JBL Reference 610 Installations- und Betriebshandbuch

Bring home theater to life

Turn your ﬂat panel TV into a full home theater with the JBL Cinema 610. Easily connectable

to any audio/video receiver, the JBL Cinema 610 delivers a box ofﬁce experience that can’t

be matched anywhere else. Sink into pure JBL bliss with an 8” bass reﬂex, 100W powered

subwoofer with 5 identical voice-matched satellite speakers, and a dedicated center speaker

to ensure you receive flawless sound reproduction and perfect dialogue reproduction

from all your music and movie sources. With customized wall-mount options and an easy

plug-and-play format, you’re headed to the movies in no time.

CINEMA 610

Advanced 5.1 Home Theater System with Powered Subwoofer

Easy-to-install system

Voice matched satellites for detailed listening

Dedicated center channel for vocal clarity

8” (200mm) powered subwoofer for deep

rich bass

Wall brackets (built-in) and loudspeaker

cable included

Key speciﬁcations:

HARMAN International Industries, Incorporated

8500 Balboa Boulevard, Northridge, CA 91329 USA

www.jbl.com

CINEMA 610

Advanced 5.1 Home Theater System with Powered Subwoofer

What’s in the box:

5 voice-matching satellite speakers

1 powered subwoofer

Wall mounts

Speaker cables

Subwoofer LFE cable

Quick-start guide

Product speciﬁcations:

Type: speaker system

Frequency response: 38Hz – 20kHz

Maximum SPL: 109dB @ 1m

Power output (sub): 100W

Industries, Incorporated, registered in the United States and/or other countries. Features, specifications and

appearance are subject to change without notice.

Features

Satellites

Recommended Ampliﬁer Power: 10 - 100 Watts

Power Handling (Continuous/Peak): 60W

Impedance: 8 ohms

Sensitivity: 86dB @ 2.83V/1 meter

Frequency Response: 130Hz – 20kHz (-6dB)

Midrange: 75mm (3”) cones

Tweeter: 32mm (1.25”)

Dimensions (H x W x D):

(7.87” x 3.8” x 3.92”)

200mm x 96.8mm x 99.5mm

Weight: 0.8kg (1.76lb)

Subwoofer

Ampliﬁer: 100 Watts RMS

Frequency Response: 38Hz – 250Hz (–6dB)

Woofer: 200mm (8”)

Enclosure: Bass reﬂex

Dimensions (H x W x D): 357mm x 320mm x 324mm (14” x 12.6” x 12.7”)

Weight: 8.12kg (17.9lb)

Center

Impedance: 8 ohms nominal

Sensitivity: 89dB @ 2.83V/1 meter

Frequency Response:

150 Hz - 20kHz (-6dB)

Midrange: Dual 75mm (3”) cones

Tweeter: 32mm (1.25”)

Dimensions (H x W x D):

(3.92” x 9.4” x 3.78”)

99.5mm x 239mm x 96mm

Weight: 1.23kg (2.7lb)
