KanexPro MP-SC-6E Bedienungsanleitung

MP-SC-6E

Compact Scaler Switcher 6x1

Version: MP-SC-6E_2016V1.0

User Manual

Compact Scaler Switcher 6x1

Preface

Read this user manual carefully before using this product. Pictures shown in this manual

is for reference only, different model and specifications are subject to real product.

This manual is only for operation instruction only, not for any maintenance usage.

Trademarks

Mentioned product model and logo are trademarks. Any other trademarks mentioned in

this manual are acknowledged as the properties of the trademark owner. No part of this

publication may be copied or reproduced without the prior written consent.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. It has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a commercial

installation.

Operation of this equipment in a residential area is likely to cause interference, in which

case the user at their own expense will be required to take whatever measures may be

necessary to correct the interference.

Any changes or modifications not expressly approved by the manufacture would void

the user’s authority to operate the equipment.

Compact Scaler Switcher 6x1

SAFETY PRECAUTIONS

To insure the best from the product, please read all instructions carefully before using

the device. Save this manual for further reference.

Unpack the equipment carefully and save the original box and packing material for

possible future shipment

Follow basic safety precautions to reduce the risk of fire, electrical shock and injury

to persons.

Do not dismantle the housing or modify the module. It may result in electrical shock

or burn.

Using supplies or parts not meeting the products’ specifications may cause damage,

deterioration or malfunction.

Refer all servicing to qualified service personnel.

To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this

product near water.

Do not put any heavy items on the extension cable in case of extrusion.

Do not remove the housing of the device as opening or removing housing may

expose you to dangerous voltage or other hazards.

Install the device in a place with fine ventilation to avoid damage caused by

overheat.

Keep the module away from liquids.

Spillage into the housing may result in fire, electrical shock, or equipment damage. If

an object or liquid falls or spills on to the housing, unplug the module immediately.

Do not twist or pull by force ends of the optical cable. It can cause malfunction.

Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to

the device before cleaning.

Unplug the power cord when left unused for a long period of time.

Information on disposal for scrapped devices: do not burn or mix with general

household waste, please treat them as normal electrical wastes.

Compact Scaler Switcher 6x1

Contents

1. Introduction.................................................................................................................1

1.1 Introduction to MP-SC-6E..................................................................................1

1.2 Features ............................................................................................................1

1.3 Package List......................................................................................................1

2. Panel Description........................................................................................................2

2.1 Front Panel........................................................................................................2

2.2 Rear Panel.........................................................................................................3

3. System Connection.....................................................................................................3

3.1 Usage Precautions............................................................................................3

3.2 System Diagram................................................................................................4

3.3 Connection Procedures.....................................................................................4

3.4 Application.........................................................................................................4

4. System Operations .....................................................................................................4

4.1 Front Panel Button Control................................................................................4

4.2 RS232 Control...................................................................................................6

4.2.1 Control Software Operation.....................................................................6

4.2.2 Basic Settings..........................................................................................6

4.2.3 RS232 Communication Commands ........................................................7

Notes:....................................................................................................................10

4.3 IR control.........................................................................................................10

4.4 Firmware Updating..........................................................................................11

5. Specification .............................................................................................................11

6. Panel Drawing ..........................................................................................................14

7. Troubleshooting & Maintenance ...............................................................................15

8. After-sales Service....................................................................................................16

Compact Scaler Switcher 6x1

1. Introduction

1.1 Introduction to MP-SC-6E

MP-SC-6E is a compact 6x1 mini unit with 6 video inputs (4 HDMI, 2 VGA), 2 auxiliary

audio inputs (switched following VGA), 1 HDMI output and 3 audio outputs (1 dual-mono

analog audio, 1 3.5mm stereo audio, 1 optical audio).

MP-SC-6E switches VGA or HDMI/DVI input signal to HDMI output. Besides, the unit

up-scales VGA to HDMI output and supports resolution adjustment (6 types in total). It

bypass HDMI and provides comprehensive resolution capacities up to 4K& 1080p 3D.

The unit also supports RS232&IR control and EDID management.

1.2 Features

Control -- via Front panel buttons, RS232 commands and IR Remote

Switch -- select 6 input source to HDMI output

Scale –scale VGAto HDMI output, Output resolutions selectable to assure preferred

output, and supports various output resolutions, such as 1920x1200，1920x1080，

1360x768，1280x800，1024x768，1280x720

Support HDMI 1.4, 4Kx2K&1080P 3D, compliance with HDCP1.4.

Transmit 4Kx2K signal up to 15m.

Support EDID management

Two input switching modes: auto-switching or manual-switching

Intuitive indicator for power connect states & source selection & output resolution

selection

Support audio & video output management via OUTPUT BLACK button.

