LCD Pulse Counters – Codix 130
• ow-price and high efficiency
• arge 8-digit CD display, height of the
figures 8 mm [0.315”]
• Optional backlighting
• Simple counter for fast and slow count
pulses, counting direction switchable via
control input
• High voltage input for 10 ... 260 V AC/DC
voltage pulses
• Unified Codix design, matches the
extensive Codix family
• IP 65
• Screw terminals, RM 5 mm [0.197“]
• ifetime of the battery
approximately 8 years
• ocking of the reset key via the input
‘Reset Enable’
• Ambient temperature –10 ... +60 °C
[14 ... 140 °F]
• For positive and negative count edges,
depending on version
• Filter function for bounce-free counting
with mechanical contacts.
Technical data:
Power supply: internal lithium battery,
approx. 8 years at 20 °C (68 °F)
Backlighting: external electrical source
24 V DC +/-20 %, 50 mA
Display: CD, 8 digits, height of the figures 8 mm [0.315]
Mode: adding or subtracting (selectable)
Display range: –9999999 ... 99999999, with overflow display
Reset: manual and electrical
EMC: Emitted interference EN55011 Cl ss B
Immunity to interference: EN61000-6-2
Device s fety: design to: EN61010 P rt 1
protection: Cl ss: 2
pplic tion re : Soiling Level 2
Housing: d rk grey RAL 7021
Oper ting temper ture: –10 ... +55 °C [14 ... 131 °F] non-condensing
Ambient temper ture: –10 ... +60 °C [14 ... 140 °F] non-condensing
Stor ge temper ture: –20 ... +70 °C [–4 ... 158 °F]
Altitude: to 2000 m
Protection: IP 65 front
UL certified: file: E128604
Weight: approx. 50 g [1.764 oz]
Counting inputs:
Counting input of the DC-versions (max. 30 V DC)
Slow counting input: max. 30 Hz NPN
Fast counting input: max. 12 kHz (PNP), 7 kHz (NPN)
Switching level: NPN: low: 0 ... 0.7 V, high:
3 ... 30 V DC
PNP: low: 0 ... 0.7 V, high:
4 ... 30 V DC
Counting input of the high voltage versions (10 ... 260 V DC/V AC)
Counting input: optocoupler input, max. 30 Hz
Min. pulse time: 16 ms
Switching level: ow: 0 ... 2 V DC/V AC, High: 10 ... 260 V DC/V AC
Counting direction switching (only DC-version)
Mode: see order table
Contact input: open collector NPN (switching at 0 V DC)
Switching level: NPN: low: 0 ... 0.7 V, high: 3 ... 5 V DC
Reset Input (only DC and high voltage)
Minimum pulse time: DC: 50 ms, high voltage: 16 ms
Contact input DC: NPN: low: 0 ... 0.7 V, high:
3 ... 30 V DC
High voltage input: 10 ... 260 V DC/V AC
Electrical reset key locking (for DC and AC)
Contact input: open collector NPN (switching at 0 V)
Switching level: NPN: low: 0 ... 0.7 V, high: 3 ... 5 V DC
Pulse Counters, electronic
Connection diagram:
(-) BL
(+) BL
INPA
INP B
Reset
Mode
GND
1
2
3
4
5
6
7
8
Reset
Enable
max. 5 V DCmax. 30 V DC
24 V DC ±20 %, 50 mA
DC type:
6.130.012.8x2
(-) BL
(+) BL
INPA
INP B
Reset
Mode
GND
1
2
3
4
5
6
7
8
Reset
Enable
max. 5 V DCmax. 30 V DC
24 V DC ±20 %, 50 mA
DC type:
6.130.012.8x0
max. 5 V DC
10 .. 260
10 .. 260
VAC/VDC
VAC/VDC
(-) BL
(+) BL
INPA
INP B
Common
AC/DC
GND
n.c.
