JuicePro ALI-VJP-W2 Handbuch

For Customer Care visit www.juice-pro.com.au

1300 764 325

Alibaba Imports Pty Ltd

c/- Perks & Associates

180 Greenhill Road

Parkside SA 5063 Australia

www.juice-pro.com.au

Congratulations on your purchase

of a JuicePro Cold Press Juicer

Note: Please read through the instructions carefully before using or installing the product and ensure that the

manual is kept in a safe place for future reference.

The system must be properly installed and located in accordance with the installation instructions before it is used.

Electrical Requirements:

Australia / New Zealand 240V / 230V 50Hz

Due to manufacturing alterations product may

vary slightly from that is pictured.

N 31230

INSTALLATION AND OPERATING INSTRUCTIONS | WWW.JUICE-PRO.COM.AU 1

OPERATION CONDITIONS & SAFETY PRECAUTIONS

• All components need to be installed in accordance with the

user manual instructions for correct per formance of unit.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance

by a person responsible for their safety.

• Children should be supervised to ensure that they do not play

with the appliance.

• Do not operate any appliance with a damaged cord or plug or

after the appliance malfunctions.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualiﬁed persons in

order to avoid a hazard.

• To protect against risk of electrical shock, do not put the main

body (motor) in water or any other liquid.

• Unplug from outlet when not in use, before assembling or

taking off parts and before cleaning.

• Avoid contact of moving parts.

• Do not use attachments not recommended or sold by the

manufacturer as it may lead to ﬁre, electric shock or injury.

• Always ensure you switch the juicer to the off position and the

motor has stopped completely before disassembling.

• Do not put your ﬁngers or foreign objects into the juicer while

it is in operation. If food becomes lodged in the inlet use the

plunger to push it down, or use the reverse button on the

machine to dislodge. If this is not possible turn juicer off and

wait for motor to completely stop before disassembling juicer to

remove food.

• Do not use outdoors.

• Do not use appliance for other than intended purpose.

• Lift appliance with the handle only.

• Do not put any parts into the dishwasher,

NOT dishwasher safe.

• Do not use appliance continuously for more than 15 minutes

as overheating will automatically shut down the unit. This unit

is for household use only and warranty is not extended to units

used for commercial purposes.

• Do not use the appliance to juice hard materials, including pips,

ice, frozen fruit, large seeds.

2INSTALLATION AND OPERATING INSTRUCTIONS | WWW.JUICE-PRO.COM.AU

INSTALLATION & OPERATING INSTRUCTIONS

A. Component identiﬁcation & content check list:

ALI-VJP-W2 / ALI-VJP-R2 - JuicePro Cold Press Juicer

Ref Description Qty

Main Components

A Hopper 1

B Squeezing Screw 1

C Strainer (yellow) - less pulp 1

D Spinning Brush 1

E Bowl 1

F Base 1

G Cleaning Brush 1

H Pusher 1

I Container 2

Note: Do not pre-operate before inputting materials or do not

operate with an empty bowl.

Important: The Base, Bowl and Hopper must be correctly

aligned for the machine to operate correctly. (See Fig 1).

Fig 1

Pulp

outlet Juice outlet

INSTALLATION AND OPERATING INSTRUCTIONS | WWW.JUICE-PRO.COM.AU 3

B. Assembly Instructions:

Important: Prior to Assembling the Juicer please check this point:

At the base of the bowl there is a rubber stopper. When in place

the stopper ensures all of the juice only exits via the juice outlet.

Before juicing always ensure that the rubber stopper is ﬁrmly in

place. (See Fig 2).

1. Assemble the bowl on the base

(See Fig 3).

A. Make sure the bowl is sitting

securely on the base.

2. The strainer supplied is a ﬁne strainer and will reduce the

amount of pulp in your juice.

A. Insert the strainer into the spinning brush.

B. Align the dot on the strainer

with the dot on the bowl and

insert strainer + spinning

brush into the bowl. When the

dots are correctly aligned the

strainer + spinning brush will

lock in place. (See Fig 4).

3. Insert the squeezing screw

into the strainer and turn

until it drops into position.

(See Fig 5).

Fig 2

Rubber stopper

Fig 3

Bowl

Fig 5

Squeezing

screw

Fig 4

Dot on

strainer

Strainer Spinning

brush

Dot on the

bowl

4INSTALLATION AND OPERATING INSTRUCTIONS | WWW.JUICE-PRO.COM.AU

4. Assemble the hopper onto

the bowl. (See Fig 6).

A. Align the small arrow on the

hopper with the dot on the bowl.

