User Guide
Heat • Vent • Light
Eco Tastic®
Model: 11341 Eco Triumph
Model: 12343 Eco Sensation
Model: 12341 Eco Silhouette
Electrical Rating: 230~240 V. 50 Hz.
Model: 12341 Eco Silhouette
Model: 12343 Eco SensationModel: 11341 Eco Triumph
2
Welcome
Thank you for buying this IXL Eco Tastic. Even if you have used a Tastic before, there are very good
reasons to read this user guide before using this one:
• Youandyourfamily,propertyandhomewillbesafefromharm.
• Youwilllearnhowthisappliancemaydifferfromothers.
• ByusingtheTasticfullyandproperly,youwillgetmaximumlifeandvaluefromit.
• OurwarrantydependsonyouusingtheTasticaccordingtothisuserguide.
Itwillonlytakeyouafewminutes,sopleasereadon!
Contents
Eco Tastic Range ............................................................. Pg 3
Safety ............................................................................... Pg 4
How it Works ................................................................... Pg 5
Ventilation Requirements................................................ Pg 6
Clearances ....................................................................... Pg 7
Flat Roof Installations (with insufficient clearances) .... Pg 8
Electrical Requirements .................................................. Pg 8
Wiring Diagrams........................................................ Pg 9-10
Installation................................................................Pg 10-11
Replacement Lamps...................................................... Pg 12
Cleaning ......................................................................... Pg 12
Troubleshooting ........................................................Pg 13-14
Products......................................................................... Pg 15
Warranties.................................................................Pg 16-17
Record Your Model ........................................................ Pg 18
Notes .........................................................................Pg 18-19
Model: 11341 Eco Triumph
Eco Tastic Range
Tastic®
11341 Eco Triumph
2x275WHeat,Vent&Light
15WCFLCentreGlobe
Cutout Template Supplied
200mmFan,257m3/hror72l/s
12343 Eco Sensation
4x275WHeat,Vent&Light
15WCFLCentreGlobe
HalfHeatFunction
Cutout330mmx330mm
200mmFan,348m3/hror97l/s
12341 Eco Silhouette
4x375WHeat,Vent&Light
15WCFLCentreGlobe
HalfHeatFunction
Cutout330mmx330mm
200mmFan,396m3/hr or 110l/s
Model: 12343 Eco Sensation
Model: 12341 Eco Silhouette
4
Safety
Tastic®
NOTE: This product must be installed by a qualified installer.
Read through these instructions completely before commencing installation.
The infra-red lamps heat by direct radiation rather than by heating the air in the room, so the Tastic
shouldbelocateddirectlyoverwheredryingoffoccurs.
LocatetheTasticinaccordancewiththerequirementsofthecurrentAustralian/NewZealandWiring
RulesAS/NZS3000relatingtodampsituations.
In some installations this may mean that no part of the Tastic may be located directly above any part of
abathorshowerrecessorenclosure.
ForunenclosedshowersrefertoWiringRulesconditions.
Switchesandothercontrolsmustnotbelocatedwheretheycanbetouchedbyapersoninthebath
orshower.
NOTE: Tastic products must only be installed horizontally in ceiling.
•Donotlookdirectlyintoheatlampswheninuse.
•Tasticproductsarenottanninglamps.
•
MakesurethelampshavecooledandpowerisofftotheTasticbeforeremovinglampsforreplacement.
•Donotoperatethisappliancewithouttheplasticlampsurroundinposition.
•Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensory
ormentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervision
or instruction concerning use of the appliance by a person responsible for their safety.
•Youngchildrenshouldbesupervisedtoensuretheydonotplaywiththeappliance.
•Thisappliancemustbemountedwiththelowestpointatleast2.1metresfromtheoor.
WARNING:Curtainsorcombustiblematerialmayigniteifincontactwiththeheater.
SAFETYFEATURES
Thermal switch:
WhenEcoTasticworksinFANOFFmodeandthetemperatureinsidetheunitreaches55°C,the
thermalswitchwillswitchonthefanautomatically.Whenthetemperaturedrops,thethermalswitch
willswitchoffthefan.
Thermal fuse:
Whenforanyreasonthetemperatureinsidetheunitreaches93°C,thethermalfusewillcutoffpower
to the Eco Tastic. In such a case the Service Centre should be called to replace the thermal fuse.
Do not allow insulation material to rest against the sides or top
of the Tastic unit when installed. This Tastic must not be installed
where there is a possibility of water splashing on to the lamps.
There is no IP rating on any IXL Tastic.
How it Works
Tastic®
TheIXLTasticrangehasbeendesignedtoexactingstandardstogiveyoumanyyearsoftrouble-free
operation.ToensureyougetthemostfromyourTasticthereareafewsimplepointstokeepinmind.
