SRX5800 Services Gateway Getting Started
Guide
December 2013
Part Number: 530-055498
Revision 01
This document describes how to install the SRX5800 Services Gateway.
Contents About This Guide | 3
Step 1: Prepare the Site for SRX5800 Services Gateway Installation | 4
Rack-Mounting Requirements | 4
Tools Required to Unpack and Prepare the SRX5800 Services Gateway for Installation | 6
Step 2: Install the Mounting Hardware | 6
Install the Mounting Hardware in a Four-Post Rack or Cabinet | 6
Install the Mounting Hardware in an Open-Frame Rack | 8
Step 3: Install the Services Gateway | 9
Remove Components | 9
Install the Services Gateway | 11
Reinstall Components | 12
Step 4: Connect the Grounding Cable | 13
Step 5: Connect External Devices and Network Cables | 14
Connect to a Network for Out-of-Band Management | 15
Connect a Management Console | 15
Connect the Network Cables | 15
Step 6: Connect Power Cables | 17
Connect Power to an AC-Powered Services Gateway | 17
Connect Power to a DC-Powered Services Gateway | 21
1
Step 7: Perform the Initial Software Configuration | 25
Enter Configuration Mode | 26
Configure User Accounts and Passwords | 26
Configure System Attributes | 27
Commit the Configuration | 28
Safety Warnings | 31
SRX5800 Services Gateway Compliance Statements for EMC Requirements | 34
Canada | 34
European Community | 35
Japan | 35
United States | 35
SRX Series Documentation and Release Notes | 35
Requesting Technical Support | 36
Revision History | 37
2
About This Guide
This guide contains information that you need to install and configure the SRX5800 Services Gateway
quickly. For complete installation instructions, see the SRX5800 Services Gateway Hardware Documentation
at www.juniper.net/documentation/.
WARNING: This guide contains a summary of safety warnings in “Safety Warnings” on
page 31. For a complete list of warnings for this services gateway, including translations,
see the SRX5800 Services Gateway Hardware Documentation at
www.juniper.net/documentation/.
The SRX5800 Services Gateway is a high-performance, highly scalable, carrier-class security device with
multiprocessor architecture. The services gateway is 16 rack units (RU) tall. Three services gateways can
be stacked in a single floor-to-ceiling rack, for increased port density per unit of floor space. The services
gateway provides 14 slots that can be populated with up to 12 Services Processing Cards (SPCs) and
interface cards and two Switch Control Boards (SCBs) in nonredundant fabric configurations. The interface
cards can be any of the following types:
•I/O cards (IOCs) have fixed ports on their front panels.
•Flex I/O cards (Flex IOCs) have two slots on their front panels for smaller cards called port modules that
add additional ports to the services gateway.
•Modular Port Concentrators (MPCs) have two slots on their front panels for smaller cards called Modular
Interface Cards (MICs) that add additional ports to the services gateway.
The SRX5800 Services Gateway provides redundancy and resiliency. The hardware system is fully redundant,
including power supplies and SCBs.
By installing various combinations of interface cards and SPCs, you can tailor both the number of ports
and the maximum services processing capacity to suit your network. Table 1 on page 3 describes the
minimum system configuration for the SRX5800 Services Gateway.
Table 1: Minimum System Configuration
MinimumComponent
1SPC
1Interface card (IOC, Flex IOC, or MPC)
1SCB
3
Table 1: Minimum System Configuration (continued)
MinimumComponent
1Routing Engine
For detailed information about the cards supported by the services gateway, see the SRX5400, SRX5600,
and SRX5800 Services Gateway Card Reference at www.juniper.net/documentation/.
The services gateway is shipped in a cardboard box strapped securely to a wooden pallet. Plastic straps
secure the top and bottom in place. The services gateway chassis is bolted to this pallet. A printed copy
of this document and a cardboard accessory box are also included in the shipping container.
Step 1: Prepare the Site for SRX5800 Services
Gateway Installation
IN THIS SECTION
Rack-Mounting Requirements | 4
Tools Required to Unpack and Prepare the SRX5800 Services Gateway for Installation | 6
Rack-Mounting Requirements
•You can install the services gateway in a four-post rack or cabinet or an open-frame rack.
•The rack rails must be spaced widely enough to accommodate the services gateway chassis’s external
dimensions: 27.75 in. (70.5 cm) high, 23.0 in. (58.4 cm) to 27.7 in. (70.6 cm) deep (depending on power
supply type), and 17.37 in. (44.11 cm) wide. The outer edges of the mounting brackets extend the width
to 19 in. (48.3 cm). See Figure 1 on page 5.
4
Figure 1: SRX5800 Services Gateway Rack Clearance and Chassis Dimensions
•The rack must be strong enough to support the weight of the fully configured services gateway, up to
400 lb (180 kg). If you stack three fully configured services gateways in one rack, it must be capable of
supporting about 1,200 lb (542 kg).
