IWantit ICRIPBT12 Bedienungsanleitung

bluetooth clock radio with docking

iCRIPBT12

instruction manual

(iPhone, iPod and iPad not included)

iCRIPBT12_IB_RC_120926_Zell.indd 1 26/9/12 10:49 AM

Contents

unpacking .......................................................................................................................................... 3

product overview ............................................................................................................................ 4

front view...................................................................................................................................................................... 4

top view......................................................................................................................................................................... 4

rear view........................................................................................................................................................................ 5

bottom view................................................................................................................................................................. 5

LCD display window.................................................................................................................................................. 6

remote control ............................................................................................................................................................ 7

operating your remote control...................................................................................................... 8

remote control operation range.................................................................................................... 8

power sources ................................................................................................................................... 9

mains power ................................................................................................................................................................ 9

installing the batteries.............................................................................................................................................. 9

basic operation ............................................................................................................................... 11

powering ON/OFF....................................................................................................................................................11

selecting modes .......................................................................................................................................................11

adjusting the volume..............................................................................................................................................11

setting the clock .......................................................................................................................................................11

setting the alarms ....................................................................................................................................................12

activate/ deactivate alarm timer.........................................................................................................................12

snooze alarm..............................................................................................................................................................12

set sleep timer...........................................................................................................................................................12

radio operation ............................................................................................................................... 13

tuning into stations.................................................................................................................................................13

storing stations automatically.............................................................................................................................13

selecting preset stations........................................................................................................................................13

iPod / iPhone / iPad operation ..................................................................................................... 13

listening to iPod / iPhone / iPad .................................................................................................. 14

charging the iPod / iPhone / iPad.......................................................................................................................14

AUX operation................................................................................................................................. 14

bluetooth operation ...................................................................................................................... 14

pairing Bluetooth-enabled devices...................................................................................................................14

listening to music from the bluetooth device........................................................................... 15

maintenance.................................................................................................................................... 15

hints and tips................................................................................................................................... 16

specications................................................................................................................................... 17

safety warnings............................................................................................................................... 18

iCRIPBT12_IB_RC_120926_Zell.indd 2 26/9/12 10:49 AM

If items are missing or damaged, please contact Partmaster (UK only).

Tel: 0844 800 3456 for assistance.

unpacking

Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so

according to local regulations.

The following items are included:

Thank you for purchasing your new iWantit bluetooth clock radio with docking.

We recommend that you spend some time reading this instruction manual in order that you fully

understand all the operational features it oers. You will also nd some hints and tips to help you

resolve any issues.

Read all the safety instructions carefully before use and keep this instruction manual for future

reference.

The Main Unit

3.5mm to 3.5mm AV Cable Instruction Manual

Remote Control

iCRIPBT12_IB_RC_120926_Zell.indd 3 26/9/12 10:49 AM

product overview

front view

top view

1. IR Sensor

Detects signals from the remote

control.

2. LCD Display

Shows the current mode or time.

1 32

3. Bluetooth Indicator

• Flashes blue once a second during

pairing mode.

• Lights up solid blue and unit beeps

when paired or connected with a

compatible Bluetooth device.

1. iPod / iPhone / iPad Dock

2. SLEEP Button

Sets the sleep timer.

3. CLOCK Button

Sets the clock time in 12 hour or

24 hour mode.

4. STANDBY Button

Switches the unit between ON and

STANDBY.

5. TUNING Buttons

• Searches the current track.

• Tunes in to a radio station.

• Adjust the time.

6. ALARM 1 / ALARM 2 Buttons

• Sets either the 1st alarm or the

2nd alarm, or both alarms.

• Turns o the alarm(s).

• Views alarm settings.

7. + VOLUME

Buttons

Adjusts the volume.

8. SOURCE Button

• Selects a media input source: FM

Tuner, AUX, iPod/iPhone/iPad or

Bluetooth.

9. PRESET Button

• Skips to the previous/next track.

• Selects a preset radio station.

10. SNOOZE Button

• Start or pause iPod/iPhone/iPad

playback.

• Switches o alarm temporarily.

iCRIPBT12_IB_RC_120926_Zell.indd 4 26/9/12 10:49 AM

rear view

bottom view

You can only use the AC adapter for the power supply.

Batteries (not supplied) are used to remember the clock setting if the mains power is

interrupted.

1 32

1. Mains Power Cable

2. FM ANT

FM Aerial for FM radio reception.

3. LINE IN

Socket for an external media source.

To insert the batteries:

1. Open the battery compartment.

2. Insert 2 x AA 1.5V batteries (not included) with the correct polarities (+/-) as indicated.

3. Close the battery compartment.

• Remove batteries if they are exhausted or will not be used for a long time.

• Batteries contain chemical substances, so they should be disposed of properly,

according to local regulations.

