No.52067B

AV-32Z25EUY

AV-28Z25EUY

Jan. 2003

AV-32Z25EUY

AV-28Z25EUY

CONTENTS

!STANDARD CIRCUIT DIAGRAM (REPLACEMENT) ････････････････････････････････

････････････････････････････････････････････････････････････････

･･･････････････････････････････････

･･････

･･･ 2

!CHANGED ITEMS ････････････････････････････････

････････････････････････････････････････････････････････････････

･････････････････････････････････

･･

･3

!PARTS LIST ････････････････････････････････

････････････････････････････････････････････････････････････････

･･････････････････････････････････････

････････････

･･････3

SERVICE MANUAL

COLOUR TELEVISION

BASIC CHASSIS

MFⅡ

ⅡⅡ

Ⅱ

Supplementary

Since some details of the AV-32Z25EUY/AV-28Z25EUY SERVICE MANUAL (No.52067, Sep. 2002)

which were previously revised are incorrect, we are informing you of these errors and providing

you with the new descriptions given below.

AV-32Z25EUY

AV-28Z25EUY

STANDARD CIRCUIT DIAGRAM (REPLACEMENT)

FRONT CONTROL PWB CIRCUIT DIAGAM (Page 2-19)

No.52067B

CN00K

MA3033-X

D018

150 1/2W

QRE121J-151Y

R035

100/16

QETN1CM-107Z

C019

CN102

T3.15AH

QMF51D2-3R15J1

! F901

[POWER ON GRN]

POWER

[STD BY RED]

SPR-39MVWF

D010

SMF-

8406A-U2 SMF-

8405A-U2

CN002 QGF1220

C2-25 X

CN102

CHGH0001-0H-N

CN00W

XQGF1220

C2-25

QSW0824-001

!S901

GP1U281Q

REMOCON RECEIVER

IC001

OUT

Vcc

GND

NCB31CK-104X

C004

CN0PW

MA3068/M/-X

D014

POWER CORD

QMPK160-185-JC

47/25

QETN1EM-476Z

C022

R008

LED SW

Q003

220

R005

CN002

330

R039

XY904

D011

LED SW

Q002

XY903

Y901 X

Y902

QQR1095-001

! LF901

LED SW

Q004

VA901 .47 MM

QFZ9072-474

AC275V

C901

STBY_5V

[G]

KEY2

TIMER_ON/OFF

GND

[R]

GND

3D_ON/OFF

ECO_ON/OFF

GND

REMOCON

SMF-8406A-U2 (AV-28Z25EUY)

FRONT CONTROL PWB

SMF-8405A-U2 (AV-32Z25EUY)

MAIN

POWER

KEY1

H/P DET

ECO

GND

KEY3

GND

STBY_5V

ISOLATED

STBY_5V

P.ON/OFF

12V

(AC220~240V)

BLU

BRN

LIVE

H/P_R

TO MAIN PWB ASSY

H/P_GND

12V

AC230V 50Hz

STB3.3V(H/P_L)

IM-BW

Y001

No. 52067B

AV-32Z25EUY

AV-28Z25EUY

■

■■

■CHANGED ITEMS

"MAIN DIFFERENCE LIST (Page 5)

"USING PW BOARD (Page 33)

"PRINTED WIRING BOARD PARTS LIST [AV-32Z25EUY] (Page 38~51) / [AV-28Z25EUY] (Page 52~58)

"STANDARD CIRCUIT DIAGRAM (Page 2-5 ~ 2-24)

AV-32Z25EUY PWB ASS’Y AV-28Z25EUY PWB ASS’Y

PART NAME

INCORRECT CORRECT INCORRECT CORRECT

MAIN PWB SMF-1406A SMF-1406A-U2 SMF-1405A SMF-1405A-U2

POWER&DEF.PWB SMF-2406A SMF-2406A-U2 SMF-2405A SMF-2405A-U2

CRT SOCKET PWB SMF-3406A SMF-3406A-U2 SMF-3407A SMF-3407A-U2

FRONT CONTROL

PWB SMF-8405A SMF-8405A-U2 SMF-8405A

(REPLACEMENT)

SMF-8406A-U2

(Refer to Page 5)

SIDE CONTROL PWB SMF-8106A SMF-8106A-U2 SMF-8105A SMF-8105A-U2

DOLBY PWB SMF-0D401A SMF0D401A-U2 SMF-0D401A SMF0D401A-U2

MICOM PWB SMF-0M403A SMF0M403A-U2 SMF-0M403A SMF0M403A-U2

AV SW PWB SMF-0S402A

(CHANGE) SMF0S403A-U2 SMF-0S402A

(CHANGE) SMF0S403A-U2

100Hz PWB SMF-0Z404A SMF0Z404A-U2 SMF-0Z404A SMF0Z404A-U2

■

■■

■PARTS LIST

"EXPLODED VIEW PARTS LIST (Page 34) [AV-32Z25EUY]

Part No.

!Ref. No. INCORRECT CORRECT Part Name Description

12 CHFD125-14BD-N CHFD125-14BD FFC WIRE

17 LC31205-001B LC31205-002A-U CONTROL SHEET

"EXPLODED VIEW PARTS LIST (Page 36) [AV-28Z25EUY]

Part No.

