Itek ITMF44A121DFHD Bedienungsanleitung
2. Maintenance Guidelines
3.
Product Overview
4.
S a a it nd Inst llat on5.
Table Of Contents
Connectivity Options
6.
Basic Operation
7.
Indicator Light
8.
OSD
9.
10.
LED Effects System Console
11.
Safety Precautions
1.
12.
Box Contents
RGB Ranges and Gameplus Switching
13. Technical Specifications
Mount Installation
ITMF44A121DFHD User Manual
For more information please visit our web site or write us an email:
https://www. itekevo. com
info@itekevo.com
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.
Eng-1
1. Safety Precautions
WARNING:Safety Instructions
Do not place the monitor in rain,humid environment or open the monitor case to
avoid any s hock, electrical haz ards,and/or mechanical haz ards .
Operation
• Keep the monitor out of direct sunlight and away from stoves or any other heat
source.
• Keep the monitor out of water source.
• Remove any object that could fall into ventilation holes or prevent proper
cooling of the monitor’s electronics.
• Do not block the ventilation holes.
• Do not knock or drop the monitor during operation or transportation.
• To clean your screen, slightly dampen a soft, clean cloth with water, If possible,
use a special screen-cleaning tissue or solution. Do not use benzene, thinner,
ammonia, abrasive cleaners, or compressed air.
• Use a slightly dampened, warm cloth to clean the frame. Avoid using detergent
of any kind as some detergents might leave a milky film on the plastics.
• Unplug the monitor if you are not going to use it for an extended period of time.
• To avoid the risk of shock or permanent damage to the set, do not expose the
monitor to dust, rain, water, or excessive moisture environment. If your monitor
gets wet, wipe it with dry cloth as soon as possible.
Caring For Your Monitor
Before cleaning the monitor, unplug the monitor power c able from the elec trical
outlet.
CAUTION
2. Maintenance Guidelines
Eng-2
2. Maint enance Guideli nes
3.
Product Over view
4.
S a a it nd Inst llat on5.
Table Of Contents
Connectivity Op tions
6.
Basic Operation
7.
Indicator Light
8.
OSD
9.
10.
LED Effects System Console
11.
Safety Precautions
1.
12.
Box Conten ts
RGB Ranges and Gameplus Switching
13. Technical Specif ications
Mount Installation
ITMF44A121WFHD User Manual
For mo re inf orm ati on ple ase visit o ur web sit e or w rite u s an e mail :
http s://www .itekevo .com
info@it ekevo.co m
User Manual x 1
3. Box Contents
Monitor x 1
Screws PM4*16mm x 4
(for wall mounting)
DP Cable x 1 TYPE-C Cable x 1
USB Cable x 1
Stand Stem x 1 Stand Base x 1
Power Cable x 1
VESA Adapter x 1
Screws PM5*15mm x 4
(for stand installation)
Eng-3
4. Product Overview
4.1 – Monitor Buttons
4.2 – Monitor Ports
M Menu Button: Press to display the OSD menu or enter sub-menus.
Down Button: Press to move down in the menus.
Up Button: Press to move up in the menus.
E Exit Button: Press to exit.
Power Button: Press to turn the monitor on/off.
LED lndicator: Changes colors to indicate status.
Type-c: Insert one end of the Type-c cable into the computer's Type-c
output and connect the other end to the monitor's Type-c port.
HDMI Connectors: Insert one end of the HDMl cable into the computer's
HDMl output and connect the other end to the monitor's HDMI port.
DP Connectors: lnsert one end of the DP cable into the computer's DP
output and connect the other end to the monitor's DP port.
Audio Output: Insert the audio cable for output of audio signals.
USB A: USB out Port.
USB B: USB in Port.
Power Connector: Insert the power cable to supply power to the monitor.
2
1
3
4
5
6
8
7
9
10
11
12
13
1
7 8 9 10
11 121 13
2 3 4 5 6
Eng-4
5. Stand lnstallation
1. Take out the two main parts of the stand. Then use the screwdriver and the 3
screws to fasten base to the stem.
2. Take out the monitor and put it on the flat foam, insert the stand on the back of
monitor.
3. Use both hands to place the assembled monitor on a flat desk.
Stem
Base
PM5*15 Screws X3
Quick release button
Make sure the monitor is laid on a flat surface before removing the stand.
Eng-5
6. Mount lnstallation
This monitor only includes screws which may be used when attaching the monitor to
a VESA 75*75mm type mount. No VESA mount or mounting accessory is included.
1. Take a screwdriver to remove the four screws locked in the middle of the whole
machine. (when disassembling the screws, the display screen cannot leave the
Styrofoam to prevent the screen from breaking)
2. Take out the wall-mounted adapter/four PM4*16 screws from the accessories as
shown in the figure above, assemble it in the middle of the whole machine, and fix
it by locking.
3. Do not pinch the screen directly with your hands during the process of hanging
the product.
Disassemble the four screws that lock the whole machine
The wall-mounted adapter is assembled to the middle
of the whole machine. (fixed with PM4*16 screws in the
accessory bag)
Wall adapter
PM4*16 screw X4
Wall bracket
Wall adapter
Eng-6
7. Connectivity Options
7.2 – Connecting Your Earphones
Plug in your earphones to receive audio signals from your monitor. If you have an
audio device connected to your computer when you connect your earphones to the
monitor, the audio devices will not produce sound. Earphones and other audio
devices are not included.
Earphones (not included)
Exposure to loud audio for prolonged periods of time may permanently
damage your hearing.
Connect the included power cable to the power connector and then plug the other
end into a wall outlet.
7.1 – Connecting the Power Cable
Power Cable
Eng-7
7.3 – DP Connectivity
For the monitor to receive DP signals from the computer, use the DP cable to
connect the monitor to the computer.
DP
DP OUTPUT
DP Cable (Included)
7.4 – HDMI Connectivity
For the monitor to receive HDMI signals from the computer, use an HDMI cable to
connect the monitor to the computer.
HDMI OUTPUT
PC
HDMI Cable (Not Included)
Eng-8
8. Basic Operation
9. lndicator Light
1. Insert one end of the DP cable into your PC's graphics card. An HDMl cable may
also be used. HDMI cable is not included.
2. Connect the other end of the cable to the corresponding connector on your monitor.
3. Connect the power cable to your monitor then connect the other end to your power
source. It is recommended that you use a surge protector with adequate voltage if
a wall outlet cannot be reached directly.
4. Locate the power button on the monitor and press it to turn the monitor on.
Solid blue light indicates power is on and the monitor is operating normally. Flashing
blue light indicates no video source, no horizontal or vertical signal has been detect-
ed or power is low.Please ensure your computer is on and all video cables are fully
inserted and/or connected.
Type-C
HDMI Connectors Audio Output Power Connector
Indicator light
USB A
DP Connectors USB B
Eng-9
10. On-Screen Display (OSD)
When using the monitor for the first time, settings will automatically adjust to
optimal settings according to your computer's configuration and parts etc.
The On-Screen Display (OSD) Menu may be used to adjust your monitor's settings
and appears on screen after turning on the monitor and pressing the Mbutton.
1. Press one of the buttons( ) to activate the navigation window.
2. Press M ( ) to enter the OSD screen.
3. Press or to browse functions.
Highlight the desired function, then press Mto enter the sub-menu.
Press or to browse sub-menus, then press Mto highlight the desired
function.
Press or to highlight an option, then press Mto confirm the settings
and exit the current screen.
4. Press Eto exit the current screen.
M, , , E,
Resolution: 3840x1080@120Hz SDR
Resolution: 3840x1080@120Hz