HEATLAMPS
TheIXLTasticHeatLampshavenowarmupperiodbecausetheinfraredlampsprovideinstantaneous
heat,andaredesignedtoheatyouandnotyourbathroom-that’stheefcientwayinfraredheat
works.You’llsavemoneyandenergy,withanaveragecostofaroundonecentashowerifused
correctly,(basedonaverage5minutedryingtime).Also,togetthefullbenetofTastic’sinfrared
warmth,standdirectlyundertheheatlamps.IXL’sexclusiveclearheatlampshavebeendesigned
specicallyforthisapplication,andconcentratetheirheatformaximumeffectiveness.
Make sure you have the Tastic model that suits your bathroom ceiling height. This Tastic is
manufacturedtoofferpeakperformancewithbathroomceilingheightsupto2.4mfortheTriumph
11341,2.7mfortheSensation12343and3.3mfortheSilhouette12341.
TheTastichalfheatfunctionisavailableonthe4lampmodels,andisanotherenergysaver,allowing
you to adjust the heat level to suit prevailing conditions or personal preference.
VENTILATION
Toensureoptimumperformanceoftheexhaustfan,itisessentialthatthereisadequateairowinto
yourbathroomtohelptheTastic’spowerfulandefcientexhaustfantoquicklyremovesteamwhile
youshower.YourTasticworksbydrawingsteam-ladenairfromtheroom,andaswithallexhaustfans
itisessentialthatsufcientairinletisprovided.Ensureadequateinletsexistthroughwindows,vents
orunderthedoor.Airowpathfrominlettofanshouldideallypassoverthesteamsource.
CENTRELIGHT
The centre light in all Tastic models is designed to provide general illumination in your bathroom.
Forspecictaskslikeshavingorputtingmake-upon,youmayneedextralightingtosuityour
individual needs.
Heat lamps can also be used to provide additional bright illumination for your bathroom. Lighter
colouredwallsanddecoralsohelpbrightenyourbathroombyreectingmorelight.
6
Ventilation Requirements
Tastic®
Formaximumefciencyandfanperformancethere
areafewkeypointstokeepinmindwheninstalling
your Tastic.
Sufficient air inlet into room
Steamwillonlyberemovedifthereissufcientow
ofairthroughtheroom.Ensuregenerousinletsexist
throughwindows,ventsorunderthedoor.Airow
path from inlet to fan should ideally pass over the
steamsources(seeFig.1).
Adequateventilationinroofcavity
Itisessentialthatthereisadequatespacewithin
theroofcavitysothatexhaustairfromtheTastic
candissipate.Wherespaceisrestricted,useFig.3
as a guide to minimum requirements for adequate
ventilation.
Theroofcavityitselfshouldbewellventilatedto
outside so that moist air can be removed. Local
buildingcodesmayrequireueingtooutsidethrough
rooforasperFig.5(page8)foratroofinstallation.
Whereventilationspaceisrestricted
This product is not recommended for installation
betweenoorsofmulti-storeydwellings,orwhere
spacewithintheroofcavityisseverelyrestrictedand
aueasperFig.5cannotbetted.IXLhasother
Tastic products available that are particularly suited
toinstallationsbetweenoorsorwherespaceis
restricted. Contact your nearest IXL Service Centre
on the numbers located on the back of this booklet.
For further details and advice on ventilation products
and tips, visit the IXL Ventilation Selection Guide on
our website: www.sampfordixl.com.au
Fig. 1: Ideal placement of Tastic.
Sufficient air inlets into room are required
Clearances
Tastic®
Allappliancesmustbemountedsothatthelowest
pointisatleast2.1mabovetheoor.Aminimum
clearanceof75mmforModel11341and90mm
forModels12343&12341isrequiredabovethetop
oftheTasticwheninstalledinawellventilatedroof
cavity.Whereventilationisrestricted,thisclearance
should be increased by a minimum of 25 mm.
Additionally,aminimumof15mmclearanceis
requiredbetweenthetwoverticalsidesoftheTastic
and any adjoining parts of the roof structure, such as
walls,joistsorinsulationbatts.
Figure 3 measurement A :
ModelNo11341
75mmmin.wherethereisgoodventilationtothe
sides of the unit.
100mmmin.whereventilationtothesidesofthe
unit is restricted.
ModelNo’s12341&12343
90mmmin.wherethereisgoodventilationtothe
sides of the unit.
115mmmin.whereventilationtothesidesofthe
unit is restricted
Figure 3 measurement B:
ModelNo11341
290 mm.
ModelNo12341
220 mm
ModelNo12343
220 mm.
Figure 3 measurement C:
15mmmin.clearanceonthetwoverticalsides.
Figure 4 measurement D:
35mmmin.clearancerequiredwhenusingthe
inbuilt clip fasteners.
