Kambrook KHC10B Bedienungsanleitung

Hair Clipper Kit

KHC10B Issue 1/01

Kambrook Safety

Welcome to Kambrook and your new

Hair Clipper Kit.

At Kambrook we believe that the safe

performance of our products is the first

priority in any consumer product so that

you, our valued customer, can confidently

use and trust our products.

We ask that any electrical appliance that

you use be operated in a sensible fashion

with due care and attention placed on the

following important operating instructions:

Read all instructions thoroughly

before activating the appliance and

retain them for future reference.

Ensure that the power source to be used

is the same as the voltage requirements of

the product.

Never immerse the power cord or

appliance in any form of liquid and do not

use near bath tubs, basins or other vessels

containing water.

The appliance is not intended for use by

young children or infirm persons without

supervision.

Young children should be supervised to

ensure that they do not play with the

appliance.

This hair clipper is for household use only,

and not for animal clipping or shearing.

The hair clipper may be plugged into any

230/240V power outlet. It should not be

left unattended when plugged in.

Always switch the hair clipper off then

switch off and unplug from the power

outlet when not in use and before

cleaning.

Disconnect by gripping the plug and do

not pull the cord.

Do not place or store hair clipper where

it can fall or be pulled into bath tub or

sink. If hair clipper falls into water, unplug

it immediately. Do not reach into the water.

The hair clipper has arcing or sparking

parts inside, do not use in areas where

petrol, paints, aerosols, oxygen or other

inflammable substances are used or stored.

Keep the power cord and unit away from

hot or heated surfaces.

Do not pull, twist or wrap the power

cord around the casing, when using or

storing hair clipper. Periodically check the

cord for signs of wear.

Do not operate the hair clipper if it has

been dropped or damaged in any manner.

Regularly inspect the power cord,

plug and actual appliance for any

damage. If found damaged in any

way, immediately cease use of the

appliance and return the entire

appliance to the nearest authorised

Kambrook Service Centre for

examination, replacement or repair.

Please call 1800 800 634 for service

centre details.

Never drop or insert any object into any

opening, as this may cause an electrical

hazard.

Always switch the hair clipper OFF before

putting down on any surface.

Do not use the hair clipper with a

damaged or broken comb nor with teeth

missing from the blades, to avoid injury.

Use this hair clipper only as described

in this instruction book.The use of

attachments not recommended by the

manufacturer may cause a hazard.

Keep blades regularly oiled and clean

blades after each use.

If the appliance is connected to an

extension cord or power board then

the extension cord or power board

should be positioned so that is not subject

to splashing or contact with moisture.

The installation of a residual current

(RCD) is recommended to provide

additional safety protection when using

electrical appliances, It is also advisable

that a RCD with a rated residual

operating current not exceeding 30mA be

installed in the electrical circuit supplying

the bathroom. See your electrician for

professional advice.

Features Of Your Kambrook Hair Clipper

Adjustable blade

control lever for

close trimming and

finishing off

particularly around

the neck and ears.

Easy hold clipper

On/Off switch

Blade guard – protects

blade when not in use

#2 #3 #4

Barber’s scissors – quality

stainless steel blades

Barber’s comb – for

precision cutting control

Trim guide # 1 – for short hair

Trim guide # 2 – for medium hair

Trim guide # 3 – for medium – long hair

rim guide # 4 – for longer hair

Blade brush – for cleaning

the cutting blades after use

Lubricating oil – to keep

blades in peak condition

Before using the hair clipper, make sure

the blades are clean and well oiled.

Unwind the cord to its full length, ensure

that the on/off switch is off ‘O’ and plug

the cord into a 230 /240V power outlet,

then turn the power on.

Operate the hair clipper with the

ON/OFF switch.

NOTE: For uniform cutting, never push or force the

hair clipper through the hair at a fast speed.The

hair clipper works most efficiently when it works at

its own speed.

Adjustable Lever

The adjustable lever adds versatility to

your hair clipper by allowing you to

gradually change the closeness of your cut

without using an attachment comb.

When the lever is in the uppermost

position, the blade will give you the

closest cut.To increase the cutting length,

push the lever downward gradually.

