2. CONNECTION
1. GENERAL INFORMATION
Dear customer,
thank you very much for choosing our product.
In the following, we will introduce you to what to observe while starting
up and using this product.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us.
During use, special attention must be paid to the personal rights and
the right to informational self-determination that apply in Germany.
Connect the camera module to the CSI interface of your Raspberry Pi
with the included ribbon cable as shown in the picture. Pay attention to
the orientation of the cable.
3. INSTALLING THE CAMERA
To use the camera with your Raspberry Pi, you just need to add two lines
to Config.txt.
To do this, enter the following command to open the file you want to
edit:
Now add the following two lines to the end of the file:
Aerward, you can save the file with CTRL+O and close it with CTRL+X.
Then restart your Raspberry Pi with the following command:
sudo nano /boot/config.txt
dtoverlay=imx219
camera_auto_detect=0
sudo reboot
4. USING THE CAMERA
4.1 Taking pictures
To capture images with the camera, the following console command can
be used:
The image is then saved under the name test.jpg. The numbers aer --
width and --height represent the resolution in pixels used for the photo.
4.2 Recording videos
Videos can be recorded with the following command:
The video is then saved under the name test.h264. The number aer -t
represents the recording time in milliseconds.
The numbers aer --width and --height represent the resolution used for
the video in pixels.
libcamera-jpeg --qt -r -o test.jpg --width 3280 --height 2464
libcamera-vid --qt -t 10000 -o test.h264 --width 1920 --height 1080
5. ADDITIONAL INFORMATION
Our information and take-back obligations according to
the Electrical and Electronic Equipment Act (ElektroG)
Symbol on electrical and electronic equipment:
This crossed-out dustbin means that electrical and electronic appliances
do not belong in the household waste. You must return the old appliances
to a collection point.
Before handing over waste batteries and accumulators that are not en-
closed by waste equipment must be separated from it.
Return options:
As an end user, you can return your old device (which essentially fulfills
the same function as the new device purchased from us) free of charge for
disposal when you purchase a new device.
Small appliances with no external dimensions greater than 25 cm can be
disposed of in normal household quantities independently of the pur-
chase of a new appliance.
Possibility of return at our company location during opening hours:
SIMAC Electronics GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn, Germa-
ny
Possibility of return in your area:
We will send you a parcel stamp with which you can return the device to
us free of charge. Please contact us by email at Service@joy-it.net or by
telephone.
Information on packaging:
If you do not have suitable packaging material or do not wish to use your
own, please contact us and we will send you suitable packaging.
6. SUPPORT
If there are still any issues pending or problems arising aer your purcha-
se, we will support you by e-mail, telephone and with our ticket support
system.
Email: service@joy-it.net
Ticket system: http://support.joy-it.net
Telephone: +49 (0)2845 9360-50 (10-17 o‘clock)
For further information please visit our website:
www.joy-it.net