1
3
2
4
5
6
7
8
Reset
Enable
24 V DC ±20 %, 50 mA
AC type:
6.130.012.8x3
B = backlight
RoHS
Clearwater Tech - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.clrwtr.com - Email: [email protected]
www.kuebler.com 57
6/2009
Pulse Counters, electronic
Type Input type Count input
INP A INP B
6.130.012.8x0* Count1) 0 ... 0.7 V DC count NPN 7 kHz 0 ... 0.7 V DC count NPN 30 Hz
6.130.012.8x2* 4 ... 30 V DC count PNP 12 kHz 0 ... 0.7 V DC count NPN
6.130.012.8x3* 10 ... 260 V AC/DC count AC/DC 30 Hz 10 ... 260 V AC/DC reset AC/DC –
24 [0.945]
48 [1.89]
47.7 [1.878] 3 [0.118]
2.8[0.11]
max. 19.3 [0.76]
22 x 45
[0.866 x 1.772]
Dimensions:
22.2+0.3
[0.874+0.012]
45+0.6 [1.772+0.024]
53 [2.087]
[1.103]
28
[0.984 x 1.969]
25 x 50
1 [0.039]
4 [0.158]
[0.984+0.02]
25+0.5
[1.969+0.024]
50+0.6
Panel cut-out
Panel cut-out
Dimensions for bezels (included in delivery):
LCD Pulse Counters – Codix 130
56 [2.205]
1 [0.039]
14 [0.158]
M3
40 [1.575]
32 [1.26]
25 x 50
[0.984 x 1.969]
25+0.5
[0.984+0.02]
32±0.1
[1.26±0.004]
50+0.6 [1.969+0.024]
56 [2.205]
1 [0.039]
14 [0.158]
M3
40 [1.575]
32 [1.26]
25 x 50
[0.984 x 1.969]
25+0.5
[0.984+0.02]
32±0.1
[1.26±0.004]
50+0.6 [1.969+0.024]
56 [2.205]
1 [0.039]
14 [0.158]
M3
40 [1.575]
32 [1.26]
25 x 50
[0.984 x 1.969]
25+0.5
[0.984+0.02]
32±0.1
[1.26±0.004]
50+0.6 [1.969+0.024]
Countersinking Af3, DIN 74
1
– Digital display
– Panel mounting clip
– Bezel for screw mounting
(56 x 40 mm) [2.205 x 1.575“], panel cut
out 50 x 25 mm [1.969 x 0.984“]
– Bezel for clip mounting
(53 x 28 mm) [2.087 x 1.103“], panel cut
out 50 x 25 mm [1.969 x 0.984“]
– Gasket
– Operating instructions
Delivery specification:
X: 5 = no backlight
X: 6 = with backlight
1): one-channel, adding or subtracting counting
* standard stock model
Order information:
Pulse Counters
Clearwater Tech - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.clrwtr.com - Email: [email protected]
LCD Pulse Counters – Codix 131
• ow-price and high efficiency
• arge 8-digit CD display, height of the
figures 8 mm [0.315”]
• Optional backlighting
• Various counting modes such as
Totalizing, Up/ Down and Difference.
• High voltage input for 10 ... 260 V AC/DC
voltage pulses
• Unified Codix design, matches the
extensive Codix family
• IP 65
• Screw terminals, RM 5 mm [0.197“]
• ifetime of the battery
approximately 8 years
• ocking of the reset key
• Ambient temperature –10 ... +60 °C
[14 °F ... 140 °F]
• For positive and negative count edges,
depending on version
• Filter function for bounce-free counting
with mechanical contacts.
