JVC HD-ILA HD-52G587 Bedienungsanleitung

Important Note:

In the spaces below, enter the model and serial number of your monitor (located

at the rear of the monitor cabinet). Staple your sales receipt or invoice to the

inside cover of this guide. Keep this user’s guide in a convenient place for future

reference. Keep the carton and original packaging for future use.

LCT2065-001B-A

1206TNH-II-IM

Model Number:

Serial Number:

Illustration of HD-52G587 and RM-C1273G

For Models:

HD-52G587

HD-61G587

Projection Monitor Users Guide

LCT2065-001B-A ENG.indd 1LCT2065-001B-A ENG.indd 1 12/18/06 10:10:40 AM12/18/06 10:10:40 AM

Important Safety Precautions

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid Improper installation and never position the unit where good ventilation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair

it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this monitor set for a long period of time, be sure to disconnect both the

power plug from the AC outlet and antenna for your safety.

* To prevent electric shock do not use this polarized plug with an extension cord, receptacle or

other outlet unless the blades can be fully inserted to prevent blade exposure.

CAUTION: To reduce the risk of electric shock. Do not

remove cover (or back). No user serviceable

parts inside. Refer servicing to qualified service

personnel.

The lightning flash with arrowhead symbol, within an

equilateral triangle is intended to alert the user to the

presence of uninsulated “dangerous voltage” within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

NOTICE (for USA)

This product has a High Intensity Discharge (HID) lamp that

contains a small amount of mercury. It also contains lead in some

components. Disposal of these materials may be regulated in your

community due to environmental considerations. For disposal or

recycling information, please contact your local authorities, or the

Electronics Industries Alliance: http://www.eiae.org

LCT2065-001B-A ENG.indd 2LCT2065-001B-A ENG.indd 2 12/18/06 10:10:49 AM12/18/06 10:10:49 AM

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has

two blades with one wider than the other. A grounding type plug has two blades and a third

grounding prong. The wide blade or the third prong are provided for your safety. If the provided

plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with

the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to

avoid injury from tip-over.

IMPORTANT SAFETY INSTRUCTIONS

• As an “ENERGY STAR®” partner,

JVC has determined that this

product or product model meets the

“ENERGY STAR®” guidelines for energy

efficiency.

LCT2065-001B-A ENG.indd 3LCT2065-001B-A ENG.indd 3 12/18/06 10:10:50 AM12/18/06 10:10:50 AM

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has

been damaged in any way, such as power-supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as

vases, shall be placed on the apparatus.

16) Avoid improper installation and never position the unit where good ventilation is impossible. When

installing this monitor, distance recommendations must be maintained between the set and the

wall, as well as inside a tightly enclosed area or piece of furniture. Keep to the minimum distance

guidelines shown for safe operation.

17) Cautions for installation

— Do not tilt the monitor towards the left or right, or towards the back.

— Install the monitor in a corner on the floor so as to keep cords out of the way.

— The monitor will generate a slight amount of heat during operation. Ensure that sufficient

space is available around the monitor to allow satisfactory cooling.

18) Make enough room for inserting and removing the power plug. Place the monitor as close to the

outlet as possible. The main power supply for this monitor is controlled by inserting or removing

the power plug.

150 mm

200 mm

150 mm

200 mm

50 mm

LAMP

POWER

VOLUME

INPUT-4

OPERATE

–

VIDEO

L/MONO

AUDIO

INPUT

FCC Notice:

Note: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or monitor

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/monitor technician for help.

CAUTION - The television model, HD-52G587 is for use only with JVC Model RK-CPRS7

stand. HD-61G587 is for use only with JVC Model RK-CPTM7 stand. Use with other stands

is capable of resulting in instability causing possible injury.

LCT2065-001B-A ENG.indd 4LCT2065-001B-A ENG.indd 4 12/18/06 10:10:50 AM12/18/06 10:10:50 AM

Warnings

Caring for the Cabinet

Caring for the Screen

Normally, light dusting with a soft, non-scratching duster will keep your monitor clean.

If you wish to wipe down the monitor, first unplug it. Then wipe gently with a soft cloth, slightly

moistened with water. You can add a few drops of mild liquid detergent to the water to help

remove spots of oily dirt.

• DO NOT allow liquid to enter the monitor through the ventilation slots.

• DO NOT use strong or abrasive cleaners on the monitor.

• DO NOT spray liquids or cleaners directly on the monitor’s surface.

• DO NOT rub or scrub the monitor harshly. Wipe the set gently with a soft cloth.

The screen is treated with an electrostatic-proof coating. When it gets dirty, wipe it gently with a

soft cloth. If the screen is very dirty, wipe it down with a cloth dipped in a diluted kitchen cleaner

and thoroughly wrung-out. Then wipe immediately after with a clean, dry cloth.