Support online software upgrading

Compact design for easy operation

Support power-off memory

Support hot plug

1.3 Package List

1 x MP-SC-6E

2 x Mounting ears (separate from MP-SC-6E)

4 x Screws

4 x Plastic cushions

1 x Power adapter (DC 5V 3A)

2 x 3-pin Pluggable terminal blocks (pitch:3.81mm)

1 x IR Receiver

1 x IR Remote (Cell battery is not included)

Compact Scaler Switcher 6x1

1 x User manual

Notes：Confirm all the accessories are included, if not, please contact with the dealers.

2. Panel Description

2.1 Front Panel

No.

Name

Description

①

Power LED

Indicator for power status

Off when no power.

Constantly green when the system is in working.

Constantly red when the system is enter in standby.

②

Inputs LED

Constantly green when choosing the corresponding audio

source.

③

Auto-switching

LED

Constantly green when enter in auto-switching mode.

④

Output resolution

selection LED

Constantly green when choosing the corresponding output

resolution (Input is VGA).

⑤

SOURCE/AUTO

Audio source selection button: switching circularly

between HDMI1, HDMI2, HDMI3, HDMI4, VGA1,

VGA2. dial ◀to select the previous one, dial ▶to

select the next one.

Switching mode selection button ◀: Press and hold for

3 seconds or more to enter in auto-switching mode,

press and hold for 3 seconds or more again to enter in

manual-switching mode.

⑥

RESOLUTION/FW

UPDATE

Output resolution manual switching button for VGA

input: selection circularly among 1920×1200, 1920×

1080, 1360×768, 1280×800, 1024×768, 1280×

720.default resolution:1920×1080.

Firmware updating button: press and hold for 7 seconds

or more to enter in software updating procedure. All

LED blinking when the system is loading firmware

RESOLUTION

HDMI 1 HDMI 2 HDMI 3 HDMI 4 VGA 1 VGA 2 1280x800 1360x768 1920x10801280x7201024x768 1920x1200

AUTO /3s FW UPDATE/7s

AUTO SOURCE OUTPUT BLA CK

Compact Scaler Switcher 6x1

⑦

OUTPUT BLACK

Press to switch on/off audio & Video output. All LED turn off

except power LED when switch off output.

Note: Pictures shown in this manual are for reference only, different model and

specifications are subject to real product.

2.2 Rear Panel

No.

Name

Description

①

INPUTS

HDMI: 4 HDMI/DVI video source input ports(embedded HDMI

audio format：PCM).

VGA: 2 VGA video source input ports.

AUDIO: 2 3.5mm stereo audio source input ports, switched

following the corresponding VGA.

②

OUTPUTS

HDMI: HDMI video output port.

3P AUDIO: Dual-Mono analog audio output port.

3.5mm AUDIO: stereo audio output port.

OPTICAL: optical audio output port.

③

Control

FIRMWARE: Type-AUSB port for updating firmware.

RS232: Serial port, 3-pin pluggable terminal block, connect

with control terminal (e.g. a PC) to control MP-SC-6E.

IR IN: connect to an IR Receiver, to receive IR signal send by

corresponding IR remote.

④

DC 5V

Connect to a DC 5V 3A power adapter.

Note: Pictures shown in this manual are for reference only, different model and

specifications are subject to real product.

3. System Connection

3.1 Usage Precautions

1) System should be installed in a clean environment that has a prop temperature and

humidity.

2) All of the power switches, plugs, sockets and power cords should be insulated and

safe.

3) All devices should be connected before power on.

INPUTS

HDMI 1 HDMI 2 HDMI 3 H DMI 4 VGA 2 AUDIO 2 HDMI OPTICAL DC 5V

OUTPUTS CONTROL

IR INRS232FIRMWARE

VGA 1 AU DIO 1

POWER

AUDIOAUDIO

Tx RxL R

Compact Scaler Switcher 6x1

3.2 System Diagram

Figure 3- 1 Connection Diagram

3.3 Connection Procedures

Step1.Connect HDMI/DVI sources (e.g. DVD) to HDMI input ports of MP-SC-6E with

HDMI cables.

Step2.Connect VGAsources (e.g. DV Camera) to VGA input ports of MP-SC-6E with

VGA cables.

Step3.Connect sources to the AUDIO input ports of MP-SC-6E with audio cables.

Step4.Connect a HDMI display (e.g. HDTV) to HDMI output port of MP-SC-6E.

Step5.Connect audio amplifiers (e.g. speaker/earphone) to audio outputs of MP-SC-6E.

Step6.Connect a control device (e.g. PC) to the RS232 port of MP-SC-6E

Step7.Connect an IR Receiver（working voltage:5V）to the IR IN port of MP-SC-6E.

Step8.Plug DC 5V 3A power adapter to MP-SC-6E.

3.4 Application

MP-SC-6E has a good application in various occasions, such as computer realm,

monitoring, conference room, big screen displaying, television education, command &

control center and smart home etc.

