OWNER’S

MANUAL

CQ SERIES

SEQUENCED POWER CONTROL

COVERS MODELS

CQ-1515TM, CQ-1520TM, CQ-1TM, CQ-2200TM,

CQ-3000TM and CQ-PD1-4TM

FEBRUARY 2015

File: 3176209DEN-001

Standard: UL508

DISCLAIMER

Juice Goose shall under no circumstances be held responsible for any

losses, damage, or injury resulting directly or indirectly from the use of a CQ

Series device in a manner contrary to accepted safe operating methods or

any instructions contained in this document. The user should determine prior

to use whether this product is adequate, suitable and safe for the application

intended. Since individual applications can be subject to extreme variation

Juice Goose makes no representation or guarantee as to the suitability of a

CQ product for any generally described application.

CQ-SERIES

SEQUENCED POWER CONTROL SYSTEM

The Juice Goose CQ Series products are power distribution devices that will

control AC power application to multiple pieces of equipment. The primary in-

tent of the design of this equipment is to power rack mounted audio or video

equipment with electric power current requirements of less than 15 amps, 20

amps or 30 amps depending on the CQ model being considered.

All CQ Series products can be remote activated. Several CQ devices can be

connected to form a power sequencing system that includes multiple circuits in

multiple locations.

SAFETY PRECAUTIONS

CQ Series products are designed to operate at 120 volts, 60 hertz. Operation

with any voltage or frequency other than that can damage the equipment and

create an unsafe situation.

CAUTION #1: All CQ devices must be grounded. If a power extension cord is

required, use a properly insulated and grounded cord. Failure to ground the

device could expose the user to dangerous electric shock.

CAUTION #2: All CQ devices should be installed only by qualified electrical

technicians using appropriate mounting hardware and correct installation tech-

niques. When installing make sure main power is off before attaching the CQ

device. There are no user serviceable parts inside any of the CQ products.

CAUTION #3: Do not expose the CQ product to moisture or salty air. Doing so

could cause significant damage and create an unsafe condition.

PRÉCAUTIONS DE SÉCURITÉ

Série CQ produits sont conçus pour fonctionner à 120 volts, 60 hertz. Fonction-

nement avec une tension ou une fréquence autre que celle qui peut endom-

mager l'équipement et de créer une situation dangereuse.

ATTENTION #1 : CQ tous les périphériques doivent être mis à la terre. Si une

extension de cordon est nécessaire, utiliser un correctement isolés et cordon

mis à la terre. Échec à la masse le périphérique pourrait exposer l'utilisateur à

choc électrique.

ATTENTION #2 : Tous les périphériques CQ ne devrait être installé que par

des électriciens qualifiés avec matériel de montage approprié et correct tech-

niques d'installation. Lors de l'installation assurez-vous que l'alimentation princi-

pale est hors tension avant de procéder à l'accrochage de la CQ périphérique.

Il n'y a aucune pièce réparable par l'utilisateur à l'intérieur des CQ produits.

ATTENTION #3 : Ne pas exposer le CQ produit de l'humidité ou air salé. Cela

pourrait causer des dommages importants et créer une situation dangereuse.

DETAIL SPECIFICATIONS

DIMENSIONS (H x W x D inches)

CQ 1515 & CQ 1520……..………………….…………….....….....………...1.72 x 19.00 x 7.00

CQ 1(Including 3 Gang Utility Box).............................................................4.50 x 6.50 x 3.75

CQ 2200 ................……………….......................……………………………5.50 x 6.40 x 3.75

CQ 3000.....................................................................................................9.00 x 6.00 x 4.00

CQ PD1-4.…..…………………………………………….....………………...32.00 x 3.50 x 2.00

WEIGHT (lbs)

CQ 1515 & CQ 1520….…………..…………………………...........................……………..10.0

CQ 1...................................................................................................................................1.0

CQ 2200 ................…………………………....…………………..............……………………4.0

CQ 3000.............................................................................................................................6.0

CQ PD1-4……………………………………............................................................……...15.0

CIRCUIT BREAKER

CQ 1515.........................................................................................Back Panel, 15A Thermal

CQ 1520………………………………………………........…………..Back Panel, 20A Thermal

CQ 1...............................................................................................................................None