The lever extends the variety of lengths

that can be achieved with each attachment

comb, by using the varying cutting edges

with each attachment comb.

Attachment Combs

Attachment combs should be fitted to

hair clipper by placing the top edge (comb

edge) of the attachment comb over the

top of the cutting blades.

Gently lift the tab at the other end of the

attachment comb and push down until a

click is heard.

Attachment Comb #1 – leaves hair

approx. 3mm (1/8") in length

Attachment Comb #2 – leaves hair

approx. 6mm (1/4") in length

Attachment Comb #3 – leaves hair

approx. 9mm (3/8") in length

Attachment Comb #4 – leaves hair

approx. 12mm (1/2") in length

Initially cut only a small amount of hair

until you become accustomed to the

length each attachment comb leaves the

hair.

It is suggested to try the longest

attachment comb on the hair clipper first,

then use the shorter one if a shorter

length is desired.

Using Your Kambrook Hair

Clipper

1. Place a towel around the neck of the

person to prevent hair from falling down

inside the collar.

2. Position the person in a chair so that

his/her head is at your eye level.

3. Comb the hair to remove all the

tangles, hold the clipper in a relaxed,

comfortable grip to help you maintain

accurate cutting control.

4. Before using the clipper ensure that the

blades are free of any hair clippings and

the blades are well oiled. (See Maintaining

Your Kambrook Clipper on page 6)

Medium to Long Cut

(with attachment combs)

A-1 A-2 A-3 A-4

1. Start by combing the hair in its natural

direction.

2. Place the largest attachment comb

onto the hair clipper and start by

trimming the sides from the bottom

upwards. Hold the hair clipper lightly

against the hair with the teeth of the

attachment comb pointing up but flat

against the head. Slowly lift the hair

clipper up and outward through the hair,

cutting only a small amount at a time.

(Diagram A-1)

3. Repeat around sides and back of head.

(Diagram A–2 & A–3)

4. If you desire shorter hair, either change

to a lower number attachment comb or

apply more pressure and less lift away

from head with the present attachment

comb.

5. For the top of the head, you will give a

fairly short cut if you use the #4

attachment comb.With the teeth flat

against the head, slowly start trimming

from the front to the back. (Diagram A-4)

Note:The entire procedure requires practice, and it

is always better to leave the hair longer in the first

few haircuts.

Outlining

B-1 B-2

1. Outlining requires no attachment comb.

Take the hair clipper and push the

lever up to the close – cut position

(see “adjustable lever

”

2. Comb hair into the style. Position hair

clipper between the side burns and the

ear. (Diagram B-1)

3. Make sure the corner edge of the blade

is up against the hairline.With the outline

of the hair as your guide, slowly move the

hair clipper over, around and behind the

ears. (Diagram B-2)

4. For the back of the neck and side

burns, hold the clipper up side down, and

holding it against the skin at the length

desired, move downwards.

Short Cuts to Perfect Flat Tops,

Crew Cuts

C-1 C-2 C-3

1.Always cut from the back of the neck to

the crown, using the longest attachment

comb. Holding it flat against the head,

slowly move the hair clipper up through

the hair. (Diagram C-1)

2. Use the same technique for the sides,

cutting from the bottom to the upper side

of the head.

3. From the front to the crown, cut the

hair against the direction in which it

grows.Then even it up with the sides.

(Diagram C-2)

4. For a flat top, use a normal flat comb

and cut hair on top of the head over it.

5.To taper hair down to the neckline, use

closer cutting attachment combs. Comb

hair and check for uneven spots and

outline sideburns and neckline. (Diagram

C-3)

6. If a short tapered cut on the sides and

back is desired, follow the diagram below

and change attachments as illustrated.

(Diagram C-4)

Maintaining Your Kambrook

Hair Clipper

Cleaning

After you have finished using your hair

clipper rapidly move the adjustable lever

up and down a couple of times while the

hair clipper is still running, to remove any

hair that may be caught in between the

blades.Then switch off the appliance and

power outlet.Then unplug your hair

clipper and clean the blades with the

brush supplied.

Oiling

To maintain the hair clipper in peak

condition, the blades should be regularly

oiled before, during and after every

haircut.A substitute/replacement for the

clipper oil supplied in the kit is household

sewing machine oil.

