JOSTechnik HK2 Bedienungsanleitung

Original Operating Instructions Flap Actuator HK2 10/2020

Automatic Chicken Door Flap Actuator

HK2 (standalone de ice)

HK2-RH

HK2-RE

HK2-RG

HK2-RB

Description and Operating Instructions

Original Operating Instructions  Flap Actuator HK2 10/2020
Table of Contents
General Description...............................................................................................................1
Installation Instructions...........................................................................................................2
HK2 - standalone device....................................................................................................2
HK2 - R..............................................................................................................................2
Optional Modules...............................................................................................................3
Operation and Settings..........................................................................................................4
General Structure...............................................................................................................4
Settings and  hanges.......................................................................................................5
Factory Setting..............................................................................................................5
Main menu level “Flap actuator”....................................................................................6
Submenu Timer 1 / Timer 2.......................................................................................6
Submenu Mode.........................................................................................................6
Submenu Delay.........................................................................................................7
Submenu Light Sensor..............................................................................................7
Submenu Emergency Stop.......................................................................................7
Submenu Redefine End Position (slider  LOSED)..................................................7
Submenu  astor.......................................................................................................7
Main Menu Level “Time / Date”.....................................................................................8
Submenu Time..........................................................................................................8
Submenu Date..........................................................................................................8
Main menu level “Extras”...............................................................................................8
Submenu Attractor Light............................................................................................8
Submenu Language..................................................................................................8
Main Menu Level “Reset”..............................................................................................9
Start-up and Operation...........................................................................................................9
Start-up..............................................................................................................................9
Operating Displays..........................................................................................................10
Automatic Mode...............................................................................................................10
Manual Mode...................................................................................................................10
Troubleshooting and Service...........................................................................................11
Technical data......................................................................................................................12
Data..................................................................................................................................12
Disposal...........................................................................................................................12
Declaration of  onformity................................................................................................13
 hanges, Additions and Extensions....................................................................................14

Original Bedienungsanleitung Klappensteller HK2 10/2020

General Description

JOSTechnik’s electronic flap actuator HK2 is a further development of JT-HK’s series of

flap actuators, which have been on the market for a number of years. It is used for the

automated opening and closing of sliders to poultry houses. Sliders weighing

approximately 400 g - max. 2.5 kg can be moved using the HK2.The slider must run

smoothly, it must not rub or tilt.

The flap actuator HK2 is available in 2 versions:

1 Framework device consisting of a control unit on a fully assembled self-locking

slider forming a compact unit (HK2-R..)

2 Standalone device (HK2) to be used with external sliders (standard or self-locking)

Range of functions:

Automatic opening/closing of the slider

ontrol by dimmer switch and integrated timer

Manual operation with (▲ und ▼) keys integrated on the device

◦or with optional radio remote control

◦or optional remote keys

The closing point is reached without external limit switches using the travel time

control

Safety function with control if animals are in the path of the slider

◦an interrupted closing process is repeated - real emergency stop or emergency

opening function

Optional remote display of the slider status by means of 2 extra bright LED lights

an be installed inside or outside the poultry house

Integrated attractor light controlled by a light sensor

The HK2 basically works in automatic mode, but can also be operated manually (see

section on Manual Operation).

Internally, the device works with a stable D voltage of 12 V. Standard batteries are not

suitable for operating the HK2. A plug-in power supply for connection to the 230V power

supply is part of the delivery package. The device has IP65 protection and can be used

outdoors without additional protection. The plug-in power supply must be connected in-

doors in any case, since it has no suitable protection for outdoor use.

The basic function can be enhanced or adapted using optional sensors and modules (see

section on Optional Modules).

The JT-LDR external light sensor is definitely required

◦if the control unit is located in the poultry house or is installed in the shade

JT-FT wired remote keys are required

◦if the control unit is in the poultry house, for example.

The JT-FA wired remote display is required

◦if the slider status cannot be seen from a distance

Radio remote control with 2 JT-FB keys are required

◦for operating the slider

Radio remote control with 4 JT-FB4T keys are required

Seite 1 on 14

Original Bedienungsanleitung Klappensteller HK2 10/2020

◦for operating the slider and the lighting

Attractor light (no dimmer function)

◦1 x LED light bar up to max. 12 V / 12 W can be connected directly

You can easily retrofit optional sensors and modules yourself. All the necessary connec-

tions are available and are connected or plugged in using screws (see section on Installa-

tion Instructions). A flexible cable bushing is built into the housing for the additional cables

so that no additional drilling is required.

The housing must be opened in any case to carry out any retrofitting. The power must be

disconnected beforehand. After connecting the sensors and/or modules, close the housing

and reconnect the power supply.

The slider can be controlled according to brightness and the time of day. The setting of the

threshold values is menu-driven and further control options, such as permanent or semi-

automatic operation, are available.

If there is no explicit reference to differences between the HK2.0-R.. framework device and

the HK-2.0 standalone device, these instructions apply to both types of device.