Do not apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the screen.

These will remove the coating layer and cause discolorations.

Do not push or hit the screen. This could cause scratches on the screen surface and image

distortions.

LCT2065-001B-A ENG.indd 5LCT2065-001B-A ENG.indd 5 12/18/06 10:10:50 AM12/18/06 10:10:50 AM

Thank you for purchasing a JVC HDTV-ready projection monitor which uses the high-quality

HD-ILA projection system. This is one of the highest quality and most technologically advanced

monitor available today. It is recommended that you read this instruction manual before using

your monitor in order to learn about it’s many features. Cautions related to the safe use of the

device and important information which will help you to be able to use this device for a long time

is in the Appendix. Once again, thank you for purchasing this monitor and please enjoy using it.

This monitor uses a lamp to project the picture onto the screen. Before using this monitor,

please read the safety cautions and information about this monitor which are summarized below.

1. When the power is turned on, the warming up commences

This monitor uses a lamp to project the picture onto the screen. Once the lamp has warmed up,

you can enjoy the pictures at their full brightness. What happens when the power is turned on is

explained below. Immediately after the power is turned on, since the lamp has not had time to

warm up, the picture is displayed only dimly on the screen. As the lamp warms up, the picture

becomes brighter. It takes approximately one minute for the lamp to warm up to it’s normal

operating temperature. There are 2 LED indicators on the front panel of the monitor that can be

used as a guide. When the POWER button is pressed, the LAMP LED indicator blinks in orange

for approximately 1 minute at approximately every 2 seconds, and then goes out.

Note: It is impossible to turn the power off during this period. After 1 or more minutes have

passed, you can turn off the power.

2. Cooling the inside of the monitor and the lamp

Cooling is also performed while the monitor is being shut down.

When the POWER button is pressed to turn off the power, the following operations are

performed. When the monitor is turned off, the picture on the screen disappears. Once the

screen is dark, cooling is performed for approximately 90 seconds. When the cooling is being

performed, the LAMP LED indicator on the front panel blinks in orange at approximately every

3 seconds. The monitor can not be operated while the cooling is being performed. After

the cooling has been performed for 90 seconds, the power is turned off. Do not remove

the electrical plug until after the cooling process has completed. If the electrical plug is

removed before the cooling process has completed, the internal circuits and lamp may overheat

leading to the life of the lamp being shortened and the possibility of malfunctions.

Do not block the ventilation holes.

Do not block the ventilation holes while the power is turned on. Do not block the air intake holes

behind the speaker grills.

3. The lamp is a consumable item

Replace the lamp when it has blown or when the picture becomes dark. The lamp is a user

replaceable item. The lamp must be recycled. For a detailed explanation on how to recycle the

lamp, refer to the Appendix and the instructions that are included with the replacement lamp kit.

The life of the lamp changes depending on the atmospheric temperature and altitude in which

the monitor is being used.

Warnings

In order to use the monitor for a long time

LCT2065-001B-A ENG.indd 6LCT2065-001B-A ENG.indd 6 12/18/06 10:10:51 AM12/18/06 10:10:51 AM

4. The monitor requires a lot of electrical power

It is recommended that the monitor is connected directly to the wall socket, and not to another

device. When connecting the monitor to a wall socket that is being used by another device, or

when using an extension cord, be careful not to exceed the electrical capacity of the socket.

Do not turn the power on and off repeatedly in a short amount of time.

It subjects the monitor and the lamp to stress and may lead to malfunctions and the life of the

lamp being shortened.

5. The screen is made of plastic

Handle the screen very carefully as it can scratch easily. Do not rub, hit or press on it with any

hard objects. When the screen is dirty, gently wipe it with a soft cloth. Refer to the Appendix for

details on how to clean the screen.

6. Caution! Warm air from the air ducts

This unit has an air duct for cooling. The duct will blow warm air while the monitor is operating.

When placing the monitor, make sure not to locate it too close to wallpaper. The warm air could

cause the color of the wallpaper to change. Also, take care to keep children and pets away from

the warm air ducts. Long exposure to the warm air from the ducts could cause a minor burn.

7. Caution! Moving this monitor

When lifting this monitor, Do not hold by the screen frame. Holding the screen frame could

cause it to detach, causing the monitor to fall.

8. Do not replace the lamp immediately after use

The lamp becomes extremely hot during use. If the lamp is touched immediately after use

before it has a chance to cool down, there is a danger of burns. Be careful when handling the

lamp.

9. Do not touch the lamp glass

If the lamp is used when there is dirt from ﬁngers on the lamp glass, there is a possibility of the

lamp breaking. Be careful not to touch the lamp glass.