CQ 2200………………................………………………..…………...Side Panel, 20A Thermal

CQ 3000………………………......…………………………………….Side Panel, 30A Thermal

CQ PD1-4…………………………………………………………………...………………….None

POWER INPUT

CQ1515……….........………..………....…Power Cord, 7 Foot, 14/3 SJTW with NEMA 5/15P

CQ1520……….........………..………....…Power Cord, 7 Foot, 12/3 SJTW with NEMA 5/20P

CQ 1.........................................................................................................................Hardwire

CQ 2200 .……….......................................…...Hardwire with Crimp Tight Fast-on Terminals

CQ 3000.....................................................................................Hardwire to Screw Terminal

CQ PD1-4……………….............................…………Hardwire with External 4’ Wire Harness

VOLTAGE INPUT.……………………………………………...……………...120 VAC at 60 Hz

POWER OUTPUTS

CQ 1515.…,,…..........…..Six NEMA 5/15R, Sequenced and One NEMA 5/15R Unswitched

CQ 1520.…,,…..........…..Six NEMA 5/20R, Sequenced and One NEMA 5/15R Unswitched

CQ 1...........................................................................................................Two NEMA 5/15R

CQ 2200……………………………………………….......…….Four NEMA 5/20R, Sequenced

CQ 3000.…....................................................................…..One NEMA L5/30R, Sequenced

CQ PD1-4..………………………………………………...…...Eight NEMA 5/20R, Sequenced

NUMBER OF SEQUENCE EVENTS

CQ 1515 & CQ 1520..………………………………………………………………………..Three

CQ 1.…………………………….......…………………………………………………………..One

CQ 2200……………………………….………………………………………………………...Two

CQ 3000……………………………….………………………………………………………...One

CQ PD1-4……………………………….……………………………………………………….Four

POWER LINE FILTRATION

CQ 1515 & CQ 1520……..……………..........……………Multi-stage Filter (48dB at 30 MHz)

VOLTAGE SPIKE PROTECTION

CQ 1515 & CQ 1520….………………………...…................………Triple MOV Matrix, L-N-G

COMMUNICATIONS LINE…........................……RJ-45 (See Owners Manual for Assembly)

MONITOR FEATURES………....................................................................Front Panel LEDs

INSTALLATION

CQ 1515 & CQ 1520 —Mount the CQ-1515 or CQ-1520 to a 19” wide rack

with metal mounting rails, designed with 1.75” spacing. Use appropriate rack

mounting hardware. Plug the power cord into a grounded outlet. Do not de-

feat the grounding feature of the power cord.

CQ 1, CQ 2200, CQ 3000 & CQ-PD1-4 -These products were designed to be

installed only by qualified electrical technicians. Failure to follow correct instal-

lation techniques and instructions could result in equipment damage and/or

personal injury.

CQ 1 -This product should be installed in a three gang utility box mounted

inside a wall. The installation process may vary depending on whether the

installation is in new or retrofit construction. Fit the utility box into the space

where the CQ 1 will be installed.

CAUTION: Be certain power has been turned off at the breaker panel or dis-

connected before installation. (ATTENTION: certains power a été désac-

tivé sur le panneau de disjoncteur ou déconnecté avant l'installation.)

Pull the main power cable and the RJ45 signal cable(s) into position inside the

utility box. Connect the power feed to the corresponding colored wires on the

CQ 1 using wire nuts or another acceptable method. Plug the input signal ca-

ble into the Input port on the CQ1 and the output cable into the Output port.

Install the CQ 1 enclosure and cover plate onto the utility box with the screws

provided with the unit.

CQ 2200 & CQ 3000 are intended to be hardwired to a main utility power sup-

ply with power cable routed through conduit. A “squeeze” type conduit connec-

tor is assembled onto the CQ back box specifically for this purpose. A power

line strain relief is also included in the box with the CQ device in case alternate

power connection is necessary.

These two CQ Series models have front panel and a back box construction

that are held together with seven screws. To begin installation, remove the

screws that hold these two pieces together. The back box has four holes in

the back surface. These holes are large enough to accommodate mounting

screws or bolts (not included) to hold the CQ device securely to a stable, flat

mounting surface, such as a wall. At least two screws or bolts should be used

to mount the back box.

CAUTION: Be certain power has been turned off at the breaker panel or dis-

connected before installation. (ATTENTION: certains power a été désac-

tivé sur le panneau de disjoncteur ou déconnecté avant l'installation.)

After the back box is secured, feed the cable that is connected to the desired

power source through the hole in the side of the back box. Securely crimp a

connector (provided) to the end of each wire lead (hot, neutral and ground).

