Installing 40W and 50W ERT®Modules

Revision B

Installing 40W and 50W ERT Modules

Identification

Installing 40W and 50W ERT®Modules

PUB-0126-001 4/04

Trademark Notice

ERT®, Itron, and ReadOne are registered trademarks of Itron, Inc. All other product names and logos in this manual are used for

identification purposes only and may be trademarks or registered trademarks of their respective companies.

Your company has the right to reproduce this contract document, provided that such reproduction shall be subject to the same use and

disclosure restrictions contained in the Confidentiality and Non-Disclosure paragraphs in the Sales Contract.

Compliance Statement FCC ID: EO940GN-1 CANADA: 864-K1124

This equipment has been tested and found to comply with Part 15 of the FCC rules and R.S.S.-210 of Industry and Science Canada.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any

interference that may cause undesired operation of the device. Complies with IC: CNR-210; en conformite´ avec IC: CNR-210.

Transportation Classification

Itron classifies and ships model 40W and 50W ERT modules as non-hazardous material. The proper shipping name is Lithium

Batteries contained in Equipment, Class 9, UN3091, Packing Group II.

The Federal Aviation Administration prohibits operating transmitters and receivers on all commercial aircraft. When powered, the

model 40W and 50W ERT modules are considered operating transmitters and receivers and cannot be shipped by air.

Applicable Patents

U.S. Patent numbers: 4,614,945; 4,733,169; 4,799, 059; 4, 786, 903; 4, 876, 700.

Canadian Patent numbers: 1,254, 949; 1, 267, 936; 1, 282, 118.

Warning

Only authorized Itron personnel should attempt repairs on Itron equipment. Attempts to do so by others might void the warranty and/or

any maintenance contract with your company. Unauthorized service personnel might also be subject to shock hazard on some Itron

equipment if removal of protective covers is attempted.

Related Documents

ReadOne Pro®ERT Programming Guide TDC-0027

Water ERT Ordering Guide PUB-0063-001

Contact Information

If you have suggestions on how we can improve this document, please send them to:

Itron, Inc.

2401 North State Street

Waseca, MN 56093

Phone 1-800-392-3185

Printed in the U.S.A.

Installing 40W and 50W ERT Modules PUB-0126-001 4/04

TABLE OF CONTENTS

Section Page

Section 1

INTRODUCTION

1.1 Installation Features ........................................................................................................................... 1–1

1.2 Physical Features .............................................................................................................................. 1–1

1.3 Functional Features ........................................................................................................................... 1–1

1.4 Meter-ERT Compatibility ..................................................................................................................... 1–2

1.5 40W and 50W ERT Configurations .................................................................................................... 1–3

1.5.1 Badger RTR and ADE .............................................................................................................. 1–3

1.5.2 ABB Digital, Scancoder and InVISION .................................................................................. 1–3

1.5.3 Hersey Translator .................................................................................................................... 1–4

1.5.4 Hersey ER ................................................................................................................................ 1–4

1.5.5 Schlumberger ARB V and ProRead ........................................................................................ 1–5

1.5.6 Sensus ECR and ICE .............................................................................................................. 1–5

1.6 Installation Kits .................................................................................................................................... 1–6

1.7 Tools and Materials You Must Supply ................................................................................................. 1–7

Section 2

INSTALLING THE BADGER DIRECT-MOUNT ............................................................................................... 2–1

Section 3

INSTALLING THE AMCO InVISION, DIGITAL OR SCANCODER DIRECT-MOUNT....................................... 3–1

Section 4

INSTALLING THE SHLUMBERGER ARB V OR PROREAD REGISTER-MOUNT ......................................... 4–1

Section 5

INSTALLING THE SENSUS ECR REGISTER-MOUNT .................................................................................. 5–1

Section 6

INSTALLING A REMOTE-MOUNT ................................................................................................................... 6–1

Section 7

PIPE MOUNT (AND REGISTER-MOUNTS REQUIRING A BAND CLAMP) .................................................... 7–1

Appendix A

CONNECTING CABLE WIRES WITH GEL CONNECTORS .........................................................................A–1

Appendix B

ITRON INSTALLATION KITS (ILLUSTRATED) .............................................................................................. B–1

REVISION HISTORY ...................................................................................................................................... R–1

iii

Installing 40W and 50W ERT Modules

The 50W contains two batteries

The 50W ERT module can be programmed two ways:

1. Wake-Up Mode: A “wake-up” signal is sent from the meter-reading device* to the ERT module,

which responds with data transmission. This configuration requires an FCC license.

2. “Bubble-Up” Mode. In this mode, the FCC requires that no wake-up signal be sent. The

transmission of data from the ERT module occurs at preset times. No wake-up signal is needed

and no FCC license is required for this type of installation. To turn off the transmitter from the meter-

reading device, refer to the operating instructions for that device.

The 40W ERT module functions only in the “wake-up” mode.

