iTVGoggles FPView 3Dxi PRO Bedienungsanleitung
QUICK START GUIDE
Version 1.1
FPView 3Dxi PRO
Function Description
Magnetic elastic headband
02
Instructions
Magnec eye mask
0-700degree diopter
adjustment
2D/3Dswitch button
3.5mm headphone
jack
AB
1. Power on
Connect USB interface to the DC5V power supply then Connect
the HDMI output device via HDMI cable. The goggles should be
recognized as a display device such as a monitor/TV.
2. Power off (IMPORTANT)
Unplug the USB power first, THEN disconnect HDMI (This is important!)
3. 3D Mode
If you need to switch to 3D Mode, press the 2D/3D switch button to
switch between 2D/3D
4. External headphone
The FPVIew 3Dxi Pro comes with dual directional sound speakers built-
into the handles. You can also use your choice of 3.5mm external head/
ear phones. Plug in the headphone to automatically switch the sound to
the headphone.
5. Diopter adjustment (0-700°)
First remove the magnetic light mask, turn the diopter adjustment knob
(each scale corresponds to 100 degrees of myopia), adjust the left and
right eyes to the corresponding degrees, and then put on the goggles to
make fine adjustments to make the left and right eyes see the image
clearly . Then put on the magnetic light mask and start using it.
6. Headband adjustment
First install end A of the headband to the leg of the glasses. After
wearing the glasses, magnetically attract end B of the headband to
the other leg of the glasses.
IMPORTNANT NOTES
Note:
1 - When the iTVGoggles are connected to the HDMI output
device, directly plug into the HDMI interface.
2 - Make sure to follow the connection sequence: always connect
the USB power first, before connecting the HDMI.
3 - When the power supply of the USB is insufficient, it may cause
the goggles to display abnormally Or a black screen. Please connect
the USB plug to the DC5V power supply.
4 - 3D playback function supports Side-By-Side 3D videos/input.
Technical Specifications
ITEM
Parameter
PPI
Lens
Diopter
HDMI interface
Eye relief 18mm
0-700 degrees adjustable for myopia
Interface
Exit pupil 7mm
Usage environment Temperature：-10℃--60℃ Humidity： <95%
Dimension 184x165x59 mm/63x165x59mm
150 g
Power consumption 2.5 W
Sound Directional sound speaker,3.5mm headphone
Operational control Button, Host device
2.1" 1600 *1600 , PPI up to 1058
A group of multiple glass lenses
Net weigh
