait for 3 seconds and the digital display area

will show the temperature again. The "TIMER

ON & TIMER OFF" indicator remains on and

this function is activated.

Off Stop

Start

2 hours later

after setting

5 hours later

after setting

Set

1111 1212

Use the remote controller within a distance of 8

meters from the appliance, pointing it towards the

receiver. Reception is confirmed by a beep.

The remote controller can be attached to a wall or pillar

by using a remote controller holder(not supplied,

purchased separately).

Before installing the remote controller, check that the

air conditioner receives the signals properly.

Install the remote controller with two screws.

For installing or removing the remote controller, move

it up or down in the holder.

The following cases signify exhausted batteries.

Replace old batteries with new ones.

Receiving beep is not emitted when a signal

is transmitted.

Indicator fades away.

Location of the remote controller.

Using the remote controller holder(optional)

The remote controller is powed by two dry

batteries (R03/LR03X2) housed in the back rear

part and protected by a cover.

(1) Remove the cover in the rear part of the

remote controller.

(2) Remove the old batteries and insert the new

batteries,placing the(+) and (-) ends correctly.

(3) Install the cover back on.

NOTE: When the batteries are removed, the

remote controller erases all programming. After

inserting new batteries, the remote controller

must be reprogrammed.

Replacing batteries

CAUTIONS

The air conditioner will not operate if curtains,

doors or other materials block the signals from

the remote controller to the indoor unit.

Prevent any liquid from falling into the remote

controller. Do not expose the remote controller

to direct sunlight or heat.

If the infrared signal receiver on the indoor unit

is exposed to direct sunlight, the air conditioner

may not function properly. Use curtains to

prevent the sunlight from falling on the receiver.

If other electrical appliances react to the remote

controller, either move these appliances or

consult your local dealer.

Do not drop the remote controller. Handle with care.

Do not place heavy objects on the remote controller,

or step on it.

CAUTIONS

Do not mix old and new batteries or batteries

of different types.

Do not leave the batteries in the remote

controller if they are not going to be used for

2 or 3 months.

Do not dispose batteries as unsorted

municipal waste. Collection of such waste

separately for special treatment is necessary.

Handling the remote controller

1313 1414

ΠΕΡΙΕΧΟΜΕΝΑ

Μοντέλο

Ονομαστική Τάση

Εύρος Θερμοκρασίας

περιβάλλοντος

3.0V (Μπαταρίες στεγνού τύπου R03/LR03 2)

RG57B2/BGE

Χαρακτηριστικά Ασύρματου Τηλεχειριστηρίου

Εμβέλεια Σήματος

Λήψης

-5C 60C

•

Σημείωση:

Ο σχεδιασμός των πλήκτρων μπορεί να διαφέρει ελαφρά από αυτό που

έχετε αγοράσει

Όλες οι λειτουργίες που περιγράφονται στο παρόν εγχειρίδιο

υποστηρίζονται από την μονάδα. Αν η μονάδα δεν υποστηρίζει κάποιο

χαρακτηριστικό, όταν πιέζετε το αντίστοιχο κουμπί στο τηλεχειριστήριο

δεν θα υπάρχει αντίστοιχη λειτουργία.

Οταν υπάρχουν ουσιαστικές διαφορές μεταξύ του παρόντος εγχειριδίου

και του εγχειριδιου χρήσης, υπερισχύει η ανάλυση των λειτουργιών τους

εγχειριδιου χρήσης της κλιματιστικής μονάδας.

Χαρακτηριστικά του Ασύρματου Τηλεχειριστηρίου ............................

Λειτουργίες Πλήκτρων .......................................................................

Ενδείξεις στην LCD Οθόνη ................................................................

Χρήση των πλήκτρων ........................................................................

Αυτόματη Λειτουργία .........................................................................

Λειτουργίες Ψύξης/Θέρμανσης/Ανεμιστήρα ......................................

Λειτουργία Αφύγρανσης ....................................................................

Προσαρμογή της κατεύθυνσης του αέρα...........................................

Λειτουργία Timer ...............................................................................

Χειρισμός του Ασύρματου Τηλεχειριστηρίου ....................................

