Riva®5

SOAKING BATH

MODEL NUMBER:

9360

EXTERIOR DIMENSIONS:

62" long x 43" wide x

19" high

INTERIOR DIMENSIONS:

41" long x 26" wide

Riva®5

WHIRLPOOL BATH

MODEL NUMBER:

9330 — Left-hand

EXTERIOR DIMENSIONS:

62" long x 43" wide x

19" high

INTERIOR DIMENSIONS:

41" long x 26" wide

# OF JETS/TYPE OF JETS:

4 TheraPro™ Jets,

1 AccuPro™ Lumbar Jet

OPERATING GALLONS:

48 gallons

Evoking the breathtaking beauty and ancient maritime

tradition of the northern Italian town for which it is

named, the Riva®is true to form—an elegant classic. And

truly versatile—at home in both traditional and more

contemporary interior design.

WHIRLPOOL BATH FEATURES:

• Sculpted armrest.

• Contoured backrest.

• 4 Fully adjustable TheraPro™ jets

• 1 Directionally adjustable AccuPro™ lumbar jet.

• Exclusive Tru-Level™ base system.

• Slip-resistant bottom.

• Patented Silent Air™ Induction system.

• Drain included on whirlpool baths

Riva®5 |WHIRLPOOL BATH and SOAKING BATH

Detail:

The Jacuzzi Magic Touch®control system makes customizing your

bath in the Riva®whirlpool bath easy. 4 massaging TheraPro™ jets

soothe sore, tired muscles.

Riva®5

WHIRLPOOL BATH

Technical Speciﬁcations

DIMENSIONS

62” L x 43” W x 19” H

(1575 mm) L x (1092 mm) W x (483 mm) H

DRAIN/OVERFLOW

A: 14-3/4” (375 mm) B: 9-1/2” (241 mm)

CUTOUT

Template Provided Part Number: P186000

TOTAL WEIGHT

9330: 746 lb (338 kg) / 40 lb/sq. ft. (197 kg/m2)

9360: 701 lb (318 kg) / 38 lb/sq. ft. (185 kg/m2)

OPERATING GALLONAGE

48 U.S. Gal. (182 Liters)

PRODUCT WEIGHT

9330: 96 lb (44 kg)

9360: 51 lb (23 kg)

SKIRT MOUNTING

Not Available

ELECTRICAL SPECIFICATIONS — MODEL 9330 ONLY

Requires a dedicated GFCI protected separate circuit.

Motor/Pump: 120 VAC, 15 AMP, 60 Hz.

RapidHeat™: 120 VAC, 15 AMP, 60 Hz.

HEATER (OPTIONAL) — MODEL 9330 ONLY

Requires a dedicated GFCI protected separate circuit.

RapidHeat™: P/N S750000

INSTALLATION NOTES

Refer to installation instructions included with xture before

beginning installation. Please conrm product availability and

specications before commencing with any installation work.

PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT

TO CHANGE WITHOUT NOTICE.

#FS10-000 05/08

9330

Riva 5 Whirlpool Bath, Left Hand

9360 Riva 5 Bath

• Left Hand Drain Location

• Accessories / Hardware:

Trim Kit: 4 HTC Jet Rings #D095

Rotary Drain Kit, 26” Cable #8730

Trim Kit: 2 BMH Jet Rings #J869

Trip-Lever Drain Kit: #X559

• Trim Kit Finishes Available:

(827) – Chrome

(898) – Brushed Chrome

(815) – Satin Nickel

(829) – Bright Brass

(805) – Platinum

(826) – Brushed Nickel

(849) – Oil Rubbed Bronze.

Riva®5

SOAKER BATH

Electrical Components and Electrical Speciﬁcations do not apply

to non-jetted baths.

62"

21-1/2"

43"

12" x 4"

9-1/2"

Motor

12" H x 18" L

Service Access

SIDE VIEW

H2''

END VIEW

DRAIN/OVERFLOW

Product Shown: Riva™ 5 Whirlpool Bath

Left Hand Shown Model: 9330

* Measurements inside unit represent cutout in

ﬂoor to allow for drain/overﬂow.

Minimum Service Access dimensions given.
