Kalorik PPG 45587 Bedienungsanleitung

www.KALORIK.com

PPG 45587 - 180330

RECHARGEABLE AUTOMATIC SALT AND PEPPER MILLS

MOLINOS AUTOMÁTICOS RECARGABLES DE SAL Y PIMIENTA

MOULINS À SEL ET À POIVRE AUTOMATIQUES

RECHARGEABLES

4 x Ni-MH rechargeable battery (each mill)

PPG 45587

EN……. 4

ES……..12

FR…......20

www.KALORIK.com

PPG 45587 - 180330

PARTS DESCRIPTION

www.KALORIK.com

PPG 45587 - 180330

PARTS DESCRIPTION

ENGLISH:

1. Refill chamber

2. Lid / Grinding head

3. Opening mechanism for refill

chamber

4. Battery block

5. Gravity mechanism

6. Base / Cap of the battery

compartment

7. Housing

8. Charging base

9. Indicator lights

10. Adapter

ESPAÑOL:

1. Cámara de recarga

2. Tapa / Cabeza del molinillo

3. Mecanismo de apertura

para la cámara de relleno

4. Bloque de batería

5. Mecanismo de gravedad

6. Base

7. Cubierta

8. Base de Carga

9. Luces Indicadoras

10. Adaptador

FRANÇAIS:

1. Réservoir a épices

2. Molette de réglage de la

mouture

3. Mécanisme d’ouverture du

réservoir

4. Bloc piles

5. Mécanisme de gravité

6. Base / Couvercle du bloc-

piles

7. Corps en acier

8. Base de charge

9. Voyants

10. Adaptateur

www.KALORIK.com

PPG 45587 - 180330

IMPORTANT SAFEGUARDS

Please read these instructions carefully before using the appliance.

Important: People (including children) who are not able to use the

appliance in a safe way, due to their physical, sensorial or mental

capacity or their lack of experience or knowledge, must never use the

appliance except if they are supervised by a person responsible for

their safety or if they previously received instructions concerning the

safe use of the appliance.

Close supervision is necessary to prevent children from using the

appliance as a toy.

•Never leave the appliance unsupervised when in use.

•From time to time check the appliance for damages. Never use the

appliance if it shows any signs of damage. All repairs should be

made by a qualified service, like the after-sales service of the

manufacturer or a qualified electrician use to the repair of this type

of appliance. Please return the appliance to this service in case of

dysfunction.

•Only use the appliance for domestic purposes and in the way

indicated in these instructions.

•Use only with charger provided with the appliance. Do not attempt

to charge this product with any other charger.

•To protect against electrical shock, do not put the charger base or

motor body of this appliance in water or other liquid. Never

submerge any other portion of this unit. If any part falls into liquid,

remove immediately. Carefully remove, clean and dry unit

thoroughly before continuing

•Appliance should be plugged into an electrical outlet away from

the sink or hot surfaces.

•Do not use an extension cord. Plug charger base adapter directly

into an electrical outlet.

•Do not operate in the presence of explosive and/or flammable

fumes.

•Do not incinerate the mills, even if they are severely damaged. The

batteries can explode in a fire.

www.KALORIK.com

PPG 45587 - 180330

•This product contains nickel-metal hydride (NiMH) batteries, which

must be recycled and disposed of properly. Do not incinerate or

compost batteries as they will explode at high temperatures.

•Before cleaning, always remove the batteries and unplug charger

base from outlet

•Do not operate any appliance with a damaged cord or plug, or

after the appliance has malfunctioned or has been dropped or

damaged in any way or is not operating properly. Contact Kalorik

customer service.

•If the batteries leak, remove them, clean the contacts of the

appliance and wash your hands.

•If you do not use the appliance for a long time, remove the

batteries so that they do not leak.

Important: Do not mix old and new batteries. Do not mix alkaline,

standard (zinc-carbon), or rechargeable (Ni-Cd, Ni-MH, etc.) batteries.

SAVE THESE INSTRUCTIONS

HOUSEHOLD USE ONLY

PARTS DESCRIPTION

See page 2-3.

BEFORE USE

•Place charging base and all removable parts on a clean flat

surface and unpack all pieces.

•Before using the mills for the first time, we suggest wiping the

product with a clean, damp cloth to remove any dirt or dust.

•Dry it thoroughly with a soft, absorbent cloth.

•Read all instructions completely for detailed operating procedures.

