Jasco 39723 Bedienungsanleitung

60-Watt

Wirelessly control, schedule, or dim your

bulb from anywhere

Smart LED Light Bulb

60W Smart Dimmable

LED Light Bulb

SKU#: 39723

Features

• Standard ﬁt – Replace any standard A19 bulb with an E26 base to immediately turn

lamps, ceiling fans, recessed lights and more into smart devices.

• Full-range dimmability – The bulb adjusts brightness levels from 0-100 percent, which

reduces energy costs and improves bulb life.

• Long-life LEDs – Rated for up to 25,000 hours of use, long-lasting LEDs virtually elimi-

nates replacing bulbs for more than 22 years when used for three hours per day.

• Energy ecient – Using only 9W, the 60W-equivalent bulb oers an estimated energy

cost of $1.09 per year, which saves approximately $140 over its life.

•Range extender – The dimmer repeats your Z-Wave signal from your hub or other

Z-Wave device to extend your range by up to 150ft. Extended signal range increases your

home automation coverage to enhance your control.

See life in a new light with the Jasco Enbrighten

Z-Wave Smart LED Bulb. When paired with a

compatible hub, the smart bulb supports

ON/OFF/dim commands and programmed

settings. Wirelessly operate lamps, sconces, ceiling

lights and other ﬁxtures that use standard A19

bulbs for eortless management of your home.

39723 PRODUCT OVERVIEW

OMNI-DIRECTIONAL LIGHT

The 750-lumen LEDs are optimally conﬁgured to emit soft

white (2,700K) light evenly around the room.

PRODUCT OVERVIEW

STANDARD FIT

Wirelessly operate lamps, sconces, ceiling lights and other

ﬁxtures that use standard A19 bulbs for eortless

management of your home. Compatible with any standard

A19 bulb with an E26 base to immediately turn lamps, ceiling

fans, recessed lights and more into smart devices.

FULL-RANGE DIMMABILITY

The Smart Bulb adjusts brightness levels from 0-100 percent,

which reduces energy costs and increases life.

UNIVERSAL COMPATIBILITY

Z-Wave Plus and all previous Z-Wave generations work

together to allow continued expansion of your

home-automation network. The dimmer repeats your Z-Wave

signal from your hub or other Z-Wave device to extend your

range by up to 150ft. Extended signal range increases your

home automation coverage to enhance your control.

39723

PRODUCT SPECIFICATIONS39723

Bulb: A19

Signal Frequency: 908.4/916

Range:Up to 150 feet from controller or closest Z-Wave device

Operating Temperature: 32-104° F (0-40° C)

Warranty:2-year limited product warranty

For indoor use only.

Enbrighten®Z-Wave

Smart LED Bulb

Design Features

· Full-Range Dimmability

Adjust brightness levels

from 0-100% (1% increments)

· Omni-directional lighting

Enbrighten LEDs are

optimally to

provide a bright, evenly

distributed glow

· 60W Bulb Equivalent

Lightoutput is equivalent to a

standard 60W bulbwhile

onlyusing 9W of electricity

· Save $140 over life of bulb**

Enbrighten LEDs can reduce

energy usage by up to 85%

· OTA (Over-the-Air) Updateable

Utilizes the Z-Wave Firmware

Update Meta Data command

classfor standardized wireless

updates

· Visit http://www.ezzwave.com/

hubs/for hub compatibility

· Trilingual Instruction manual –

(English, French, Spanish)

Z-Wave Plus Features

·Works with Z-Wave Classic

and Z-Wave Plus Products

·50% more wireless range

·250% faster processor

·400% more memory

·Supports wireless upgrades

to future-proof your home

** Time and cost estimates as compared to a

60W incandescent bulb over the life of the

product (25,000 hrs) at .11¢/kWh. Results

will vary based on rates and use.

PRODUCT SPECIFICATIONS39723

subject to change without notice

Distributed by Jasco Products Company LLC

10 E. Memorial Rd., Oklahoma City, OK

©Jasco 2018

Adding your device to a Z-Wave network

Once the hub is ready to add your LED smart bulb, turn on

power to the socket. The bulb will be automatically

added into your network within 30 seconds and the bulb

To remove and reset the device

Once the controller is ready to remove your LED smart bulb, turn

successful removal from the network.

To return to factory defaults

Cycle the wall switch ON/OFF 4 times within 4 seconds

(completing one successive OFF and ON action counts as

succesful reset.

Omni-Direction Light

to provide a bright, evenly distributed glow

60W Bulb Equivalent

Light output is equivalent to a standard 60W

bulb while only using 9W of electricity.

Brightness

Estimated Yearly Energy Cost

Based on 3 hrs/day, 11¢/kWh

Cost depends on rates and use

Life

Based on 3 hrs/day

Light Appearance

Warm Cool

2700 K

Energy Used

750 lumens

$1.09

22.8 years

9 watts

Lighting Facts

Per Bulb

39723 QUICKSTART GUIDE

IMPORTANT!

Please note that it is extremely important to follow the below practice or to use ONLY

your preferred wireless remote control device to turn the smart bulb ON or OFF. Without

electrical power to the light bulb, the smart bulb cannot be turned ON remotely nor function

as a signal repeater to maintain proper Z-Wave network.

To avoid family members from accidently turning OFF the power to the smart bulb, install

the separate installation sheet.

QUICKSTART GUIDE

39723

¡IMPORTANTE!

Tenga presente que es sumamente importante observar la práctica descrita arriba o usar

ÚNICAMENTE su dispositivo de control remoto inalámbrico preferido para encender y

apagar la bombilla inteligente. Sin alimentación eléctrica, la bombilla inteligente no se

puede encender de manera remota ni funcionar como repetidor de la señal para mantener

adecuadamente la red Z-Wave.

Para evitar que los miembros de su familia desconecten la alimentación a la bombilla

inteligente, instale la tapa transparente opcional sobre el interruptor de pared (incluida con

el producto). Consulte la hoja de instalación que viene aparte.

IMPORTANT!

Veuillez noter qu’il est extrêmement important de respecter la pratique susmentionnée ou

intelligente. Sans alimentation électrique vers l’ampoule, l’ampoule intelligente ne peut être

allumée à distance ni fonctionner comme répétiteur de signaux servant à maintenir le réseau

Z-Wave approprié.

Pour éviter que les membres de la famille coupent accidentellement l’alimentation de l’ampoule

intelligente, installez le couvercle transparent en option qui se place sur votre interrupteur mural

(compris avec le produit). Veuillez vous reporter à la feuille d’instructions d’installation fournie.