!Ref. No. INCORRECT CORRECT Part Name Description

12 CHFD125-11BD-N CHFD125-11BD FFC WIRE

17 LC31205-001B LC31205-002A-U CONTROL SHEET

"PRINTED WIRING BOARD PARTS LIST [AV-32Z25EUY]

POWER & DEF. P.W. BOARD ASS’Y (SMF-2406A-U2) (Page 40 ~ 42)

Part No.

!Symbol

No. SMF-2406A SMF-2406A-U2 Part Name Description

C2409 QFV71HJ-474Z QFVF1HJ-474Z MF CAP. 0.47μF 50V J

C2410 QFV71HJ-474Z QFVF1HJ-474Z MF CAP. 0.47μF 50V J

C2503 QFV71HJ-224Z QFVF1HJ-224Z MF CAP. 0.22μF 50V J

!C2522 QFZ0200-123 QFZ0196-123 MPP CAP. 0.012μF1.5kVH±3%

C2959 QFV71HJ-684Z QFVF1HJ-684Z MF CAP. 0.68μF 50V J

No. 52067B

AV-32Z25EUY

AV-28Z25EUY

AV SW P.W. BOARD ASS’Y (SMF0S403A-U2) (Page 48 ~ 49)

Part No.

!Symbol

No. SMF-0S402A SMF0S403A-U2 Part Name Description

R0156 NRSA63J-101X NRSA63J-221X MG R 220Ω1/16W J

R0158 NRSA63J-101X NRSA63J-221X MG R 220Ω1/16W J

C0156 ────── NDC31HJ-390X C CAP. 39pF 50V J

"PRINTED WIRING BOARD PARTS LIST [AV-28Z25EUY]

POWER & DEF. P.W. BOARD ASS’Y (SMF-2405A-U2) (Page 55 ~ 56)

Part No.

!Symbol

No. SMF-2405A SMF-2405A-U2

Part Name Description

C2409 QFV71HJ-474Z QFVF1HJ-474Z MF CAP. 0.47μF 50V J

C2410 QFV71HJ-474Z QFVF1HJ-474Z MF CAP. 0.47μF 50V J

C2503 QFV71HJ-224Z QFVF1HJ-224Z MF CAP. 0.22μF 50V J

!C2522 QFZ0200-113 QFZ0196-113 MPP CAP. 0.011μF1.5kVH±3%

C2959 QFV71HJ-684Z QFVF1HJ-684Z MF CAP. 0.68μF 50V J

"PACKING PARTS LIST [AV-32Z25EUY] (Page 59)

Part No.

!Ref. No.

INCORRECT CORRECT

Part Name Description

1 LC10101-017A AEM1002-A79-E PACKING CASE

3 LC11361-001C LC11361-002C-U CUSHION ASSY

"PACKING PARTS LIST [AV-28Z25EUY] (Page 59)

Part No.

!Ref. No.

INCORRECT CORRECT

Part Name Description

1 LC10101-016A AEM1002-B76-E PACKING CASE

3 LC11318-002C LC11318-004E-U CUSHION ASSY

No. 52067B

AV-32Z25EUY

AV-28Z25EUY

"PRINTED WIRING BOARD PARTS LIST (REPLACEMENT)

FRONT CONTROL P.W. BOARD ASS’Y (SMF-8406A-U2)(Page 58)

!Symbol No. Part No. Part Name Description

RESISTOR

R8005 NRSA63J-221X MG R 220Ω1/16W J

R8008 NRSA63J-102X MG R 1kΩ1/16W J

R8035 QRE121J-151Y C R 150Ω1/2W J

R8039 NRSA63J-331X MG R 330Ω1/16W J

CAPACITOR

C8004 NCB31CK-104X C CAP. 0.1µF 16V K

C8019 QETN1CM-107Z E CAP. 100µF 16V M

C8022 QETN1EM-476Z E CAP. 47µF 25V M

!C8901 QFZ9072-474 MM CAP. 0.47µFAC275V M

!OR QFZ9075-474 MPP CAP. 0.47µFAC275V M

DIODE

D8010 SPR-39MVWF LED

D8011 MA111-X SI.DIODE

D8014 MA3068/M/-X ZENER DIODE

D8018 MA3033-X ZENER DIODE

TRANSISTOR

Q8002 DTC124EKA-X DIGI.TRANSISTOR

Q8003 DTA124EKA-X DIGI.TRANSISTOR

Q8004 DTA124EKA-X DIGI.TRANSISTOR

IC8001 GP1U281Q IR DETECT UNIT

OTHERS

LC30349-001A-H LED HOLDER

CEMG002-001Z FUSE CLIP x2

CN8002 QGF1220C2-25 FFC/FPC CONNE

!F8901 QMF51D2-3R15J1 FUSE 3.15A

!LF8901 QQR1095-001 LINE FILTER

!S8901 QSW0824-001 PUSH SWITCH MAIN POWER

[ AV-28Z25EUY ]

Printed in Japan

0301 WPC

DP6061

VICTOR COMPANY OF JAPAN, LIMITED

AV & MULTIMEDIA COMPANY DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
