Jeep 2022 CHEROKEE Bedienungsanleitung
Jeep®Cherokee
Q
S
G
U
T
U
I
A
I
C
R
D
K
T
E
Garage Door
Opener
4WD Controls
Cruise Control
Buttons
Instrument Cluster
Display & Voice
Recognition Buttons
Hood Release
Memory Seat
Control Buttons
Power Liftgate
Light Controls
Stop/Start
OFF Button
USB Ports
Tune/Browse
Button
VEHICLE OVERVIEW
Push and hold the two outside HomeLink® buttons for 20 seconds until
the orange indicator flashes. An individual channel cannot be erased.
TO ERASE ALL SET CHANNELS:
Garage Door Opener
11
22Push and hold both the HomeLink® button being programmed
and the button on the garage door transmitter.
While the car is ON, hold the handheld garage door transmitter
1-3 inches from the HomeLink® button you want to program in
the vehicle.
LINK YOUR GARAGE DOOR
NEED ASSISTANCE?
1-800-355-3515
Scan For
HomeLink®
Video
33For Non-Rolling Code garage door openers, watch for
the indicator light to go constant.
For Rolling Code garage door openers, watch for the
indicator light to go from a slow blink to blinking rapidly.
44 For Rolling Code garage door openers only, firmly push
and release the “LEARN” or “TRAIN” button on your
garage door opener motor in your garage, then push the
HomeLink® button in your vehicle for two long presses.
55If the programming was successful, your
garage door should open and close with
your chosen HomeLink® button.
??ROLLING OR NON-ROLLING?
Check your garage door opener motor in your
garage for a “LEARN” or “TRAIN” button by the
hanging antenna. If you have one of these, you
have a Rolling Code garage door opener.
Pair a Phone
11
22
33
44
55
With the vehicle in the ACC or ON/RUN
position, press the Phone button on the
vehicle’s touchscreen menu bar.
Press “Pairing”.
Press “Paired Phones and Audio Devices”.
Select “Add Device” then follow the
prompts on your phone and on the
touchscreen.
Make sure Bluetooth® is enabled on
your mobile device.
Ready to remove a phone or audio device?
44
Press “Delete Device”.
11
Press the Pairing button on the touchscreen.
22
Press “Paired Phones and Audio Devices”.
55
Press “X” to exit the settings screen.
The device should be removed.
Press “Settings” next to the phone or
device you want to remove.
33
CONNECT YOUR PHONE
CONNECT YOUR APPS
Connect your smartphone to the media USB port.
KEEP IN MIND:
The Android AutoTM or Apple CarPlay® icon will replace the phone icon on
the touchscreen.
For AndroidTM Users, if the Android AutoTM app was not previously
downloaded, it will download the first time you plug in your device.
For Apple® Users,Apple CarPlay® is only compatible with iPhone®5
or later and requires Siri being enabled in Settings.
Connected Services
WITH CONNECTED
SERVICES YOU CAN...
Lock Your Vehicle
Unlock Your Vehicle
Remote Start Your Vehicle
Cancel Remote Start
Activate Your Horn
ACTIVATE YOUR
REMOTE SERVICES
11Press “Apps” on the
touchscreen.
22Press “Activate Services”.
33Press “Activate Now”.
44There are two ways to
activate: via email or via an
agent. On the next screen,
you can either enter your
name and email, or press
“Call An Agent” to directly
speak with a certified agent.
**Requires an active SiriusXM Guardian™ subscription
Mopar® YOUR Way
CREATE YOUR OWNER'S PROFILE TODAY!
Get 24/7 Access To Everything You Need
GET PERSONALIZED BY REGISTERING
Custom vehicle dashboard
Schedule dealer service with ease
View maintenance records**
Mobile vehicle commands**
Access to your vehicle's Owner's Information
Obtain special oers on Mopar® service
*Canadian residents
are not required to
create a profile, as
one is created when
a SiriusXM Guardian™
account is activated.
Registration
is simple.
Provide your
email address
to get started.
!!
Hands-Free Liftgate
Use a Straight
In-and-Out Kicking Motion
Make sure your kicking motion is straight
in and out, and within the activation zone.
Please note, this feature is available only
on vehicles equipped with Passive Entry.
LIFTGATE NOT OPENING?
Activation Zone
Scan For
Liftgate Video
X
Do not move your foot sideways or in a sweeping
motion; the sensors may not detect the motion.
??
Keyless Enter 'n Go™ — Passive Entry
LOCK & UNLOCK YOUR VEHICLE WITH EASE
Grab the door handle to unlock the vehicle.
WITH YOUR KEY FOB ON YOUR PERSON:
Press the Passive Entry Button on the door handle, making sure not to grab the door handle,
to lock the vehicle.
The driver's door handle
will unlock the driver's door
(this can be adjusted within
Uconnect Settings). The front
passenger handle unlocks all
doors and the liftgate.
KEEP IN MIND:
LIFTGATE BUTTONS
11Passive Entry Button
Press the Passive Entry button to the
left of the liftgate release handle to
lock all doors and the liftgate. 22Liftgate Release
Grab the liftgate release handle to
open the liftgate.
OPEN YOUR DOORS AND LIFTGATE
Steering Wheel Controls
The Right-Hand button will let you adjust/mute the volume of Uconnect system. The Left-Hand button
will Seek Up/Seek Down through radio stations and audio tracks or change the radio source.
DID YOU KNOW THERE ARE BUTTONS ON THE BACK OF YOUR
STEERING WHEEL?
Scan For
Audio Control
Video
Increase Volume
Mute/Unmute
Decrease Volume
Seek Down
Source Select
Seek Up
LIGHTS, WIPERS & AUDIO BUTTONS
Lights & Wipers Operation
OFF
HIGH
INT
LOW
PULL
TO ACTIVATE THE
FRONT WINDSHIELD WASHER
PUSH UP
TO MIST THE WINDSHIELD
PUSH
FORWARD
TO ACTIVATE THE
REAR WINDSHIELD WASHER
TO ACTIVATE HIGH BEAMS
PUSH
FOR FLASH-TO-PASS
PULL
Headlights, Parking Lights
& Instrument Panel Lights
Parking Lights
& Instrument
Panel Lights
Fog Lights
Rear
Wipers OFF
Rear
Wipers ON
Front Wipers
Scan For
Headlight
Video
Use these buttons to activate your
Cruise Control system
and set
your speed.
Advanced Driving Assist Systems
Adjust your
LaneSense system
strength and sensitivity settings
through your radio.
Use these buttons to activate your
Adaptive Cruise Control (ACC) system
and set your following distance.
Scan For
ACC Video
Turn the
Forward Collision Warning (FCW) system
on or o, and adjust the sensitivity and active
braking status through your radio.
Scan For
FCW Video
Scan For
LaneSense Video
Turn your
ParkSense system
on or o by using the ParkSense switch.
The chime volume settings can be programmed through your radio.
UNDERSTAND YOUR DRIVING AIDS
Turn the
ParkSense Active Park Assist system
on or o using
the ParkSense Active Park Assist switch. You can switch parking
maneuvers through your instrument cluster display using the
arrows on the left side of the steering wheel.
Scan For
Park Assist
Video
Use your radio to choose between
three
Blind Spot Monitoring (BSM)
system
modes:
• Blind Spot Alert Lights Only
• Blind Spot Alert Lights/Chime
• Blind Spot Alert O
Scan For
BSM Video
©2022 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une marque déposée de FCA US LLC.
App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.
Warning & Indicator Lights
For additional information on any of the topics in this publication, please refer to your Owner’s Manual.
Second Edition
KL_QSG_EN_USC_BA
Service LaneSense
Engine Check/
Malfunction
LaneSense
Anti-Lock Brake
System (ABS)
Oil Temperature
Electronic Throttle
Control (ETC)
Air Bag
Water In Fuel
Stop/Start Active
Battery Charge Brake Door Open Electric Power
Steering Fault (EPS)
Engine Temperature Hood Open Liftgate Open
Seat Belt Reminder Transmission
Temperature
Electronic Stability
Control (ESC) OFF
Electronic Stability
Control (ESC) Active
Electronic Park Brake
Service Forward
Collision Warning (FCW)
Service Stop/Start
System
Cruise Control SET
Immobilizer Fail/VPS
Electrical Alarm
Service Adaptive
Cruise Control (ACC)
Low Washer Fluid
Low Fuel Rear Axle Lock Service 4WD
Adaptive Cruise Control
(ACC) Set No Target
Tire Pressure Monitoring
System (TPMS)
Wait To Start
Front Fog Lights Parking/Headlights On
Forward Collision
4WD Low
LaneSense
Forward Collision
Warning (FCW) OFF
Oil Pressure
Vehicle Security
LaneSense
Hill Descent
Control (HDC) High Beam
Adaptive Cruise Control
(ACC) Set With Target
Turn Signal
Cruise Control Ready
Fuel Cuto
Cruise Control Fault