Technical data:
Power supply: non-replaceable lithium battery
(lifetime approximately 8 years at 20°C [68 °F])
Backlighting: external electrical source
24 V DC +/-20 %, 50 mA
Display: CD, 8 digits, height of the figures 8 mm [0.315]
Mode: adding or subtracting (selectable)
counting direction
differential counting or
Display range: –9999999 ... 99999999, with overflow display
Reset: manual and electrical
EMC: Emitted interference EN55011 Cl ss B
Immunity to interference: EN61000-6-2
Device s fety: design to: EN61010 P rt 1
protection Cl ss: 2
pplic tion re : Soiling Level 2
Housing: dark grey RA 7021
Operating temperature: –10 ... +55 °C [14 ... 131 °F] non-condensing
Ambient temperature: –10 ... +60 °C [14 ... 140 °F] non-condensing
Storage temperature: –20 ... +70 °C [–4 ... 158 °F]
Altitude: to 2000 m
Protection: IP 65 front
U certified: File: E128604
Weight: approx. 50 g [1.764 oz]
Counting inputs:
Counting input of the DC-versions (max. 30 V DC)
Fast counting input: max. 12 kHz (PNP), 7 kHz (NPN)
Switching level: NPN: low: 0 ... 0.7 V, high:
3 ... 30 V DC
PNP: low: 0 ... 0.7 V, high:
4 ... 30 V DC
Counting input of the high voltage versions (10 ... 260 V DC/V AC)
Counting input: optocoupler input, max. 30 Hz
Min. pulse time: 16 ms
Switching level: low: 0 ... 2 V DC/V AC, high: 10 ... 260 V DC/V AC
Counting direction switching (only DC-version)
Mode: see order table
Contact input: open collector NPN (switching at 0 V DC)
Switching level: NPN: low: 0 ... 0.7 V, high: 3 ... 5 V DC
Reset Input (only DC and high voltage)
Minimum pulse time: DC: 50 ms, high voltage: 16 ms
Contact input DC: NPN: low: 0 ... 0.7 V, high:
3 ... 30 V DC
High voltage input: 10 ... 260 V DC/V AC
Electrical reset key locking (for DC and AC)
Contact input: open collector NPN (switching at 0 V)
Switching level: NPN: how: 0 ... 0.7 V, high: 3 ... 5 V DC
max. 5 V DC
(-) BL
(+) BL
INPA
INP B
GND
1
3
2
4
5
6
7
8
Reset
Reset
Enable
10 .. 260
10 .. 260
VAC/VDC
VAC/VDC
Common
AC/DC
24 V DC ±20 %, 50 mA
AC type:
6.131.012.8x3
B = backlight
(-) BL
(+) BL
INPA
INP B
Reset
Mode
GND
1
2
3
4
5
6
7
8
Reset
Enable
max. 5 V DCmax. 30 V DC
24 V DC ±20 %, 50 mA
(-) BL
(+) BL
INPA
INP B
Reset
Mode
GND
1
2
3
4
5
6
7
8
Reset
Enable
max. 5 V DCmax. 30 V DC
24 V DC ±20 %, 50 mA
DC type:
6.131.012.8x1
DC type:
6.131.012.8x0
Connection diagram:
Pulse Counters, electronic
RoHS
Clearwater Tech - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.clrwtr.com - Email: [email protected]
24 [0.945]
48 [1.89]
47.7 [1.878] 3 [0.118]
2.8[0.11]
max. 19.3 [0.76]
22 x 45
[0.866 x 1.772]
Dimensions:
22.2+0.3
[0.874+0.012]
45+0.6 [1.772+0.024]
53 [2.087]
[1.103]
28
[0.984 x 1.969]
25 x 50
1 [0.039]
4 [0.158]
[0.984+0.02]
25+0.5
[1.969+0.024]
50+0.6
Panel cut-out
Panel cut-out
Dimensions for bezels (included in delivery)
LCD Pulse Counters – Codix 131
56 [2.205]
1 [0.039]
14 [0.158]
M3
40 [1.575]
32 [1.26]
25 x 50
[0.984 x 1.969]
25+0.5
[0.984+0.02]
32±0.1
[1.26±0.004]
50+0.6 [1.969+0.024]
56 [2.205]
1 [0.039]
14 [0.158]
M3
40 [1.575]
32 [1.26]
25 x 50
[0.984 x 1.969]
25+0.5
[0.984+0.02]