Installation Instructions

The plug-in power supply is usually already connected when you receive the product. If

you have to connect the plug-in power supply yourself, make sure it is connected correctly

to the 12 V terminal (red to +, black to -). If you have purchased optional modules, connect

them as well (see section on Optional Modules). Note the polarity of the attractor light.

Please ensure that you read all the operating instructions in order to be able to make use of all the

features offered by the flap actuator.

HK2 - standalone de ice

Before the electronic flap actuator is put into use, it must be fitted according the installation

instructions and be attached to the chicken door by means of a connection cord. Using the

flap actuator with out the connected slider will lead to malfunctions.

Note the following: (applies only to the standalone device with separate slider)

The aluminium nut of the flap actuator must be directly on the housing (the cord is rolled up). Do not cut this

nut off under any circumstances. Attach a separate connecting cord here (not included in the delivery

package). Push the slider into the open position and now connect the separate cord to the opened slider.

The minimum distance between the upper edge of the opened slider and the lower edge of the HK2 must

be at least 10 cm.

HK2 - R..

The frame unit is pre-assembled ready for use and requires no further assembly work.

Fasten it to your stable with the screws supplied. Use the existing holes in the rails, do not

drill new holes.

Seite 2 on 14

Original Bedienungsanleitung Klappensteller HK2 10/2020

Optional Modules

A R R P

Attractor light Re ote display Re ote key Plug-in Power

Supply

External light

sensor

*The pictures show the cable colours co only used.

The optional remote display indicates the status of the slider (OPEN/ LOSED) over a dis-

tance of about 30 metres.

The extre ely bright LED lights indicate the following:

Red Green Slider status

On Off Open

Off On losed

Flash Off Open (manually)

Off Flash losed (manually)

You can operate the device by hand using the optional remote keys without using a radio

remote control.

The different functions are shown as follows:

Open slider Key ▲

lose slider Key ▼

Seite 3 on 14

Original Bedienungsanleitung Klappensteller HK2 10/2020

If you have ordered a radio remote control, the receiver is pre-installed in the device and

paired with the transmitter. This means that the transmitter and receiver have a common

communication address. You do not have to do anything else.

If you want to retrofit the radio remote control yourself at a later date, please refer to the

pictures below.

Radio receiver Slot for radio receiver Radio receiver plugged in

Operation and Settings

The HK2 flap actuator is operated using the timer display. Operation is menu-driven and is

described below.

General Structure

Key < takes you to the previ-

ous menu item or exits the

< Main or submenu > Key > takes you to the next

menu item or exits the menu

Key  takes you to the submenu or to

the parameter level

Note: If you hold down the > key or the < key in the main or sub-menu level, you automatically scroll

forwards or backwards through the menus.

Key < sets parameters to 0

or factory settings

< Submenu > Key> increases parameters or

scrolls through the list of set-

ting values

Other parameters

Key  confirms the change and goes

to the next parameter or to the sub-

menu.

Note: If you keep the > key pressed in the parameter level, the parameter increases automatically or

scrolls continuously through the list of set values.

To open the menu press  key until the display lighting is switched on.

In order to be able to display / change parameters, use the > key or < key to move

through the main / submenus; it is not possible to go straight to specific parameters. For

most settings, there are limits in the setting range (see section on Factory Setting). The

changed parameters are saved immediately after exiting the menu item and are retained

even in the event of a power failure.

Seite 4 on 14

Original Bedienungsanleitung Klappensteller HK2 10/2020

It is imperative that you exit the menu so that the device switches back to automatic mode.

No functions are possible within the menu.

The enu is structured and divided into the following ain and sub- enu levels:

Flap actuator Date / Time Extras Reset

Timer 1 Time Attractor light

Timer 2 Date Language

Mode

Light sensor

Emergency stop

Redefine the end position

astor

Settings and Changes

Factory Setting

Parameter / Setting alue Factory setting Adjustment range (specified)

Flap actuator

Timer 1 Open 1 7:03 am 3:00 am – 2:59 pm

lose 1 7:05 pm 3:00 pm – 10:59 pm

Timer 2 Open 2 00:00 00:00 – 11:59 pm Time-of-day ranges

must still be ob-

served

lose 2 00:00 00:00 – 11:59 pm

Time-of-day ranges Morning 3:00 am - 2:59 pm Automatically only opening Not adjustable

Evening 3:00 pm - 10:59 pm Automatically only closing

Night 11:00 pm - 2:59 am No automatic function

11:00 pm Forced closure

Operating mode Open +/+ -/-, x/- , x/x , -/x , +/+

lose x/x -/-, x/- , x/x , -/x , +/+

Delay 0 minutes 0 – 60 minutes

Brightness value Open 18 % 15 % - 75 %

lose 5 % 2 % - 12 %

Set the lower end position No Automatic

Emergency stop On On / Off

astor Off On (3 seconds) / Off

Time / Date

Time urrent time

On On / Off

Date urrent date

Extras

Attractor light Off On / Off

Switch-on value 20 % 10% - 30%

Seite 5 on 14

Original Bedienungsanleitung Klappensteller HK2 10/2020

Parameter / Setting alue Factory setting Adjustment range (specified)

Light duration 00 min 05 – 60 min

Language German German, English, French, Dutch

Main menu le el “Flap actuator”

Submenu Timer 1 / Timer 2

Setting the times for automatic opening (▲) and closing (▼) of the slider. Entering times is

limited to the range between 3:00 am and 10:59 pm. No automatic function is available

between 11:00 pm and 2:59 am. This does not apply to manual operation.

