110 Zone Controller
Installation and User
Manual
Section Description Page No.
1.0 Installation 3
1.1 Standard wiring layout 3
1.2 Installation instructions 4
2.0 System initialisation 5
3.0 System configuration 6
3.1 Set the number of zones required 6-7
3.2 Set the number of electronic constants required 6-7
3.3 Testing and Labelling 6-7
4.0 User manual 8
5.0 Further assistance 10
Table of contents
2
3
1.1 Standard wiring layout
C110MC
iZone 110 Master Controller
CZDA
Zone 3
Zone 2
Zone 4
Zone 6
Zone 5
CT24AC
6 Zone system with 2 wall controllers shown.
A maximum of 6 zones and 2 wall controllers can be supported by one iZone 110
system
Zone 1
C110WC
C110WC
4
1.2 Installation instructions
1. The C110MC can be installed on top of the indoor fan coil unit.
2. Do not run the blue network cables alongside 240 Volt wiring.
3. When installing network cables down wall cavities or chasing network cables into walls, tape up and protect the RJ45 connector to avoid
damage to the connectors.
4. Always install zones in consecutive ports starting at Zone 1. The back of the C110MC is marked with the zone port numbers.
5. Do not directly hardwire the CT24AC into the AC unit’s power supply. This may void the warranty as it will require an electrician in the
event that repair of the iZone 110 system is required.
6. Connect Zone Damper Actuators (CZDA) to the zone ports using the RJ11 cables as shown.
7. Connect the Wall controller(s) (C110WC) to the C110WC ports using the RJ45 cables.
8. Only connect the power supply to the CT24AC port after all components have been connected.
5
2.0 System initialisation
All new or modified systems must be initialised
prior to system configuration.
To initialise the system press the button on the
underside of any wall controller. This button is
recessed so you will need to use a pen to
press the button.
The time to initialise the system will vary
depending on the number of motors
connected.
The system will also initialise when power is
restored after a power failure.
Using a pen, press the buon on the
underside of the screen.
Master
Study
Lounge
Kitchen
Guest
Family
6
3.0 System configuration
WARNING ! Only qualified iZone 110 installers should configure the iZone 110 System. Incorrect configuration could result in
damage to your air conditioning unit and system.
3.1 On the C110MC, set the number of active zones required on the 6 position dip switch. By moving the associated dipswitch
up the respective zone will be deactivated and conversely by setting the dipswitch down (ON), the associated zone will be
activated. The factory setting is all 6 zones activated.
3.2 On the C110MC set the number of electronic constants you require to ensure the safe operation of the system.
An electronic constant is a safety feature and ensures that a predetermined number of zones remain open at all times even
if all the zones are switched off. If 1 electronic constant is selected, Zone 1 will automatically open if all the zones are
closed. If 2 electronic constants is selected, Zone 1 and 2 will automatically open if all the zones are closed. Only set the
number of electronic constants to 0 if the system is an old fashioned design with at least one supply air outlet that is not
zoned.
3.3 Set the AC unit fan speed to high and close all zones. Open one zone at a time and check which room the air is being
supplied to. Label the zone using the stickers provided, being care full to place the sticker squarely in the recess provided.
Peel off the protective coating from the sticker.
7
3.1 & 3.2 Set up number of zones & electronic constants required
As an example the diagram sho s 4
ac!ve zones
C110MC
——
Zone 1 ——
Zone 2 ——
Zone 5 ——
Zone 3 ——
Zone 4 ——
Zone 6 ——
CT24AC —
— C110WC
— C110WC
N29007
Installation Instructions
1. Connect Zone Damper Actuators (CZDA) to the Zone ports
using the RJ11 cables.
2. Connect the Wall Controllers (C110WC) to the ports using
the Blue RJ45 cables.
3. Select the number of active zones required on the dip
switch.
4. Select the number of electronic constant zones required.
5. Connect the power supply to the(CT24AC) port.
1 2 3 4 5 6 ON
—— 1
—— 0
—— 2
Electronic
Constant Zones
required
Active
Zones
Set number of zones on the dips itch
on the side of the C110MC box
Set number of electronic constant zones
required on s itch on the side of the
C110MC box
As an example the s itch is sho n
selec!ng 1 electronic constant
Master Bed
Bedroom 1
8
3.3 Testing and Labelling
Label the zone accordingly
S itch all zones OFF and one zone
ON. Check hich zone is being
supplied ith air.
Master Bed
Lounge
Kitchen
Family
Guest
Bedroom 1
4.0 User manual
9
Press the silicone buon to
s itch zones on and off
The LED ill illuminate hen
the zone is on
5.0 Further assistance
10
1. If you require warranty or repair on your air conditioning system or iZone system you should contact your installation company.
2. If you want to add more zones you should contact your installation company.
3. If your require assistance operating your iZone contact:
Airstream Components
www.air-stream.com.au
Phone 08 6254 2408
