IRiver iGP-100 Bedienungsanleitung
Model iMP-350
Model iGP-100
http://www.iRiverAmerica.com
InstructionManual
PORTABLESTORAGEDEVICE
& MULTI-CODECJUKEBOX
Model iGP-100
Thank you for your purchase.
Please read this manual carefully
before using your new player.
http://www.iRiverAmerica.com
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE, RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
NOTE : This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR
TV INTERFERENCE CAUSED BY UNAUTHORIZED
MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
1
Portable Storage Device
iGP can be used as a storage device (1.5 GB media).
USB 2.0 is supported
iGP supports USB 2.0 with maximum transfer speed of 480 Mbit/Sec as well
as USB 1.1.
Multi-Codec Player
Supports MP3, WMA, ASF, and OGG formats as a Multi-Codec player.
The iGP also supports 44.1 KHz, 32~500Kbps based OGG files.
Firmware Upgrade
Provides the latest updated features via firmware upgrade.
Graphic LCD supporting Multiple Languages
iGP-100 comes with a graphic LCD which can support multiple languages,
including: English, French, Spanish, German, Italian, other alphabet-oriented
fonts, Korean, Japanese (Katakana, Hiragana, Kanji), Chinese (Traditional,
Simplified) and others. A total of 38 languages are supported.
FM Tuner
Auto scanning and station memory functions make it easy for you to enjoy
listening to the FM Radio.
Supports 6 Equalizer Patterns.
Normal, Rock, Jazz, Classic, Ultra Bass, User EQ
This player supports 3D Surround Sound developed by SRS Lab.
The player can recognize up to 200 folders and 999 files.
Graphic User Interface Menu Support iRiver Limited does not assume any responsibility for errors or omissions in
this document or make any commitment to update the information contained
herein. iRiver is a registered trademark of iRiver Limited in the Republic of
Korea and/or other countries and is used under license.
All other brand and product names are trademarks of their respective
companies or organization.
All other product names may be trademarks of the companies with which
they are associated.
1999~2003 iRiver Limited, All rights reserved.
Microsoft Windows Media and the Windows logo are trademarks or registered trademarks
of Microsoft Corporation in the United States and /or other countries.
The information, artwork, text, video, audio, pictures, software
and other intellectual property are protected by copyright and
international laws.
You may not reproduce, distribute, publicly perform, publicly
display, modify or create derivative works of the intellectual
property, unless authorized by the appropriate copyright
owner(s). iRiver does not encourage any of our customers to
use copy-righted Intellectual property illegally by using this
product.
URL : http://www.iRiverAmerica.com
Provides information on our company, products, and customer support
information.
Download the latest Software and Firmware Upgrades
Register your iRiver product online so that our Customer Service is enabled
to provide support as efficiently as possible.
Contents described in this manual may be changed with out notice.
2 3
FRONT VIEW
SIDE VIEW
4 5
1. Locating the Controls
Front View, Side View.......................................................
Side View..........................................................................
LCD Window.....................................................................
2. Getting started
Using AC POWER ADAPTER..........................................
Installing the iGP Device Driver........................................
Connecting the iGP to the Host PC..................................
Using as a Portable Storage Device.................................
Disconnecting the iGP from the Host PC..........................
Listening to Music.............................................................
Basic Operation................................................................
3. Useful Features
Playback Mode.................................................................
Navigation.........................................................................
Operating the FM Tuner....................................................
Playback Mode.................................................................
EQ/SRS............................................................................
Menu.................................................................................
Using WINAMP Playlist.....................................................
Firmware Upgrade............................................................
4. Additional Information
References........................................................................
Precautions.......................................................................
Trouble Shooting...............................................................
Accessories.......................................................................
Product Specifications......................................................
Regulatory Information......................................................
5
6
7
8
9
10
11
12
13~14
15~16
17
18
19~21
22
23
24~31
32~33
34
35
36
37
38
39
40
(Stop)/ Power OFF
Power ON
(Play / Pause)
EQ
Display Screen
HOLD
NAVI/MENU /
Volume + / -
A-B / MODE
Charging Indicator
Drive activity light
SIDE VIEW
LCD Window
6 7
EARPHONES
Volume + / -
DC IN 5.0 V
USB Connection
Port
RESET
EQ
TRACK NUMBER
BIT RATE
PLAYBACK
INFORMATION
PLAYBACK MODE
BATTERY INDICATOR
LEVEL METER
FOLDER NAME
SAMPLE RATE
FILE FORMAT
ARTIST NAME
HOLD
PLAY TIME
TITLE NAME
PROGRESSIVE BAR
LEVEL METER
The player will charge automatically when the AC adapter is connected to the
player.
When fully charged, charge indicator light turns off.
Charging : Approx. 2 hours (At full discharge)
Discharging (Playback time) : Approx. 12 hours (At full charge)
Playtime is measured under playback of MP3 128Kbps at full charge.
Use only the AC Power Adapter supplied with the player.
The AC operating voltage of this player is 100~240V, 50~60Hz.
Connect the adapter to the 5.0V DC jack on the player and into an AC
outlet.
Using AC POWER ADAPTER
Recharging Method
Win
auto
Win
reco
func
8
TO INSTALL THE DEVICE DRIVER
Place a checkmark next to
"Specify a location" and click
Browse.
Choose "iGP-
100 Driver”
folder on the
installation CD
and Click “OK”.
Once the path has been located,
Click “Next”. Click “Next”
Click “Finish”
The installation of the Device Driver is
complete.
Choose "Search for the best
driver for your device
(Recommended)." Click Next.
Connect the player to your PC,
Windows will display the "Add New
Hardware Wizard. Click Next.
