J5 create JUC100 New Version Bedienungsanleitung

JUC100

User Manual

Manuel de l'utilisateur

Bedienungsanleitung

Manual del usuario

使用手冊

ユーザーマニュア

Wormhole Switch

JUC100 －New Version

JUC100

Wormhole Switch

JUC100 －New Version

User Manual

WORMHOLE SWITCH USER MANUAL

FUNCITON LIST

Function Behavior for Operation

System

Windows

Android

Windows

iPad

Keyboard & Mouse Control Switching

Use Mouse Middle button

Yes

Yes*

Use Mouse Move off the edge of

screen

Yes

Hotkey Toggle [Alt+S]

Yes

Yes*

Keyboard Control Sharing

Yes

Yes**

Yes

Clipboard Sharing

Text Share

Yes

Picture Share

Yes

Data Transfer

Drag and Drop

Yes

File Shuttle

Yes

Note for Android User:

*Some Android platforms and iPad don’t support a cursor function. In that case, the

JUC100 can only share the keyboard and not the mouse.

**When Android OS tablet is connected, the keyboard sharing will be active, but only

Roman Alphabet is supported by Android.

Required Environments

Microsoft: Windows 8 , 7, Vista, XP, 2000 SP3 (32-bit or 64-bit)

Available USB port (USB 2.0 is recommended)

Android: 3.1, 3.2, 4.0↑

Available USB port (USB OTG)

iPad: USB Connection Kit

GETTING STARTED

Follow the below steps to configure the j5 Wormhole Switch

1.Connect one end of the Wormhole Switch to a standard USB

port on one of the two computers

2.Connect the other end of the Wormhole Switch to a USB port

on the second computer. (Please see below pictures)

WORMHOLE SWITCH USER MANUAL

3. The device will automatically start Wormhole Switch software

installation on both computers

4. Window might open “AutoPlay” options. Please Click on The

option “Run WKMLoader.exe”

5. If the “User Account Control”

window appears on the screen,

Click “Yes” to continue.

6. When you see the pop-up message appear at the bottom right

of the screen then you are ready to operate the Wormhole

Switch application.

Troubleshooting:

If auto-run is not launched, please follow the step below to start the j5 Wormhole

Switch application:

1. Check each connector on the USB cable that it is correctly

inserted on your two computers.

2. Go to My Computer and double-click the j5 Wormhole

Switch icon to start the application ( ).

WORMHOLE SWITCH USER MANUAL

EXPLORE THE OUTSTANDING FEATURES

After configuring the settings on the previous section, you can start

playing your Wormhole Switch and enjoying the convenience it

brings to you.

Sharing Keyboard and Mouse

oMove mouse cursor between two displays intuitively and

seamlessly.

A.Use mouse to move off the edge of the screen

Choose “left side of this pc” in Preferences. Now you can move

the mouse cursor across the left edge of the display to switch the

mouse between the two Windows OS computers.

B. Hotkey Toggle

Press both (Alt+S) buttons on the keyboard to activate the control

switching. To switch back, just press both (Alt+S) buttons again.

C.Use Mouse Middle Button

Click the middle button of the mouse to switch the keyboard and

mouse control from Windows to Android. To switch back, just click

the middle button again.

oSwitch the Keyboard usage to another computer

Move the mouse cursor to the second computer and open any

Editing applications such as word, excel, power point, etc. and

use the keyboard of the first computer to type the text on the file

WORMHOLE SWITCH USER MANUAL

of the second computer.

Note: Recommendation when additional keyboard/mouse is

plugged-in: A Third set of USB Mouse and keyboard must be used

in combination when connected to an open USB port on the

wormhole docking station.

When using a Non-Combination set of USB Mouse or Keyboard, the

wormhole docking station will default to its limited screen switching

function mode only.

*When switching the keyboard or mouse control to another

computer, the ( ) icon appears at the bottom right of the screen.

Clipboard Sharing

With the clipboard sharing feature you can easily edit copy or

paste clipboard content bi-directionally.

1. Open a file and select the content (text/ pictures) you want in

the first computer, and right-click and select “Copy”.

2. Move the cursor to the second computer, and open any file

3. Move the cursor to the location you want to place the

Content (text/ pictures), and right-click and select “Paste

* When receiving clipboard data from another computer, the

( ) icon appears at the bottom right of the screen.

WORMHOLE SWITCH USER MANUAL

File Transferring

oDrag & Drop: It is an easy and fast way to transfer files

between 2 computers. Just drag and drop the file or folder to

the other computers.

oCopy & Paste:

1. Use Mouse Right-click on the files that you want to

copy and select Copy

2. Move the cursor to the other computer

3. Move the cursor to the location that you would like to

place the file, and Right-click on mouse, then select

Paste

oHotkeys (Shortcut on Keyboard) :

1. Click on the files that you would like to copy, and press

the (Ctrl+C) Keys

2. Move the cursor to the other computer

3. Move the cursor to the location that you would like to

place the files, and press the (Ctrl+V) Keys to paste the

copied files to another computer.

WORMHOLE SWITCH USER MANUAL

oFile Shuttle () :

The bar description

Keyboard sharing for iPad

Due to the lack of a USB port on the iPad, you will need a “USB

connection kit” to connect the Wormhole Switch and other Computer.

Please follow the steps below:

1. Connect USB connection kit to iPad connector

2. Connect Wormhole Switch to a computer and an iPad

3. Press “Alt+S” on computer to switch the usage of Keyboard to iPad

4. You can touch the screen on the iPad to the location you want to

start.

5. Now, you are ready to type on the iPad.

Active Information

Simply Drag a file from your computer to here. The file

will copy to the destination of another computer.

Minimize

Option

Computer Icon

The bar

Guider

File List

WORMHOLE SWITCH USER MANUAL

SOFTWARE INSTRUCTIONS

Wormhole Switch Utility Icon Function

To begin set up, please click the Wormhole Switch Utility Icon( )

oFile Shuttle:

It is a user-friendly and simple operation with a data transmission

software interface, which combines high speed transmission with

nontechnical requirements. File Shuttle allows you to easily

transfer and share data between two computers.

oThe Position of Other PC:

You can quickly set up the position of the other computer by

using one of the 4 options (Right/Left/Up/Down)

oDisable (Enable) the Keyboard and Mouse Control Temporarily&

Disable (Enable) Clipboard Share Temporarily:

You can quickly Disable or Enable sharing option.

If Disabling one of those functions temporarily, the icon ( ) will

be shown.If Disabling both functions temporarily, the icon ( )

will be shown.

oPreferences:

You can change your preferences in the "Wormhole Switch

Preference Setup". Your settings will be saved every time you

restart your computer.

* For detailed function settings, please refer to “Preference setup”

WORMHOLE SWITCH USER MANUAL

oOnline Update

Check and update the latest version of software for Wormhole.

1. Please make sure your network is available and Do Not unplug

the Wormhole during the driver update.

2. Remove the Wormhole cable from the slave computer.

3. Select “Online Update”

4. After you have finished the installation process, re-plug the

Wormhole device into both computers.

oAbout the Wormhole Switch:

Information about the j5 create Wormhole Switch can be found

here.

oQuit USB Switch / Exit:

The Wormhole device can be uninstalled in the Confirmation box.

PREFERENCES SETUP:

This selection allows you to change your preferences. When you select

Preferences, the window below will pop up.

Keyboard & Mouse Control Switching Settings

This option allows you to switch the control of the keyboard and

mouse from one computer to another.

oTurn Off

Disable Keyboard and Mouse Control Switching Sharing.

oUse Mouse to Move Off the Edge of Screen:
