Jorjin WS2119E20 Bedienungsanleitung

http://WWW.JORJIN.COM.TW

a module solution provider

WS2119E20 User Guide

WS2119-A0 Development Kit

Drift 0.2

Prepared By

Reviewed By

Approved By

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 1

Index

1. INTRODUCTION............................................................................................................................2

2. GETTING STARTED......................................................................................................................3

2.1. SYSTEM REQUIREMENTS...............................................................................................................3

2.2.APPLICATION SOFTWARE SETUP....................................................................................................3

3. HARDWARE DESCRIPTION.......................................................................................................4

3.1. BOARD OVERVIEW........................................................................................................................4

3.2. WS2119-A0 MODULE CONNECTIONS ...........................................................................................5

3.3. POWER SUPPLY.............................................................................................................................6

3.4. OTHER JUMPERS...........................................................................................................................7

3.5. EXTENSION CONNECTORS.............................................................................................................7

3.6. PUSH-BUTTONS ............................................................................................................................8

3.7. JTAG CONNECTOR .......................................................................................................................8

3.8. LEDS...........................................................................................................................................8

3.9. STM32L151CBU6 MICROCONTROLLER......................................................................................8

3.10. HARDWARE SETUP......................................................................................................................8

4. SCHEMATIC DIAGRAMS..........................................................................................................10

5. HISTORY CHANGE.....................................................................................................................14

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 2

1. INTRODUCTION

The Jorjin WS2119-A0 is Bluetooth®Low Energy and Sub-1GHz dual band module. The

WS2119E20A is the development kit for WS2119-A0. The WS2119E20A provides a set

of hardware resources for RF signal evaluation of both BLE and Sub-1GHz and

development platform. It also provides a set of hardware resources for a wide range

of application scenarios: sensor data (accelerometer, pressure and temperature

sensor, needs additional sensor board), remote control (buttons and LEDs) and

debug message management through USB virtual COM. Three power options are

available (USB only, battery only and external power supply plus USB) for high

application development and testing flexibility.

Figure 1: WS2119E20 development kit

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 3

2. GETTING STARTED

2.1. System requirements

The application software require:

PC with Intel® or AMD® processor running one of the following Microsoft®

operating systems:

-Windows XP SP3

-Windows Vista

-Windows 7

-Windows 10

At least 128 MB of RAM

USB ports

At least 40 MB of available hard disk space

Adobe Acrobat Reader 6.0 or later.

2.2. Application software setup

Please download the application from below link.

BlueNRG-1 DK SW package:

http://www.st.com/content/st_com/en/products/embedded-software/evaluation-t

ool-software/stsw-bluenrg1-dk.html

BLUENRG family GUI:

http://www.st.com/content/st_com/en/products/embedded-software/wireless-con

nectivity-software/stsw-bnrgui.html

And please contact Jorjin to get more application and development software.

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 4

3. HARDWARE DESCRIPTION

3.1. Board overview

The following figure and table describe physical sections of the board.

Figure 2: WS2119E20 board components

Table 1: WS2119E20 board component descriptions

Region

Description

WS2119-A0 module

BLE RF signal U.FL connector

Sub-1GHz RF signal U.FL connector

Micro USB connector for power supply and I/O

E,F

Two rows of Arduino-compliant connectors

JTAG connector for BlueNRG-1

RESET button

USER button

PWR LED

User LED

Battery power input point

STM32L151CBU6 48-pin microcontroller (USB to serial bridge for I/O

channel to PC communication)(1)

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 5

JTAG connector for STM32L151CBU6 (1)

ST2378E level translator to adapt voltage level between STM32 and

BlueNRG-1

EEPROM

Serial port connection jumpers

R,S

Power source selection jumpers.

DIO6 function selection jumper.

Current measurement jumper for BlueNRG-1

Current measurement jumper for S2LP

Current measurement jumper for RFX1010

(1) STM32 is not intended to be programmed by users

3.2. WS2119-A0 module connections

The WS2119-A0 dual band module (Figure 2: " WS2119E20 board components" –

region A) has 2 RF signal connector. One is for BLE (region B), another is for sub-1GHz

RF(region C).

The microcontroller of BlueNRG-1 is connected to various components such as

buttons, and LEDs. The following table describes the microcontroller pin functions.

