Kaufmann PRO2000 Systemhandbuch
OWNER’S MANUAL & OPERATING INSTRUCTIONS
PRO2000
LED RECHARGEABLE SPOTLIGHT
READ AND FOLLOW ALL
WARNINGS AND INSTRUCTIONS IN
THIS MANUAL TO AVOID PERSONAL
INJURY OR PROPERTY DAMAGE.
WARNING
TO PREVENT DAMAGE TO EYESIGHT,
NEVER LOOK INTO LIGHT WHEN
LIGHT IS ON. DO NOT SHINE LIGHT
INTO THE FACE OF SOMEONE ELSE.
WARNING
V0700102
1
IMPORTANT SAFETY WARNINGS
READ AND FOLLOW ALL SAFETY WARNINGS AND INSTRUCTIONS IN THE OWNER’S MANUAL
BEFORE OPERATING SPOTLIGHT.
WARNING
tNever place spotlight face down when light is on or is still hot from recent use. Doing so could burn/
ignite surfaces such as seats, carpeting, etc. and cause major property damage. Always turn spotlight
off when not in use.
tAlways unplug charger from light and power source when not in use.
tTo prevent serious damage to eyesight, never look into light when light is on. DO NOT shine light into
the face of someone else.
tDO NOT touch lens of spotlight when light is on or if it was recently on. The lens will be hot and could
cause serious burns.
tDO NOT allow children to handle or operate this spotlight.
tDO NOT use this product for other than its intended use.
tDO NOT charge or operate in close proximity of combustible or flammable materials.
tDO NOT charge battery in gas tight enclosures.
tDO NOT attempt to charge battery pack using both AC and DC chargers at the same time.
tDO NOT attempt to charge or operate this spotlight if cord, plug, battery, bulb or any part of the
spotlight is damaged or corroded.
tDO NOT use an outdoor AC outlet to recharge battery.
tTo prevent accidental electrical shock we recommend this product always be charged on a GFCI
(Ground FaultCircuit Interrupter) outlet.
tOnly use charging devices that are provided with the Rechargeable LED Spotlight or its
replacements.
tDO NOT disassemble or tamper with the battery.
tDO NOT dispose of battery in fire as this may result in explosion.
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR RECHARGEABLE LIGHT.
FAILURE TO ADHERE TO THE SAFETY WARNINGS AND GUIDELINES IN THIS MANUAL
COULD RESULT IN BODILY INJURY OR PROPERTY DAMAGE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
2
OPERATING INSTRUCTIONS
READ AND FOLLOW ALL SAFETY WARNINGS AND INSTRUCTIONS IN THE OWNER’S MANUAL
BEFORE OPERATING SPOTLIGHT.
Part List:
To Operate
IMPORTANT: Turn spotlight OFF before charging from
AC outlet. Leaving spotlight ON during charging may cause
damage to battery
12~24-volt DC charger/adapter operates from a DC receptacle
Step 1:
Step 2: Press trigger switch in handle once to turn spotlight ON.
Press switch again to cycle through High, Low and S.O.S.
modes. Press trigger switch again to turn spotlight OFF.
WARNING: Never place spotlight face down when light is on or
is still hot from recent use. Doing so could burn/ignite
surfaces such as seats, carpeting, etc. and cause
major property damage. Always turn spotlight off
when not in use.
1
and AC charger.
4
5
PRO2000 Rainproof Rechargeable Spotlight
◆The main body is made of Aluminium,rubber,TPR,
PC and ABS materials.
◆Shatterproof aluminium head helps cooling fast.
◆PC reflector provides well-distributed beam.
◆1pc USA Cree XHP50.2 super bright LED.
◆Powered by 2pcs 18650 rechargeable
Lithium batteries(7.4V 2600mAh).
◆Waterproof (Floats on Water) and Dustproof
protection:IP66
Detachable Red & Green Filter Lenses
12~24-Volt DC Charger/Adapter(Output:DC 9V 1.5A)
100~240-Volt AC USB Charger(Output:DC 5V 1A)
Owner’s Manual
1
Draw-string Carrying / Storage Bag
6
3
2
4
120cm Micro USB cord
5
3
Follow charging instructions on next page of this manual and
allow battery to fully charge.
6
2
◆Detachable Filter Lens
◆Trigger Switch
◆Adjustable Bracket for
Hand Held or as a Stable Stand
Designed with a hanging nail hole
◆Charging Panel
◆A M8 nut for Mounting/Tripod
Inspect contents of the box to ensure all parts are included and undamaged
3
To Charge
Dual function LED indicators
-Charging indication
-Battery Status in 4 levels
Transparent tail cap -
Glows in the dark
Design with IC Chip Controlling the Battery
Saver and Safe Mode:Automatically/Intelligently
Reduces Brightness/Temperature after 5 Minutes/56 ℃
to Extend Run Time and Ensure Safety.
Step 1:
Step 2:
Step 3:
Plug the AC USB charger(Micro USB cord) or the designated DC charger/
adapter into corresponding charging port.
Make sure spotlight is off while charging with AC USB charger
(Micro USB cord).
Spotlight can operate while charging with the designated
DC charger/adapter.
Always allow battery to fully charge.
in use.
For best results leave Spotlight on trickle charge for an extra 1 hour after all
3 indicators have turned on.
Note:
Note:
Intellective Dual function LED indicators:
WARNING:
Recharge battery fully before first use.
DO NOT leave battery uncharged for extended period (recharge the battery
every 6 months).
The normal charging time is about 5Hrs by AC USB home adapter
or about 4Hrs by DC 12~24V car charger (never charge longer than
12Hrs continuously).
same time. This will damage the battery and charger.
For DC Charger/Adapter- Battery charges / continuous working only
while vehicle engine is running.
When the spotlight is fully charged,lock the cap in place for rainproof purpose.
Never dismantle the battery parts.
AC USB Charger
(Micro USB cord)
DC Charger/Adapter
To Prevent Damage to Spotlight and Battery:
• Do not attempt to use spotlight while charging directly from AC
outlet. Doing so may cause damage to battery and AC charger.
• DO NOT attempt to charge battery using both AC and DC chargers at
the same time. This will damage the battery
Only use charging devices that are provided with the Rechargeable
LED Spotlight or its replacements.
• Do not allow battery to completely discharge. A dim light indicates a
low battery. Recharge battery as soon as possible after each use.
• Always keep the battery fully charged when not in use.
• For best results, fully charge battery after each use. This will prolong
•
the overall life of the battery.
WARNING:
A damaged battery can leak acid. Avoid contact with eyes
and skin. If contact occurs, flush immediately with large
amounts of water. DO NOT ingest. If contact with eyes or
ingestion occurs, consult physician immediately.
To Replace DC Plug Fuse
Step 1: Disconnect spotlight from power source.
Step 2: Unscrew cap of DC plug and pull out of fuse.
Step 3: Pull fuse holder and fuse out of DC plug. Observe to see if
fuse is burned out.
Note:
Replace with new 5A fuse if fuse element is
missing or broken.
Step 4: Pull fuse out of fuse holder. Insert new fuse into holder.
Step 5: Insert fuse holder and fuse into DC plug.
Step 6: Screw cap onto DC plug.
4
DC Plug
DC Cap
DC Plug
DC Cap
Fuse
DC Cap
DC Cap
DC Plug Fuse Holder
V1.1
and chargers.