SHORT

CUT

TIMER

OFF

AUTO

(Αυτόματο)

COOL

(Ψύξη)

DRY

(Αφύγρανση) HEAT

(Θέρμανση)

FAN

(Ανεμιστήρας)

AUTO LOW MED HIGH

Πλήκτρο SLEEP

Λειτουργίες Πλήκτρων

Πλήκτρο TIMER ON

Πλήκτρο TIMER OFF

Πλήκτρο ( )

Πλήκτρο TURBO

Πλήκτρο SHORTCUT

Πλήκτρο ON/OFF

Με αυτό το πλήκτρο γίνεται η εκκίνηση και η

διακοπή της λειτουργίας της κλιματιστικής

μονάδας.

Πιέστε αυτό το πλήκτρο για να αυξήσετε την

εσωτερική ρύθμιση της θερμοκρασίας σε βήματα

1°C έως 30 °C.

Πιέστε αυτό το πλήκτρο για να μειώσετε την

εσωτερική ρύθμιση της θερμοκρασίας σε βήματα

1°C έως 17°C.

Πιέστε αυτό το πλήκτρο, για να επανέλθουν οι

τρέχουσες ή οι προηγούμενες ρυθμίσεις της

μονάδας.

Κατά την πρώτη εκκίνηση της μονάδας, εάν

πιέσετε αυτό το πλήκτρο, η μονάδα θα λειτουργεί

στην αυτόματη λειτουργία, στους 26°C και η ταχύτητα

του ανεμιστήρα ρυθμίζεται αυτόματα.

Πιέστε αυτό το πλήκρο όταν το τηλεχειριστήριο είναι

ενεργοποιημένο ώστε η μονάδα να επαναφέρει

αυτόματα τις προηγούμενες ρυθμίσεις, όπως

πρόγραμμα λειτουργίας, ρύθμιση θερμοκρασίας,

ταχύτητα ανεμιστήρα και λειτουργία sleep (εαν

έχει ενεργοποιηθεί). Εάν το πιέσετε για 2 δευτε-

ρόλεπτα, η μονάδα θα επαναφέρει τις τρέχουσες

ρυθμίσεις, όπως πρόγραμμα λειτουργίας, ρύθμιση

θερμοκρασίας, ταχύτητα ανεμιστήρα και λειτουργία

sleep (εαν έχει ενεργοποιηθεί).

Πιέστε αυτό το πλήκτρο για να ενεργοποιήσετε την

ρύθμιση της αυτόματης ενεργοποίησης. Κάθε

φορά που πιέζετε αυτό το πλήκτρο η ρύθμιση της

ώρας αυξάνεται κατά μισή ώρα έως τις 10ώρες και

κατά 1ώρα εώς τις 24 ώρες. Για να ακυρώσετε τη

ρύθμιση, πιέστε το πλήκτρο μέχρι η ένδειξη της

ώρας να γίνει 0.0.

Πιέστε αυτό το πλήκτρο για να ενεργοποιήσετε την

ρύθμιση της αυτόματης απενεργοποίησης. Κάθε

φορά που πιέζετε αυτό το πλήκτρο η ρύθμιση της

ώρας αυξάνεται κατά μισή ώρα έως τις 10ώρες και

κατά 1 ώρα έως τις 24 ώρες. Για να ακυρώσετε τη

ρύθμιση, πιέστε το πλήκτρο μέχρι η ένδειξη της

ώρας να γίνει 0.0.

ΣΗΜΕΙΩΣΗ: Η λειτουργία του έλεγχου της

θερμοκρασίας δεν είναι διαθέσιμη σε λειτουργία

ανεμιστήρα.

Πλήκτρο MODE

Με αυτό το πλήκρο ρυθμίζετε την λειτουργία της

κλιματιστικής μονάδας όπως παρακάτω:

Πλήκτρο FAN

Με αυτό το πλήκτρο μπορείτε να επιλέξετε την

ταχύτητα του ανεμιστήρα όπως παρακάτω:

Σημείωση: Η ρύθμιση της ταχύτητας του

ανεμιστήρα ισχύει μόνο για τις λειτουργίες AUTO

και DRY.

Η λειτουργία διατηρεί ευχάριστη την ατμόσφαιρα

και συνεισφέρει στην εξοικονόμηση ενέργειας.

Η ενεργοποίηση της συγκεκριμένης λειτουργίας

είναι διαθέσιμη μόνο κατά την λειτουργία της

ψύξης, θέρμανσης και στην Αυτόματη λειτουργία

της κλιματιστικής μονάδας.