Fig. 2: Adequate open space in the roof cavity
is required
Fig. 3: Minimum clearances for installation
Fig. 4: Joist clearances
A
D
C
Flaps
Fasten with 2 screws
B
Electrical Requirements
8
Flat Roof Installations
Tastic®
Seethewiringdiagramsonthefollowingpagesforsupplyrequirementsandmaximumloadingsfor
eachmodel.Tasticsmaybeconnectedtoalightingorpowercircuitifloadingpermits.Thesemodels
areforwired-ininstallationandwiringmustbecarriedoutbyaregisteredelectrician.*Switchesand
awallplateareprovidedwiththeTastic,attachedtotheunit.Removethelampsurroundforaccess.
Donotusethisproductwithanysolidstatespeedcontrolorcommercialdimmingdevice.
IMPORTANT: To ensure correct and safe operation of the Eco Tastics it is not recommended to use a
secondexhaustfanwiththeTastic.Ifasecondexhaustfanistobeuseditmustbewiredsothatitis
controlledbythesamefanswitchastheTastic,seecircuitdiagrams.
NOTE:“S/WAFAN-LOW”connectionisthepermanentactivesupplytotheunit.Itmustbeprovided
sotheunitcanfunctionasitwasdesignedtodoso.
*Number of switches depends on your Tastic model.
Wheninstallingintoaatroofwithinsufcient
clearance,orwhereceilingcavityventilationis
restricted,anexternalventingductmustbeinstalled.
UseFig.5(atleft)asaguidetominimum
externaloutletrequirements.
IMPORTANT:Donotattachtheducttothebodyof
theTastic.Allowfor10-20mmminimum
gapbetweentheTasticandtheendoftheduct.
235mm
DUCT
100mm
Do not attach
Ensure flue does
not prevent flaps
from opening
duct to body
230mm
Tastic unit
Top of
Roof
Fig. 5: Minimum external outlet requirements
Tastic units are fitted with a CFL centre lamp. To ensure
correct operation and to prolong the life of the CFL please wire as
per the following wiring diagrams for the appropriate model.
Wiring Diagrams
Tastic®
EARTH
11341: 2.5A 50Hz
ACTIVE
NEUTRAL
C
C
C
2
2
2
1
1
1
S/W FAN LOA
S/W FAN HIA
S/W LIGHTA
S/W HEATA
Terminal
Block 5 way
Earthing Terminal ( Screw M4)
Thermal Switch
Thermal Fuse
330 Ohm 20 W
Ceramic Resistor
CFL GLOBE
Heat Lamps
Fan
Motor
Second
Fan
Isolating switch must
be installed as
per AS/NZS 3000
(not supplied)
12341: 6.5A 50Hz, 12343: 4.8A 50Hz
ACTIVE
EARTH
NEUTRAL
C
C
C
C
2
2
2
2
1
1
1
1
Terminal
Block 7 way
Thermal Fuse
Thermal Switch
330 Ohm 20 W
Ceramic Resistor
Terminal
Block 2 way
Heat Lamps
Heat Lamps
CFL Globe
Fan
Motor
Second
Fan
S/W A FAN LO
S/W A LIGHT
S/W A HEAT
S/W A HEAT
S/W A FAN HI
Isolating switch must
be installed as
per AS/NZS 3000
(not supplied)
Fig. 6: Wiring diagram for model 11341. Centre Lamp may be a CFL.
Fig. 7: Wiring diagram for model 12341 & 12343. Centre Lamp may be a CFL.
TheTasticmaybeinstalledbetweenjoistsusingtheinbuiltclipfasteners.Alternatively,theunitcan
beinstalledagainstajoistusingtwoscrewsthroughholeslocatedintheange(Fig.4onpage7),
providedthattheclearancesforthetwoverticalsidesaremaintainedasperFig.3onpage7.
Dependingonyourmodel,theTastichasaweightof2–3.5kg(seebelow).Ifadequatesupportisnot
availablefortheTastic,itmaybenecessarytoprovideextrastrengthening.
EcoTriumph–approx2kg
EcoSensation/EcoSilhouette–approx3.5kg
IMPORTANT:
Joists, beams and rafters shall not be cut or notched to install the appliance.
FittingTriumphBackDraughtFlaps
10
Installation
Tastic®
Back draught collar is fitted
upside down when packed.
Thicker rim of back draught
collar should now face
towards Tastic body.
Lift back draught collar up.
Fit back draught collar
to Tastic.
Turn the back draught
collar over.
Attach back draught flaps so
that they open outwards away
from the fan as pictured.
Dieses Handbuch passt für folgende Modelle
5
Inhaltsverzeichnis
Beliebte Beleuchtungsausrüstung Handbücher anderer Marken
Qazqa
Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung
Commercial Electric
Commercial Electric 54568141 Bedienungsanleitung
CREE LIGHTING
CREE LIGHTING 304 Series Bedienungsanleitung
Goobay
Goobay 49867 Bedienungsanleitung
ECOMAN ITALIA
ECOMAN ITALIA LED T8 Bedienungsanleitung
Alkalite
Alkalite Krypton KT-81 Bedienungsanleitung