9
Windows Me, Windows 2000, and Windows XP will recognize the iGP as a USB drive
automatically and you can use the player with out installing the driver. For Windows 98
SE users, the driver must be installed for the computer to recognize the player.
First, insert the installation CD, then connect the iGP to your PC and power on the
player. Then follow the instructions below."
TO USE AS A PORTABLE STORAGE DEVICE
If the player is not connected to the host PC, connect it to the host PC.
(Refer to page 10)
The player will show up as a new
drive in Windows Explorer.
The iGP operates just like an additional hard drive in Windows Explorer.
Files can be copied, deleted, etc.
Note
When the iGP is attached to a computer for an extended
period of time, be sure to plug in the AC adapter. Low batteries can
prevent the proper functioning of the iGP.
Click and Drag files from the PC
to the iGP player.
To delete files or folders from the iGP, select the files (folders) to be
deleted and press "Delete" on the keyboard. Click “Yes” when asked to
confirm the delete.
11
TO CONNECT THE IGP TO THE HOST PC
Type “A”
Type “B”
USB port on the PC USBporton
the player
USB cable
Type “A”
Type “B”
Click to turn on the player.
Connect the USB cable to the player and the host PC.
Windows XP and Windows 2000 will display a
"Device Attached" icon.
Once installed, open Windows
Explorer and an additional drive
should be listed called “iGP-100”.
10
To PC
To iGP
Note
Windows may ask to install a driver for the iGP. Please follow the
provided driver installation guide on the previous page.
TO DISCONNECT THE PLAYER FROM THE HOST PC
Click the 'Safely Remove Hardware" icon in
the System Tray.
Click OK after confirming the “Safe To Remove Hardware” massage.
Disconnect the USB cable between the iGP and host PC.
Click “Stop iRiver iGP-100-Driver(X)” or “Safely Remove CORNICE Inc.
Storage-Drive(X:)”. (Where X is the drive letter assigned to the iGP)
Caution
Do not disconnect the player while the drive is in use.
Wait for any file copying to complete before disconnecting the iGP from
your computer."
12
Press the PLAY/STOP button to
turn on the player.
Press it again to play.
To select music
: To select previous track
: To select next track
Switch the HOLD button to "off".
To adjust the volume
:
To increase volume
:
To decrease volume - When "Hold" is ON, the buttons on the
player will not function.
- When the player is stopped, it will shut off
according the "Stop Power Off" setting in
the Menu. (Refer to page 29.)
Connect the headphones as shown
below.
NOTE
13
Power ON
To play / pause
To stop
To
play next track
To
play next folder
To
turn off the player
To turn off the player
To fast forward
To fast reverse
To
play previous track
To
play previous folder
To
change EQ
File Format displayed as below
MP3 WMA
ASF OGG
15
14
To activate Navigation
1. Operating light is illuminated when the iGP-100
is turned on.
2. Charging light is illuminated during charging.
3.
To increase volume.
4. A-B repeat / MODE :
5. To decrease volume.
6. To select the previous track.
7.
To select NAVI/MENU function or search files.
8. To select the next track.
9. Reset button : To initialize the iGP-100.
10. HOLD: Enable or disable HOLD function.
Buttons do not work when HOLD is enabled.
11. To start or pause playback
12.Tostopplaybackorturnoff.
13. To change
EQ Mode
To activate Menu
Basic Operation
NAVIGATION
To adjust the volume
Press + on volume button to increase
volume and press – on button to
decrease volume.
Press NAVI/MENU button and find the desired track by pressing or ,
NAVI/MENU button.
17
(Refer to page 19)
Selecting FM Mode
when listening FM
Stereo Mono
File playback FM
receiving
16
Press A-B button once to select
the beginning <A> Point.
A-B interval will be repeated.
Select interval to play repeatedly.
Interval Repeat
Press A-B button again to
select the ending <B> Point.
Inhaltsverzeichnis
Andere IRiver MP3-Player Handbücher
IRiver
IRiver E10 Bedienungsanleitung
IRiver
IRiver iFP-120 Bedienungsanleitung
IRiver
IRiver N11 Bedienungsanleitung
IRiver
IRiver S10 1GB Bedienungsanleitung
IRiver
IRiver H120 Bedienungsanleitung
IRiver
IRiver Spinn 4GB Bedienungsanleitung
IRiver
IRiver Astell & Kern AKT1 Bedienungsanleitung
IRiver
IRiver T10 Bedienungsanleitung
IRiver
IRiver S100 Soft Silhouette Bedienungsanleitung
IRiver
IRiver Astell & Kern AK120 II Bedienungsanleitung
IRiver
IRiver H10 Bedienungsanleitung
IRiver
IRiver Astell & Kern AK380 Bedienungsanleitung
IRiver
IRiver iFP-195T Anleitung zur Verwendung
IRiver
IRiver T7 2GB Bedienungsanleitung
IRiver
IRiver IFP-800 Series Montageanleitung
IRiver
IRiver Data Play IDP-100 Bedienungsanleitung
IRiver
IRiver N10 Bedienungsanleitung
IRiver
IRiver HP-120 Bedienungsanleitung
IRiver
IRiver iFP-990 Bedienungsanleitung
IRiver
IRiver iFP-190T Anleitung zur Verwendung
Beliebte MP3-Player Handbücher anderer Marken
Blaupunkt
Blaupunkt Compact Drive MP3 Bedienungsanleitung
Memorex
Memorex MMP9008 - 8GB USB 2.0 Bedienungsanleitung
Meizu Electronic Technology
Meizu Electronic Technology E5 Bedienungsanleitung
Naxa
Naxa NMV-173NX Bedienungsanleitung
Philips
Philips PSA250 Bedienungsanleitung
Zipy
Zipy go! Waving Bedienungsanleitung