The logic of the times is checked when the times are entered. If there are any discrepan-

cies and it is not possible to exit the menu item, the cursor is placed on the incorrect entry

for you to correct the entry.

< Timer 1 > < Timer 2 >

▲7:00 am ▼7:05 pm ▲ 9:00 am ▼ 6:30 pm

If only timer 1 is set, this applies to all days of the week. If timer 2 is also set, this applies

to Saturday and Sunday. Timer 1 applies accordingly from Monday to Friday. Timer 2 is

deactivated if both times are set to 00:00.

Submenu Mode

The operating mode determines the way in which the slider is opened / closed. The front

character stands for the timer function, and the character after the slash for the light sen-

sor. The mode must be set separately for opening and closing.

The following odes are available:

Operating modes* Open/Close if Explanation

0 +/+ Switching time and light sensor value reached

1 x/- Switching time reached Timer only

2** -/x Light sensor value reached Light sensor only

3 x/x Switching time and light sensor value reached

4 -/- Manual key or remote control operated Manual operation only

* The set operating modes apply to both timers and cannot be set separately.

** if selected for evening, the delay submenu described below appears

Exa ples of what the sy bols ean:

Mode Meaning

0 Morning +/+ Slider opens when it is "light" but not before the set opening time

3 Evening x/x Slider closes when it is "dark" or at the set closing time

2 Evening -/x Slider closes when it is "dark" and the set delay time has expired

Seite 6 on 14

Original Bedienungsanleitung Klappensteller HK2 10/2020

Submenu Delay

This submenu is only displayed if mode 2 -/x is set for the evening. The adjustable delay

time only applies to the automatic closing of the slider and does not affect opening or man-

ual operation.

< Delay >

00 minutes

Submenu Light Sen or

Setting of the switching thresholds of the light sensor when the slider is opened (▲) or

closed (▼).

< Light sensor >

85 % □ 18% ■ 05%

Note: the smaller the percentage, the darker it must / can be

Submenu Emergency Stop

The device has a real emergency stop or emergency opening function. This means that

should be an animal under the slider when it is closing, the slider will stop closing and re -

open as soon as it touches the animal. The slider will then attempt to close again. After 3

unsuccessful attempts, this function is temporarily switched off and the slider finally closes.

If "false" emergency stops are triggered too often through the use of cables and guide

rollers or other mechanical impairments (i.e. the slider attempts to close a number of times

without being triggered by animals), the function can be permanently switched off here.

< Emergency stop >

Submenu Redefine End Po ition ( lider CLOSED)

Structural differences between poultry houses mean that the path of the slider has to be

defined. It is necessary to redefine the end position function so that the flap actuator

knows when the slider is closed.

< Redefining the end position >

Please wait

You only have to call up this menu item if you want to reset the lower end position, e.g. be -

cause the slider has changed or the device has been installed in a different position. No

other settings are deleted.

Submenu Ca tor

When using the HK2 as a standalone device with a separate self-locking slider, the motor

must continue to run after the slider has been attached until the locking lever has engaged.

This is done by the castor function.

Seite 7 on 14

Original Bedienungsanleitung Klappensteller HK2 10/2020

< Castor >

Off

Note: No castor is required with the HK-ZSU-Rx. The locking mechanism is located directly in the

control unit.

Main Menu Le el “Time / Date”

The device is delivered from the factory with the current time and date. If you are in a dif -

ferent time zone, if the clock runs incorrectly after changing the battery or if you identify a

rate deviation, you can set the time and date manually.

Submenu Time

The seconds are set to "00" after exiting the menu.

< Time >

10:32 ET/summer time

The automatic normal / summer-time changeover can be switched off if required.

Submenu Date

< Date >

01.01.20

The date is set as follows

1 Year - heck for leap year

2 Month - heck for length of month

3 Day - Determine the day of the week

Note: Time and date are also current after a power failure (backup battery available)

Main menu le el “Extras”

Submenu Attractor Light

The attractor light is used to attract animals into the poultry house before the slider closes.

The light is switched on or off, and dimming is not possible.

< Attractor light >

Off 20% 00 min

The attractor light is switched on when the set switching threshold is reached and the

slider is OPEN. After the slider closes, the attractor light lights up for the set time.

Submenu Language

After changing the language and exiting the language menu, the device restarts. All dis-

play outputs are then shown in the selected language.

Seite 8 on 14

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere JOSTechnik Controller Handbücher

JOSTechnik

JOSTechnik HK2.0-R Series Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