NOTE: Do not use hair oil, grease, oil mixed with

kerosene or solvent, as the solvent will evaporate

and leave the thick oil, which may slow down the

blade motion.

To oil the blades, gently squeeze a few

drops of oil between the blade teeth and

turn the clipper on, checking that the

clipper is running smoothly.

If the blades are dulled and have stopped

cutting, replace them with new blades

from your nearest Kambrook service

centre.

C-4

KAMBROOK

12 MONTH

REPLACEMENT WARRANTY

KAMBROOK warrants the purchaser

against defects in workmanship and

material, for a period of 12 months from

the date of purchase (3 months

commercial use).

Guarantee and purchase receipt for this

product are to be retained as proof of

purchase and must be presented if making

a claim under the terms of the

KAMBROOK guarantee.

KAMBROOK reserves the right to

replace or repair the appliance within

the warranty period.

Warranty does not apply to any defect,

deterioration, loss or injury or damage

occasioned by, or as a result of the misuse

or abuse, negligent handling or if the product

has not been used in accordance with the

instructions.The guarantee excludes

breakages and consumable.

This warranty is void if there is evidence

of the product being tampered with by

unauthorised persons.

If the product includes one or a number of

accessories only the defective accessory

or product will be replaced.

In the event of KAMBROOK choosing to

replace the appliance, the guarantee will

expire at the original date, ie. 12 months

from the original purchase date.

In Australia, this KAMBROOK Guarantee

is additional to the conditions and

guarantees which are mandatory as

implied by the Trade Practises Act 1974

and State Territory legislation.

For service, spare parts or product

information in Australia, please call

KAMBROOK on the customer Service

Line (free call) 1800 800 634.

For service, spare parts or product

information in New Zealand, please

call KAMBROOK New Zealand, Mono

Place, Ellerslie,Auckland.

Phone 0800 253 007, FAX 0800 263 001.

If claiming under this guarantee the product

must be returned to freight prepaid.

YOUR PURCHASE RECORD (Please complete)

DATE OF PURCHASE______________________________________________________

MODEL NUMBER ________________________________________________________

SERIAL NUMBER (If applicable) ______________________________________________

PURCHASED FROM ______________________________________________________

Attach purchase receipt here.

Please don’t return purchase record

unless you are making a claim

Issue 1/01

Kambrook 4Kingston Town Close Oakleigh,Victoria 3166,Australia

Customer Service Line (free call) 1800 800 634 Customer Service Fax 1800 621 337

Kambrook (New Zealand) Mono Place Ellerslie, Auckland, New Zealand

Customer Service Line/Spare Parts 0800 253 007 Customer Service Fax 0800 263 001

Due to continual improvement in design or otherwise,the product you purchase may differ slightly from the one illustrated in this book. Issue 1/01

Andere Kambrook Haarschneider Handbücher

Kambrook

Kambrook KHC100 Bedienungsanleitung

Beliebte Haarschneider Handbücher anderer Marken

Clatronic

Clatronic HSM 800 Bedienungsanleitung

Mellerware

Mellerware MACRO ALDANY MA20001 Bedienungsanleitung

Create

Create CLIPPER EASY Bedienungsanleitung

VALERA

VALERA X-Master 652 Bedienungsanleitung

Wahl

Wahl 1870Li Bedienungsanleitung

Remington

Remington HC5780 Bedienungsanleitung

Lister

Lister Legend Bedienungsanleitung

Philips

Philips HC5440/80 Bedienungsanleitung

Andis

Andis MBA 23125 Bedienungsanleitung

Philips

Philips Philishave HQC488/61 Bedienungsanleitung

Shear Magic

Shear Magic Nifty 1800 Bedienungsanleitung

Philips

Philips QC5390 Bedienungsanleitung

Andis

Andis US-1 Kurzanleitung

Panasonic

Panasonic EH-KA81 Bedienungsanleitung

Philips

Philips HC5450 Bedienungsanleitung

Andis

Andis US-1 Montageanleitung

Remington

Remington Classic HC450 Bedienungsanleitung

Andis

Andis ML Montageanleitung