10. ILA element characteristics

Do not project still pictures or pictures that have still segments for a long period of time. The still

parts of the picture may remain on the screen. This is a characteristic of ILA elements and not a

malfunction. The picture will disappear over time.

11. Condensation

When a heater is turned on or the monitor is moved from a cold place to a hot place, droplets

of water may form on the lamp and screen. This is called condensation. If the monitor is used

while this condensation is still present, the picture may seem distorted, and the inside of the

screen may become dirty. In this case, wait until the condensation has gone before using the

monitor.

12. Do not open the rear cabinet of this monitor

This monitor has a DIGITAL-IN terminal. Opening up the rear cabinet will violate the copyright of

the program or software shown on the monitor. Please do not open the rear cabinet.

13. Usable Time

Do not keep the monitor on for more than 24 hours consecutively. There is a possibility of the

life of the lamp being shortened.

Warnings

LCT2065-001B-A ENG.indd 7LCT2065-001B-A ENG.indd 7 12/18/06 10:10:51 AM12/18/06 10:10:51 AM

Table of Contents

Important Safety Precautions . . 2

Warnings . . . . . . . . . . . . . . . 5

Quick Setup . . . . . . . . . . . . . . 9

Unpacking your monitor . . . . . . . . . 9

Monitor models . . . . . . . . . . . . . 10

Remote Control . . . . . . . . . . . . 12

Getting Started . . . . . . . . . . . . . 13

The Remote Control . . . . . . . . . . 13

Connecting Your Devices . . . . . . . 14

Interactive Plug In Menu . . . . . . . . 23

Programming your remote . . . . . . . 25

Onscreen Menus . . . . . . . . . 29

Using the Guide . . . . . . . . . . . . . 29

Onscreen Menu System . . . . . . . . . 30

Initial Setup . . . . . . . . . . . . . 32

V-Chip . . . . . . . . . . . . . . . . . . 32

Set Lock Code . . . . . . . . . . . . . 38

Language . . . . . . . . . . . . . . . . 39

Closed Caption . . . . . . . . . . . . . 39

Auto Shut Off . . . . . . . . . . . . . . 40

XDS ID . . . . . . . . . . . . . . . . . 40

Noise Muting . . . . . . . . . . . . . . 40

Front Panel Lock . . . . . . . . . . . . 41

V1 Smart Input . . . . . . . . . . . . 41

Video Input Label . . . . . . . . . . 42

Position Adjustment . . . . . . . . . . . 43

Power Indicator . . . . . . . . . . . . . 43

Digital-In . . . . . . . . . . . . . . . 44

Digital-In Audio . . . . . . . . . . . . 44

Picture Adjust . . . . . . . . . . . . . 45

Picture Settings . . . . . . . . . . . . . 45

Color Temperature . . . . . . . . . . . . 45

Color Management . . . . . . . . . . . . 46

Dynamic Gamma . . . . . . . . . . . . . 46

Smart Picture . . . . . . . . . . . . . . . 46

Natural Cinema . . . . . . . . . . . . . 47

Digital VNR . . . . . . . . . . . . . . . . 47

MPEG NR . . . . . . . . . . . . . . . 48

Reset . . . . . . . . . . . . . . . . . . 48

Sound Adjust . . . . . . . . . . . . . 49

Sound Settings . . . . . . . . . . . . . 49

Turn On Volume . . . . . . . . . . . . . 49

Volume Limit . . . . . . . . . . . . . . 49

Reset . . . . . . . . . . . . . . . . . . 49

Clock/Timers . . . . . . . . . . . . . . . . 50

Set Clock . . . . . . . . . . . . . . . . 50

Lamp Timer Reset . . . . . . . . . . . . 51

Button Functions . . . . . . . . . . 52

Multi Screen Function . . . . . . . . . . 52

Twin . . . . . . . . . . . . . . . . . . 52

Freeze . . . . . . . . . . . . . . . . . 53

Swap . . . . . . . . . . . . . . . . . 53

Select . . . . . . . . . . . . . . . . . . 53

Menu . . . . . . . . . . . . . . . . . . 53

OK . . . . . . . . . . . . . . . . . . . 53

Back . . . . . . . . . . . . . . . . . . . 53

Power . . . . . . . . . . . . . . . . . . 54

Number Buttons . . . . . . . . . . . . . 54

Set . . . . . . . . . . . . . . . . . . 54

Input . . . . . . . . . . . . . . . . . . . 54

TheaterPro . . . . . . . . . . . . . . . 54