• Risk of explosion! Keep batteries away from heat, sunshine or re. Never discard

batteries in a re.

iCRIPBT12_IB_RC_120926_Zell.indd 5 26/9/12 10:49 AM

LCD display window

1. SNOOZE Indicator

2. ALARM 1 Indicator

3. PM Indicator

4. FM Radio Indicator

5. ALARM 2 Indicator

6. iPod / iPhone / iPad Indicator

7. LINE IN / AUX IN Indicator

z Z

iCRIPBT12_IB_RC_120926_Zell.indd 6 26/9/12 10:49 AM

9. FM Button

Selects the FM radio mode.

10. BLUETOOTH Button

Selects the Bluetooth source.

11. MENU/DIM Button

• Selects the iPhone/iPad menu

(may not select the iPod menu).

• Adjusts the display brightness:

Dim / Normal / Bright.

12. MUTE Button

Mutes and restores the volume.

13. SLEEP Button

Sets the sleep timer.

14. VOLUME + / - Buttons

Adjusts the volume.

remote control

1. STANDBY Button

Switches the unit between ON and

STANDBY.

2. OK

Conrms selection.

Buttons

• Scrolls up/down.

• Selects a preset radio station.

Buttons

• Searches the current track.

• Tunes into a radio station.

• Adjusts the time.

3. SNOOZE Button

• Starts or pauses iPod/iPhone/

iPad playback.

• Repeats the alarm.

4. DOCK/LINE IN

• Selects the iPod/iPhone/iPad

source.

• Selects an external media

source.

5. CLOCK/PROG Button

• Sets the clock time.

• Displays the clock time.

• Programmes radio stations.

6. S-BASS Button

• Turns on or o super bass

enhancement.

7. P-EQ Button

• Selects a preset equalizer

setting.

8. ALM 1 / ALM 2 Buttons

• Sets 1 or 2 or both alarms.

• Turns o the alarm(s).

• Views alarm settings.

iCRIPBT12_IB_RC_120926_Zell.indd 7 26/9/12 10:49 AM

operating your remote control

The remote control requires a CR2025, 3V Lithium battery

1. Press and slide the battery cover to open the battery compartment of the remote

control.

2. Pull out the battery holder and remove the old battery.

3. Replace with a new battery.

4. Insert the battery holder back into the remote control.

remote control operation range

• The remote control sensor on the front unit is

sensitive to the remote control’s commands

up to a maximum of 5 metres away and within

a maximum of a 60° arc.

• Please note that the operating distance may

vary depending on the brightness of the

room.

Remove the Plastic Strip from the Remote Control

Remove the plastic strip from the battery if the

battery is being used for the rst time. It is located

at the bottom rear side of the remote control.

30° 30°

Max. 5 m

iCRIPBT12_IB_RC_120926_Zell.indd 8 26/9/12 10:49 AM

power sources

mains power

Connect the mains cable to the mains

socket on wall.

• Ensure the mains power is switched

on. Your unit is ready to use.

installing the batteries

You can only use the AC adapter for the power supply.

Batteries (not supplied) are used to maintain the unit’s settings if the mains power is

interrupted.

1. Open the battery compartment.

2. Insert 2 x AA 1.5V batteries with the correct polarities (+/-) as indicated.

3. Close the battery compartment.

• Remove batteries if they are exhausted or will not be used for a long time.

• Batteries contain chemical substances, so they should be disposed of properly,

according to local regulations.

• Risk of explosion! Keep batteries away from heat, sunshine or re. Never discard

batteries in a re.

Unplug the unit from the mains

power when not in use.

iCRIPBT12_IB_RC_120926_Zell.indd 9 26/9/12 10:49 AM

handling the batteries

• Improper or incorrect use of batteries may cause corrosion or battery leakage, which

could cause re, personal injury or damage to property.

• Install the battery correctly in the battery compartment. Normally the battery’s positive

polarity (+) will face up.

• When the battery is exhausted, the remote control will not function.

• Only use the battery type indicated in this manual.

• Do not dispose of the used battery as domestic waste. Dispose of it in accordance with

local regulations.

• Small button cell batteries such as the one used in the remote control are easily

swallowed by young children and this is dangerous. Keep loose button cells away from

young children and make sure that the battery is secure in the remote control. Seek

medical advice if you believe a battery cell has been swallowed.

Handling the Remote Control

• Be aware of your ngernails when removing the battery cover and the battery.

• Do not drop the remote control.

• Do not allow anything to impact the remote control.

• Do not spill water or liquid on the remote control.

• Do not place the remote control on a wet object.

• Do not place the remote control under direct sunlight or near sources of excessive

heat.

• Remove the battery from the remote control when not in use for a long period of time,

as corrosion or battery leakage may occur and result in physical injury, and/or property

damage, and/or re.

iCRIPBT12_IB_RC_120926_Zell.indd 10 26/9/12 10:49 AM