Για περισσότερες λεπτομέρειες ανατρέξτε στο

εγχειρίδιο λειτουργίας χρήσης.

ΣΗΜΕΙΩΣΗ: Όταν η μονάδα λειτουργεί σε

κατάσταση SLEEP αν πιέσετε τα πλήκτρα MODE,

FAN, SPEED ή ON/OFF η λειτουργία θα

απενεργοποιηθεί.

Η λειτουργία Turbo επιτρέπει στη μονάδα να

φτάσει την προκαθορισμένη θερμοκρασία

σε λειτουργία ψύξης ή θέρμανσης στο

συντομότερο χρόνο.

Σημείωση: Η λειτουργία Θέρμανσης δεν ισχύει για

τις μονάδες που είναι μόνο για Ψύξη.

Λειτουργίες Πλήκτρων

ON/ OFF

SH O R T

CU T

MODE

FAN

TEMP

ON/OFF

SH O R T

CU T

TIMER

OFF

TIMER

SLEEP

TURBO LED

MODE

FAN

TEMP

TIMER

OFF

TIMER

SLEEP

TURBO LED

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere INVENTOR Fernbedienung Handbücher

INVENTOR

INVENTOR AR5VI-09WFI Bedienungsanleitung

INVENTOR

INVENTOR LV4MCI-12UR Bedienungsanleitung

INVENTOR

INVENTOR Neo N2UVI-09WFI Bedienungsanleitung

INVENTOR

INVENTOR RG35A/BGE Bedienungsanleitung

INVENTOR

INVENTOR LV5MLI32-12 Bedienungsanleitung

INVENTOR

INVENTOR V5MFO-66 Bedienungsanleitung

INVENTOR

INVENTOR V4MFO-66B Bedienungsanleitung

INVENTOR

INVENTOR L4VI32-09WiFiR Bedienungsanleitung

INVENTOR

INVENTOR MGHP-12 Bedienungsanleitung

INVENTOR

INVENTOR V4MVI-09WFR Bedienungsanleitung

INVENTOR

INVENTOR A2MVI-09/A2MVO-09 Bedienungsanleitung

INVENTOR

INVENTOR PFI2VI-09WFI Bedienungsanleitung

INVENTOR

INVENTOR V2MCI-24 Bedienungsanleitung

INVENTOR

INVENTOR RG57A2/BGEF Bedienungsanleitung

INVENTOR

INVENTOR LV4MCI-07 Bedienungsanleitung

INVENTOR

INVENTOR V6MLI32-18/V6MLO32-18 Bedienungsanleitung

INVENTOR

INVENTOR YB1FA Bedienungsanleitung

INVENTOR

INVENTOR M3GHP290-12 Bedienungsanleitung

INVENTOR

INVENTOR V6MCRI32-18WiFiR/U6MRS32-18 Bedienungsanleitung

INVENTOR

INVENTOR RG10B1/BGEF Bedienungsanleitung

INVENTOR

INVENTOR V7DI-12WiFiR/U7RS-12 Bedienungsanleitung

INVENTOR

INVENTOR CR2VI-18WFIB Bedienungsanleitung

INVENTOR

INVENTOR P9MVI32-12WiFi Bedienungsanleitung

INVENTOR

INVENTOR EPC-09 Bedienungsanleitung

Beliebte Fernbedienung Handbücher anderer Marken

Panasonic

Panasonic EUR7622KB0 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen Beo4 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Bedienungsanleitung

Multiplex

Multiplex PROFI TX 9 Bedienungsanleitung

One Remote

One Remote RMB4 Bedienungsanleitung

FUTABA

FUTABA 9ZAP - PART2 Bedienungsanleitung

HR Matic

HR Matic HR MULTI 3 Bedienungsanleitung

Yamaha

Yamaha ACC-GNRST-30-20 Bedienungsanleitung

EisSound

EisSound KBSOUND Bedienungsanleitung

Marantz

Marantz RC101 Bedienungsanleitung

Conrad

Conrad FS20 TC6 Bedienungsanleitung

Anritsu

Anritsu MP1777A Bedienungsanleitung

Niles

Niles WVC100 Fehlerbehebungshandbuch

RCA

RCA RCU1300 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen BEO6 Bedienungsanleitung

GE 94901 Bedienungsanleitung

Onbon

Onbon YQ1-75 Bedienungsanleitung

FUTABA

FUTABA R7108SB Montageanleitung