4. System Operations

4.1 Front Panel Button Control

Front panel buttons can be used for source selections, output resolution adjusting, front

panel buttons management, software updating and output screen setting. (Please refer

to chapter 2.1).

DVD

HDMI/DVI Signal ：

AUDIO Signal ：

IR Signal ：

RS232 Signal ：

HDTV Speaker2

IR Remote

MPSC6E

DV Camera

Speaker1 VGA Signal ：

Compact Scaler Switcher 6x1

Here is the detail information for source selections:

There are 6 sources for choose in total, including HDMI1, HDMI2, HDMI3, HDMI4,

VGA1, VGA2. Video signals support auto-switching and manual-switching (factory

default). Press and hold for SOURCE/AUTO for 3 seconds or more to enter in

auto-switching/ manual-switching mode.

Manual-switching:

Dial ◀to select the previous source, dial ▶to select the next source.

Auto-switching:

In this mode, select input source via front panel button (◀▶) is not available, but

RS232 command and IR remote are able to switch mode. The auto LED turn green and

keep on.

The auto-switching mode abides by the following principles:

New input principle

Once detecting a new input signal, MP-SC-6E would switch to this new signal

automatically.

Rebooting device principle

MP-SC-6E have the ability of power-off memory. If the last switching mode is

auto-switching, once rebooted, MP-SC-6E will automatically enter auto-switching mode,

and then detect all inputs and memorize their connection status for future rebooting

using. If the last displayed signal is still available, MP-SC-6E will output the signal. If not,

the unit will detect all the inputs signals with priority from HDMI1 to VGA2. When

detected the first signal, it will transfer to output.

Signal removing principle

Once removing the current display signal, MP-SC-6E will detect all input signals with

priority from HDMI1 to VGA2. It will transfer the signal firstly detected to be available to

output devices

Operation Examples:

Connect HDMI2, HDMI4, and VGA2 ports with source devices, select HDMI4 to

outputs.

Press and hold for the front button SOURCE/AUTO for 3 seconds or more to enter

in auto-switching mode.

Connect HDMI3 with a source device, and then it will choose HDMI3 to output.

Remove the signal of HDMI3, MP-SC-6E will detect from HDMI1 to VGA2. And when

it detects that HDMI2 is available, it will choose HDMI2 to output.

Cut off the power of MP-SC-6E, then reboot. As the unit is in auto-switching mode, it

will choose HDMI2 to output.

Compact Scaler Switcher 6x1

4.2 RS232 Control

Here we take the software CommWatch.exe as example.

4.2.1 Control Software Operation

Installation Copy the control software file to the computer connected with

MP-SC-6E.

Uninstallation Delete all the control software files in corresponding file path.

4.2.2 Basic Settings

Firstly, connect MP-SC-6E with an input device and an output device. Then, connect it

with a computer which is installed with RS232 control software. Double-click the

software icon to run this software. The icon is showed as below:

The interface of the control software is showed as below:

Please set the parameters of COM number, bound rate, data bit, stop bit and the parity

bit correctly, only then will you be able to send command in Command Sending Area.

Monitoring area, indicates

whether the command

sent works.

Command Sending area

Inhaltsverzeichnis

Andere KanexPro Schalten Handbücher

KanexPro

KanexPro SW-HD4X1AUD4K Bedienungsanleitung

KanexPro

KanexPro SW-SDI4X1 Bedienungsanleitung

KanexPro

KanexPro HDSC51HDBT Bedienungsanleitung

KanexPro

KanexPro HDMMX3232-4K Bedienungsanleitung

KanexPro

KanexPro HDSC71D-4K Bedienungsanleitung

KanexPro

KanexPro SW-4X1SL18G Bedienungsanleitung

KanexPro

KanexPro SW-HD5X14K Bedienungsanleitung

KanexPro

KanexPro SW-HDSC51HDBT Bedienungsanleitung

KanexPro

KanexPro MXHD1616A Bedienungsanleitung

KanexPro

KanexPro SW-HD3X14K Bedienungsanleitung

KanexPro

KanexPro MX-HDBT8X818G Bedienungsanleitung

KanexPro

KanexPro WP-HDBTKVM3 Bedienungsanleitung

KanexPro

KanexPro SW-2X14KUSBC Bedienungsanleitung

KanexPro

KanexPro HDSC31D-4K Bedienungsanleitung

KanexPro

KanexPro HDSC12D Bedienungsanleitung

KanexPro

KanexPro HDSC12 Bedienungsanleitung

KanexPro

KanexPro HDBT-VTSC72-4K Bedienungsanleitung

KanexPro

KanexPro HDSC61D-4K Bedienungsanleitung

KanexPro

KanexPro HDMMX88-4K Bedienungsanleitung

KanexPro

KanexPro SW-HD20-3X1 4K Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
