luxura™ 5 whirlpool bath and soaking bath with 3 tile ﬂange

luxura means, quite literally “luxury”—and what more could you ask? simply, your water never felt this good.

Perfectly stylish in contemporary

décors, but wonderfully relevant in

more classic settings, the Luxura®bath

is both a restorative and retroﬁt dream.

features:

• Contoured backrest.

• 4 Fully adjustable TheraPro™ jets

• 2 AccuPro™ foot jets.

• Exclusive Tru-Level™ base system.

• Slip-resistant bottom.

• Patented Silent Air™ Induction system.

• Drain included on whirlpool baths

luxura™ 5 (with 3 tile ﬂange)

whirlpool bath

model number: F941 - LH, F942 - RH

exterior dimensions:

60" long x 32" wide x 20¼" high

interior dimensions:

44½" long x 20" wide

# of Jets/type of Jets:

4 TheraPro™ Jets,

2 AccuPro™ Foot Jets

operating gallons:

44 gallons

luxura™ 5 (with 3 tile ﬂange)

soaking bath

model number: F943 - LH, H168 - RH

exterior dimensions:

60" long x 32" wide x 20¼" high

interior dimensions:

44½" long x 20" wide

Luxura™ 5 Whirlpool Bath with 3 Tile Flange

Model: F941, F942

Luxura™ 5 Bath with 3 Tile Flange

Model: F943, H168

Installation Notes

Refer to installation instructions included with ﬁxture before beginning installation.

Please conﬁrm product availability and speciﬁcations before commencing with any

installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE

WITHOUT NOTICE.

Electrical Components and Electrical Speciﬁcations do not apply to non-jetted baths.

Ordering Information

Product Code:

F942 Luxura™ 5 Whirlpool Bath with

3 Tile Flange Right Hand

F941 Luxura™ 5 Whirlpool Bath with

3 Tile Flange Left Hand

H168 Luxura™ 5 Bath with 3 Tile

Flange Right Hand

F943 Luxura™ 5 Bath with 3 Tile

Flange Left Hand

• Right and Left Hand Drain Location

• Accessories / Hardware:

Trip-Lever Drain Kit #X559

Rotary Drain Kit, 26” Cable #8730

HTC Jet Trim Kit: #D095

BMH Jet Trim Kit: #J869

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(845) – Oil Rubbed Bronze

Technical Speciﬁcations

Dimensions

60” L x 32” W x 20-1/4” H

(1524 mm) L x (813 mm) W x (514 mm) H

Drain/Overﬂow

A: 15-1/4” (387 mm) B: 8-1/4” (210 mm)

Cutout

Not Applicable

Total Weight

F941, F942: 697 lb (264 kg) / 52 lb/sq. ft. (255 kg/m2)

F943, H168: 672 lb (305 kg) / 50 lb/sq. ft. (246 kg/m2)

Operating Gallonage

44 U.S. Gal. (167 Liters)

Max. 50 U.S. Gal. (189 Liters)

Product Weight

F941, F942: 80 lb (36 kg)

F943, H168: 55 lb (25 kg)

Skirt Mounting

Optional, U-Frame

Electrical Speciﬁcations Models F941, F942 only

Requires a dedicated GFCI protected separate circuit.

Motor/Pump: 120 VAC, 15 AMP, 60 Hz.

RapidHeat™: 120 VAC, 15 AMP, 60 Hz.

Heater (Optional) Models F941, F942 only

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N S750000

2-1/2"

60"

16"

32"

12" x 5"*

8-1/4"

Motor

12" H x 18" L

Service Access

Opt. Service Access

2-1/2"

5-1/4"

END VIEW

(25 mm)

SIDE VIEW

#FR59 12/06

DRAIN/OVERFLOW

Product Shown: Luxura™ 5 Whirlpool Bath with 3 Tile Flange Left Hand Model: F941

* Measurements inside unit represent cutout in ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
