JBL Harman Link Music Bedienungsanleitung
WHAT’S
IN THE
BOX
quick
START
GUIDE
Power on
back
RESET
speaker
MUSIC
>10S
Bluetooth pairing
Mic mute/unmute
Power connector
Light up when active
The Google Assistant
setup
AirPlaysetup
ForAirPlay 2 only users, Link Music can be setup using the
Apple Home app.
Apple home
GOOGLE HOME
1. Open the Home app, tap , then tap AddAccessory.
2. Tap Don’t have a Code or Can’t Scan, then tap the speaker.
3. Wait for your speaker to be added.
Give your speaker a name and choose a room where it's located.
4. Tap Done.
Download the Google Home app and set up your Link Music.
top & front
Press >2s to activate
your GoogleAssistant
Press to stop audio, timer,
alarms and responses
WHAT’S
IN THE
BOX
quick
START
GUIDE
Power on
back
RESET
speaker
MUSIC
>10S
Bluetooth pairing
Mic mute/unmute
Power connector
Light up when active
The Google Assistant
setup
AirPlaysetup
ForAirPlay 2 only users, Link Music can be setup using the
Apple Home app.
Apple home
GOOGLE HOME
1. Open the Home app, tap , then tap AddAccessory.
2. Tap Don’t have a Code or Can’t Scan, then tap the speaker.
3. Wait for your speaker to be added.
Give your speaker a name and choose a room where it's located.
4. Tap Done.
Download the Google Home app and set up your Link Music.
top & front
Press >2s to activate
your GoogleAssistant
Press to stop audio, timer,
alarms and responses
WHAT’S
IN THE
BOX
quick
START
GUIDE
Power on
back
RESET
speaker
MUSIC
>10S
Bluetooth pairing
Mic mute/unmute
Power connector
Light up when active
The Google Assistant
setup
AirPlaysetup
ForAirPlay 2 only users, Link Music can be setup using the
Apple Home app.
Apple home
GOOGLE HOME
1. Open the Home app, tap , then tap AddAccessory.
2. Tap Don’t have a Code or Can’t Scan, then tap the speaker.
3. Wait for your speaker to be added.
Give your speaker a name and choose a room where it's located.
4. Tap Done.
Download the Google Home app and set up your Link Music.
top & front
Press >2s to activate
your GoogleAssistant
Press to stop audio, timer,
alarms and responses
WHAT’S
IN THE
BOX
quick
START
GUIDE
Power on
back
RESET
speaker
MUSIC
>10S
Bluetooth pairing
Mic mute/unmute
Power connector
Light up when active
The Google Assistant
setup
AirPlaysetup
ForAirPlay 2 only users, Link Music can be setup using the
Apple Home app.
Apple home
GOOGLE HOME
1. Open the Home app, tap , then tap AddAccessory.
2. Tap Don’t have a Code or Can’t Scan, then tap the speaker.
3. Wait for your speaker to be added.
Give your speaker a name and choose a room where it's located.
4. Tap Done.
Download the Google Home app and set up your Link Music.
top & front
Press >2s to activate
your GoogleAssistant
Press to stop audio, timer,
alarms and responses
WHAT’S
IN THE
BOX
quick
START
GUIDE
Power on
back
RESET
speaker
MUSIC
>10S
Bluetooth pairing
Mic mute/unmute
Power connector
Light up when active
The Google Assistant
setup
AirPlaysetup
ForAirPlay 2 only users, Link Music can be setup using the
Apple Home app.
Apple home
GOOGLE HOME
1. Open the Home app, tap , then tap AddAccessory.
2. Tap Don’t have a Code or Can’t Scan, then tap the speaker.
3. Wait for your speaker to be added.
Give your speaker a name and choose a room where it's located.
4. Tap Done.
Download the Google Home app and set up your Link Music.
top & front
Press >2s to activate
your GoogleAssistant
Press to stop audio, timer,
alarms and responses
WHAT’S
IN THE
BOX
quick
START
GUIDE
Power on
back
RESET
speaker
MUSIC
>10S
Bluetooth pairing
Mic mute/unmute
Power connector
Light up when active
The Google Assistant
setup
AirPlaysetup
ForAirPlay 2 only users, Link Music can be setup using the
Apple Home app.
Apple home
GOOGLE HOME
1. Open the Home app, tap , then tap AddAccessory.
2. Tap Don’t have a Code or Can’t Scan, then tap the speaker.
3. Wait for your speaker to be added.
Give your speaker a name and choose a room where it's located.
4. Tap Done.
Download the Google Home app and set up your Link Music.
top & front
Press >2s to activate
your GoogleAssistant
Press to stop audio, timer,
alarms and responses
WHAT’S
IN THE
BOX
quick
START
GUIDE
Power on
back
RESET
speaker
MUSIC
>10S
Bluetooth pairing
Mic mute/unmute
Power connector
Light up when active
The Google Assistant
setup
AirPlaysetup
ForAirPlay 2 only users, Link Music can be setup using the
Apple Home app.
Apple home
GOOGLE HOME
1. Open the Home app, tap , then tap AddAccessory.
2. Tap Don’t have a Code or Can’t Scan, then tap the speaker.
3. Wait for your speaker to be added.
Give your speaker a name and choose a room where it's located.
4. Tap Done.
Download the Google Home app and set up your Link Music.
top & front
Press >2s to activate
your GoogleAssistant
Press to stop audio, timer,
alarms and responses
WHAT’S
IN THE
BOX
quick
START
GUIDE
Power on
back
RESET
speaker
MUSIC
>10S
Bluetooth pairing
Mic mute/unmute
Power connector
Light up when active
The Google Assistant
setup
AirPlaysetup
ForAirPlay 2 only users, Link Music can be setup using the
Apple Home app.
Apple home
GOOGLE HOME
1. Open the Home app, tap , then tap AddAccessory.
2. Tap Don’t have a Code or Can’t Scan, then tap the speaker.
3. Wait for your speaker to be added.
Give your speaker a name and choose a room where it's located.
4. Tap Done.
Download the Google Home app and set up your Link Music.
top & front
Press >2s to activate
your GoogleAssistant
Press to stop audio, timer,
alarms and responses
TECH SPEC
Transducer: 1 x 64mm
Output power: 1 x 20W RMS
Frequency response: 60Hz − 20kHz
Signal-to-noise ratio: >80dB
Power input: 100-240V-50/60Hz
Wireless network: 802.11 a/b/g/n/ac (2.4/5GHz)
Bluetooth version: 4.2
Bluetooth transmitter frequency range: 2402 − 2480MHz
Bluetooth transmitter power: <12dBm
Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
5G Wi-Fi transmitter frequency range: 5.150~5.350GHz, 5.470~5.725GHz,
5.725~5.825GHz
5G Wi-Fi transmitter power: <20dBm (EIRP)
5G Wi-Fi modulation: OFDM, BPSK, QPSK, 16QAM, 64QAM, 256QAM
5G Wi-Fi network compatibility: IEEE 802.11 a/n/ac
2.4G Wi-Fi transmitter frequency range: 2412 – 2472MHz (2.4GHz ISM Band, USA
11 Channels, Europe and others 13
Channels)
2.4G Wi-Fi transmitter power: <19dBm (EIRP)
2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM
2.4G Wi-Fi network compatibility: IEEE 802.11b/g/n
Supported audio formats: HE-AAC, LC-AAC, MP3, Vorbis, WAV (LPCM),
FLAC, Opus
Dimensions (Dia x H): 112 x 134 mm
Weight: 730g
