IRiver S10 1GB Bedienungsanleitung

S10.

SERIES

•Intuitive iriver D-Click System™

•17.5g, ultra light player

•Comes with Lanyard Earphones

•Color OLED Display (1.15”)

•Plays up to 8 hours with internal rechargeable battery

•Supports music file such as MP3, WMA and OGG Q10

•FM radio and FM recording reservation

•Voice recording

•USB 2.0, Ultra Fast Data Transfer

• Comes with iriver plus 3 software

• Firmware Upgradable

• Alarm with real-time clock

Launching - Sep, 2006

Model variation

S10 1GB / S10 2GB *

Color variation

Black & White

Always enjoyable

*1GB=1,000MB = 1,000,000,000Byte. Not all memory space available for file storage.

Black & White Only

Simple Shining

and Stylish

S10.

1. Necklace Reborn

1) Earphone wires can be adjusted in length except in the hook part of the necklace to

allow you the maximum convenience.

2) The clip-on hook makes up for the potential shortcoming of the necklace-type earphone

wires that can easily be detached from the main body.

2. Pivot Function

S10 features the pivot function to provide greater convenience when using it in the

necklace form. The window automatically makes a pivotal turn to fit the display by 180

degress.

3. Lighter Than Ever

Stylish design, various functions, and internal battery: everything in just 17.5g. Lighter

than ever S10 in small size offers you the better portability and greater comfort for your

neck than ever.

4. D-Click System, Speed Along

S10 follows upon on the D-Click System of the U10 despite of its small size for the greater

user convenience. The command response rate was significantly enhanced to allow

easier and faster access to different services.

5. Colorful Display Organization

1.15-inch OLED offers you the brightest and clearest display of 65,000 colors. Mobile

emoticons can add an extra flare to the blend LED, and personally-set slide shows can be

used as a screen saver option.

6. Recharge? Dowload? Earphone? All in One from Now

A mini- USB port is all you need to recharge the power, download the music, and listen to

the music with S10 through the earphone port on the top part of the main body.

S10 Features - new concept, new style S10

SSERIES

S10.

S10 Functions – Small Yet Compact

SSERIES

1. Small in Size, Big in Performance

S10 may be small in size, but it does not leave any useful functions behind. It supports a

number of codec types including MP3, WMA, ASF, and OGG (including Q10), allows 8-

hour simultaneous play, and accommodates other basic functions. At the same time,

complementary functions such as the FM radio reception/recording, image viewer, voice

recording, timer, alarm, and portable data storage.

2. Storage Me Crazy!

Small yet powerful S10 goes far into offering large storage up to 2GB to leave no

consumer needs behind.

3. iriver Plus 3 Compatible

iriver Plus 3 supports the library function through which all contents including music, video,

image, and e-book files can be transmitted. Any contents of your choice can be dragged

and dropped into the iriver Plus 3 for transmission, and the image files can be

automatically transformed into the optimal size and type at the time of transmission.

4. FM Radio & Schedule Planner

Automated tuning and frequency memory functions allow you the easy-access to the

high-quality FM radio transmission. The programs of your choice can be recorded both on

site and through timer. The clock and alarm functions also make S10 the schedule

planner from your dream.

S10.

S10 Design – Simple Modernity

SSERIES

1. Brighter than the Jewelries: S10

S10 allows you the top of the time trendy look in simple modernity. Its small and thin

design Is sure to make you the fashion leader of the time anyway you want.

iriver is a registered trademark of ReignCom Ltd. All other company or product names are trademarks or registered trademarks of their respective owners.

All technical features are subject to change without notice. The final version of the product may differ slightly from the pictures and verbal descriptions provided

herein.

Detailed Specification

Series iriver S Series

Continuous Playback Time

Connection Type

Equalizer

Dimensions

Weight

Operational Temperature

Recording

Multimedia

Support File Type BMP

O/S Windows requirement Windows 98SE/ME/2000/XP

Product S10

Models in the S10 Capacity / Color 1GB / 2GB* (Black/White)

8 hours

USB 2.0

Normal / Classic / Live / Pop / Rock / Jazz / Ubass / Metal / Dance / Party / SRS 2.0 / Custom

Approx. 42(W) x 30(H) x 10.8(D) mm

Approx. 17.5g

-5 ~ 40

General

Voice, FM

Display Main Set Display 1.15-inch OLED Display (96x128)

Power Battery Built-in Lithium Polymer Rechargeable Battery

Frequency Range 20Hz~20kHz

Headphone Output Power 15mW + 15mW (at Max. Volume)

S/N Ratio 90dB

No. Channels Stereo (L+R)

Frequency Range KR,US,EU : 87.5MHz ~ 108MHz, JP : 76MHz ~ 108MHz

S/N Ratio 60dB : a weighted

Antenna Headphone / Earphone-Cord Antenna

Audio File Type MPEG 1/2/2.5 Layer 3, WMA, ASF, OGG

Bit Rate MP3, WMA : 8kbps ~ 320kbps / OGG : Up to Q10

Tag ID3 V1 Tag, ID3 V2 2.0, ID3 V2 3.0, ID3 V2 4.0

www.iriver.com

Audio

Support

FM Tuner

Audio

S10.

SSERIES

*1GB=1,000MB = 1,000,000,000Byte. Not all memory space available for file storage.