B. Twist the hopper clockwise

so that the plastic tab on the

hopper is in line with the on/off

switch and handle. (See Fig 7).

Note: The small arrow from part

4.A will no longer be aligned with

the dot once the hopper is locked

to the close position. (See Fig 7).

C. Operating Instructions:

Warning:

• Do not operate the juicer with wet hands as it may cause an

electric shock.

• Do not operate the juicer prior to imputing juicing materials.

• Do not operate for more than 15 minutes at one time.

Important:

To protect the motor and provide you with a long lasting machine

the Juice Pro has an auto shut down feature. If the components

are not aligned or installed correctly, the motor overheats due to

extended juicing or the strainer becomes clogged the machine will

automatically shut down. This is normal and prevents damage to

your Juice Pro.

If this happens switch the machine off. Check components are

correctly installed and that there is no food caught in the strainer.

Wait 5 minutes for the motor to cool then recommence normal

operation.

Fig 7

Fig 6

dot on bowl

hopper arrow on

hopper

INSTALLATION AND OPERATING INSTRUCTIONS | WWW.JUICE-PRO.COM.AU 5

1. Plug in the juicer.

2. Place a container below the juice outlet and a container below

the pulp outlet.

3. The juicer power button (located at the top of the handle)

has 3 positions.

A. ON - This starts the motor and juicing process.

B. OFF - Is the central position of the button. It switches off

the appliance.

C. REV - Is reverse. Only use this function when something is

stuck in the juicer and it needs to be unclogged.

4. Prepare the material you wish to juice. The Juice Pro is

designed to juice many different materials. The preparation for

each material will differ, the below points are a guide. Please

read page 8 and 9. Getting started with your Juice Pro for

further tips on Juicing.

• Ensure juice material is cut into small portions for optimal juice

extraction. Each portion should easily fall down the hopper

chute without the need for force.

• Remove any large pips or seeds. This includes stones from

stone fruits and peel from citrus fruits.

• Always pre-wash food before juicing.

5. Switch the power button to ‘ON’. Insert the food into

the hopper.

• Insert food slowly one piece at a time and allow juicer

time to work.

• Do not overstuff the hopper

or force food in. The pusher

is only to be used if food

becomes stuck. (See Fig 8).

6. When you are ﬁnished switch

the power button to ‘OFF’.

Note: If you are making multiple

juices in one session to avoid

cross over of ﬂavours, pour

water into the hopper between

drinks to clean the unit. Capture

rinsing water in a separate bowl

so as not to dilute your juice.

Depending on the material being

juiced you may need to clear

some pulp from the strainer.

REV

OFF

Fig 8

Insert pieces

Pusher

6INSTALLATION AND OPERATING INSTRUCTIONS | WWW.JUICE-PRO.COM.AU

D. If the machine becomes clogged and inoperable:

1. Turn the machine off and press the reverse button for a few

seconds then try operating again. Note: The reverse button

works with a ‘pulse’ motion.

2. If the reverse button does not work turn off the machine

and switch off at the power point. Disassemble the unit to

dislodge any material then reassemble as per the instructions

and try again.

E. How to disassemble and clean the unit:

1. Switch off the unit.

2. Twist the hopper anti clockwise then lift off.

(See Fig 9). Lift the bowl straight up to remove from the base.

3. Disassemble the parts from the bowl in the order shown by the

diagram. (See Fig 10).

4. Use the brush to clean all of these parts thoroughly in warm

soapy water then dry thoroughly. Ensure the pulp outlet on

the bowl is clear (the end of the cleaning brush is designed to

clear trapped material from the pulp outlet). Unplug the rubber

stopper for easier access to the pulp outlet.

Caution: Before juicing ensure the rubber stopper is ﬁrmly in place.

(See Fig 2, Page 3).

5. Use a damp cloth to wipe down the base of the unit.

Cleaning Tips:

• Periodically remove the silicone brushes from the spinning

brush and clean thoroughly before reassembling.

• Thoroughly clean immediately after each use to minimize staining.

• Pull out the rubber stopper on the base of the bowl to clean

bowl effectively. Always ensure the rubber stopper is re-inserted

prior to juicing otherwise it may cause a leak.

• Do not use harsh abrasives or chemicals to clean the juicer.

• Do not clean in the dishwasher.

1 2 3 4

Fig 10

Fig 9

INSTALLATION AND OPERATING INSTRUCTIONS | WWW.JUICE-PRO.COM.AU 7

TROUBLE SHOOTING

BEFORE YOU CALL FOR SERVICE PLEASE REVIEW THE TROUBLE SHOOTING TIPS FIRST.

Problem Possible Causes What To Do

No power to juicer.