*Such as a Data Command Unit (DCU) or DataPac

1-1

SECTION 1. INTRODUCTION

This section overviews the installation procedures, and the physical and functional features of the 40W

and 50W ERT modules. This section also lists the specific meters that are compatible with these

modules and illustrates their various configurations. Finally, this section lists the available installation

kits and the tools and materials you’ll need to install the 40W and 50W modules.

1.1 Installation Procedures

INSTALLATION PROCEDURES FOR THE 40W AND 50W ARE IDENTICAL

1.2 Physical Features

The only visible difference is that the 40W contains one battery, and the 50W contains two batteries.

The 40W contains one battery

1.3 Functional Features

Installing 40W and 50W ERT Modules PUB-0126-001 4/04

40W PART NUMBER INSTALL ON THESE METERS

ERW-0008-001

BADGER RTR

• Direct-Mount

• Remote-Mount

ERW-0008-002

AMCO (ABB) SCANCODER

• Direct-Mount

• Remote-Mount

ERW-0008-004

SCHLUMBERGER PROREAD

• Remote-Mount

• Register-Mount

ERW-0008-005

SENSUS ECR,ICE BADGER ADE

• Remote-Mount • Remote-Mount

• Register-Mount • Direct-Mount

1.4 Meter-ERT Compatibility

Before you install a 40W or 50W ERT module, make sure it is the correct one for the meter. Match

the part number in Table 1-1 with the meter. Refer to Water ERT® Meter Compatibility list for details

and exceptions.

Table 1-1. Meter-ERT Compatibility

AMCO (ABB) DIGITAL

• Direct-Mount

• Remote-Mount

ERW-0008-003

SCHLUMBERGER ARB V

• Remote-Mount

• Register-Mount

50W PART NUMBER

ERW-1008-501

ERW-1008-502

ERW-1008-503

ERW-1008-504

ERW-1008-505

1-2

ERW-1008-505

HERSEY TRANSLATOR

• Remote-Mount

• Register-Mount

CAUTION: The 50W ERT for Hersey ER, Precision, and AMCO Digital registers

must be programmed to the appropriate meter type to prevent the possibility of

reporting inaccurate consumption values. To perform this function, refer to the

instructions supplied with the ReadOne®Pro ERT Programming Guide TDC-

0027-005 (or higher). Also, verify that the ReadOne Pro used for programming

is software version 5.0 or higher, and your ROCL is base VO9 or higher. Each

of these attributes can be verified from the various screens on the ReadOne

Pro.

(Note: ReadOne Pro software version 5.0 does not support 25G ERT modules. Contact Customer

Care at 1-800-635-8725 for additional information.)

NOTE: Although all procedures are illustrated with photos of the 40W module, the installation procedure for

the 50W is exactly the same.

ERW-1008-506

AMCO InVISION

• Remote-Mount

• Register-Mount

ERW-1008-501

HERSEY ER

• Remote-Mount

• Register-Mount

Installing 40W and 50W ERT Modules

1.5 40W & 50W ERT Configurations

The next three pages illustrate the installation configurations described in this manual.

1.5.1 Badger

1.5.2 AMCO (ABB) Digital, Scancoder and InVISION

DIRECT MOUNT. The AMCO Digital, Scancoder

or InVISION ERT module mounts directly on the

bracket supplied by AMCO.

REMOTE-MOUNT. The ERT module is wired to

the unterminated cable, which can be up to 500

feet in length. Three feet to 100 feet can be

ordered from Badger (typically 25 feet is supplied

by Badger). The remote can be mounted on a

pipe or flat surface.

DIRECT-MOUNT. The ERT module mounts

directly on the bracket supplied by Badger.

REMOTE-MOUNT. The ERT module is wired to

the cable, which can be up to 300 feet in length.

The remote can be mounted on a pipe or flat

surface.

01265F

01545

0109001092

CAUTION: Be sure to attach correct ERT module to appropriate meter register.

1-3

Installing 40W and 50W ERT Modules PUB-0126-001 4/04

1.5.3 Hersey Translator

REMOTE-MOUNT. The ERT module is wired to the cable, which can be up to 300 feet in

length. The remote can be mounted on a pipe or flat surface.

1-4

1.5.4 Hersey ER

REMOTE-MOUNT. The ERT module is wired to either the 5 foot or 25 foot ER cable assembly.

The remote can be mounted on a pipe or flat surface.

01863

01872

Installing 40W and 50W ERT Modules

1-5

1.5.6 SENSUS ECR OR ICE

Sensus meters must be equipped with ECR or ICE registers. The remote-mount cable

can be up to 300 feet in length. The remote can be mounted on a pipe or flat surface. A

band clamp is used to mount the ERT module to the register.

01349e

1.5.5 SCHLUMBERGER ARB V and ProRead

The illustration shows a remote-mount on a Neptune T-10 meter equipped with a ProRead

be mounted on a pipe or flat surface, with a cable up to 300 feet in length. A band clamp is

used to mount the ERT module to the register.

CAUTION: Be sure to attach an ARB V register to an ARB V ERT and a ProRead register

to a ProRead ERT. ARB V and ProRead ERTs do not have the same part number.

