IQ DIGITAL PICTURE FRAME

iQ DIGITAL PICTURE FRAME

User Guide

Model: DPF800SB

IQ DIGITAL PICTURE FRAME

Table of Contents

Introduction....................................................................................................... 3

Main Features................................................................................................... 3

Getting Started.................................................................................................. 4

Package Contents......................................................................................... 4

Installing your unit ......................................................................................... 5

Connecting to a PC....................................................................................... 5

Operation....................................................................................................... 5

Controls............................................................................................................. 6

Using your Remote Control .............................................................................. 7

Inserting Memory Cards ................................................................................... 8

Main menu ........................................................................................................ 9

Viewing Pictures.......................................................................................... 10

Previous................................................................................................... 11

Play or Pause .......................................................................................... 11

Next ......................................................................................................... 11

Rotate...................................................................................................... 11

Stop ......................................................................................................... 11

Zoom........................................................................................................ 11

Watching video............................................................................................ 12

Previous................................................................................................... 13

Fast Forward............................................................................................ 13

Play or Pause .......................................................................................... 14

Fast Backward......................................................................................... 14

Next ......................................................................................................... 14

Stop ......................................................................................................... 14

Zoom........................................................................................................ 14

Listening to MP3 music............................................................................... 15

File Management......................................................................................... 16

Playing a slideshow with music................................................................... 16

Previous................................................................................................... 17

Play or Pause .......................................................................................... 17

Next ......................................................................................................... 17

Rotate...................................................................................................... 17

Stop ......................................................................................................... 17

Zoom........................................................................................................ 17

VOL.......................................................................................................... 17

Copying and Deleting Files......................................................................... 18

Using the SETUP option................................................................................. 20

Technical Support........................................................................................... 21

Frequently asked questions........................................................................ 21

Specifications............................................................................................ 23

Maintenance and Precaution.......................................................................... 24

Cleaning the LCD screen............................................................................ 24

IQ DIGITAL PICTURE FRAME

Introduction

Congratulations on your purchase of IQ Digital Picture Frame.

Before operating the unit, please read this manual thoroughly, and retain it for

future reference. This manual will help you use many of the exciting and

useful features that will make your Digital Picture Frame viewing more

enjoyable.

This Digital Picture Frame lets you view digital pictures directly from your

camera's memory cards. You will be able to create a slideshow using multiple

transition effects or display one picture at a time.

No computer, digital camera or Internet connection is required.

This Digital Picture Frame is compatible with the following popular memory

card formats: CompactFlash®, SD™, XD, MultiMediaCard™, and Memory

Stick®.

It can also read files stored on a USB Flash drive using the USB host port.

Main Features

•Displays digital pictures (JPEG) without a computer

•Internal Memory option

•Simply insert a compatible memory card into the Digital Picture

Frame to show photos, play MP3 music or supported video files

•Compatible memory cards include Secure Digital Card (SD),

MultiMedia Card (MMC), Memory Stick (MS), XD Cards &

Compact Flash

•Able to read files located on a USB Flash drive

•Instantly plays MP3 music with the integrated speakers.

•Instantly plays MPEG1/2/4 files stored on supported memory

cards*.

•Supports up to 12 Mega Pixels image files (JPEG format).

•Compatible with most digital cameras’ stored JPEG images and

motion JPEG files.

•Includes a remote control

•Automatic slide show with multiple transition effects.

•Plays slide show with MP3 music on the background.

•User-friendly on-screen display lets you access all controls easily.

•Interchangeable Frames

*Video files may not play properly if stored on a low speed card.

IQ DIGITAL PICTURE FRAME

Getting Started

Package Contents

Digital Picture Frame

User Manual

AC/DC Adapter

Remote control

USBCable

IQ DIGITAL PICTURE FRAME

Installing your unit

•Open the package and remove the protective foam. Remove the

protective sleeve from the unit.

•Install the Digital Picture Frame stand as the back of the unit.

•Plug in the AC adapter into power outlet. Plug the other end into the

unit.

•After the content is stored on the target flash media; insert the

media into the correct slot.

•Turn power to ON position via the ON/OFF switch.

Connecting to a PC

The Digital Picture Frame has a USB port for connection to a PC (USB Slave)

and a second USB port for connection to other devices such as a Flash Drive,

USB card reader, or a camera (USB Host). When connected to the PC you

can drag-and-drop content from the PC to the internal memory or memory

card. You can also delete content from the internal memory.

NOTE: USB Slave and USB Host can not be used at the same time.

Operation

This Digital Frame is extremely easy to operate:

1. Remove memory card from camera:

2. Insert memory card into the frame with face away from the unit:

IQ DIGITAL PICTURE FRAME

3. The slideshow will start automatically:

Controls

IQ DIGITAL PICTURE FRAME

Using your Remote Control

The following table briefly describes the remote control functions

Button Description

Power Turn on/off

Photo Access your photo files

Music Access your music files

Video Access your videos files

Combo Start the slideshow

Time Display the time/ Calendar

Mute Mutes volume

Menu Displays the main menu

Enter Select highlighted item

VOL +/- Adjusts volume

Arrows Navigate on screen

X/II Play/ pause

IQ DIGITAL PICTURE FRAME

Inserting Memory Cards

The Digital Picture Frame is compatible with the following memory cards:

•Secure DigitalTM Card (SD)

•MultiMediaTM Card (MMC)

•Memory StickTM

•CompactFlashTM (CF) Card

•XD Picture Cards

Insert the memory card with the front label facing AWAY from you. Do not

force the memory card into the memory slot. If you are not able to easily insert

the memory card completely, you may have inserted it the wrong way.

Note:

The Digital Picture Frame will ONLY recognize digital pictures stored in JPEG

format. Digital pictures stored in other formats will be ignored by the device.

Make sure you have at least one picture stored on the memory card. The

frame will not function properly without a stored picture.

You also can use a USB flash drive in the exact same way as you would use

a memory card. Simply copy files on the flash drive and insert it at the right

side of the unit in the USB Host plug.

IQ DIGITAL PICTURE FRAME

Main menu

Upon turning on the Digital Picture Frame, you will go straight to the MENU

screen. To set the Auto Start feature Choose the SETUP screen. Use the

left/right arrow to go to the “Set up”. Press Enter button to enter the options

screen. Use the Up / down arrows to choose your auto start option. Press the

“MENU” button to show the following menu:

Use the left and right arrows to move inside the menu and then press “Enter”

to continue

Note: In all menus, pressing the “Menu” button will bring you back to the main

Function Description

Nand Play files in internal memory

Setup Set system menu

Calendar Display calendar, clock, alarm

SD/MMC/MS/xD Play files on SD/MMC/MS/xD memory card

CF Play files on CF memory card

USB Play files on USB flash drive

NOTE: Icons of above functions shall appear automatically on MENU

screen when certain memory card is inserted. Icons shall disappear

when correspondent card is removed from card slot.

IQ DIGITAL PICTURE FRAME

Viewing Pictures

Make sure you have at least one picture on your memory card or your USB

flash drive. When this is done:

•Select the desired flash media on main menu.

(SD/xD/CF/MS/USB/NAND-Internal Memory)

•Select the “PHOTO” option from the menu and press “ENTER”

•A Photo thumbnail will appear. User UP/DOWN/LEFT/RIGHT arrows

can move the highlight. If the highlighted is a folder, press Enter to

enter the folder.

•Otherwise press Enter to enter the full screen photo (pause mode) and

press Play to enter into slideshow mode.