Channel +/- . . . . . . . . . . . . . 54

Volume +/- . . . . . . . . . . . . . 54

Sound . . . . . . . . . . . . . . . . . . 55

Sleep Timer . . . . . . . . . . . . . . . 55

Muting . . . . . . . . . . . . . . . . . . 55

Video Status . . . . . . . . . . . . . . . 56

Display . . . . . . . . . . . . . . . . . 57

C.C. . . . . . . . . . . . . . . . . . . . 57

Aspect . . . . . . . . . . . . . . . . . 58

Aspect Ratios . . . . . . . . . . . . . 58

MONITOR/CATV Slide Switch . . . . . 60

VCR/DVD Slide Switch . . . . . . . . . 60

VCR Buttons . . . . . . . . . . . . . . . 60

DVD Buttons . . . . . . . . . . . . . . . 60

Light . . . . . . . . . . . . . . . . . . 60

Lamp Replacement . . . . . . . . 61

Troubleshooting . . . . . . . . . . 66

Specifications . . . . . . . . . . 68

Warranty . . . . . . . . . . . . . 69

Authorized Service Center . . . 70

Notes . . . . . . . . . . . . . . . . . 71

LCT2065-001B-A ENG.indd 8LCT2065-001B-A ENG.indd 8 12/18/06 10:10:51 AM12/18/06 10:10:51 AM

Batteries x 2

Monitor x 1 Remote Control x 1

Note: Your monitor

and/or remote

control may differ

from the examples

illustrated here.

Quick Setup

Thank you for your purchase of a JVC projection monitor. Before you begin setting up your

new monitor, please check to make sure you have all of the following items. In addition to this

guide, your monitor box should include:

AA Alkaline

–

AA Alkaline

–

POWER

DISPLAY

SLEEP TIMER

LIGHT

FREEZE

THEATERPRO

VIDEO STATUS

SET

MUTING

BACK

CH +

VOL

–VOL

REC

OPEN/CLOSE STILL/PAUSE

STOP PAUSE

PLAY FFREW

MONITOR CATV VCR DVD

-VCR CHANNEL+

PREV NEXT TV/VCR

VCR/DVD

POWER

SOUND

CH –

MONITOR

RM-C1273G

ASPECT

SWAP SELECT

MULTISCREEN

INPUT

C.C.

TWIN

LAMP

POWER

We recommend that before you start using your new monitor, you read your entire User’s

Guide so you can learn about your new monitor’s many great features. If you’re anxious to

start using your monitor right away, a quick setup guide follows on the next few pages.

Unpacking your monitor

LCT2065-001B-A ENG.indd 9LCT2065-001B-A ENG.indd 9 12/18/06 10:10:52 AM12/18/06 10:10:52 AM

OVER

LICENSED UNDER THE

FOLLOWING U.S. PATENTS

6,183,091

6,419,362

INPUT-3

PC IN

(D-SUB)

INPUT-1

INPUT-2

INPUT-3

HDMI 1

INPUT-1

INPUT-2

VIDEO

R - AUDIO - L

Y Pb Pr

S-VIDEO

OVER

R L

AUDIO

OUTPUT

1DIGITAL-IN

Quick Setup

Before you connect your monitor to another device, please refer to the proper diagrams for

your specific monitor and remote. These will help assist you in understanding how to connect

your monitor to another device, as well as use the remote to set up your monitor.

Rear Panel Diagram

Monitor Models

LCT2065-001B-A ENG.indd 10LCT2065-001B-A ENG.indd 10 12/18/06 10:10:52 AM12/18/06 10:10:52 AM

Andere Handbücher für HD-ILA HD-52G587

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere JVC Projektionsfläche Handbücher

JVC

JVC EF-S100FG Bedienungsanleitung

Beliebte Projektionsfläche Handbücher anderer Marken

FART PRODUKT

FART PRODUKT Standard SCREEN Bedienungsanleitung

Draper

Draper E Series Handbuch

Elite Screens

Elite Screens Elite Tripod Series Bedienungsanleitung

Laarhoven

Laarhoven Companion II Bedienungsanleitung

Renogy

Renogy RMS-LFPS-US Bedienungsanleitung

Da-Lite

Da-Lite ExecutiveElectrol Bedienungsanleitung

Samsung

Samsung S*H65* Bedienungsanleitung

FONESTAR

FONESTAR PPTR-43100-FA Bedienungsanleitung

Slide Clear

Slide Clear Varro XL Bedienungsanleitung

Elite Screens

Elite Screens M85XWS1-SRM Bedienungsanleitung

OS РХ-090Н Bedienungsanleitung

Niko

Niko 10-845 Bedienungsanleitung

Speaka Professional

Speaka Professional 2357532 Betriebsanleitung

Sima

Sima XL-72 Bedienungsanleitung

Jasic

Jasic EVO 2.0 ET-200P Bedienungsanleitung

Elite Screens

Elite Screens Starling 2 Series Bedienungsanleitung

InFocus

InFocus SC-WALL GRY-92H Handbuch

Barco

Barco OverView MVL-615 Bedienungsanleitung