32±0.1
[1.26±0.004]
50+0.6 [1.969+0.024]
56 [2.205]
1 [0.039]
14 [0.158]
M3
40 [1.575]
32 [1.26]
25 x 50
[0.984 x 1.969]
25+0.5
[0.984+0.02]
32±0.1
[1.26±0.004]
50+0.6 [1.969+0.024]
Countersinking Af3, DIN 74
1
– Digital display
– Panel mounting clip
– Bezel for screw mounting
(56 x 40 mm) [2.205 x 1.575“], panel cut
out 50 x 25 mm [1.969 x 0.984“]
– Bezel for clip mounting
(53 x 28 mm) [2.087 x 1.103“], panel cut
out 50 x 25 mm [1.969 x 0.984“]
– Gasket
– Operating instructions
Delivery specification:
X: 5 = no backlight
X: 6 = with backlight
2): counting input with counting direction input
3): one adding and one subtracting counting input
(differential mode)
* standard stock model
Order information:
Type Input type Count inputs
INP A INP B
6.131.012.8x0* Cnt.Dir2)/Up.Dn3) 0 ... 0,7 V DC count NPN 7 kHz 0 ... 0,7 V DC count/direction NPN 7 kHz
6.131.012.8x1* 4 ... 30 V DC count PNP 12 kHz 4 ... 30 V DC count/direction PNP 12 kHz
6.131.012.8x3* Up.Dn3) 10 ... 260 V AC/DC count AC/DC 30 Hz 10 ... 260 V AC/DC count AC/DC 30 Hz
Pulse Counters, electronic
Pulse Counters
Clearwater Tech - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.clrwtr.com - Email: [email protected]
LCD Display counter CODIX 132
• Low-price and high efficiency
• Large 8-digit LCD display, height of the
figures 8 mm [0.315”]
• Optional backlighting
• Counting mode up /down,
• High voltage input for 10 ... 260 V AC/DC
voltage pulses
• Unified Codix design, matches
the extensive Codix family
• IP 65
• Screw terminals, RM 5 mm [0.197“]
• Lifetime of the battery
approximately 8 years
• Locking of the reset key
• Ambient temperature –10 ... +60 °C
[14 ... 140 °F]
• All versions for positive or negative
counting edge
• Filter function for bounce-free counting
with mechanical contacts.
Technical data:
Power supply: non-replaceable lithium battery
(lifetime approximately 8 years at 20 °C [68 °F])
Backlighting: external electrical source
24 V DC +/-20 %, 50 mA
Display: LCD, 8 digits, height of the figures 8 mm [0.315]
Mode: adding or subtracting (selectable)
counting direction
differential counting or
phase discriminator single or
dual evaluation, selectable
Display range: –9999999 ... 99999999, with overflow display
Reset: manual and electrical
UL certified: File: E128604
Interference emissions: EN 55011 Class B, EN 61000-6-2
EN 61010 Section 1 (only AC versions)
Housing: dark grey RAL 7021
Operating temperature: –10 ... +55 °C [14 ... 131 °F]
Ambient temperature: –10 ... +60 °C [14 ... 140 °F]
Storage temperature: –20 ... +70 °C [–4 ... 158 °F]
Protection: IP 65 front side
Weight: approx. 50 g [1.764 oz]
Counting inputs:
Counting input of the high voltage versions (10 ... 260 V DC/V AC)
Counting input: Optocoupler input, max. 30 Hz
Min. pulse time: 16 ms
Switching level: Low: 0 ... 2 V DC/V AC, High: 10 ... 260 V DC/V AC
Reset Input (only DC and high voltage)
Minimum pulse time: DC: 50 ms, high voltage: 16 ms
Contact input DC: NPN: Low: 0 ... 0.7 V, High: 3 ... 30 V DC
High voltage input: 10 ... 260 V DC/V AC
Electrical reset key locking (for DC and AC)
