gallery™ 5 pure air®ll bath

model number: Y900

exterior dimensions:

62" long x 43" wide x 19" high

interior dimensions:

41" long x 26" wide

operating gallons:

38 gallons

The Gallery™ is a work of art a clean,

stylish well of relaxation, ideal for quiet

contemplation.

features:

• Exclusive 360º Balanced Airﬂow™ system

• 600 watt variable speed heated air blower

• Thermal Lumbar Comfort (TLC)™

• Timed purge cycle

• Safely use salts and aromatic oils

• PrO

™

Cleansing System

Detail: Air channels soothe the body. Effervescent

bubbles uplift the mind. And in the Gallery™ Pure

Air ll®bath, elegant, traditional styling entices the

designer in all of us.

gallery™ 5 pure air®ll bath

the gallery—an artful experience. the gallery™ pure air®ll bath—the art of hydrotherapy

Gallery™ 5 Pure Air® II Bath

Model: Y900

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

Ordering Information

Product Code:

Y900 Gallery™ 5 Pure Air® II Bath

Left Hand

• Left Hand Drain Location

• Accessories / Hardware:

Trim Kit Rotary: #BN21

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(845) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

62” L x 43” W x 19” H

(1575 mm) L x (1092 mm) W x (543 mm) H

Drain/Overﬂow

A: 14-3/4” (375 mm) B: 9-1/2” (241 mm)

Cutout

Template Provided P/N P186000

Total Weight

671 lb (304 kg) / 36 lb/sq. ft. (176 kg/m2)

Operating Gallonage

38 U.S. Gal. (144 Liters)

Product Weight

104 lb (47 kg)

Skirt Mounting

Not Available

Electrical Speciﬁcations

Requires a dedicated GFCI protected separate circuit.

Blower: 120 VAC, 15 AMP, 60 Hz.

Heater

No water heater is available on this unit. Blower has integral air heater.

62"

21-1/2"

43"

12" x 4"

9-1/2"

Blower

12" H x 18" L

Service Access

END VIEW

SIDE VIEW

(51 mm) (Blower)

#FR54 07/07

DRAIN/OVERFLOW

Product Shown: Gallery™ 5 Pure Air II™ Bath Left Hand Shown Model: Y900

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
