InWin POC Bedienungsanleitung

User Manual

POC Product Video

Product Video Information

POC Assembly Guide

Application download link:

POC's Origin

Birthed from InWin's iBuildiShare DIY product

lineup, POC aims to provide an overall unique PC

chassis experience. Hand-folding metal sheets into

a lightweight yet sturdy PC structure delves into an

origami-like art form. The design concept supersedes

thinking outside the proverbial box and encourages

builders to assemble said box instead.

Enrich Our Life

iBuildiShare is committed to developing

interactive and engaging products that achieve a

much more enriching PC building experience.

Specications

* InWin's products comply with RoHS regulations.

* Speci󽗉cations may vary based on di󽗈erent regions.

InWin POC Chassis

Model POC

Model Numbers IW-CS-POCBLU

IW-CS-POCGRE

Colors Black/Blue, Green/Yellow

Case Type Mini-ITX Tower

Materials SECC

M/B Compatibility Mini-ITX

Expansion Slots 3 x PCI-E

(Supports 3.5-Slot GPUs. PCI-E 4.0 Riser Cable Included.)

Maximum Compatibility

GPU Length: 346 mm

GPU Thickness: 82 mm

CPU Heatsink Height: 142 mm

I/O Ports

1 x USB 3.2 Gen 2x2 Type-C

2 x USB 3.2 Gen 1

HD Audio Combo (CTIA – SPK/Mic)

Internal Drive Bays 1 x 2.5"

Thermal Solution

Compatibility

Air Cooling Fans:

Rear: 1 x 120 mm

(1 InWin Luna AL120 Fan Included)

Power Supply Compatibility PSII: ATX12V

- Length up to 160 mm

Product Dimensions

(L x W x H)

256 x 278 x 423 mm

10.1 x 10.9 x 16.7"

Package Dimensions

(L x W x H)

449 x 418 x 45 mm

17.7 x 16.4 x 1.78"

Net Weight 4 kg / 8.82 lbs

Gross Weight 5.2 kg / 11.46 lbs

* Speci󽗉cations may vary based on di󽗈erent regions.

* Our products comply with RoHS regulations.

InWin LUNA AL120

Model Luna AL120

Quantity Included Single Pack

Model Number IW-FN-AL120-1PK

Colors Black

Fan Size 120 x 120 x 25 mm

Materials PC, PBT

Rated Voltage DC 12V

Rated Power 3.96W

Rated Current 0.33A

ADD RGB Rated Voltage DC 5V

ADD RGB Rated Power 1.5W

ADD RGB Rated Current 0.3A

Speed Mode PWM 400-1800 +/-10% RPM

Air Flow 82.96 CFM

Air Pressure 2.31 mm / H2O

LED Addressable RGB

Connector (Fan to Fan) Non-Modular Cables

Connector to M/B 4-Pin (PWM, 12V), 3-Pin (ARGB, 5V)

Noise Level 25 dB(A) (Normal)

Bearing Type Long Lifespan Sleeve Bearing

Net Weight 133 g

Gross Weight 169 g

Package Dimensions

(L x W x H) 185 x 125 x 30 mm

Warranty 2 Years

Specications

Package Contents

1MB Plate

2Front Panel

3Rear Panel

4Side Covers x 2

5Top Panel

6Bottom Panel

Package Contents

1I/O Module

2Footpads x 4

3PCI-E 4.0 Riser Cable

4Handles x 2

5Accessories

6Luna AL120

7Velcro Strips x 5

8Cable Ties x 5

1 4 5

7 8

Package Contents

Accessories

1S1 Screws x 25

2S2 Handle Screws x 4

3S3 Thumb Screws x 4

4S4 2.5" SSD Screws x 4

5P1 M/B Stand-o󽗈s x 6

6P2 GPU Stand-o󽗈s x 2

7P3 GPU Stand-o󽗈s x 2

8Stand-o󽗈 Socket x 1

9PCI-E Slot Bracket x 1

10 Cables Mounts x 2

11 Double-sided Tapes x 2

1 5

2 6

3 7

4 8

910 11

Package Contents

LUNA AL120 Package Contents

1LUNA AL120 Fan x 1

2Screws x 4

Case Structure

1Handles

2Power Supply Mounting Area

3Motherboard Mounting Area

4Rear Fan Mounting Area

52.5" SSD Mounting Area

6Shock-Proof Stands

7Graphic Card

Mounting Area

8PCI-E Expansion Slots

1 1

Power LEDPower Button

HDD LEDUSB 3.2 Gen 1

HD Audio Combo

(CTIA – SPK/Mic)

USB 3.2 Gen 2 x 2 Type-C