•Please note, this product comes with batteries ready for use.

www.KALORIK.com

PPG 45587 - 180330

To fill with pepper or salt:

•With the pepper mill standing on its base, hold the black plastic rim

located around the edges of the grinding head and turn it

counterclockwise to uncover the salt/pepper chamber’s opening.

•Fill the transparent refill chamber with salt or pepper.

•Close the grinding head by returning it back into its initial position,

lock in place by turning the black plastic part counter-clockwise,

until the opening is completely closed.

USE

•Connect the other end of power adapter to the charging base by

grasping the end of the power adapter and inserting it horizontally

into the back opening of the charge base.

•Connect the power adapter plug into an outlet. The blue indicator

lights will turn on letting you know the base is properly plugged in

and ready for use.

•Hold the mills upright and gently push the grinding mills into the

charging base until they lock in place. The grinding containers will fit

comfortably with the unit housing.

•The blue indicator lights will start to blink after the mills are inserted

to show the mills are currently being charged.

•Charging the mills will take about 2 to 4 hours. It takes the same

amount of time to charge whether charging one or both mills at a

time.

CLOSED

OPEN

www.KALORIK.com

PPG 45587 - 180330

•The mills are fully charged once the blue indicator lights are turned

off.

•Each mill gives you around 60-80 uses before having to recharge

again. This can be 25 minutes of grind/ continuous use.

•Hold the appliance above the meal to season. There is no button to

push, grinding will start automatically when the grinder is placed

upside down (gravity-activated and automatic function).

ADJUSTING THE GRIND

•Before seasoning your meals, you can adjust the fineness of the

ground salt and pepper by turning the adjustment wheel on the

underside of the mill.

•To do so, turn the wheel clockwise for a finer grind and

counterclockwise for a coarser grind.

MAINTENANCE

Clean the housing and grinding head with a damp cloth and dry with a

paper towel. Do not immerse the mill in liquid or put it in a dishwasher.

Do not use with wet hands. Do not use cleaning products or

detergents.

Do not wet battery contacts.

BATTERIES

•Each mill runs on 4 x Ni-MH rechargeable batteries.

•Rechargeable batteries are included with your salt and pepper mill

set.

•To open the unit and access the battery compartment, turn the mill

upside down and turn the plastic cap counterclockwise to unlock it.

Once unlocked, simply lift the battery compartment out from the

unit.

•When inserting batteries, make sure that the polarity of each

battery is respected and matches with the symbol indicated on the

battery cradle.

www.KALORIK.com

PPG 45587 - 180330

•To close the battery housing, put the battery cradle back into the

appliance, and replace the cap turning it clockwise until it gets

locked firmly.

Important:

•Do not mix old and new batteries

•Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-

cad, Ni-MH, etc.) batteries

If your appliance does not work properly, it is probably because the

batteries are discharged. In that case, recharge the batteries on the

charging base, or replace the batteries with a new set of NiMH

rechargeable batteries.

This product includes four Ni-Mh rechargeable and recyclable batteries

(1.2V) in each mill. At the end of the batteries’ useful life, they should be

recycled. These batteries must not be incinerated or composted. See

“Protection of the environment”. Do not incinerate or compost

batteries, as they will explode at high temperatures.

TROUBLESHOOTING

If the mill does not grind, or if no motor noise can be heard, please

check that the batteries are installed correctly and are not discharged.

If the mill gets stuck during use (motor produces hum, but internal shaft

does not turn and no pepper is ground], gently shake the mill or tap the

mill gently on a hard surface, to remove the stuck pepper or salt.

To remove deeply stuck peppercorn, remove the upper lid as if for re-

filling the mill, turn the coarseness setting to its coarsest, and tap lightly

on a hard surface until all the peppercorn is released. Re-adjust

coarseness setting to the desired level once done and replace upper

lid.

Note: Too fine a grind setting may not enable salt or pepper to be

ground. If this is the case, set the grinder to a coarser setting (see

above).

www.KALORIK.com

PPG 45587 - 180330

PROTECTION OF THE ENVIRONMENT

In order to preserve our environment and protect human health,

electrical and electronic equipment waste should be disposed of in

accordance with specific rules with the implication of both suppliers

and users. For this reason, as indicated by the symbol on the rating

label or on the packaging, your appliance should not be disposed of

as unsorted municipal waste. The user has the right to bring it to a

municipal collection point performing waste recovery by means of

reuse, recycling or use for other applications in accordance with the

directive.
