IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. CAUTION – To prevent electrical shock, do not mate unit connector until installation is complete and A.C.
power is supplied to the unit.
2. CAUTION – This fixture provides more than one power supply output source. To reduce the risk of electrical
shock, disconnect both normal and emergency sources by turning off the A.C. branch circuit and by discon-
necting the unit connector.
3. CAUTION – This is a sealed unit. Components are not replaceable. Replace the entire unit when necessary.
4. CAUTION – Installation and servicing should be performed by qualified personnel only. De-energize before
opening.
5. The ILB-CP20-HE-SD-R is for use with grounded LED luminaires listed to UL standards. Not for use in
heated air outlets or hazardous locations.
6. The ILB-CP20-HE-SD-R requires an unswitched A.C. power source of 120 to 277 volts AC, 50/60Hz.
7. The ILB-CP20-HE-SD-R and A.C. driver must be on the same branch circuit.
8. Do not mount near gas or electric heaters.
9. The ILB-CP20-HE-SD-R should be mounted in locations and at heights where it will not readily be subjected
to tampering by unauthorized personnel.
10. The ILB-CP20-HE-SD-R will supply 20-60VDC output at the individual rated specification for 90 minutes. See
individual units for output specifications.
11. The ILB-CP20-HE-SD-R is certified in the CA Title 20 Modernized Appliance Efficiency Database System
(MAEDBS) as a small battery charger
12. Suitable for use in damp locations and plenum.
13. Suitable for luminaires, recessed Type IC (intended for insulation contact).
14. For use in 0° C minimum, 55° C maximum ambient temperatures.
15. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition, void
warranty, and result in non-compliance with UL specifications.
16. Do not use this equipment for other than intended use.
17. Install in accordance with the National Electrical Code and local regulations.
18. Lighting fixture manufacturers, electricians, and end-users need to ensure product system compatibility before
final installation. See addendum for compatibility and covered luminaire requirements.
SAVE THESE INSTRUCTIONS
ILB-CP20-HE-SD-R
HIGH EFFICIENCY SELF-DIAGNOSTIC
EMERGENCY LIGHTING EQUIPMENT
FOR LED
INSTRUCTION MANUAL