Table 2: WS2119-A0 module pin description with board functions

Pin Name

Function

Arduino Connectors

CN1

CN2

CN3

CN4

GND

Pin7

Pin6,7

RESETN

System reset

Pin3

Pin8

DIO13

S2-LP for interrupt

Pin3

DIO12

User button input

Pin1

TEST

Test pin put to GND

DIO11

UART RX from STM32

Pin1,3

DIO10

JTMS-SWTDIO

DIO9

JTCK-SWTCK

DIO8

UART TX to STM32

Pin1

Pin2

GND

Pin7

Pin6,7

VBAT

Power for BlueNRG-1

Pin8

Pin2,4

GND

Pin7

Pin6,7

DIO7

Bootloader pin / LED driver

Pin2

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 6

DIO6

RESET pin of STSAFE-A1SX or EEPROM_CS pin

Pin7

DIO5

SDA pin of STSAFE-A1SX

Pin9

DIO4

SCL pin of STSAFE-A1SX

Pin10

DIO3

SDO pin of S2-LP and EEPROM

Pin5

Pin6

DIO2

SDI pin of S2-LP and EEPROM

Pin4

Pin5

DIO1

CS pin of S2-LP

Pin3

DIO0

SCLK pin of S2-LP and EEPROM

Pin6

Pin4

DIO14

SDN pin of S2-LP

Pin4

ANATEST1

Pin2

ADC1

Pin5

GND

Pin7

Pin6,7

ADC2

Pin6

GND

Pin7

Pin6,7

VCC_S2LP

Power for S2-LP

Pin8

Pin2,4

GND

Pin7

Pin6,7

GPIO3

S2-LP for interrupt

Pin3

GPIO2

TXEN pin of RFX1010

GPIO1

MODE pin of RFX1010

GPIO0

RXEN pin of RFX1010

PA_DET

Analog Voltage Proportional to the PA

Power Output

VCC_PA1

Power for RFX1010

Pin8

Pin2,4

VCC_PA2

Power for RFX1010

Pin8

Pin2,4

GND

Pin7

Pin6,7

3.3. Power supply

Green LED CR1 (Figure 2: WS2119E20 board components" –region J) signals the

board is being powered, either via:

micro USB connector J4 (Figure 2: WS2119E20 board components" –region D)

batteries(region L)

an external DC power supply plus micro USB connector

The following table describes the power supply modes available on the WS2119E20

board and corresponding jumper settings.

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 7

Table 3: WS2119E20 kit platform power supply modes

Power supply mode

Comment

1- USB

Fitted:1-2

Fitted:2-3

USB supply through connector J4 (region D)

2- Battery

Fitted:2-3

Fitted:1-2

The supply voltage must be provided through

battery pins (region L)

3- Combo

Fitted:1-2

Optional

USB supply through connector J4 for STM32L1;

J6 pin 2 external power for WS2119-A0 module

3.4. Other jumpers

The following jumpers are available:

Table 4: WS2119E20 kit platform jumpers

Jumper

Description

Test points for S2-LP GPIO0 –GPIO3

UART TX of BlueNRG-1 is connected (Fitted) or disconnected (Not fitted) to STM32.

UART RX of BlueNRG-1 is connected (Fitted) or disconnected (Not fitted) to STM32.

pin 1 and 2 UART RX and TX of MCU

pin 3 GND

J10

DIO6 of BlueNRG-1 is connected (Fitted) or disconnected (Not fitted) to EEPROM_CS pin.

J11

Fitted: to provide VBLUE to BlueNRG-1. It can be used also for current measurement.

J12

Fitted: to provide VBLUE to RFX1010. It can be used also for current measurement.

J13

Fitted: to provide VBLUE to S2-LP. It can be used also for current measurement.

3.5. Extension connectors

WS2119-A0 module signal test points are shared on two Arduino-compliant

connector rows: CN1, CN3 (Figure 2: " WS2119E20 board components" –region E)

and CN2, CN4 (region F). See Table 2: "WS2119-A0 module pin description with

board functions".

You can also install some sensor module board in the WS2119E20 kit platform

through these extension connectors. Please contact Jorjin to get more information.

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 8

3.6. Push-buttons

The board has one user button to reset the microcontroller (Figure 2: " WS2119E20

board components" –region H) and one further button for application purposes

(region I).

3.7. JTAG connector

A JTAG connector (Figure 2: " WS2119E20 board components" –region G) allows

BlueNRG-1 microcontroller programming and debugging with an in-circuit

debugger and programmer such as ST-LINK/V2.

Only SWD mode is supported.

3.8. LEDs

LEDs CR1 (green, power LED) and CR2 (red) are available on the board (Figure 2:

"WS2119E20 board components" –regions J and K).

3.9. STM32L151CBU6 microcontroller

The most important feature of the STM32L151CBU6 48-pin microcontroller (Figure 2:

"WS2119E20 board components" –regions M) is the USB to serial bridge providing an

I/O channel with the BlueNRG-1 device.

The microcontroller is connected to the BlueNRG-1 device through an ST2378E level

translator (region O).

The STM32L microcontroller on the board is not intended to be programmed by users.

ST provides a pre-programmed firmware image for the sole purpose of interfacing

BlueNRG-1 to a USB host device (e.g., a PC). The JTAG connector (Figure 2:

"WS2119E20 board components" –regions N) is only for Jorjin internal used.

3.10. Hardware setup

1. Connect one 2.4GHz antenna to BLE U.FL connector (Figure 2: "WS2119E20 board

components" –regions B), Connect one 915MHz antenna to Sub-1GHz U.FL

connector (regions C)

Doc No: WS2119E20A-UG-D02

http://WWW.JORJIN.COM.TW

Page 9

2. Configure the board to USB power supply mode as per the jumper settings in

Table 3: “WS2119E20 kit platform power supply modes”

3. Connect the board to a PC via USB cable (connector J4)

4. Verify the power indication LED CR1 is on.
