Jaton iRok Digital MP3 Player

User Manual

Version 3

Table of Contents

1. FEATURES SUMMARY --------------------------------------PG 2

2. SPECIFICATIONS ---------------------------------------------PG 2

3. BUTTON FUNCTION VIEW --------------------------------PG 3

4. DESCRIPTION OF BUTTON FUNCTION ------------PG 3-4

5. SCREEN DISPLAY VIEW -----------------------------------PG 4

6. FUNCTIONS DESCRIPTION -----------------------------PG 4-8

7. MAIN MANU OPTIONS ----------------------------------PG 8-14

8. FM RADIO FUNCTIONS -------------------------------PG 14-16

9. CAUTION ---------------------------------------------------PG 16-17

10. WARRANTY ---------------------------------------------PG 17-18

11. CONTACT-------------------------------------------------PG 18

1. FEATURES SUMMARY

1. Play MP3, WMA, and WAV music files

2. Play WAV and ASF voice recording files

3. Support USB port (2.0)

4. Support multi languages: English, Chinese Traditional, Chinese

Simplified, English&Kor, English&Jnp, English&Eur, English&Rus

5. 5 music equalizer effects: Normal, Jazz, Classical, Rock, and Pop

6. FM radio

7. Voice Recording：Support PCM，IMADPCM，MASADPCM formats；

Support 8K，11.025K, 16K, 22.05K, 32K Sample Rates；

Input Selections：MIC，FM and Line-In

8. Support A—B Repeat

2. SPECIFICATION

1. Memory Space: 256MB/1GB NAND FLASH

2. Character Space: Chinese (simple/complex) ，English, English&Kor,

English&Jnp, English&Eur, English&Rus

3. Display Size: 128*64dot，Yellow、Blue double color

4. Dimension: 62mm*32mm*14mm

5. Battery Size: 3.7V lithium battery

6. Noise Ratio: 96dB

7. Speaker Efficiency: 4mW+4mW（16Ω）

8. Output Frequency: 20Hz-20 KHz

9. Music File Format: MPEG1/2、MP3、WMA、WAV

10. Bit Rate: 8Kbps--320Kbps

11. Voice Recording Format: PCM/WAV/IMADPCM /MSADPCM

12. Voice Recording Input: Mic，FM Tuner，Line-in

13. Weight: 33.5g

14. Interface: USB 2.0

3. BUTTON FUNCTION VIEW

Picture 1.1

4. DESCRIPTION OF BUTTON FUNCTION

Power On/Power Off/Play/Pause/Stop ：While the power is off, press the button for

Power On ;while stopping or pausing, press the button to play or resume; while

playing，press the button for pausing; While playing or pausing, press and hold the

button for stopping. While stopping, press and hold the button for power off.

Menu /A-B：While stopping, pausing, or playing, press and hold the button to go to the

menu. While playing, press the button to set for A-B repeating.

Fast Forward/Next Song/Volume +：While playing or stopping, press the button to go

to the next song; while playing, press and hold the button

for fast forwarding; in the menu mode，press the button to go to the

next selection of the menu; In the volume mode, press the button to increase the volume;

and press and hold the button for continuous volume increase.

Fast Rewind/Previous Song/Volume -：While playing or stopping, press the button to

go to the previous song; while playing，press and hold the button for fast rewinding；in

the menu mode，press the button to go to the previous selection of the menu; in the

volume mode，press the button to decrease the volume，and press and hold the button

for continuous volume decrease.

5. SCREEN DISPLAY VIEW

Picture 1.2

6. FUNCTIONS DESCRIPTION

6.1 Turning power On/Off

6.1.1 To turn power on:

1) Push “Power Switch” from right to left to turn on power.

2) Press and hold “ ”Button to turn on the power. (Jaton iRok screen

appears - system memory screen appears and then get into music mode.)

Refer to Picture 1.3

Picture 1.3

3) LCD screen display as Picture 1.2 after that.

6.1.2 To turn power off:

1) Press and hold “ ”button to turn off the power and keep all the new

setting.

2) Push “Power Switch” from left to right to turn off power.

* It will set to default setting when you turn off by power switch.

6.2To Play Music

1) Press “ ” button two times to play the music if the Screen Display

Mode of left-top corner screen shows as “ ”sign.

2) Press “ “button to pause. Screen Display Mode of screen shows as

“”.

3) Press “ ” button to play again. Screen Display Mode of screen shows

as “ ”.

6.3 Setting for next songs

1) While playing or stopping - press “+” button to move to next songs.

2) While playing or stopping – press “-” button to go back to previous song.