Juicer not plugged in. Check the juicer is plugged in.

Incorrect assembly. Reassemble the juicer according to the instructions.

Motor has stopped.

Bowl has been overﬁlled with material. Press the reverse power button to try and clear the clog.

May need to be try this a few times.

Overuse has caused the motor to shut

down as a precaution to overheating. Switch off and let the motor cool before using again.

Leaking from beneath the

bowl.

Rubber plug on base of bowl not correctly

inserted. Rubber plug on base of bowl not correctly inserted.

A small amount of residual juice is normal. It is normal to ﬁnd a small amount of juice, clean from

the appliance with damp cloth.

Stain on the bowl, strainer,

spinning brush. Natural colour from juicing materials.

This is perfectly normal. To reduce discolouration

ensure you rinse and clean the appliance immediately

after use.

Squeaking noise during

operation. Juicing noise from squeezing screw. This is perfectly normal. Ensure you do not overload

the juicer.

Damage to the strainer. Frozen foods, ice, pips, seeds, unknown

substance or too much material in the bowl.

Ensure you read the instructions carefully on the correct

use of the juicer. Do not overﬁll the juicer.

Spare parts available, visit www.juice-pro.com.au

8INSTALLATION AND OPERATING INSTRUCTIONS | WWW.JUICE-PRO.COM.AU

Material Size and Juicing Speed

The size of the material and the speed at which you feed it

into your juicer is very important in achieving good results.

To familiarise yourself with the process we recommend you

start with easy to juice materials such as citrus fruits.

(Remember to always remove the peel ﬁrst!).

Cut the material into small portions that will easily fall down

the hopper chute without being forced. The harder the fruit or

vegetable type the smaller the portion should be, for example

carrot and beetroot should be cut into 2cm segments.

Feed the material into the hopper, generally a segment at a time.

Allow the juicer time to work and process the material before

adding more. Gradually increase the feeding rate, through trial and

error you will soon familiarise yourself with the right material size

and feeding speed.

You will ﬁnd that harder materials like beetroot may need longer to

process than softer materials like citrus fruit.

Time to Experiment

Once you are conﬁdent in using your juicer get creative and

experiment, who knows you may just invent a new ﬂavour!

Here are a few ideas to get you started:

• You can try all sorts of fruit / vegetable combinations - don’t

forget to try adding beetroot, cucumber, broccoli, berries or

tomatoes to name a few.

• Juice leafy greens such as spinach or wheat grass.

(See page 9 for juicing for leafy greens.)

• Try adding fennel for an aniseed ﬂavour.

• To get a nice kick add a small amount of Ginger or Garlic.

• Make an almond or soy milk. (See page 9 for Soy & Nut milks.)

Getting started with your Juice Pro

Juicing is a fun and easy way to enjoy fruit and vegetables.

The different taste combinations are endless and only limited by your imagination!

The Juice Pro Cold Press Juicer is not a conventional juicer and therefore cannot be used in the same way.

Take the time to get to know the mechanics of your juicer and how it works best, to do this we suggest you

start with easy to juice items and work up to experimenting with different ﬂavour combinations.

Andere Handbücher für ALI-VJP-W2

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere JuicePro Entsafter Handbücher

JuicePro

JuicePro ALI-VJP-W2 Handbuch

Beliebte Entsafter Handbücher anderer Marken

GE 169201 Bedienungsanleitung

Exquisit

Exquisit ZP 3001 WET Bedienungsanleitung

Philips

Philips HR1851 Bedienungsanleitung

Sam Cook

Sam Cook MASTERCHEF EXECUTIVE PSC-50 Bedienungsanleitung

Termozeta

Termozeta spremiagrumi Bedienungsanleitung

ElectrIQ

ElectrIQ WF1000 Bedienungsanleitung

Bella

Bella WHOLE FRUIT JUICER Bedienungsanleitung

HAEGER

HAEGER Little Juice CJ-025 006A Bedienungsanleitung

Havells

Havells Fusion Bedienungsanleitung

Siemens

Siemens MK554 SERIES Bedienungsanleitung

Beper

Beper 90.302B Kurzanleitung

NATURSAFT

NATURSAFT 015.401.3 Bedienungsanleitung

Moulinex

Moulinex BKB 2 Bedienungsanleitung

Royal Catering

Royal Catering RCJU-01 Bedienungsanleitung

camry

camry CR 4002 Bedienungsanleitung

AIGOSTAR

AIGOSTAR 30HIM Bedienungsanleitung

ZUMEX

ZUMEX MINEX Bedienungsanleitung

Skymsen

Skymsen EX Bedienungsanleitung