•For service personnel to remove and install hardware components, there must be adequate space at the
front and back of the services gateway. Allow at least 30 in. (76.2 cm) in front of the services gateway
and 24 in. (61 cm) behind the services gateway.
•The rack or cabinet must have an adequate supply of cooling air.
•Ensure that the cabinet allows the chassis hot exhaust air to exit from the cabinet without recirculating
into the services gateway.
•The services gateway must be installed into a rack that is secured to the building structure.
•Mount the services gateway at the bottom of the rack if it is the only unit in the rack.
•When you are mounting the services gateway in a partially filled rack, load the rack from the bottom to
the top, with the heaviest component at the bottom of the rack.
5
Tools Required to Unpack and Prepare the SRX5800 Services Gateway for
Installation
To unpack the services gateway and prepare for installation, you need the following tools:
•A mechanical lift—recommended
•Phillips (+) screwdrivers, numbers 1 and 2
•2.5 mm flat-blade (–) screwdriver
•7/16-in. torque-controlled driver or socket wrench
•1/2-in. or 13-mm open-end or socket wrench to remove bracket bolts from the shipping pallet
•Electrostatic discharge wrist strap
•Antistatic mat
Proceed to “Step 2: Install the Mounting Hardware” on page 6.
Step 2: Install the Mounting Hardware
IN THIS SECTION
Install the Mounting Hardware in a Four-Post Rack or Cabinet | 6
Install the Mounting Hardware in an Open-Frame Rack | 8
Install the Mounting Hardware in a Four-Post Rack or Cabinet
To install the mounting shelf as shown in Figure 2 on page 7:
1. On the front rack rails, install cage nuts in the holes specified in the SRX5800 Services Gateway Hardware
Guide for the large shelf.
2. On the front of each front rack rail, partially insert a mounting screw into the hole containing the lowest
cage nut.
3. Install the large shelf on the front rack rails. Rest the bottom slot of each ear on a mounting screw.
6
4. Partially insert a mounting screw into the top hole in each ear of the large shelf.
5. Tighten all the screws completely.
6. On the rear rack rails, install cage nuts in the holes specified in the SRX5800 Services Gateway Hardware
Guide for the small shelf.
7. On the back of each rear rack rail, partially insert a mounting screw into the hole containing the lowest
cage nut.
8. Install the small shelf on the back rack rails. Rest the bottom slot of each ear on a mounting screw. The
small shelf installs on the back of the rear rails, extending toward the center of the rack. The bottom
of the small shelf should align with the bottom of the large shelf.
9. Partially insert screws into the open holes in the ears of the small shelf.
10. Tighten all the screws completely.
Figure 2: Mount Hardware for a Four-Post Rack or Cabinet
7
Install the Mounting Hardware in an Open-Frame Rack
To install the mounting shelf as shown in Figure 3 on page 8:
1. On the rear of each rack rail, partially insert a mounting screw into the highest hole specified in the
SRX5800 Services Gateway Hardware Guide for the large shelf.
2. Install the large shelf on the rack. Hang the shelf over the mounting screws using the keyhole slots
located near the top of the large shelf flanges.
3. Partially insert screws into the open holes in the ears of the large shelf.
4. Tighten all the screws completely.
Figure 3: Mount Hardware for an Open-Frame Rack
Proceed to “Step 3: Install the Services Gateway” on page 9.
8
Step 3: Install the Services Gateway
IN THIS SECTION
Remove Components | 9
Install the Services Gateway | 11
Reinstall Components | 12
Because of the services gateway’s size and weight, you must use a mechanical lift to install the services
gateway in the rack. Also, you must remove all components, as shown in Figure 4 on page 9 and
Figure 5 on page 10, before you install the services gateway.
Remove Components
Figure 4: Components to Remove from the Front of the Services Gateway
Lower
fan tray
Upper
fan tray
Air
filter tray
SCB0
IOC and
SPC slots
IOCs
IOC and
SPC slots
RE
SCB1
SCB2
or card 6
g030211
9
Figure 5: Components to Remove from the Rear of the Services Gateway
Before you install the services gateway, you must remove the following components:
•Power supplies
•Cards (SCBs, SPCs, IOCs, Flex IOCs, and MPCs)
•Air filter
•Fan trays
•Cable management system
To remove the components from the services gateway:
1. Slide each component out of the chassis evenly so that it does not become stuck or damaged.
2. Label each component as you remove it so you can reinstall it in the correct location.
3. Immediately store each removed component in an electrostatic bag.
4. Do not stack removed components. Lay each one on a flat surface.
NOTE: For complete instructions on removing services gateway components, see the SRX5800
Services Gateway Hardware Documentation at www.juniper.net/documentation/.
10
