Jura IMPRESSA XF70 Bedienungsanleitung
IMPRESSA X
F
70
Short operating instructions
Art. 65478 – XF70 GB – 12/2005
Control elements Control elements
10
9
2
1
21
11 22
13
12
13
14
15/16
17
18
19
20
33 45678
Rotary Switch
1. Rotary Switch
2. Illuminated ring
3. ON/OFF key
4. Programming key
5. Draw-off key 1 cup
6. Draw-off key 2 cups
7. Maintenance key
8. Steam pre-selection key
9. Display dialog system
10. Water tank with carrying handle
11. Filler funnel for pre-ground coffee
12. Bean tank cover
13. Aroma preservation cover
14. Steam/hot water draw-off valve
15. Replaceable 2-stage frothing jet
16. Replaceable hot water nozzle mounted in illustration
17. Height-adjustable coffee spout
18. Coffee grounds container
19. Drip grate
20. Drip tray
21. Power Switch
22. Metal shelf
(1)
(2)
First use
Press power switch (I) (on rear)
Fill bean tank
Touch symbol
Display text: SPRACHE - DEUTSCH
Turn the Rotary Switch until the required language is displayed
Confirm selected language by pressing the Rotary Switch
Lift out water tank
Fill water tank and place back into the machine
Display text: OPEN TAP
Place a receptacle (ca. 1 litre) under the hot water nozzle
Turn tap to position
Turn it back to the initial position when display prompts you to
do so
Display text: PRESS - MAINT.
Place receptacle under height-adjustable coffee spout
Touch symbol when display prompts you to do so
The machine is ready for use
Insert filter (first use)
Remove water tank and empty it
Flip up cartridge (1) holder
Insert filter cartridge (2) into water tank, applying slight
pressure
Close cartridge holder (1) (engages audibly)
Fill water tank and insert
Hold Rotary Switch down until the display shows FILTER
Confirm setting by pressing the Rotary Switch
Turn Rotary Switch until the display shows YES
Confirm setting by pressing the Rotary Switch
Place a receptacle (ca. 1 litre) under the hot water nozzle
Turn tap to position
Turn it back to the initial position when display prompts you to
do so
The machine is ready for use
(1)
(2)
Cleaning (duration: approx. 15 minutes)
Display text: READY - CLEAN
Touch the maintenance symbol until the display shows
EMPTY - TRAY
Empty drip and grounds tray and place back into the machine
Remove drip tray
Place a receptacle (ca. 1 litre) under the coffee spout
Touch the maintenance symbol
Drop an original JURA cleaning tablet into the filler funnel for
ground coffee when display prompts you to do so
Close lid
Touch the maintenance symbol
Empty drip and grounds tray and place back into machine when
display prompts you to do so
Wipe out filler funnel for ground coffee with a dry cloth after
the cleaning program has finished.
The machine is ready for use
Changing the filter
Display text: READY - FILTER
NOTE:
After having used 50 litres of water or after two months at the
latest, the filter cartridge will be used up.
Touch symbol to switch machine off
Touch maintenance symbol until the display shows
CHG FILTER - OPEN TAP
Remove and empty water tank
Flip up cartridge holder (1)
Remove old CLARIS plus filter cartridge from the tank
Place new filter cartridge (2) into water tank, applying slight
pressure
Close cartridge holder (1) (engages audibly)
Fill water tank and place back into machine
Place a receptacle (ca. 1 litre) under the hot water nozzle
Turn tap to position
Turn it back to the initial position when display prompts you to
do so
The machine is ready for use
Display text: READY - DECALCIFY
Touch symbol to switch machine off
Touch maintenance symbol until the display shows
EMPTY - TRAY
Empty drip and grounds tray and place back into machine
Remove 2-stage frothing jet or hot water nozzle
Remove water tank and empty it
Completely dissolve contents of a blister (3 tablets) in 0.6 litres
of water
Pour solution into the empty water tank
Place water tank back into machine
Place a receptacle (ca. 1 litre) under the spout
Turn tap to position
Turn it back to the initial position when display prompts you to
do so
Decalcifying (duration: approx. 40 minutes)
Empty drip and grounds tray and place back into machine when
display prompts you to do so
Rinse water tank well, fill with cold, fresh tap water and place it
back into the machine
Place receptacle under spout
Turn tap to position
Turn it back to the initial position when display prompts you to do
so
Empty drip and grounds tray and place back into machine when
display prompts you to do so
Fit 2-stage frothing jet or hot water nozzle
Shift receptacle under height-adjustable coffee spout
Touch maintenance symbol when display prompts you to
do so
The machine is ready for use
Decalcifying (continuation)
Cleaning the 2-stage frothing jet
TIP:
To ensure perfect operation of the 2-stage frothing jet, we
recommend you clean it regularly.
Hold the nozzle at the top and at the bottom end or use a 7 mm
open-ended spanner
Screw the nozzle apart
Thoroughly rinse the 3 parts under running water
NOTE:
The display will not prompt you to clean the 2-stage frothing jet
Notes