Press the connectors onto the appropriate locations on the circuit board as

labeled. Attach the front panel (containing the circuit board) to the back box

using all seven screws. Gently pull excess cable length out of the box by

tugging slightly on the cable from the outside of the box. Insert conduit into

squeeze connector and tighten the connector to hold the conduit in place.

CQ-PD1-4 -The CQ-PD1-4 has two slotted side brackets that can be relo-

cated along the length of the chassis. Use only appropriate hardware (not

included) and use four mounting holes to secure the device. The wire har-

ness should be connected directly to a circuit breaker panel or to an appro-

priate junction box.

SIGNAL CABLE ASSEMBLY

The interconnecting CQ Series devices requires eight wire, RJ-45 cable.

While this is the same component used to assemble CAT5 and CAT6 ca-

bles, orientation of the connectors on the CQ Series cable is slightly differ-

ent than for the CAT data networking cable. Therefore, standard CAT5 or

CAT6 cables will not work with CQ Series devices.

After crimping a RJ45 connector on one end of the eight wire cable, attach a

connector on the other end “upside down” from the first so that when the

connectors are placed side by side the wire orientation will appear as shown

in the above illustration. Check the cable with a continuity tester prior to in-

stallation.

There is no known distance limit for the connection of CQ units by means of

this cable system. The CQ signal is not sensitive to voltage changes or fre-

quency interference.

1 2 3 4 5 6 7 8 8 7 6 5 4 3 2 1

REMOTE SWITCH CONNECTION

Although a Juice Goose CQ Series product can be remote controlled with a

Juice Goose RC-5 accessory or another CQ device, it can also be remote

activated with a simple contact closure using a switch or relay. The following

instructions are provided to assist with this configuration. This information is

also useful for assembling interface wiring going to and from the RJ type

cable specified for the CQ system.

SINGLE POLE DOUBLE THROW

LATCHING SWITCH

In the illustration below, connecting a single pole, double throw (SPDT)

switch to the signal input line of a CQ Series device will control the se-

quence up and down activity. Closing Pin 3 to Pin 7 will begin a sequence

UP. Closing Pin 4 to Pin 7 will begin a sequence DOWN. Closing both 3 and

4 to 7 will PAUSE. the sequence process. The control switch on the chassis

will be inoperative, except for the Manual On feature, when there is such a

contact closure on the input line.

OPERATION

These versatile CQ devices can be controlled by way of either another CQ

device, a remote latching contact closure, a Juice Goose RC5 accessory

unit or the switch on the CQ device itself (except the CQ 1).

CQ DEVICES -Any CQ device can operate in concert with others. Each

can be a master (except the CQ 1) or slave unit. Any number of CQ de-

8 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8

PIN ASSIGNMENTS

The chart above shows assigned locations for each

of the eight pins on the RJ45 connectors on the CQ

Series Signal Input and Output. Note: although

there are eight pins, only the middle six are being

used.

This information may be used to connect a latching

contact, as per the diagram on the previous page.

It also illustrates the reversed orientation of the

connectors on each end of a CQ signal cable.

Pin assignments are correct when viewed from the

outside of the chassis.

Signal

Input

Signal

Output

CQ Series

Signal Cable Connectors

vices can be connected in a daisy chain fashion to operate as a power

sequencing system.

REMOTE CONTACT CLOSURE -As one option, to control the sequenc-

ing function, the Signal Input for the first CQ device can be connected to a

contact closure (see Remote Switch Connection). Any latching switch or

relay will work. Juice Goose recommends use of a double throw device in

order to maintain one of two contact closures at all times. Digital proces-

sor controlled devices such as those produced by Crestron and similar

companies will also work to control the CQ system.

RC-5 REMOTE ACCESSORY -Juice Goose offers, as an accessory, the

RC-5 Remote Control/Monitor. These devices provide sequence control

as well as indicators to show the status of the power sequencing opera-

tion. The RC-5 connects directly to the Signal Input of the first CQ device.

SEQUENCE SWITCH (Not including the CQ 1) -Without a contact clo-

sure on the Signal Input, the switch on the front or top of the CQ device

will control its operation. Switches on the CQ 2200, CQ 3000 and CQ

PD1-4 have three positions: Sequence up, Sequence Down and Manual

On. The Sequence Up and Down positions will activate the sequence

process for that CQ unit and cause it to activate any units connected to its

Signal Output. In the event of a failure of a particular CQ unit, the Manual

On switch position allows activation of the CQ device. (Note: the Manual

On option does not provide sequencing). The CQ 1515 and CQ1520 have

a two position sequence switch and a second, recessed Manual On

switch on the front panel of the chassis.