6.4 Repeating – A–B

1) While playing, stopping or pausing, press “MODE” button to start the

point from. (Screen Display Mode of center-top screen shows “S A-”.

Refer to Picture 1.4)

2) Press “MODE” button again to end the point of repeating. (Screen

Display Mode from screen shows as “A-B”.) Refer to Picture 1.4

Picture 1.4

6.5 Fast Forward/Fast Rewind

1) While playing or stopping – press and hold “+” button for fast forwarding.

2) While playing or stopping – press and hold “-“button for fast rewinding.

3) Release “+” or “-“button to stop fast forwarding or rewinding.

6.6 Settings for Volume

1) Press “VOL” button. (Volume indicator of right-bottom Screen starts

blanking.)

2) Press “+” button to increase the volume. (Volume indicator of Screen

moves to right. Volume indicator blinking at the same time.)

3) Press “- “button to decrease the volume. (Volume indicator of Screen

moves to left while Volume indicator blinking at the same time.)

4) Press “VOL” button when finish. Else, wait until Volume indicator stop

blinking automatically.

6.7 Voice Recording (MIC-in) or Line-in Recording (Line-in)

1) Press and hold “MODE” button to get into MAIN MENU.

2) Press “+” button to select record from MIC or LINE IN category of

MAIN MENU. (Recording… indicator appears on center screen). Refer

to Picture 1.5

3) Press “ ” button to stop recording. The file will be generated as

“001.WAV” and saved.

6.8 Voice Recording while in Music or FM mode:

1) Press and hold “VOL” button to start recording.

2) Press “ ” button to stop recording and the file will be saved.

Picture 1.5

6.9 To Play Recording File

6.9.1 Voice Recording file (Play under VOICE mode):

1) Press and hold “MODE” button to get into MAIN MENU to get into

Voice mode.

2) Press “+” to select “VOICE” from MAIN MENU.

3) Press to play MP3 type of file. (Sample file name: V001.WAV)

6.9.2 Line-in file (Play under MUSIC mode):

1) Press and hold “MODE” button to get into MAIN MENU.

2) Press “+” button to select “MUSIC” from MAIN MENU to get into

Music mode.

3) Press “ ” button to play Line-In type of file. (Sample file name:

L001.WAV)

6.9.3 FM Recording file (Play under MUSIC mode):

1) Press and hold “MODE” button to get into MAIN MENU.

2) Press “+” button to select “MUSIC” from MAIN MENU to get into

Music mode.

3) Press “ ” button to play FM type of file. (Sample file name:

F001.WAV)

7. MAIN MENU OPTIONS

Get into exiting Main Manu:

1) Press and hold “MODE” button to get into MAIN MENU.

2) You should see menu listed as below:

MAIN MENU:

MUSIC

VOICE

MIC

LINE IN

SET

Delete

3) Press and hold “MODE” button until it quit the MAIN MENU. (It the player is

left idling for more than 5 minutes, the player will automatic quit the MAIN

MENU.)

7.1 Settings for SET

7.1.1) Settings for EQ

1) In MAIN MENU, press “+” button to select menu SET.

2) Press “MODE” button to get into SETTING.

3) You should see menu listed as below:

SETTING

PlayMode

Sreen Savings

Power Set

Record Set

Language

Exit

4) Press “MODE” button to get into EQ.

You should see EQ SELECT mode listed as below:

SETTING

Normal

Rock

Jazz

Classic

Pop

5) Press “+” button to get into EQ mode.

6) Press “MODE” button to set the EQ SELECT. The screen will turn back

to SETTING screen automatically after EQ SELECT is selected.

7.1.2 Settings for PlayMode

1) In MAIN MENU, press “+” button to select menu SET.

2) Press “+” button to select PlayMode.

3) Press “MODE” button to get into SETTING.

4) Press “+” button to select PlayMode.

5) Press “MODE” button to get into PlayMode.

6) You should see PlayMode mode listed as below:

PlayMode:

Normal

Repeat One

Repeat All

Shuffle

Shuffle & Repeat

7) Press “+” button to select the PlayMode.

8) Press “MODE” button to set the PLAY SEQUENCE. It will turn back to

SETTING screen automatically after PLAY SEQUENCE is selected.

7.1.3 Settings for Screen Savings

1) In MAIN MENU, press “+” button to select menu SET.

2) Press “+” button to select Screen Savings.

3) Press MODE button to get into SETTING.

4) Press “+” button to select Screen Savings.

5) Press “MODE” button to get into SCREEN SAVINGS.

6) Press “+” button to select SCREEN SAVINGS’s TIME (Sec).