Contact input: Open Collector NPN (switching at 0 V)
Switching level: NPN: Low: 0 ... 0.7 V, High: 3 ... 5 V DC
Display counter electronic
max.5VDC
(-) BL
(+) BL
INP A
INP B
GND
1
3
2
4
5
6
7
8
Reset
Reset
Enable
10 .. 260
10 .. 260
VAC/VDC
VAC/VDC
Common
AC/DC
24 V DC ±20 %, 50 mA
AC type:
6.132.012.8x3
BL = backlight
Connection diagram:
RoHS
Clearwater Tech - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.clrwtr.com - Email: [email protected]
Display counters
24 [0.945]
48 [1.89]
47.7 [1.878] 3 [0.118]
2.8 [0.11]
max. 19.3 [0.76]
22 x 45
[0.866 x 1.772]
Dimensions:
22.2+0.3
[0.874+0.012]
45+0.6 [1.772+0.024]
53 [2.087]
1 [0.039]
4 [0.158]
28 [1.103]
25 x 50
[0.984 x 1.969]
25+0.5
[0.984+0.02]
50+0.6 [1.969+0.024]
Panel cut-out
Panel cut-out
Dimensions for bezels (included in delivery)
LCD Display counter CODIX 132
Display counter electronic
56 [2.205]
1
1
40 [1.575]
32 [1.26]
1 [0.039]
4 [0.158
]
25 x 50
[0.984 x 1.969]
]
M3
25+0.5
[0.984+0.02]
32±0.1
[1.26±0.004]
50+0.6 [1.969+0.024]
Countersinking Af3, DIN 74
1
– Digital display
– Panel mounting clip
– Bezel for screw mounting
(56 x 40 mm) [2.205 x 1.575“], panel cut
out 50 x 25 mm [1.969 x 0.984“]
– Bezel for clip mounting
(53 x 28 mm) [2.087 x 1.103“], panel cut
out 50 x 25 mm [1.969 x 0.984“]
– Seal
– Operating instructions
Delivery specification:
Type Input type Count inputs
INP A INP B
6.132.012.8x3* Cnt.Dir2) 10 ... 260 V AC/DC direction AC/DC 30 Hz 10 ... 260 V AC/DC count AC/DC 30 Hz
X: 5 = no backlight
X: 6 = with backlight
2): counting input with counting direction input
* standard stock model
Order information:
Clearwater Tech - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.clrwtr.com - Email: [email protected]
Andere Handbücher für codix 130
3
Dieses Handbuch passt für folgende Modelle
2
Andere Kübler Kasse Handbücher
Kübler
Kübler CODIX 547 Bedienungsanleitung
Kübler
Kübler Codix 546 Bedienungsanleitung
Kübler
Kübler CODIX 924-6 Bedienungsanleitung
Kübler
Kübler CODIX 521 Bedienungsanleitung
Kübler
Kübler CODIX 541 Bedienungsanleitung
Kübler
Kübler CODIX 520 Bedienungsanleitung
Kübler
Kübler codix 130 Bedienungsanleitung
Kübler
Kübler codix 130 Bedienungsanleitung
Kübler
Kübler Codix 141 Bedienungsanleitung
Kübler
Kübler Codix 140 Bedienungsanleitung
Kübler
Kübler codix 132 Bedienungsanleitung
Kübler
Kübler 560 Bedienungsanleitung
Kübler
Kübler CODIX 541 Bedienungsanleitung
Kübler
Kübler CODIX 521 Bedienungsanleitung
Kübler
Kübler Codix 923 Bedienungsanleitung
Kübler
Kübler CODIX 521 Bedienungsanleitung
Kübler
Kübler CODIX 924 Bedienungsanleitung
Kübler
Kübler 521 Bedienungsanleitung
Kübler
Kübler 717 Series Bedienungsanleitung
Kübler
Kübler 57 Series Bedienungsanleitung
Beliebte Kasse Handbücher anderer Marken
Cashmaster
Cashmaster Sigma 105 Bedienungsanleitung
Agilent Technologies
Agilent Technologies 53151A Bedienungsanleitung
Cashmaster
Cashmaster Sigma 105 Bedienungsanleitung
Tellermate
Tellermate TY Gebrauchs- und Pflegehandbuch
HYOSUNG
HYOSUNG MX-4000W Bedienungsanleitung
Cashmaster
Cashmaster Sigma 105 Bedienungsanleitung