01342F

Installing 40W and 50W ERT Modules PUB-0126-001 4/04

Configuration Kit (part number CFG-0067-001). This kit contains the accessories for remote-mounting a

40W or 50W Scancoder ERT module to an adapter plate, wood, or sheet metal surface. The contents of

this kit are illustrated in Appendix B.

Configuration Kit (part number CFG-0067-002). This kit contains the accessories for remote-mounting all

other 40W or 50W ERT modules (including the ABB Digital ERT) described in this manual to adapter

plates, wood, or sheet metal surfaces. The contents of this kit are illustrated in Appendix B.

40W & 50W Pipe Mount and Register-Mount Installation Kit. Use this kit to remote-mount the 40W or 50W

ERT module on a pipe, or to direct-mount the 40W or 50W ERT module on a register. One of these kits

can be ordered for each ERT module. These kits come with a choice of three band clamp sizes. To select

the correct size, see Water ERT Ordering Guide (PUB-0063-001). The contents of this kit are illustrated in

Appendix B. NOTE: There is an additional charge for this kit.

1.6 Installation Kits

1–6

To order the above kits, see the Water ERT Ordering Guide

(PUB-0063-001).

Installing 40W and 50W ERT Modules

The tools and material required depend on whether you are installing a direct-mount ERT module or a remote-

mount ERT module; and if it is remote, the way it is mounted (pipe or flat surface). You must supply some or

all of the tools and material listed in Tables 1–2 and 1-3 below. Also, If you remove and replace registers, you

might need tools specified by register manufacturer.

NOTE: For remote-mount installations, customer-supplied cable is required (Badger supplies 3 feet

to 100 feet, typically 25 feet); cable length should not exceed 300 feet (Badger 500 feet). Itron recom-

mends 19-26 gauge, pre-bonded or solid conductor wire with a maximum diameter of .082" (individual

wire with insulation).

Tool or Material Required

Required for

Direct-Mount

or Integral

ERT Modules

Klein model D234-6C pliers, 3M ScotchLok® Model E-9C

Cartridge Tool, or similar tool for crimping wire connectors

Side-cutting pliers for cutting wires, remote cables, and cable

ties (NOTE: Klien model D234-6C pliers satisfy this require-

ment).

Torx® screwdriver, size T-10 security head, for the RTR

mounting setscrew (Badger only)

Torx screwdriver, size T-15 for the screws that attach ERT modules

to integral RTRs and Remote Mounting Brackets

ReadOne® Pro unit for programming and checking ERT modules

Medium flat-blade screwdriver for band clamps

Medium flat-blade, for the screws that attach adapter plates to pipe

brackets and the screws that attach remote mounting brackets to

adapter plates

Cable ties for securing remote cables to pipes or other supports

Standard or long-nose pliers for pulling cable ties tight

1/4-inch nut driver other tool for seating tamper seals

Medium Phillips screwdriver for the screws that attach remote

mounting brackets to wood or sheet-metal surfaces

Table 1-2. Suggested Tool List

XXX

Mounted on

Pipe

Mounted on Wood

or Sheet Metal

1.7 Tools and Materials You Must Supply

1/16-inch awl for removing tamper seals

Wire strippers for removing insulation from cables and wires

XX X

XXX

1–7

Required for Remote ERT Modules

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere ITRON Steuereinheit Handbücher

ITRON

ITRON Centron C3A2H Gebrauchs- und Pflegehandbuch

ITRON

ITRON 022 Bedienungsanleitung

ITRON

ITRON 60W Endpoint Bedienungsanleitung

ITRON

ITRON OpenWay Riva Bedienungsanleitung

ITRON

ITRON 8600 Series Bedienungsanleitung

ITRON

ITRON Gen 5 500W ERT Bedienungsanleitung

ITRON

ITRON OpenWay Riva 500W ERT Bedienungsanleitung

ITRON

ITRON OpenWay Riva 500G Bedienungsanleitung

ITRON

ITRON EquaScan hMIURFV2 Bedienungsanleitung

ITRON

ITRON OpenWay Riva Bedienungsanleitung

ITRON

ITRON 100T-CP Bedienungsanleitung

ITRON

ITRON 100G Bedienungsanleitung

ITRON

ITRON OpenWay Riva Bedienungsanleitung

ITRON

ITRON ITR9002 Gebrauchs- und Pflegehandbuch

ITRON

ITRON 800 Series Bedienungsanleitung

ITRON

ITRON OpenWay Riva Bedienungsanleitung

ITRON

ITRON OpenWay Riva 500G ERT Bedienungsanleitung

ITRON

ITRON ACT1 Bedienungsanleitung

ITRON

ITRON OpenWay Riva Bedienungsanleitung

ITRON

ITRON 100G Bedienungsanleitung

ITRON

ITRON OpenWay Riva 500W ERT Bedienungsanleitung

ITRON

ITRON EquaScan wMIURF V2 Bedienungsanleitung

ITRON

ITRON Cellular 500G Bedienungsanleitung

ITRON

ITRON OpenWay Riva Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
