ISHIDA NOVA-II Benutzerhandbuch

51860

Ishida Industrial

& Non-System Retail Products

Setup & Calibration

Manual

Speciﬁcations subject to change without notice.

November 2002

Contents

Introduction.................................................................................................................................. 1

1.0 Retail Scales................................................................................................................................ 1

1.1 NOVA-II. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.2 BC-3000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2.0 Industrial Scales.......................................................................................................................... 5

2.1 MTX/MTB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2.2 MTE Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.3 MG-3000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

2.4 CWS Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2.5 CWS Series. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

2.6 NCS Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.7 QBX Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3.0 Balances .................................................................................................................................... 15

3.1 QB Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.2 MB Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3.3 MB-RE Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.4 IB Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.5 SB Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Retail Scales

Introduction

This manual is a compilation of setup and calibration

procedures for Ishida industrial and non-system retail

products sold by Rice Lake Weighing Systems. It is

intended for use by service technicians responsible for

installing and servicing these products.

Authorized distributors and their

employees can view or download this

manual from the Ishida distributor site at

www.ishidaretail.com

1.0 Retail Scales

Rice Lake Weighing Systems currently sells and distributes the following models of Ishida retail scales.

•Nova–II

• BC–3000

The following pages describe the setup and calibration procedures used for these products.

Ishida Setup & Calibration Manual

1.1 NOVA-II

Follow the steps below to set up and calibrate the NOVA-II scale.

IMPORTANT!

All work performed on the NOVA-II, including setup and calibration, must be done by an authorized

scale distributor to ensure compliance with NTEP requirements.

Figure 1-1. Bottom view of NOVA-II scale

Step Action Display

1Turn the scale off.

2Turn the scale on and immediately press the 1 key.

3Press the 1 key then the TARE key. C 0

4Press TARE after verifying the country code: 20 = United States (15 lb, 30 lb, and 60 lb)

To change the country code, enter 20 20, then press TARE. C1-1 20 0

5Press TARE after verifying the Capacity Code:

•2= 30 x 0.01 lb

•9= 15 x 0.005 lb

•7= 60 x 0.02 lb

NOTE:

XXXX

= capacity, z = code. To change, enter the code, then press TARE.

C1-2

XX.XX

6With no weight on the scale, press ZERO to set 2000 counts.

NOTE:

nnnn

= any number. 10

nnnnn nnnn

7 Place the full capacity weight on the scale as determined in Step 5. 10 2000 0

8Press TARE.

NOTE:

nnnn

= any number 10

nnnnn nnnn

9 The center display should read 32000 ± 1. If not, repeat the above starting with Step 6. 10 32000

30000

10 Remove the weights and the weigh platter. 10 32000

30000

11 Tip the scale on edge and remove the brass screw. See the diagram below.

NOTE:

nnn

any number. 10

nnnnn nnnn

12 Use a

non-metallic

device to press the memory switch on the circuit board. See the

diagram below.

The scale beeps and temporarily displays “ok.”

nnnnn nnnn

13 Replace the brass screw and the weigh platter. Turn off the scale. 10 2000 0

14 Turn the scale on again and test the calibration by placing a known weight on the platter. 0.00 0.00 0.00

Memory Switch

Retail Scales

1.2 BC-3000

Follow the steps below to set up and calibrate the Ishida BC-3000 scale.

Do not use a screwdriver or

other metal tool to press the

switch in Step 10.

Figure 1-2. View of BC-3000 scale

Step Action Display

1Turn off scale.

2Turn on scale while depressing the 1 key. Release the 1 key after two beeps. C00 0

3Press the 1 key and push ENTER two times. xxxx=default values between 500 and 5000. xxxx xxxx

4With no weight on the weigh platter, press the ZERO key to set the initial zero point. 0 2000

5 Initial A/D value should read 2000 ± 1.

If No: Press ZERO key again; If Yes: Proceed to step 6. 0 2000

6 Place 30 lb weight on platter. 30000 32000

7 Is A/D change value within 30000 ± 2?

If NO: • Press the TARE key If YES: Proceed to step 8

• Remove weight from platter and return to step 4.

30000 32000

8 Remove weight and weigh platter from unit to perform data registration.

9 Remove white plastic screw from unit (see illustration below).

10 Press memory switch inside unit.

11 Replace the white plastic screw and the weigh platter.

12 Press the END key twice C00 0

13 Turn scale off.

14 Turn on scale again and test the calibration by placing a known weight on the platter. 0.00 0.00 0.00

!Caution

Memory switch

Ishida Setup & Calibration Manual

Industrial Scales

2.0 Industrial Scales

Rice Lake Weighing Systems sells and distributes the following models of Ishida industrial scales.

• MTX Series

• MTB Series

• MTE Series

• MG-3000 Series

•CWS Series

• NCS Series

• QBX Series

The following pages describe the setup and calibration procedures for these products.

Ishida Setup & Calibration Manual

2.1 MTX/MTB

The MTX and MTB Series scales have the same conﬁguration and setup procedures.

NOTE:

Conﬁguration settings must be set before calibrating the MTX/MTB series scales.

2.1.1 Conﬁguration

To Access The Conﬁguration Settings:

1. Turn off the scale.

2. Press and hold the

ZERO

and

COUNT

keys.

3. Press and release the

ON/OFF

key.

NOTE

: For the MTB, press and hold the

ON/OFF

key for at least 2 seconds.

4. Release the

ZERO

and

COUNT

keys.

To Enter Data:

1. The table above shows the parameter settings for the MTX/MTB series models. Use the

ZERO

(+) and

TARE

(–) keys to select the corresponding settings for each parameter (Cn–C8).

2. Use the

COUNT

key to enter the data and advance to the next step.

To Review:

1. After the operator enters C8 (see table above), the input displays C4–C1 setting.

2. If the C4–C1 settings are not correct, turn the scale off, then on again and re-enter the settings.

If the C4–C1 settings are correct, press the

COUNT

key.

3. The unit displays the C8-C5 settings.

4. If the C8–C5 settings are not correct, turn the scale off, then on again and re-enter the settings.

If the C8–C5 settings are correct, press the

COUNT

key.

Calibration

Continue with normal calibration as described on page7, Section 2.1.2 beginning from Step 3 (display =

CA–).

Parameter

Models Cn C1 C2 C3 C4 C5 C6 C7 C8 Check 1 Check 2

MTX-300L F1F6b9220 B6F1 0229

MTX-60L F6F6b9220 B6F6 0229

MTB-300L F 1 E 6 b 9220 B6E1 0229

MTB-60L F 6 E 6 b 9220 B6E6 0229

MTX-150Kg F A F 6 b 9200 B6FA 0229

MTX-30Kg F2F6b9200 B6F2 0229

MTB-150Kg F A E 6 b 9200 B6EA 0229

MTB-30Kg F 2 E 6 b 9200 B6E2 0229