MONITORING

Each CQ Series device has a number of LEDs on the chassis to allow real

time monitoring of the device’s operation.

On all CQ models, one LED indicates the processor is running the CQ

control program. That LED blinks on all models except the CQ 1 on which

that LED is on but static. Should there be a question about the product’s

performance, the processor LED indicates the status of the electronic

circuitry that controls the CQ unit.

In addition, each CQ model except the CQ 1 and CQ PD1-4 has a number

of LEDs that corresponds to that unit's number of Pods (i.e. sequence

events). Each Pod LED lights to indicate that a sequence stage has been

completed and the corresponding POD has power.

Juice Goose also offers as accessories RC-5 remote and monitor devices

that provide indications of sequence operation and completion. For more

information about the RC-5, contact your Juice Goose dealer, refer to the

Juice Goose product catalog or visit our website, www.juicegoose.com.

IN CASE OF MALFUNCTION

The Juice Goose CQ Series of products are ruggedly constructed and contain quality components.

There are no user serviceable parts inside a CQ device. Unauthorized service will void all existing

warranties and may result in equipment damage and personal injury.

Should improper performance be observed consult the following guidelines for diagnosis.

SYMPTOMS AND SOLUTIONS.

(NOTE: References to LEDs and circuit breakers do not apply to the CQ-1 and CQ-PD1-4)

1. Unit will not turn on.

a. Check to see that main utility power is available.

b. Check that the circuit breaker on the CQ unit is not tripped.

c. Check the Processor LED on the chassis. If it is not lit the CQ device is probably not

receiving power. If it is lit but not flashing the CQ processor is not running. Remove power from the CQ

device by unplugging it or turning off the circuit breaker that feeds the unit. Then restore power to reset

the CQ processor. The CQ processor has an automatic reset (“watchdog”) feature. However, should

the processor “freeze”, removing and returning power to the device should correct the malfunction.

d. If the device is being remotely activated:

i. Check the signal line leading to the CQ signal input. Disconnect the signal

input cable and try to activate the CQ product with the switch on the chassis. If this works either the

cable is bad or the control device intended to remote control the CQ in question is failing to create the

correct contact closure. If possible, exchange the cable in question with a known good cable. If this

does not solve the problem examine the remote activation device and its connections to the cable.

ii. Refer to the manual’s Signal Cable Assembly and Remote Switch Connec-

tion sections.

iii. If the CQ device is being operated by another CQ unit check that controlling

unit. Is the controlling unit operating properly? Is its Processor LED flashing?

2. Unit will not turn off.

a. It is likely that when a unit fails to turn off the cause is similar to that which would cause

a unit to fail to turn on.

b. Follow steps outline in 1 c. and d., above.

c. Once a system of interconnected CQ devices is turned on, a specific CQ device will not

turn off if the device following it in the turn-on sequence is still on. Check the CQ device following the

CQ device in question. Has it turned off properly? If not, check all the following units to the end of the

CQ system. Follow the steps in 1., above regarding the last unit that is misperforming.

3. Unit turns itself off unexpectedly.

a. The unit may have encountered excessive current draw that caused the circuit breaker

to trip. Examine the breaker. If it has tripped, the button section of the breaker will be extended and

can be reset by pushing it in after the unit has been off for a brief period.

b. Review the current requirement of the equipment plugged into the CQ device and com-

pare it to the amperage rating of the CQ device in question. See the Detail Specification section of this

manual.

If the problem can not be remedied or if the encountered problem is not listed here and particularly if

any evidence of severe or hazardous performance is observed, immediately disconnect power to the

CQ device and contact your local Juice Goose dealer or Juice Goose directly.

SERVICE

Should your unit require service, contact Juice Goose to receive a service authorization number. This

number will allow us to track your returned unit. Please note that no returns will be accepted without

such a number.

7320 Ashcroft, Suite 104

Houston, Texas 77081

(p) 713-772-1404

(f) 713-772-7360

(e) [email protected]

www.juicegoose.com

Andere Handbücher für CQ Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere JuiceGoose Controller Handbücher

JuiceGoose

JuiceGoose CQ Series Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
